JL Audio Stealthbox SB-GM-CLDRO/10W3v3 User manual

➔
➔
➔
➔
Stealthbox®
INSTALLATION GUIDE
SB-GM-CLDRO/10W3v3, JL AUDIO, Inc 2006 Sheet SKU#011189 Revision 3/8/2006Page 1
for the
SB-GM-CLRDO/10W3v3
(2004-Up Chevrolet Colorado & GMC
Canyon Crew Cab)
This Stealthbox is a product which
requires professional installation skills and
tools.
Please read this installation guide thor-
oughly before beginning the project. It
will guide you step by step through the
installation.Several of the steps in this
process may require two people to
accomplish.
It is absolutely vital that the enclosure
be properly mounted to the vehicle
according to these instructions. Failure
to mount the enclosure properly pres-
ents two problems: 1)The sub-bass
performance will suffer due to the
movement of the enclosure caused by
the force exerted by the woofer(s) and
2) A loose enclosure presents a serious
safety hazard in the event of a collision
or sudden deceleration.
Please enjoy your JLAudio Stealthbox
responsibly.
STEP 1: With an 18mm deep socket,
remove the two front mounting nuts.
Also remove the jack out of the metal holder.
.
STEP 2: There are two rear mounting nuts
that need to be removed.With a long exten-
sion and the 18mm deep socket.Remove the
rear mounting nuts.
STEP 3: With the rear mounting nuts
removed,tilt the rear seat forward,off the
mounting studs.
STEP 4: With the rear seat tilted forward,
locate the middle passenger’s shoulder safety
belt.Follow the belt down to the latch.With a
flat blade screw driver, push the red button.
This will disengage the shoulder belt.Pull the
belt through the crease of the seat and up to
the return pocket, located on the back wall.
STEP 5: Remove the rear seat out of the
vehicle.You should use a second person to
help out.
Also remove the metal jack holder.
*At this time run speaker wire from the
amplifier area to the Stealthbox area. Double
check the woofer for proper working order.*
STEP 6: Place the middle of the supplied wax
square, in the middle of the mounting studs
and 3-3/4”from the point of the floor as it
starts to elevate up. Remember to remove
the paper backing.
If the Stealthbox is mounted to far to the rear,
the rear seat will not fit.If the Stealthbox is
mounted to far forward,it will hit the front
center console.
START
HERE
Continued on Next Page ➔
www.jlaudio.com
➔
➔
➔
➔
X3-3/4”
18-1/16”
36-1/8”

➔
➔
STEP 7: (A) Thread the supplied socket cup
screw into the Stealthbox.Leave 1/2”exposed.
(B) Place the Stealthbox into position and line
up the curved corners of the Stealthbox, that
are between the woofer and the square shape
of the Stealthbox.These corners need to line
up with the curvature of the transmission
hump floor as it goes to the rear and jets to
the right and left of the truck. Once into place,
push down with force.
(C)With a 1/2” drill bit, drill at the impression that
was left by the Stealthbox in STEP6.
Cont.
From
Previous
Page
Continued on Next Page ➔
➔
STEALTHBOX WALL THREADED INSERT
VEHICLE SHEET METAL
FENDER WASHER SOCKET CUP SET SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
STEP 8: With the drilled out hole in the floor.
Expose the socket cup set screw 2” out of the
Stealthbox.Place the Stealthbox into position and
guide the socket cup set screw through the drilled
hole.
From under the vehicle, place the supplied fender
washer, flat washer, lock washer and hex nut onto
the socket cup screw.
STEP 9: Place the jack back into the holder and
then place the jack assembly to the floor(same area
it was removed from) with the yellow knob facing
the passenger’s side rear door.With one factory
mounting bolt. Secure the assembly with to the dri-
ver’s side mounting threads. Use the second factory
mounting bolt to plug up the passenger’s side
mounting threads.
STEP10: With a second person, place the rear
seat back into position.Wrap the shoulder belt in
front of the seat and through bottom crease of the
seat.
SB-GM-CLDRO/10W3v3, JL AUDIO, Inc 2006 Sheet SKU#011189 Revision 3/8/2006Page 2
www.jlaudio.com
*CAUTION*
Before drilling, make sure that you are not going to be
drilling into any gas lines, brake lines, transmission lines,
electrical wiring, transfer case(4x4 vehicles) or anything
else that might cause a reduction in your weekly pay.
Always wear eye protection when drilling.
With the use of a 1/2” drill bit and drill. Drill out the
floor at the impression on the wax square.
After the hole is drilled, remove the wax square
➔

Specifications:
Enclosure Type: Sealed
Driver Type: 10W3v3-4
Nominal Impedance: 4Ω
Cont. Power Handling: 300Watts
JLAudio recommends using a high quality amplifier such as the JLAudio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.
Included Hardware:
(1) Wax Square
(1) 2-14”Socket Cup Set Screw
(1) FenderWasher
(1) FlatWasher
(1) LockWasher
(1) Hex Nut
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: [phone] Fax: [phone]
JL AUDIO 250/1
monoblock subwoofer amplifier
Amplifier Input Section
Input Sens.
Input Voltage
Low/High
Left Ch. Right Ch.
Signal Sensing
Off/On
Output Mode
Full-Range/Low-Pass/High-Pass
Left Ch. Right Ch.
Amp LP Filter
Mode/Slope
Off/12dB/24dB
Filter Freq. (Hz)
Bass Control
LF Boost (dB)
Off/30Hz
Infrasonic Filter
+1 +13
+3
+7
+10
Preamp Output Section
+12VDC Ground Remote
The JLAudio 250/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔➔
STEP 11: With the shoulder belt through the bot-
tom crease. Snap the belt back into the latch. STEP 12: Flip the rear seat back into the up-right position.
➔
SB-GM-CLDRO/10W3v3, JL AUDIO, Inc 2006 Sheet SKU#011189 Revision 3/8/2006Page 3
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
XR650-CSi
VR650-CXi
Front Location Driver Size:
6.5” separates
Applicable JL Audio Products:
VR, XR,VR &TR 650-CSi
*with 1/2” spacer
Rear Location Driver Size:
6.5”
Applicable JL Audio Products:
XR,VR &TR 650-CXi
*with 1.0” spacer
Cont.
From
Previous
Page
Difficulty Of Installation:
