JK Audio Guest Module 1 User manual
JK Audio
Guest Module 1™
User Guide
REMOTE KEYPAD
ii Guest Module 1 Remote Keypad Contents iiiii
Contents
Overview 1
Using Guest Module 1 2
Technical Information 3
Welcome
Getting Assistance
If you have technical or application
questions:
In the US & Canada, call us toll free at:
800-552-8346
All other countries dial: 815-786-2929
(M-F 8:30-5:00pm Central Time Zone)
Or, check out our FAQ section
for answers to common questions.
Thank You
Thank you for purchasing the JK Audio
Guest Module 1 Remote Keypad.
Please read this guide for instructions
on setting up and using your new
product.
Guest Module 1 is covered by a 2
year warranty to be free from defective
workmanship and materials. To obtain
service, contact JK Audio by phone
or email for return authorization.
Once authorized, you will carefully
pack and ship the faulty product and
all accessories to us. You will pay
for shipping to us and we will pay for
return back to you.
This warranty does not cover
damages due to accident, weather,
re, ood, earthquake, misuse,
unauthorized repairs or modications,
or damages occurred in shipping, only
defective workmanship or materials.
THERE ARE NO EXPRESSED OR IMPLIED
WARRANTIES WHICH EXTEND BEYOND
THE WARRANTY HERE MADE.
Limited Warranty
iv Guest Module 1 Remote Keypad Overview 1
Overview
Compatible with Broadcast Host,
innkeeper LTD, and innkeeper 1x/1rx
DTMF keypad
Keypad disable switch
Call Button
Drop Button
Ring / Call LED
Features Introducing the Guest Module 1.
Guest Module 1 gives you remote access to the on-hook / off-hook and dial
features of the Innkeeper 1, 1r, 1x,1rx or Broadcast Host digital hybrids.
This little time-saver gives you call control you simply can't get with an auxiliary
telephone and a couple of switches. An 8 pin RJ45 modular cable provides
remote power so there is no need for batteries or an external power pack. The
Call button will icker when a call comes in. Press this button to answer or place
a call. The button will stay lit when a call is present. When you dial on air, the
tones go out on the line, and do not come back mixed with the dial tone or caller
signal.
2Guest Module 1 Remote Keypad Technical Information 3
Using Guest Module 1 Technical Information
RJ-45 Modular Pinout:
Pin Description
1) Ground
2) Call / Drop Control
3) Ring / OH LED
4) DTMF Output
5) +5 VDC
6) Reserved
7) Reserved
8) Reserved
Getting Connected
Connect Guest Module 1 to your
JK Audio digital hybrid using an 8
pin RJ45 modular cable. This cable
provides remote power so there is
no need for batteries or an external
power pack. We have provided a 25
foot cable to cover most installations.
If you need a custom length cable, be
sure to purchase a cable wired so that
the wire on pin 1 of each connector is
the same color (pin 1 = pin 1). Data
cables are usually wired pin 1 to pin 1,
but telephone cables are usually wired
pin 1 to pin 8.
Dimensions
Size 4.75" x 3.4" x 2" (12 x 8.6 x 5 cm)
Weight 11 oz (300 g)
Maximum cable length 50 feet.
Operating
The Call button will icker when a call
comes in. Press this button to answer
or place a call. The button will stay lit
when a call is present. When you dial
on-air, the tones go out on the line,
and do not come back mixed with
the dial tone or caller signal. Guest
Module 1 was designed exclusively for
JK Audio Digital Hybrids.
JK Audio
JK Audio, Inc.
1311 E 6th St.
Sandwich, IL 60548
United States
Telephone: 815.786.2929
Toll Free: 1.800.jkaudio
Fax: 815.786.8502
www.jkaudio.com
