JETWAY HPC104GR-HD1900B Series User manual

Panel PC
User’s Manual
NO. G03-PCNC7ARHD-F
Manual Revision: 4.0
Release Date：October 29, 2019

i
Safety Precautions...................................................................................................................ii
User’s Notice ............................................................................................................................iii
Package Contents....................................................................................................................iii
Environmental Protection Announcement ...........................................................................iii
Chapter 1 Introduction..........................................................................................................1
1-1 General Descriptions ................................................................................................1
1-2 Specifications............................................................................................................2
1-3 I/O Outlets ..................................................................................................................3
1-4 Connector Pin Definition ..........................................................................................5
Chapter 2 Hardware and Installation ...................................................................................8
2-1 Dimensions and Outlines .........................................................................................8
2-2 To Open the Chassis ................................................................................................12
2-3 Jumper Settings ........................................................................................................13
2-4 Hardware Installation................................................................................................16
2-4-1 To install HDD...............................................................................................16
2-4-2 To install M2 SSD Card ................................................................................17
2-4-3 To install Wireless LAN Card ......................................................................18
2-4-4 To install Optional USB Device Fixed Parts ..............................................19
Chapter 3 Introducing BIOS....................................................................................................21
3-1 Entering Setup..........................................................................................................21
3-2 BIOS Menu Screen ...................................................................................................22
3-3 Function Keys ..........................................................................................................22
3-4 Getting Help..............................................................................................................22
3-5 Menu Bars.................................................................................................................23
3-6 Main Menu.................................................................................................................23
3-7 Advanced Menu........................................................................................................24
3-8 Chipset Menu............................................................................................................31
3-9 Security Menu...........................................................................................................33
3-10 Boot Menu.................................................................................................................34
3-11 Save & Exit Menu .....................................................................................................35
Chapter 4 Touch Panel Specifications ................................................................................36
APPENDIX.................................................................................................................................38
TABLE OF CONTENT

ii
Safety Precautions
Operate the product according to the correct installation steps and with great care to make sure
safety and comfort using experience. Please refer to the following safety instruction guide to avoid
danger of electric shock or fire. Abide by the previous safety instruction guide to use and maintain
the product and the hard disk to make sure of safe operating environment.
Please follow the instruction manual for operation guide.
The appropriate operating temperature ranges from 0 °C–50 °C.
The operation humidity for this product is 5% to 80% RH.
To avoid high temperature, please DO NOT overload the maximum power of the external power
supply while the system is consuming high voltage. Be aware of the maximum temperature
allowance of the power supply.
See to it that the product is not working near the water.
Always unplug power cable and other hardware cables from the system before cleaning.
Apply only dry cloth for cleansing the product.
Make sure that there is no heat source nearby when the product is working.
Make sure that the thermal louver of the product is not blocked.
Make sure to remove the power plug from the product when there is a thunder storm.
Please remove the power plug from the product when you are not going to use the product for a
long time.
Make sure to set up or use the product on a stable surface.
Make sure not to drop the product or strike it by any means.
Make sure not to move the product when the power is on.
Make sure not to step on the power cables and other cables or rest anything in them..
Be sure to ground yourself to prevent static charge when installing any internal components. Use a
grounding wrist strap and place all electronic components in any static-shielded devices. Most
electronic components are sensitive to static electrical charge.
Disconnect the power cord from the Panel PC unit prior to any installation. Be sure both the
system and all external devices are turned off. Sudden surge of power could ruin sensitive
components. Make sure the Panel PC unit is properly grounded. unit
Do not open the system’s back cover. If opening the cover for maintenance is a must, only a
trained technician is allowed to do so. Integrated circuits on computer boards are sensitive to static
electricity. To avoid damaging chips from electrostatic discharge, observe the following
precautions:
Before handling a board or integrated circuit, touch an unpainted portion of the system
unit chassis for a few seconds. This will help to discharge any static electricity on
human body.
When handling boards and components, wear a grounding wrist strap available from
most electronic component stores.
Please contact qualified technician for maintenance or repair.
Use only accessories and parts that are made by the qualified manufacturer.

iii
User’s Notice
Copyright of this manual belongs to the manufacturer. No part of this manual, including the products
and software described in it may be reproduced, transmitted or translated into any language in any
form or by any means without written permission of the manufacturer.
This manual contains all information required for the utilization of this product to meet the user’s
requirements. But it will change, correct at any time without notice. Manufacturer provides this manual
“as is” without warranty of any kind, and will not be liable for any indirect, special, incidental or
consequential damages (including damages for loss of profit, loss of business, loss of use of data,
interruption of business and the like).
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and they are used only for identification or explanation and to
the owner’s benefit, without intent to infringe.
Package Contents
X2
X1
X1
Optional
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

1
Chapter 1
Introduction
1-1 General Descriptions
Thank you for purchasing the system, a new product developed, designed and
manufactured under leading technical power and consistent dedication to fine
workmanship.
A true flat, easy-to-clean front surface with esge-to-edge design
Streamlined enclosure for highly efficient heat dissipation enclosed in robust
aluminum casing
Strong solid aluminum frame design and fanless cooling system
Support open frameless design
Designed for mounting clips and VESA mount installation
IO ports designed for easy connection
IP65-rated front bezel against water and dust (150/170/185 series)
Onboard Intel® Bay Trail series SoC processor, with low power
consumption never denies high performance
Onboard 4GB DDR3L 1333Mhz SO-DIMM
Support 1 * 2.5" SATA HDD Device, 1* Mini PCIe, 1* M.2 connector
Support dual Gigabit LAN
Support 4G SIM card socket
Support 802.11 b/g/n WiFi communication
Support VGA output
Support multiple COM ports
The system has the following features besides other basic functions:
WiFi: the Mini PCI-E onboard socket in the board is integrated a with a WiFi
card(802.11 b/g/n) that can act as a mini wireless modem when external
antennas are connected. Different computers in the house can build wireless
connections through the Mini TOP system and take necessary data from it, thus
reducing the complexity in network establishment.
Giga LAN: The system is integrated with Gigabit LAN network controller with
ACPI management realizing efficient power management for the operating
system.
USB3.0: Experience Fastest data transfers at 5Gb/s with USB3.0 the new latest
connectivity standard. Built connect easily with next-generation components and
peripherals, USB3.0 transfers data 10x faster and backward compatible with
previous USB2.0 components.
CPU Usage: The CPU Usage diagram shows a beautiful data curve that
indicates a pretty low CPU usage percentage for video playback of different
formats. GPU performances are excellent as well.
dB Value: The design of the system takes into consideration the needed quiet
operating environment in the living room and the average dB value is below 26

2
under normal operation to ensure the tranquility when you are absorbed in film
watching.
1-2 Specifications
Main CPU Board
CPU
Intel® Bay Trail series SoC processor
System Memory
Onboard 4GB DDR3L 1333MHz SO-DIMM
BIOS
AMI 64MB Flash ROM
I/O System
Standard I/O
For HPC104GR-HD1900B Series
1* Power Button
1* Lockable 9~28V DC-in Power Jack
1* VGA
2* RS-232/422/485
2* USB 3.0
4* USB 2.0 (2*USB 2.0 from Bottom rear IO+ 2*USB 2.0 from Front Panel)
2* RJ-45 for Gigabit Ethernet (Intel i211AT)
1* GPIO Port-Male
For HPC150GR-HD1900B & HPC170GR-HD1900B Series
1* Power Button
1* Lockable 9~28V DC-in Power Jack
1* VGA
2* RS-232/422/485 + 2* RS-232
2* USB 3.0
4* USB 2.0 (from Bottom rear IO)
2* RJ-45 for Gigabit Ethernet (Intel i211AT)
1* GPIO Port -Female
For HPC-185SC-HD1900B Series
1* Power Button
1* LackabLe 9~28V DC-in Power Jack
1* VGA
2* RS-232/422/485
2* USB 3.0
2* USB 2.0 (from Bottom rear IO)
2* RJ-45 for Gigabit Ethernet (Intel i211AT)

3
1-3 I/O Outlets
For HPC104GR-HD1900B Series:
Front Panel View
Bottom View
HPC104GR-HD1900B
Rear IO
Front Panel
Power Button
1
/
/
DC-in
1
/
/
VGA
1
/
/
RS232/422/485
2
/
/
RS232
/
/
/
USB3.0
2
/
/
USB2.0
2
USB2.0
2
RJ-45
2
/
/
GPIO-male
1
/
/
2* USB 2.0

4
For HPC150GR-HD1900B Series:
Bottom View
For HPC170GR-HD1900B Series:
Bottom View
HPC150GR-HD1900B/ HPC170GR-HD1900B
Rear IO
Front Panel
Power Button
1
/
/
DC-in
1
/
/
VGA
1
/
/
RS232/422/485
2
/
/
RS232
2
/
/
USB3.0
2
/
/
USB2.0
4
/
/
RJ-45
2
/
/
GPIO-female
1
/
/
Notice:
1. The diagrams in this manual only serve for illustration, if there is any differences that we
do not cover, please refer to the actual product you purchase.2.Model HPC150GR&
HPC170GR series share the same IO specifications, as the above diagram shows; 3.The
main differences of HPC150GR & HPC170GR series are mainly in size.

5
For HPC180SC-HD1900B Series:
Bottom View
HPC180SC-HD1900B
Rear IO
Front Panel
Power Button
1
/
/
DC-in
1
/
/
VGA
1
/
/
RS232/422/485
2
/
/
RS232
/
/
/
USB3.0
2
/
/
USB2.0
2
/
/
RJ-45
2
/
/
GPIO
/
/
/
1-4 Connector Pin Definition
(1) Connector Function
Icon
Name
Function
Power Button
Press to turn on/off the system.
VGA Port
To connect display device that support VGA
specification.
COM Port
Mainly for user to connect external MODEM or other
devices that supports Serial Communications Interface.
USB 3.0 Port
To connect USB keyboard, mouse or other devices
compatible with USB specification. USB 3.0 ports
supports up to 5Gbps data transfer rate.
USB 2.0 Port
To connect USB keyboard, mouse or other devices
compatible with USB specification.
RJ-45 LAN Port
This connector is standard RJ-45 LAN jack for Network
connection.
DC-in Power Jack
Connector
For user to connect compatible power adapter to provide
power supply for the system.
GPIO Connector-
Male
Male General Purpose Input Output port.
GPIO Connector-
Female
Female General Purpose Input Output port.
Power Button
VGA
2*RS232/422/485
2* USB 3.0
2* USB 2.0
2* RJ45
DC Jack

6
(2) I/O Connectors Pin Definition
COM Port Connector
The pin assignment for RS-232/ 422/ 485 is listed as follows:
Pin NO.
RS232
*RS422
(optional)
*RS485
(optional)
1
DCD
TX-
DATA-
2
RXD
TX+
DATA+
3
TXD
RX+
NC
4
DTR
RX-
NC
5
GND
GND
GND
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
RI
NC
NC
COM1 & COM2 ports can function as RS232/422/485 port. In normal settings
COM1/COM2 functions as RS232 port. With compatible COM cable they can function
as RS422 or RS 485 port. User also needs to go to BIOS to set ‘Transmission Mode
Select’for COM1/COM2 (refer to Page 25) at first, before using specialized cable to
connect different pins of this port.
VGA Port Connector
The pin assignment for VGA port connector is listed as follows:
Pin No.
1
2
3
4
5
Definition
R
G
B
NC
GND
Pin No.
6
7
8
9
10
Definition
R-GND
G-GND
B-GND
+5V
GND
Pin No.
11
12
13
14
15
Definition
NC
SDA
H-SYN
V-SYN
SCL
RJ-45 Ethernet Connector
Ethernet connection can be established by plugging one end of the Ethernet cable
into this RJ-45 connector and the other end (phone jack) to a 1000/100/10-Base-T
hub.
The pin assignment for RJ-45 Ethernet LAN connectors are listed as follows:
Pin
Definition
Pin
Definition
L1
MDI0+
L5
MDI2+
L2
MDI0-
L6
MDI2-
L3
MDI1+
L7
MDI3+
L4
MDI1-
L8
MDI3-
A
Active LED (Yellow)
B
100 LAN LED (Green) / 1000 LAN LED
(Orange)

7
GPIO (9-pin Block): GPIO Port
GPIO Port Connector
The pin assignment for GPIO connector is listed as follows:
Pin No.
1
2
3
4
5
Definition
GPIO
GPIO
GPIO
GPIO
GND
Pin No.
6
7
8
9
Definition
GPIO
GPIO
GPIO
GPIO
*Note: GPIO port comes in 2 types: male and female. Please refer to the actual
specification of the product you purchase and choose compatible cable for correct
connection.

8
Chapter 2
Hardware and Installation
2-1 Dimension and Outlines
Product Dimension for HPC104GR-HD1900B Series:
* Measure Unit: mm.

9
Product Dimension for HPC150GR-HD1900B Series:
* Measure Unit: mm.

10
Product Dimension for HPC170GR-HD1900B Series:
* Measure Unit: mm.

11
Product Dimension for HPC-185SC-HD1900B Series:
* Measure Unit: mm.

12
2-2 To Open the Chassis
1. Unscrew the above marked 6 screws that lock the back cover (see red circles).
2. Use a screwdriver to remove the screws on
the upper and lower side of the chassis cover
(see above red circles in step-1).
3. Remove the screws on left and right side of
the chassis cover as well to dissemble the
chassis cover.
Notice: When lifting the cover up to open the chassis for further installation, see to it that
the connecting cables are not unplugged. It is very important for the cables connected to
their original places for normal functioning.
HPC104GR-HD1900B Series
HPC150GR-HD1900B Series
HPC170GR-HD1900B Series
HPC-185SC-HD1900B Series

13
2-3 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install
jumper clip on 2 jumper pins to close the pins. And remove jumper clip from 2
jumper pins to open the pins. Diagram 2-1 illustrates how to set up a jumper.
(1) JP1 (3-pin): eDP Backlight VCC 5V /12V Select
1
1-2 Closed:
5V (Default);
3
1
3
2-3 Closed:
12V.
(2) JP2 (4-pin): eDP LCD VCC 3.3V / 5V /12V Select
4-6 Closed:
12V.
3-4 Closed:
5V;
2-4 Closed:
3.3V (Default);
3
2
4
6
3
2
4
6
3
2
4
6
(3) JBAT1 (4-pin): Clear CMOS Setting
4-6 Closed:
RTC_RST.
2-4 Closed:
CLEAR CMOS;
3-4 Closed:
(Default);
3
2
4
6
3
2
4
6
3
2
4
6
JP1
JP2
JBAT1

14
(4) COPEN (2-pin): Case Open Message Display Function Select
1-2 Closed: Case Open Function Selected.
COPEN → Case Open Detection
1-2 Open: Normal;
Pin1
Pin1
Pin 1-2 Closed: Case open display function enabled. Use needs to enter BIOS and
enable ‘Case Open Detect’function. In this case if you case is removed, next time
when you restart your computer a message will be displayed onscreen to inform you
of this.
(5) AT_MODE (3-pin): AT/ATX Mode Function Select
1
1
3
3
AT_MODE → ATX/AT Mode Select
1-2 Close: ATX Mode Selected(Default);
2-3 Close: AT ModSelected.
*ATX Mode Selected: Press power button to power on after power input ready;
AT Mode Selected: Directly power on as power input ready.
(6) JPLED (3-pin): LVDS Backlight VCC 5V / 12V Select
1
1-2 Closed:
5V (Default);
3
1
3
2-3 Closed:
12V.
(7) JPLCD (4-pin): LVDS LCD VCC 3.3V / 5V /12V Select
4-6 Closed:
12V.
3-4 Closed:
5V;
2-4 Closed:
3.3V (Default);
3
2
4
6
3
2
4
6
3
2
4
6
JPLED
JPLCD
AT_MODE
COPEN

15
(8) JP4 (3-pin): PS2 5VSB / VCC Select
1
1
3
3
JP4 → PS2 5VSB/VCC Select
1-2 Close: 5VSB (Default);
2-3 Close: VCC.
(9) JPCOM1/2 (4-pin): COM1/COM2 5V /12V Select
4-6 Closed:
12V.
3-4 Closed:
5V;
2-4 Closed:
RING (Default);
3
2
4
6
3
2
4
6
3
2
4
6
(10) JPCOM3/4 (4-pin): COM3/COM4 5V/12V Select
4-6 Closed:
12V.
3-4 Closed:
5V;
2-4 Closed:
RING (Default);
3
2
4
6
3
2
4
6
3
2
4
6
JP4
JPCOM3
JPCOM1
JPCOM2
JPCOM4

16
2-4 Hardware Installation
Remove the screws that lock the back cover to the system from the back side before
hardware installation procedures (refer to 2-2).
Notice: When lifting the cover up to open the chassis for further installation, see to it that
the connecting cables are not unplugged. It is very important for the cables connected to
their original places for normal functioning.
2-4-1 To Install HDD
Please refer to the following instructions and illustration to install a 2.5” SATA HDD.
Before installation, please refer to 2-2 to open the back cover and dissemble the
pre-installed HDD racks from the system.
1. Align the racks to both sides of the SATA
HDD as showed above. Match the screw
holes of the racks to corresponding screw
holes of the HDD.
2. Lock the HDD to the HDD racks by
tightening screws into matched screw
holes.
3. Find the 2.5’’ HDD connector on the
motherboard.
4. Push the installed HDD into HDD
connector on the board as showed. Lock
the racked with HDD installed to the
board by tightening the screws in the
marked spots.
