Joerns Healthcare Hoyer SS-HSP Installation and operation manual

Swimming Pool Lifter
SS-HSP
User
Instruction
Manual &
Warranty
Hoyer
Hoyer

IM-459004
I n s t a l l a t i o n
2
This manual contains important safety and maintenance instructions. Please read it
carefully before installing and using your patient lifter.
DANGER!
The National Electrical Code requires that all metallic objects in the
proximity of a swimming pool must be connected by no less than a #8
AWG solid copper wire to a common bonding grid such as the structural
reinforcing steel or the walls of a welded metal pool structure. Attach wire
to ground lug on cement-in sleeve.
WARNING!
This lifter is not interchangeable with any other Hoyer Lifter models. Use
only genuine Hoyer parts and Hoyer slings on all Hoyer lifters. Hoyer lifter
parts are not interchangeable with other manufacturers’ parts. Replace any
worn parts immediately.
WARNING!
Do not exceed maximum weight capacity of 400 lbs.
Installation of Cement-in Sleeve
Notice: All sleeves are nowbeing supplied forflush installation with flush cover
Position the sleeve location per the layout in
Figure 1. Proper position for the mast is 8 to
10 inches from the edge of the pool or tub. The
cement-in sleeve itself is a cylinder 3¼ inches in
diameter and 8 inches long. Mark a 6 inch circle
if existing concrete is to be removed. In a new
installation, position the sleeve on center and
flush with grade.
When the cement-in sleeve is to be installed in
an existing concrete floor or deck, a hole at
least 6 inches in diameter must be cut (Figure
2). The opening must be at least 8 inches deep.
Fill the bottom of the hole with non-shrinking
cement, such as Por-Rok. Make sure the sleeve
is perfectly vertical. Fill in around the sleeve
with more non-shrinking cement. Allow the
cement to set-up and finish the top surface.
Figure 1
Figure 2

IM-459004
Model s 5
M a i n tenance and Use3
The diagram (Figure 3) shows a cross section of
the finished installation for the cement-in sleeve.
Notice that the sleeve is completely imbedded in
cement and that a good bond is secured between
the new and old concrete. When installing the
sleeve in a new job, position the sleeve and line it
up when the forms are being installed. Pour the
concrete around the sleeve as the deck or floor is
poured. No special type of concrete is required.
NOTE: A wad of newspaper stuffed into the top of the
sleeve will keep the interior free of concrete while the floor is
being poured.
Installation of Lifter
When the sleeve has been installed as described
above and the concrete has had several days to
cure, the lifter may be installed. The nylon bearing
socket supplied with the lifter must be installed in
the sleeve (Figure 4). Grease the outside of the
socket lightly before it is inserted into the sleeve.
This will prevent corrosion which may cause the
socket to stick in the sleeve. Vaseline is an excel-
lent lubricant if no commercial grease is on hand.
NOTE: The socket should be removed occasionally to
prevent corrosion.
With the socket in place, unpack the lifter and
insert the base of the mast into the socket and
sleeve (Figure 4). To attach the end of the boom
in the yoke hinge at the top of the mast, remove
the wing nut and bolt from the yoke hinge and
insert the boom end. Reinsert the bolt and
secure with the wing nut. Attach the swivel bar
to the boom end and to keep the chains apart.
The lifter is now ready for use.
Maintenance
Put a drop of oil on the joints at the top of the mast, top and bottom of the pump, and
the swivel bar hook every other month.
While oiling the lifter, check all the cap nuts and bolts to be sure they are tight.
Put a drop of oil on the pump handle hinge when the Hoyer lifter is put into service
and oil again every other month. This is very important, as the holes in the hinge
socket will wear when dry.
NOTE: In high humidity or salt areas, wax exposed lifter parts periodically to help prevent corrosion.
NOTE:KEEP LIFTER DRY AND CLEAN
Figure 3
Figure 4
Boom 45”
Maximum Height 86”
Yoke Hinge
Mast
Nylon Bearing
Socket
(Grease Lightly)
Cement-In
Sleeve
Swivel
Bar

Distributed by:
Made in Taiwan
© 2011, Joerns Healthcare
IM-459004 Rev B
Joerns Healthcare Inc.
2100 Design Road • Suite 100 • Arlington • TX 76014 • USA
Tel: [phone] • Fax: [phone]
www.joerns.com
H e ade rW a r r a n t y
Operating Instructions
To use the Hoyer Swimming Pool Lifter, remove the cover from the floor sleeve and insert the nylon
bearing socket. Insert the mast of the lifter into the socket. Attach the long chains to the swivel bar.
To use the Hoyer Sling #112-D, place the sling under the person being lifted so that the end of the
seat comes to the person’s knees. Attach the ends of the chains to the swivel bar and the S-hooks
to the sling. When the person is lifted so that he/she just clears the chair, the lifter boom should be
almost at maximum height. The person being lifted can then be lowered the full 62”. Follow lifting
instructions in “How to Use a Patient Lifter” manual.
Warranty
Your Hoyer lifter is warranted to be free of defects in materials and workmanship for one (1) year
after purchase by the original consumer/owner. Components included in this warranty are as follows:
Lifter structure: base, mast, boom, andswivel bar; and Hydraulic pump
All other non-durable components, such as rubber parts, plastic parts and painted surfaces are
warranted for 3 months from first consumer purchase. These are subject to normal wear and
replacement.
Limitations
1. We do not warrant damage due to:
a. Neglect, misuse or improper installation or repair.
b. Use of parts or changes not authorized by Sunrise Medical
c. Exceeding the specified weight capacity of the lifter.
2. This warranty is void if the original lifter serial number tag/label is removed or altered.
Our sole liability is to repair or replace covered parts. This is your only remedy for consequential
damages.
What you must do
1. Obtain from us, while this warranty is in effect, prior approval for return or repair of covered
parts.
2. Contact Customer Service at 1-800-333-4000 for shipping information.
3. Pay the cost of labor to install or repair parts.
Notice to Consumer
There are no other express warranties. This warranty gives you certain legal rights. You may also
have other rights that vary from state to state.
4
DCO. 11-0375
