JLA Phase 7 D30 User manual

D-30
Parts Manual
031102JCARRITA/rmoles ADC Part No. 450589
JLALimited
Meadowcroft Lane, Halifax Road
Ripponden
West Yorkshire, England
HX6 4AJ
Telephone: [phone] / Fax: [phone]

Retain This Manual In A Safe Place For Future Reference
J.L.A. productsembodyadvancedconceptsinengineering,design,andsafety. Ifthisproductisproperlymaintained,itwill
provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVEALLSAFETYPRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
We have tried to make this manual as complete as possible and hope you will find it useful. J.L.A. reservesthe right tomake
changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to change or
discontinue models.
Important
For your convenience, log the following information:
DATE OFPURCHASE ____________________________ MODELNO. __________________________________________
RESELLER’S NAME _______________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Replacement parts can be obtained from your reseller or J.L.A. When ordering replacement parts, you can FAX your order
to J.L.A. at 01422 824390 or telephone your order directly to theJ.L.A.Parts Department at 01422 822282. Please specify the
dryer model number and serial number in addition to the description and part number, so that your order is processed
accurately and promptly.
Theillustrationsonthefollowingpagesmaynot depict your particular dryer exactly. The illustrations are a composite of the
various dryer models. Be sure to check the descriptions of the parts thoroughly before ordering.
“IMPORTANT NOTE TO PURCHASER”
Information must beobtained from your local gas supplier on the instructions
to be followed if the user smells gas. These instructions must be posted in a
prominent location near the dryer.
D-30
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence
ni d’autres vapeurs ou liquides
inflammables à proximité de cet
appareil ou de tout autre appareil.

Table of Contents
OPL Control Door Assembly
For Models Mfd. as of July 1, 2002.................................................................................................. 2
OPL Control Door Assembly
For Models Mfd. prior to July 1, 2002.............................................................................................. 3
Phase 7 OPL Microprocessor Control Panel Assembly ........................................................................... 4
Phase 7 OPL Microprocessor Control Box Assembly ............................................................................. 5
Front Panel Assembly
For Models Mfd. as of July 1, 2002.................................................................................................. 6
Front Panel Assembly
For Models Mfd. prior to July 1, 2002.............................................................................................. 7
Main Door “Steel” Assembly .................................................................................................................. 8
Main Door Switch Assembly................................................................................................................... 9
Basket (Tumbler)/Support Assemblies ................................................................................................... 10
Drop Lint Door Assembly
For Models Mfd. as of July 1, 2002.................................................................................................11
Lint Trap Assembly
For Models Mfd. as of July 1, 2002................................................................................................ 12
Lint Drawer/Lint Drawer Switch Assembly
For Models Mfd. prior to July 1, 2002............................................................................................ 13
Idler Bearing Assembly ......................................................................................................................... 14
Basket (Tumbler) Bearing Assembly ...................................................................................................... 15
Motor Mount Assembly .................................................................................................................. 16, 17
Sensor Bracket Assemblies
For Models Mfd. as of July 1, 2002.......................................................................................... 18, 19
Sensor Bracket Assemblies
For Models Mfd. prior to July 1, 2002...................................................................................... 20, 21
Direct Spark Ignition (DSI) Burner Assembly .................................................................................. 22, 23
Hot Surface Ignition (HSI) Gas Burner Assembly ............................................................................ 24, 25
Electric Oven Assembly .................................................................................................................. 26, 27
Rear Electric Relay Panel Assembly ................................................................................................ 28, 29
S.A.F.E. Temperature Probe Assembly ................................................................................................. 30
S.A.F.E. Solenoid and Piping Assembly ................................................................................................ 31
Steam Coil/Air-Operated Steam Damper Assembly ........................................................................ 32, 33
Outer Top/Back Guard Assemblies ....................................................................................................... 34
Electrical Oven Component Application Chart ....................................................................................... 35
Additional Parts Available ..................................................................................................................... 36

2OPLControl Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty.Description
1 883574 1 White OPL Control Door
(includes illus. nos. 1 and 3)
2 150321 2 #10-32 x 1/2” Phillips Machine Screw
3 117604 4 Neoprene Sponge Tape (sold by the foot)
4 150317 2 #10-16 x 3/4” TORX + BTN Type 1
5 102502 1 Control Door Support Rod
6 154011 2 #10-32 Multi-Thread U-Nut
7 102603 1 Control Door Rod Support Catch
8 102601 1 Control Door Retainer Clip

3
Illus. No. Part No. Qty.Description
1 883294 1 White Control DoorAssembly
(includes illus. nos. 1 and 3)
2 150314 4 #10-32 x 1/2” TORX + BTN
3 117604 2 Noise Suppressor Tape (sold by the foot)
4 --------* 1 Logo
5 154011 4 #10-32 Multi-Thread U-Nut
* Contact reseller for logo.
OPLControl Door Assembly
For Models Mfd. prior to July 1, 2002

4Phase 7 OPL Microprocessor Control Panel Assembly
Illus. No. Part No. Qty.Description
1 112571 1 Phase 7 OPL Keyboard
2 850984 1 Phase 7 Microprocessor Controller (computer) Panel ONLY
883301 1 Phase 7 OPL Reversing Microprocessor Controller (computer) Control
PanelAssembly Complete
(includes illus. nos. 1 through 7)
3 883277 1 Phase 7 OPL Microprocessor Controller (computer) ONLY
4 150005 2 #6-32 x 3/4” Phillips Round Head Machine Screw
5 153010 2 #6 Star Washer
6 136016 1 5-Amp Fuse
7 136097 1 500 mA Fuse

5
Illus. No. Part No. Qty.Description
1 122681 1 10-Pin Connector
2 122676 1 8-Pin Connector
3 122646 1 2-Pin Connector
4 122683 1 6-PinTerminal
5 122640 1 9-PinTerminal
6 122706 * #20-16 U.M.N.L. Socket
7 122669 * Female CrimpTerminal
* As needed.
Phase 7 OPL Microprocessor Control Box Assembly

6Front PanelAssembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty.Description
1 883567 1 White Front PanelAssembly
(includes illus. nos. 1, 3, and 5 through 6)
2 150313 11 #10-16 x 1/2” TORX + BTN Type 1
150318 1 25 IP TORX + Bit 1/4 Hex (for removal of TORX head screw)
3 -------- 1 Main Door Hinge
(refer to Main Door “Steel” Assembly on page 8)
4 122002 1 Lint Drawer Switch
5 170330 1 Friction Door Latch
6 154215 2 5/32” Pop Rivet

7
Front Panel Assembly
For Models Mfd. prior to July 1, 2002
Illus. No. Part No. Qty.Description
1 883137 1 White Front PanelAssembly
(includes illus. nos. 1, 3, and 5 through 6)
2 150313 11 #10-16 x 1/2” TORX + BTN Type 1
150318 1 25 IP TORX + Bit 1/4 Hex (for removal of TORX head screw)
3 -------- 1 Main Door Hinge
(refer to Main Door “Steel” Assembly on page 8)
4 -------- 1 Lint Drawer Switch
(refer to Lint Drawer/Lint Drawer Switch Assembly on page 13)
5 881987 1 Friction Door Latch Kit
(includes illus. nos. 5 and 6)
6 154215 2 5/32” Pop Rivet

8Main Door “Steel”Assembly
Illus. No. Part No. Qty.Description
1 881150 1 Black Main DoorAssembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
2 102354 1 Door Gasket
170731 1 Black Gasket Adhesive (10.3 oz. cartridge)
3 881152 1 BlackTop Hinge BlockAssembly
(includes illus. nos. 3 and 4)
4 150445 2 1/4-20 x 3/4” Black Cap Head Setscrew
5 153031 1 1/4” Nylon Washer
6 881151 1 Black Bottom Hinge BlockAssembly
(includes illus. nos. 5 through 7)
7 150445 2 1/4-20 x 3/4” Black Cap Head Setscrew
8 150683 3 1/4-20 x 5/8” Black Carriage Bolt
9 152014 3 1/4-20 Free Spin Wash Nut
10 151010 1 #10-32 Black Hex Acorn Nut
11 150120 1 Door Latch Screw
12 150683 3 1/4-20 x 5/8” Black Carriage Bolt
13 152014 3 1/4-20 Free Spin Wash Nut
14 881210 1 Black Main Door Handle ONLY
15 102211 1 20-7/16” Door Glass
170731 1 Black Glass Adhesive (10.3 oz. cartridge)

9
Main Door Switch Assembly
Illus. No. Part No. Qty.Description
1 150006 2 #6-32 x 7/8” Phillips Pan Head Machine Screw
2 152013 2 #6-32 Hex Nut
3 153010 2 #6 Star Washer
4 137005 1 Door Switch
5 122636 2 Flag Terminal
6 881211 1 Black Main Door Switch Housing ONLY
881153 1 Black Main Door Switch Housing Complete
(includes illus. nos. 1 through 4 and 6)
7 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw

10 Basket (Tumbler)/SupportAssemblies
Illus. No. Part No. Qty.Description
1* 800776 1 Stainless Steel Basket (tumbler) ONLY (without felt collar)
883295 1 Stainless Steel Basket (tumbler)/SupportAssemblies Complete
(includes illus. nos. 1 through 10)
2 150313 24 #10-16 x 1/2” TORX + BTN Type 1
3 301420 4 Stainless Steel Basket (tumbler) Rib ONLY
4 150518 1 5/16-18 x 3/8” Socket Button Head Screw
5 100914 4 3/8-16 x 20” Tie Rod
6 153004 4 3/8” Flat Washer
7 817084 1 Basket (tumbler) Support ONLY
8 152005 4 3/8-16 Hex Nut
9 153005 4 3/8” Lock Washer
10 153004 4 3/8” Flat Washer
11 116002 1 Felt Collar ONLY
-- 401010 1 #847 Adhesive for Felt Collar (5.0 oz. tube)
* Felt collar is not included and must be ordered separately.

11
Drop Lint Door Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty.Description
1 802277 1 Drop Lint Door (for OPL models)
(includes illus. nos. 1 through 3)
2 117604 5 Sponge Tape (sold by the foot)
3 170226 1 Slide Latch

12 Lint Trap Assembly
For Models Mfd. as of July 1, 2002
Illus. No. Part No. Qty.Description
1 800401 1 Lint TrapAssembly Complete
(includes illus. nos. 1 and 3 through 5)
800443 1 Lint Trap ONLY
2 154200 6 5/32” Pop Rivet
3 150300 3 #10-16 x 1/2” Hex Washer TEK Screw
4 304100 1 Lint Screen Holder ONLY
5 800500 2 Lint ScreenAssembly

13
Lint Drawer/Lint Drawer Switch Assembly
For Models Mfd. prior to July 1, 2002
Illus. No. Part No. Qty.Description
1 883140 1 White Lint Drawer Assembly
(includes illus. nos. 1 and 2)
2 117605 5 Gasket (sold by the foot)
3 122116 1 Lint Drawer Switch
4 122605 1 4-Pin Socket Connector ONLY
5 122701 4 Socket Terminal ONLY
122801 1 Pin/Socket ExtractionTool
6 833123 1 Lint Drawer Switch Box Assembly
(includes illus. nos. 3 through 6)
304136 1 Lint Drawer Switch Box Cover ONLY
7 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
8 122700 4 Pin Terminal ONLY
9 122604 1 4-Pin Connector ONLY

14
Illus. No. Part No. Qty.Description
1 100107 1 5L-670 V-Belt (basket [tumbler] to idler)
2 101129 1 9” x 2-1/2” Compound Pulley
3 100103 1 4L-510 V-Belt
4 154301 2 5/16-18 x 1” Allen Setscrew
5 100705 1 3/16” x 3/16” x 1-3/8” Key
6 882576 1 Idler BearingAssembly Complete
(includes illus. nos. 5 through 12)
7 150617 2 3/8-16 x 1” Hex Head Machine Bolt
8 153005 2 3/8” Lock Washer
9 153004 2 3/8” Flat Washer
10 801009 1 Idler Square Washer
11 152004 1 5/16-18 Hex Nut
12 150509 1 5/16-18 x 3” Hex Head Machine Bolt
IdlerBearing Assembly

15
Basket (Tumbler) BearingAssembly
Illus. No. Part No. Qty.Description
1 153002 3 5/16” Lock Washer
2 880213 1 1-1/4” Flange Bearing with Nylock Setscrew
3 153002 3 5/16” Lock Washer
4 152004 3 5/16-18 Hex Nut
5 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
6 153002 4 5/16” Lock Washer
7 153004 4 3/8” Flat Washer
8 883609 1 1” Bearing BoxAssembly Complete
(includes illus. nos. 8 through 14 and 19 through 21)
801105 1 Bearing Box ONLY
9 150610 2 5/16-18 x 1-1/2”Allen Setscrew
10 152004 2 5/16-18 Hex Nut
11 150501 3 5/16-18 x 3/4” Hex Head Machine Bolt
12 880201 1 1” Flange Bearing with Nylock Setscrews
13 153002 3 5/16” Lock Washer
14 152004 3 5/16-18 Hex Nut
15 101100 1 18” Pulley ONLY
16 154301 2 5/16-18 x 5/16” Setscrew
17 100713 1 1/4” x 1/4” x 7/8” Key
18 100107 1 5L-670 V-Belt (basket [tumbler] to idler)
19 319004 1 Rotational Sensor Bracket
20 883386 1 Rotational SensorAssembly
21 102120 1 Rotational Sensor Magnet

16 Motor Mount Assembly

17
Illus. No. Part No. Qty.Description
1 100103 1 4L-510 V-Belt (motor to idler)
2 100705 1 3/16” x 3/16” x 1-3/8” Key
3 101131 1 1/2” x 2-1/4” Motor Pulley
(for models mfd. as ofAugust 22, 2002)
101133 1 5/8” x 2-1/4” Motor Pulley
(for models mfd. prior toAugust 22, 2002)
4 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
5 153002 4 5/16” Lock Washer
6 153001 4 5/16” Flat Washer
7 181049 1 1/2 HP 240v 1ø 50 Hz Plug-Type Motor
(for models mfd. as ofAugust 22, 2002)
100066 1 1/2 HP 240v 1ø 50 Hz Totally Enclosed, Fan-Cooled (T.E.F.C.) Plug-Type
Motor
(for models mfd. prior toAugust 22, 2002)
8 122701 8 Socket Terminal ONLY
122801 1 Pin/Socket ExtractionTool
9 137030 1 8-Pin Housing Connector
10 152004 4 5/16-18 Hex Nut
11 153002 4 5/16” Lock Washer
12 153001 4 5/16” Flat Washer
13 117604 4 Neoprene Sponge Tape (sold by the foot)
14 154000 4 5/16-18 Tinnerman Nut
15 850017 1 1/2 HP Motor Mount ONLY (56Z frame)
817076 1 1/2 HP 240v 1ø 50 Hz Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
16 153050 2 1/2” S.A.E. Flat Washer
17 100604 1 12-1/2” Impellor with 1/2” Bore
18 100702 1 1/8” x 1/8” x 1-1/2” Key
19 153050 2 1/2” S.A.E. Flat Washer
20 152006 2 1/2-20 Left Hand Jam Nut
Motor Mount Assembly

18 SensorBracket Assemblies
For Models Mfd. as of July 1, 2002
