JL Audio Stealthbox SB-H-CIVCPE/12W3v2 User manual

➔
➔
➔
➔
Stealthbox®
INSTALLATION GUIDE
SB-H-CIVCPE2/12W3v2, JL AUDIO, Inc 2004 Sheet SKU#011158 Revision 9/17/2004Page 1
for the
SB-H-CIVCPE/12W3v2
(Fits 2001-2003 Honda Civic Coupe,
2-door)
This Stealthbox is a product which
requires professional installation skills and
tools.
Please read this installation guide thor-
oughly before beginning the project. It
will guide you step by step through the
installation. Several of the steps in this
process may require two people to
accomplish.
It is absolutely vital that the enclosure
be properly mounted to the vehicle
according to these instructions. Failure
to mount the enclosure properly pres-
ents two problems: 1) The sub-bass
performance will suffer due to the
movement of the enclosure caused by
the force exerted by the woofer(s) and
2) A loose enclosure presents a serious
safety hazard in the event of a collision
or sudden deceleration.
Please enjoy your JL Audio Stealthbox
responsibly.
STEP 1: Remove the factory cargo net, net
hooks and the flooring.
STEP 2: Cut the passenger’s side wood floor-
boards ear. Do this outside of the vehicle.
Using a straight edge and marking a line will
help in cutting a straight line.
STEP 3: Only remove this cargo net hook.
This is on the passenger side of the trunk.
*In the next two steps ,you need to plot
two marked locations from measure-
ments. This is to find the proper loca-
tion of the placement of the supplied
wax square.*
STEP 4: Measuring 5.0” (127mm) from the
floor, up to the mark from STEP 4.Mark
location.
STEP 5: Measuring 8” (203.22mm) from the
rear of the back rear to the trunk opening,
mark location.
STEP 6: This placement of the wax square is
not going to allow for good adhesion. Using a
heavy duty style tape will help the wax square
to stay into place.
*You do not want the wax square to
move, when placing the Stealthbox
into place, in STEP 9.*
START
HERE
Continued on Next Page ➔
www.jlaudio.com
➔
➔
➔➔➔
➔

➔➔
➔➔➔
STEP 7: Place the second supplied wax
square, between the second and the third
indentation starting from the front of the vehi-
cle(shown with arrows in above
picture).
The edge of this second supplied wax square
should be flush with the edge of the factory
trunk linear.
STEP 11: *CAUTION*
Before drilling, make sure that you are not going to
be drilling into any gas lines, brake lines, transmission
lines, electrical wiring or anything else that might
cause a reduction in your weekly pay. Always wear
eye protection when drilling.
With the use of a 1/2” drill bit and drill. Drill out the
floor at the impressions on the wax squares.
Cont.
From
Previous
Page
Continued on Next Page ➔
➔
STEP 8: Place the pair of supplied socket cup set
screws into the Stealthbox. Leaving about 1/4”
exposed.
The insert can be located by flipping the Stealthbox
upside down.
STEP 12: Replace the flooring, that was removed
in STEP 1. Using a utility knife, cut a slit that is lined
up with this location’s mounting hole.This is to allow
the socket cup set screw to pass through the car-
peting to the mounting hole.
STEP 13: Replace the factory cargo net and
hooks, that were removed in STEP 1.
Run speaker wire to the Stealthbox location and
attach to the terminal, on the back of the
Stealthbox.
*Double check the woofer for proper opera-
tion.*
STEP 9: Place the Stealthbox into place and
press firmly. When pulled away, the wax squares
should have the socket sup set screw markings. If
not you need to back out the set screws, for proper
marking.
The upper wax square didn’t move? You did tape it,
right?
STEP 10: Pull the Stealthbox out of location.
*CAUTION*
Before drilling, make sure that you are not going to
be drilling into any gas lines, brake lines, transmission
lines, electrical wiring or anything else that might
cause a reduction in your weekly pay. Always wear
eye protection when drilling.
With the use of a 1/2” drill bit and drill. Drill out the
floor at the impressions on the wax squares.
SB-H-CIVCPE2/12W3v2, JL AUDIO, Inc 2004 Sheet SKU#011158 Revision 9/17/2004Page 2
www.jlaudio.com
➔ ➔
1
23
➔
➔
➔
➔

Specifications:
Enclosure Type: Sealed
Driver Type: 12W3v2-D2
Nominal Impedance: 4Ω
Cont. Power Handling: 300 Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.
Included Hardware:
(2) 3/8-16 x 2-1/4” Socket Cup Set Screws
(2) 3/8” x 1-1/4” Fender Washer
(2) 3/8” Flat Washer
(2) 3/8” Split Lock Washer
(2) 3” x 3”Wax Squares
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: [phone] Fax: [phone]
JL AUDIO 250/1
monoblock subwoofer amplifier
Amplifier Input Section
Input Sens.
Input Voltage
Low/High
Left Ch. Right Ch.
Signal Sensing
Off/On
Output Mode
Full-Range/Low-Pass/High-Pass
Left Ch. Right Ch.
Amp LP Filter
Mode/Slope
Off/12dB/24dB
Filter Freq. (Hz)
Bass Control
LF Boost (dB)
Off/30Hz
Infrasonic Filter
+1 +13
+3
+7
+10
Preamp Output Section
+12VDC Ground Remote
The JL Audio 250/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔
STEALTHBOX WALL THREADED INSERT
VEHICLE SHEET METAL
FENDER WASHER SOCKET CUP SET SCREW
LOCK WASHER
FLAT WASHER
HEX NUT
STEP 14: Back out the pair of socket cap set
screws that were threaded in, from STEP 8. Expose
1-1/2” of the threads, outside the Stealthbox.
Place the Stealthbox into location, carefully guiding
the pair of socket cup set screws through the drilled
holes.
Using the supplied hardware, place in order as
shown n above illustration.
➔
SB-H-CIVCPE2/12W3v2, JL AUDIO, Inc 2004 Sheet SKU#011158 Revision 9/17/2004Page 3
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
VR600-CSi
TR690-CXi
Front Location Driver Size:
6.0”
Applicable JL Audio Products:
TR,VR 600-CSi
Rear Location Driver Size:
6.0” or 6”x9”
Applicable JL Audio Products:
TR,VR 600-CSi
TR690-TXi,VR690-CXi
Cont.
From
Previous
Page
Difficulty Of Installation:
