jobmate JMCMT18G.9 Installation manual

SAFETY AND OPERATING MANUAL
18 V
LI-ION OSCILLATING MULTI TOOL SKIN ONLY
J M C M T18 G.9

2
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an
increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors,
use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a power
tool. Do not use a power tool while you are
tired or under the influence of drugs, alcohol
or medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes,
hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power
tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better
control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used. Use of these devices can reduce dust-
related hazards.
h) Do not let familiarity gained from frequent
use of tools allow you to become complacent
and ignore tool safety principles. A careless
action can cause severe injury within a
fraction of a second.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off. Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of

3
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions
to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in
unexpected situations.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of fire when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery may cause irritation or burns.
e) Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
f) Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire
or temperature above 130 °C may cause
explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of
fire.
6) SERVICE
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
b) Never service damaged battery packs.
Service of battery packs should only be
performed by the manufacturer or authorized
service providers.
SAFETY INSTRUCTION FOR
CUTTING
Hold power tool by insulated gripping surfaces,
when performing an operation where the
cutting accessory may contact hidden wiring.
Cutting accessory contacting a “live” wire may
make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred cells or
battery pack.
b) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box or
drawer where they may short-circuit each
other or be short-circuited by conductive
materials. When battery pack is not in use,
keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or
other small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
c) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical
shock.
e) In the event of battery leaking, do not allow
the liquid to come into contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts of

4
water and seek medical advice.
f) Seek medical advice immediately if a cell or
battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean
dry cloth if they become dirty.
i) Battery pack needs to be charged before
use. Always refer to this instruction and use
the correct charging procedure.
j) Do not maintain battery pack on charge
when not in use.
k) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
l) Battery pack gives its best performance
when it is operated at normal room
temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
n) Recharge only with the charger specified by
manufacturer. Do not use any charger other
than that specifically provided for use with
the equipment. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
o) Do not use any battery pack which is not
designed for use with the equipment.
p) Keep battery pack out of the reach of
children.
q) Retain the original product literature for
future reference.
r) Remove the battery from the equipment
when not in use.
s) Dispose of properly.
GENERAL SAFETY WARNINGS
FOR BATTERY CHARGER
WARNING Read all safety warnings
and all instructions. Failure to follow the
warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that
they do not play with the appliance.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR
BATTERY CHARGER
1. Before charging, read the instructions.
2. For charge Li-Ion battery pack only.
3. Do not charge a leaking battery.
4. Do not use chargers for works other than those for
which they are designed.
5. Before charging, ensure your charger is matching
the local AC supply.
6. The charging device must be protected from
moisture.
7. Do not use the charging device in the open.
8. Do not short out the contacts of battery or charger.
9. Respect the polarity “+/-“ when charging.
10. Do not open the unit and keep out of the reach of
children.
11. Do not charge the batteries of other manufactures
or ill-suited models.
12. Ensure that the connection between the battery
charger and battery is correctly positioned and is
not obstructed by foreign bodies.
13. Keep battery charger’s slots free of foreign objects
and protect against dirt and humidity. Store in a dry
and frost-free place.
14. When charging batteries, ensure that the battery
charger is in a well-ventilated area and away from
inflammable materials. Batteries can get hot
during charging. Do not overcharge any batteries.
Ensure that batteries and chargers are not left
unsupervised during charging.
15. Do not recharge non-rechargeable batteries, as
they can overheat and break.
16. Longer life and better performance can be
obtained if the battery pack is charged when the
air temperature is between 18℃ and 24℃. Do not
charge the battery pack in air temperatures below
4.5℃, or above 40.5℃. This is important as it can
prevent serious damage to the battery pack.
17. Charge only battery pack of the same model
provided by manufacturer and of models
recommended by manufacturer

5
SYMBOLS
T 2.0A
To reduce the risk of injury, user must
read instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Indoor use only
RCM marking
Do not expose to rain or water
Do not burn
Do not dispose of batteries. Return
exhausted batteries to your local
collection or recycling point.
Fuse
Positive terminal
Negative terminal
Double insulation
Read the operator’s manual.
ABN: Australian Business Number. By this number,
business information such as entity type, status,
business location etc. can be found at website
http://abr.business.gov.au.
ABN of Positec Australia Pty Limited is 14 101 682
357

6

7
COMPONENT LIST
1. On/Off switch
2. Battery pack release button*
3. Battery pack*
4. Variable speed control
5. Venting slot
6. Flange
7. Allen key
8. Sanding plate
＊Not all the accessories illustrated or described are included in standard delivery.
ACCESSORIES
1-1/8” 28 mm standard end cut blade 1
1-3/8” 35 mm standard end cut blade 1
Rigid scraping blade 1
Sanding Plate 1
60# Sanding sheet 1
80# Sanding sheet 1
120# Sanding sheet 1
Allen key 1
We recommend that you purchase your accessories from the same store that sold you the tool. Choose the
type according to the work you intend to undertake. Refer to the accessory packaging for further details.
Store personnel can assist you and offer advice.
TECHNICAL DATA
Rated Voltage 18V
No load speed 6000-18000/min
Oscillations angle 3.2°
Machine weight 1.23 Kg
Battery pack (ABP118G1 )*
Battery capacity 1.5 Ah Li-ion battery
Char ger (ACG18LD)*
Charger protection class /II
Charger input 100-240~50/60Hz
Charger output 10.8-20V 1500 m A
Charging time 1 hr

8
Fig.B1
Fig.A
Fig.B2
Fig.C1
Fig.C2
Fig.D
Fig.C3
Fig.F
Fig.E
Fig.G
OPERATION INSTRUCTIONS
NOTE: Before using the tool, read the instruction book
carefully.
INTENDED USE
The power tool is intended for sawing and separating wooden
materials, plastic, plaster, non-ferrous metals and fasteners
(e.g. nails and clamps) as well as working on soft wall tiles and
for dry grinding of small surfaces. It is especially suitable for
working close to edges and for flush cutting.
BEFORE PUTTING INTO OPERATION
NOTE:
a) Do not use any charger other than that specifically
provided for use with the equipment.
b) If the battery pack is very hot you must remove your
battery pack from the charger and allow time for the
battery to cool down before recharging.
c) The battery in your new tool is not charged when it
leaves the plant. Therefore it must Fully charged before
using the first time.
d) Please charge the battery to reach full or no less than
half charge before storage. If the tool will not be used
for long periods of time, charge the battery every 3-6
months.
1) Plug the charger into an appropriate outlet.
2) Place the battery pack into the charger.
3) When charging is completed, unplug the charger and
remove the battery pack.
Note: If the battery pack is locked in the charger, press the
battery pack release button and remove it.
Warning: When battery charge runs out after continuous
use or exposure to direct sunlight or heat, allow time for
the battery to cool down before recharging to achieve the
full charge.
CHARGING INDICATOR
Light ON/OFF flash Status
Red on Charging
Red flash - - - - - Defective Battery
Green on Fully Charged
Green flash - - - - - Hot/Cold Delay

9
Fig.B1
Fig.A
Fig.B2
Fig.C1
Fig.C2
Fig.D
Fig.C3
Fig.F
Fig.E
Fig.G
INSTALLING AND REMOVING THE
BATTERY PACK
A) TO REMOVE THE BATTERY PACK (SEE FIG. B1)
Depress the Battery Pack Release Button (2) firmly first and
then slide the Battery Pack out from your tool.
B) TO INSTALL THE BATTERY PACK (SEE FIG. B2)
Slide the fully charged Battery Pack onto the tool with
sufficient force until it clicks into position.
2. MOUNTING THE TOOL (SEE FIG. C1-C3)
CAUTION: For all work or when changing application
tools, always wear protective gloves. Avoid danger
of injury from the sharp edges of the application tools.
Application tools can become very hot while working,
presenting danger of burns!
WARNING: To reduce the risk of injury, do not let the
universal end cut blades or any segment saw blades
face back toward the user’s hand.
- LOOSEN THE FLANGE
Use the allen key to rotate the flange clockwise. (See fig. C1)
- INSERT ACCESSORIES
Insert the accessory onto the accessory holder.(See fig. C2)
-TIGHTEN THE FLANGE
Use the allen key to rotate the flange counter-clockwise until
accessory is tightened securely.(See fig. C3)
2. MOUNTING / CHANGING THE SANDING SHEET (SEE
FIG. D)
Align the sanding sheet and press it onto the sanding plate
by hand.
Firmly press the power tool with the sanding sheet against a
flat surface and briefly switch the power tool on. This provides
for good adhesion and prevents premature wear.
If one point has become worn, pull off the sanding sheet, turn
it 120° and place it on again.
3. OPERATING THE ON/OFF SWITCH (SEE FIG. E)
——Switching the power tool ON:
Slide switch (1) forward (I).
——Switching the power tool OFF:
Slide switch (1) backward (0).

10
Fig.B1
Fig.A
Fig.B2
Fig.C1
Fig.C2
Fig.D
Fig.C3
Fig.F
Fig.E
Fig.G
5. USING THE VARIABLE SPEED CONTROL (SEE FIG. F)
Select oscillation frequency (speed) while the motor is
running.
The variable speed control (4) can be used to set the optimum
oscillating frequency according to the accessories used and
the respective application.
High oscillation frequency:
Sanding, sawing, rasping and polishing stone and metal.
Low oscillation frequency:
Polishing varnishes.
6. SANDING
Typical application: wood, metal; small areas, especially
corners, edges and places difficult to access.
Select high oscillation frequency.
Sand with a constant movement and light pressure.
Heavy pressure does not increase the removal – the sanding
sheet merely wears faster.
7. SAWING WITH THE SEMICIRCLE SAW BLADE
The workpiece must be inserted firmly or clamped tightly
before it is cut.
Typical application: wood, PVC, soft metal sheet.
Select high oscillation frequency .
The saw blade lasts longer if the wear is distributed evenly. To
ensure an even distribution, loosen the saw blade, rotate it
and retighten firmly.
8. SAWING WITH THE END CUT SAW BLADE (SEE FIG. G)
WARNING: the sawing teeth are very sharp. Do not
touch during mounting and application.
The workpiece must be inserted firmly or clamped tightly
before it is cut.
Typical application: wood, plaster board, soft plastics and
metal (e. g. nails).
When plunging and sawing use a slight pendulum motion, to
allow sufficient chip removal.
