JKS Quicker Disconnects User manual

JKS3100 - JKS3104JKS Quicker Disconect Installation Page 1
INSTALLATION
INSTRUCTIONS
Product: Quicker Disconnects™
Part Number: JKS3100 - JKS3104
Applications: Grand Cherokee WJ, 1999-2004
Welcome
CONGRATULATIONS on purchasing a set of new
Quicker Disconnects™ from JKS Manufacturing. We
are committed to providing you with the best products
available and your satisfaction is our rst priority.
PLEASE READ these Installation Instructions careful-
ly, and save them for future reference, as they contain
important installation and maintenance information.
Tools Required
Metric/Standard Socket Wrench Set
Torque Wrench
Medium Strength Threadlocker
#1 Philips Screwdriver or Small Punch
Angle Measuring Tool
15/16” Open-End Wrench
Grease Gun with Zerk Fitting Coupler
Wheel Bearing Grease
7/32 Drill Bit
Drill
Factory Service Manual (recommended)
* Asterisk denotes tools that are not required for some applica-
tions. Thoroughly read instructions rst to determine which tools
will be required for your application.
Parts
Description
A1/2" x 1-1/4” NF GR5 Bolt
BSpherical Bushing
CStainless Steel Post
DClick Pin
EPress-In Grease Zerk
FGrease Zerk Cap
GUpper Male Threaded End
HLower Female Threaded End
I1/2” Lock Washer
JOE Bracket Spacer
K1/2” x 2-1/2” NF GR5 Bolt
L5/8” Jam Nut
517-278-1226 • [e-mail] • www.jksmfg.com
491 W. Gareld Avenue, Coldwater, MI 49036

JKS3100 - JKS3104 JKS Quicker Disconect Installation
Page A
Important Product
Safety Information
For your safety and the safety of others, please
read all instructions and warnings in this pamphlet
and your Jeep® owner’s manual and off road
driving supplement before attempting installation.
Within these instructions the following signal words
refer to important product safety information:
WARNING
Indicates hazards or unsafe situations which could
result in severe personal injury or death.
CAUTION
Indicates hazards or unsafe situations which could re-
sult in property damage or minor to moderate personal
injury.
NOTICE
Careful attention is required to this operation that gener-
ally does not relate to personal injury, although damage
to your JKS product or other property may result if you
fail to follow instructions.
WARNING
Higher Rollover Risk
Modifying your Jeep® to improve off-road perfor-
mance may result in vehicle handling different than as
factory equipped, including increased ride-height and/
or chassis articulation; reduced lateral stability and
higher risk of roll-over or other accident. Also, owner’s
choice of larger tire and wheel combinations may
require additional braking force or increased stopping
distances.
To reduce risk of serious injury and accident:
ÂChoose modications that balance your actual
highway & off-road use.
ÂAvoid sharp turns, abrupt maneuvers or steep
side-cambers.
ÂAvoid other maneuvering conditions which may
cause the vehicle to trip, roll, lose traction or
compromise your ability to safely brake in an
emergency.
ÂRoutinely inspect your vehicle components for
unusual wear or off-road damage. Repair or
Replace any unserviceable components before
use.
ÂDo not modify or combine body lifts with other
mechanical lifts contrary to manufacturers’ or
Jeep® recommendations & warnings.
ÂAcquaint any other drivers with your vehicle
modications and handling.
ÂAlways wear seat belts and/or appropriate off-road
restraints, reduce your speed, Tread Lightly©.
Important
NOT COMPATIBLE WITH aftermarket swaybars.
Install product with Original Equipment swaybar only.
SOME VEHICLES MAY REQUIRE extended front
brake hoses or other modications to compensate for
additional suspension travel.
NEVER DISCONNECT swaybar when operating
vehicle on public roads.
WHEN DISCONNECTED, the Quicker Disconnects
must be completely removed from vehicle, and the
swaybar must be secured to the chassis in the hori-
zontal position to prevent interference with tires.
WARNING
Stay Connected On-Road
On-highway safety is enhanced by controlling body
roll. Never disconnect swaybar when operating on
public roads.
WARNING
To assure intended performance JKS® Quicker Dis-
connects™ are NOT COMPATIBLE with aftermarket
Swaybars. Install ONLY with Jeep® factory sway bar.
On-highway safety is enhanced by controlling body
roll. Never disconnect swaybar when operating on
public roads. When disconnected off-road, swaybar

JKS3100 - JKS3104JKS Quicker Disconect Installation Page 3
must be secured to prevent interference with other
suspension components.
Brakelines must be secured and retain some slack
throughout range of suspension travel. Check after
installation of Quicker Disconnects™ & use longer
DOT approved brakelines if necessary.
Installation
1. REMOVE ORIGINAL EQUIPMENT (OE)
SWAYBAR LINKS
Remove front swaybar drop links and mounting
hardware per the factory service manual
instructions for your vehicle.
2. INSTALL UPPER MOUNTING POSTS
Mount the tapered Stainless Steel Post (C) on the
outboard side of the swaybar, ensuring small Click
Pin holes are horizontal or parallel with the ground
Apply medium strength threadlocker to the tip of
1/2” x 1-1/4” Bolt (A).
Secure tapered post to swaybar by inserting the
1/2" x 1-1/4” Bolt (A) and 1/2” Lock Washer (I) from
the inboard side and tighten to 65 ft-lb. using a
torque wrench.
HINT: A small Philips head screwdriver or punch
inserted into the Click Pin hole will enable you to pre-
vent the mounting post from rotating when tightening
the nut.
3. INSTALL LOWER MOUNTING POSTS
Locate the original lower drop link U-bracket on
the axle housing. Insert the steel OE Bracket
Spacer (J) into the U-bracket.
IMPORTANT: The supplied OE Bracket Spacers
must be installed to prevent the U-bracket from
collapsing when the mounting bolt is tightened.
Apply medium strength threadlocker to the tip of
1/2” x 2-1/2” Bolt (K).
Insert the 1/2” x 2-1/2” Bolt (K) with 1/2” Lock
Washer (I) completely through the holes in
U-bracket and OE Bracket Spacers (J) from the
inboard side of bracket.
Thread the tapered Stainless Steel Post (C) on to
the 1/2” x 2-1/2” Bolt (K) from the outboard side
of U-bracket and and tighten to 65 ft-lb. using a

JKS3100 - JKS3104 JKS Quicker Disconect Installation
Page A
torque wrench. Ensure the small Click Pin holes
are horizontal or parallel with the ground.
4. SET QUICKER DISCONNECT
LENGTHS
Determine the ideal Swaybar Angle for your
vehicle according to the following chart.
Adjust the length of your Quicker Disconnects until
swaybar is at the Ideal Angle or within Acceptable
Range. Vehicle must be at normal ride height and
located on level ground.
Once adjusted, lay Quicker Disconnects on a
at surface and tighten 5/8” Jam Nuts (L) rmly
against the Lower Ends (H).
IMPORTANT: Bushing cradles at both ends of
Quicker Disconnect must remain parallel with
each other when Jam Nut is tightened.
5. INSTALL QUICKER DISCONNECTS
Slide Upper Ends (G) and Lower Ends (H) of
Quicker Disconnects onto the Tapered Mounting
Posts (C).
Insert Click Pins (D) as illustrated to secure.
Important: When properly installed, the ring on
the Click Pin will “snap” against the shaft of pin.
When installed backwards, the ring does not t
snugly against shaft.
6. LUBRICATE QUICKER DISCONNECTS
Lubricate all Grease Zerk ttings on the Quicker
Disconnects immediately after installation using
common wheel bearing grease or equivalent.

JKS3100 - JKS3104JKS Quicker Disconect Installation Page 5
7. CORRECT OPERATION OF QUICKER
DISCONNECTS
Remove the Click Pins (D) from the Upper and
Lower Tapered Mounting Posts (C).
Completely remove Quicker Disconnects from
vehicle and store safely inside vehicle.
HINT: To avoid losing Click Pins, reinstall them on
mounting posts while Quicker Disconnects are re-
moved.
IMPORTANT: When disconnected, the swaybar
must be secured in the horizontal position to pre-
vent interference with the tires. Failure to secure
the swaybar correctly can lead to severe tire dam-
age.
To reconnect, remove Click Pins (D) from
mounting posts and rotate swaybar down.
Slide Quicker Disconnects back onto mounting
posts and reinstall Click Pins.
JKS Technical Support
Phone [phone]
E-Mail [e-mail]
Troubleshooting
If swaybar does not rotate freely, remove from vehicle,
clean and apply rubber lubricant to chassis-mounted
bushings, and reinstall.
Maintenance
It is important to lubricate Quicker Disconnects fre-
quently for the rst three (3) months after installation
to evacuate contaminants that may build up during
break-in period.
After break-in period, Quicker Disconnects should be
lubricated regularly as part of vehicle maintenance
schedule.
Regular cleaning with pressurized water is recom-
mended to maximize ease of operation and reliability.
Always lubricate afterwards to evacuate any moisture.
©2018 JKS Manufacturing, Inc & Aftermarketing, LLC
Revision Date 04/13/18
