JL Audio Stealthbox SB-T-FJ/12W1v2 User manual

INSTALLATION
DIFFICULTY:
INSTALLATION GUIDE
for the
SB-T-FJ/12W1v2
SB-T-FJ/12W1v2
2006 - Up
2006 - Up
Toyota FJ Cruiser
Toyota FJ Cruiser
Thank you for choosing a JL Audio Stealthbox®for your automotive sound system. With proper
installation, your new vehicle-specific enclosed subwoofer system will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox®installed by your authorized JL Audio
dealer. The installation professionals employed by your dealer have the necessary tools and experience
to disassemble and reassemble your vehicle properly. Also, keep in mind that your warranty coverage
extends to 1 year if your system is installed or approved by your authorized JL Audio dealer. If you
prefer to perform your own installation, please read this installation guide completely
before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox®be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
STEP 1
Remove all contents from cargo area.
If your vehicle did not come equipped with the factory
“woofer” system, go to STEP 7.
Continued on Next Page
STEP 2
Remove the access panel from under the factory
“woofer” system.
Disconnect the white plug.
STEP 3
Remove the two mounting bolts that secure the bottom of
the factory “woofer” system.
SB-T-FJ/12W1v2_INSTR_SKU#011226
SB-T-FJ/12W1v2_INSTR_SKU#011226
1
5
OUT
OF

Continued on Next Page
SB-T-FJ/12W1v2_INSTR_SKU#011226
SB-T-FJ/12W1v2_INSTR_SKU#011226
STEP 7
Remove the factory “woofer” system or the pocket from the
vehicle.
Vehicles without the factory “woofer” system, remove the
access panel that is located on the wheel well.
STEP 6
Remove the upper right mounting bolt.
STEP 5
Remove the upper left mounting bolt.
STEP 4
Loosen the four exposed screws and remove the grille
panel.
L-BRACKET
8mm FLAT WASHER
STEALTHBOX WALL THREADED INSERT
8mm BOLT
SPACER
8mm LOCK WASHER
Page 2 • JL Audio, Inc 2006
STEP 9
Place the Stealthbox onto passenger’s side rear wheel well.
Place a supplied 6mm lock washer and 6mm flat washer
onto each of the supplied 6mm x 40mm bolts.
From inside the Stealthbox®, place one of the bolt
assemblies through the left mounting hole that is located on
the rear wall of the Stealthbox®.
STEP 11
Place the supplied pair of threaded studs into the 3 o’clock
and 9 o’clock position of the woofer’s mounting screw
locations. Leave about 1 1/2-inch exposed. As seen the
picture to the left.
Reconnect the speaker wires from inside the Stealthbox®
back onto the woofer’s terminal.
Place the woofer into the mounting hole, using the threaded
studs as guides. Mount the woofer using the mounting
screws that were removed in STEP 8. Remove the threaded
studs and secure the remaining pair of mounting screws.
STEP 10
From inside the Stealthbox®, place the other bolt assembly
through the right mounting hole that is located on the rear
wall of the Stealthbox®.
Secure both bolt assemblies.
STEP 8
With hand tools, unscrew the woofer’s mounting screws.
Disconnect the speaker wire from woofer and remove from
the woofer from the Stealthbox®.
Place a supplied
8mm lock washer,
8mm lock washer,
8mm flat washer,
8mm flat washer,
L-bracket and spacer onto each of the supplied 8mm bolts.
Place the shorter length leg of the L-bracket onto the
8mm bolt.
Secure each bolt assembly onto the bottom of the
Stealthbox®. The longer length leg of each L-bracket is to
be positioned toward the front of the Stealthbox®.

SB-T-FJ/12W1v2_INSTR_SKU#011226
SB-T-FJ/12W1v2_INSTR_SKU#011226
CONGRATULATIONS
You have completed the installation for this model!
Please refer to the Power Recommendation section for an
amplifier recommendation and basic set-up help.
STEP 13
Run speaker wire from the amplifier location to the
Stealthbox®. Double check the woofer for proper operation.
L-BRACKET
REAR WHEEL WELL
STEALTHBOX WALL
VEHICLE THREADED INSERT
6mm FLAT WASHER
6mm LOCK WASHER
6mm BOLT
STEP 12
Secure the L-brackets to the vehicle using the supplied bolts.
Page 3 • JL Audio, Inc 2006
All specifications are subject to change without notice. “JL Audio®” and the JL Audio logo, “Stealthbox” and the Stealthbox logo are registered
trademarks of JL Audio, Inc.“Ahead of the Curve”and its respective logo is a trademark of JL Audio, Inc.
JLA-SKU#011226-01-23-200
JLA-SKU#011226-01-23-200
6
6 • Printed in USA • ©2005 JL Audio, Inc. • U.S. PATENTS: #5,734,734 #5,949,898 #6,118,884 #6,229,902
#6,243,479 #6,294,959 #6,501,844 #6,496,590 #6,441,685 #5,687,247 #6,219,431 #6,625,292 #D472,891 #D480,709 Other U.S. & Foreign
patents pending. For more detailed information please visit us online at www.jlaudio.com.
[phone]
www.jlaudio.com
10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
INCLUDED HARDWARE
(
(
2)
2)
8-32 x 1-1/2-inch Threaded Studs
8-32 x 1-1/2-inch Threaded Studs
(2)
(2)
6mm x 40mm Fine Thread Bolts
6mm x 40mm Fine Thread Bolts
(2)
(2)
8mm x 35mm x w/1.25pitch Bolts
8mm x 35mm x w/1.25pitch Bolts
(2)
(2)
6mm x 25mm Fine Thread Bolts
6mm x 25mm Fine Thread Bolts
(2)
(2)
8mm Lock Washers
8mm Lock Washers
(4)
(4)
6mm Lock Washers
6mm Lock Washers
(2)
(2)
8mm Flat Washers
8mm Flat Washers
(4)
(4)
6mm Flat Washers
6mm Flat Washers
(2)
(2)
1/4-inch(H) x 3/8-inch(ID) x 3/4-inch(OD) Spacers
1/4-inch(H) x 3/8-inch(ID) x 3/4-inch(OD) Spacers
(2)
(2)
Metal L-Brackets
Metal L-Brackets
SPECIFICATIONS
Enclosure Type:
Acoustic Suspension (sealed)
Acoustic Suspension (sealed)
Driver Type:
12W1v2-4
12W1v2-4
Nominal Impedance:
4 ohms mono
4 ohms mono
Continuous Power Handling:
150 Watts
150 Watts
POWER RECOMMENDATION
JL Audio recommends using a high quality amplifier such as the JL Audio A2150.
The diagram below shows the recommended crossover, infrasonic filter and equalizer settings for the A2150 when
being used to power your Stealthbox®.
The JL Audio A2150 is a very versatile audio component. Please consult the owner’s manual for even more
detailed information about installing and tuning this amplifier.
MID/HIGH FREQUENCY DRIVER FITMENT
A variety of JL Audio coaxial and component systems will fit in the factory speaker locations of you vehicle.
Front Speaker Size / Location:
6-inch x 9-inch / Front Doors
6-inch x 9-inch / Front Doors
Fits JL Audio Models:
TR690-CXi
TR690-CXi
Rear Speaker Size / Location:
2.5-inch / D-pillars
2.5-inch / D-pillars
Fits JL Audio Models:N/A
