Joerns Oxford Adaptive Power Cradle Installation and operation manual

Oxford®
Adaptive Power Cradle
2
English
Contents
1. Installing your Oxford 4-point Adaptive Power Cradle .......................................... 3
2. Component Parts................................................................................................... 4
3. Assembly Instructions (connection and removal) .................................................. 4
4. Sling Attachment ................................................................................................... 6
5. Safety Precautions ................................................................................................ 7
6. Cradle Operation ................................................................................................... 8
7. Service & Maintenance ......................................................................................... 11
8. Electrical Specication........................................................................................... 14
9. Warranty ................................................................................................................ 15

Oxford®
Adaptive Power Cradle
3
English
1. Oxford 4-point Adaptive Power Cradle
The Oxford Presence lift is tted with a 6-point spreader bar as standard and the Stature lift is
tted with a 4-point cradle as standard (see g. 1).
As an accessory, you can retrot your standard spreader bar/cradle with an Adaptive Power
Cradle (see g. 2).
This accessory utilises Oxford Comfort slings featuring the Securi3 safety clip system
(see g. 3).
!"#$%&
Standard conguration
4-point cradle
Standard conguration
6-point spreader bar
!"#$%'
!"#$%(

Oxford®
Adaptive Power Cradle
4
English
2. Component Parts: Adaptive Power Cradle
The following components are included with your 4-point Adaptive Power Cradle (see fig. 4).
&$ 1 x 4-point Adaptive Power Cradle
'$ 1 x Battery charger
($ 2 x Rechargeable batteries, NiMH
4. 2 x Black plastic caps for Stature and Presence boom
)$ 1 x User/service manual (not shown)
3. Assembly Instructions
Assembly is quick and easy but it is important that you follow the procedure carefully.
!*++*,%-./0/%120-345-1*20%/675-+89
Removal:
To attach your 4-point Adaptive Power Cradle you must first remove the old spreader bar/cradle
from the lift. This is achieved by removing the quick-release pin that retains the non-powered
spreader bar/cradle (see fig. 5). A small flat blade screwdriver or similar is the only tool required.
!"#$%:
Battery Charger
(UK lead shown only)
2 x Rechargeable
Batteries
!"#$%)
4-point Adaptive Power Cradle
Black Plastic Caps

Oxford®
Adaptive Power Cradle
5
English
574-1*29%;<"=<%>=%<?@=A"B#%>C?%DE"FG%<?H?IJ?%K"BL%>C?%F<IMH?%B??MJ%>=%N?%JEKK=<>?M%NO%I%
J>I>"=BI<O%=NP?F>%JEFC%IJ%I%Q=<GN?BFC%=<%>INH?$%-C"J%Q"HH%K<?A?B>%>C?%F<IMH?%R<=@%M<=KK"B#%
JEMM?BHO%QC"FC%F=EHM%<?JEH>%"B%IB%"BPE<O%=<%MI@I#?%>=%>C?%F<IMH?$%
Connection:
To connect, raise the 4-point Adaptive Power Cradle up towards the boom slot. Insert the pin
sleeve through lift boom, the black plastic end cap* and the cradle king pin. Once the pin sleeve
has been installed and is supporting the weight of the Adaptive Power Cradle, re-insert the quick
release pin fully into the sleeve until it locks into position (See fig. 6).
To verify that the pin is securely fitted, press your finger into the barbed end. If the pin remains
stationary, the lift is safe to use (See fig. 7).
%%%%%%%%%%% % % ,73212ST
8*4%U40-%5./5V%-.7-%-./%;12%10%0/543/+8%!1--/WX%I%B=>"F?INH?%YFH"FGZ%Q"HH%J=EBM%
QC?B%>C?%F=BB?F>"=B%CIJ%N??B%@IM?%J?FE<?$
[/BJE<?%O=E%EJ?%>C?%F=<<?F>%A?<J"=B%=R%>C?%NHIFG%KHIJ>"F%FIK%R=<%O=E<%H"R>L%IJ%'%I<?%JEKKH"?M$%
5C?FG%>C?%FIK%Q"M>C%I#I"BJ>%O=E<%H"R>J%N==@%N?R=<?%R">>"B#$
!"#$%\!"#$%]
Black Plastic Caps

Oxford®
Adaptive Power Cradle
6
English
,73212ST
^% _?R=<?%EJ"B#%O=E<%:`K="B>%7MIK>"A?%;=Q?<%5<IMH?%?BJE<?%>C?%DE"FG%<?H?IJ?%K"B%"J%
!4++8%/2S7S/W%IJ%JC=QB%"B%R"#E<?%]%IBM%\%=B%KI#?%)$%
^% -C?%*aR=<M%]`K="B>%JK<?IM?<%NI<%IBM%>C?%*aR=<M%:`K="B>%7MIK>"A?%;=Q?<%5<IMH?%
bK=Q?<%IBM%B=B`K=Q?<c%I<?%=BHO%F=@KI>"NH?%Q">C%>C?%*aR=<M%;<?J?BF?%IBM%0>I>E<?%
H"R>J$%W=%B=>%EJ?%>C"J%F<IMH?%=<%JK<?IM?<%NI<%Q">C%IBO%=>C?<%@IBERIF>E<?<dJ%H"R>%=<%
JH"B#J$
4. Sling Attachment
7>>IFC@?B>%=R%>C?%5=@R=<>%JH"B#%>=%O=E<%7MIK>"A?%;=Q?<%5<IMH?9
The Comfort sling attaches to the cradle studs via the Securi3 safety clip system (shown below);
each sling is supplied with instructions. Please study the instruction guide before use (See g. 8).
Example of Securi3 safety clip system. The 3 key stages assure patient and carer of complete
safety and comfort throughout the transfer (see g. 9).
5. Safety Precautions
!"#$%e
!"#$%f
&$ '$ ($ :$
&$ Attach clip to lug
'$ Pull plastic clip down to secure
($ Feed green ‘safe’ tab through slot
:$ Sling is attached and ready to use

Oxford®
Adaptive Power Cradle
7
English
^% ,C?B%KHIF"B#%>C?%F<IMH?%IBM%JH"B#%"B%>C?%@=J>%EK<"#C>%K=J">"=B%M=%B=>%H?IA?%>C?%
KI>"?B>%EBI>>?BM?M$%-C?%KI>"?B>%F=EHM%JHE@K%R=<QI<M%"B%>C?%JH"B#L%QC"FC%F=EHM%<?JEH>%
"B%IB%"BPE<O%>=%>C?%KI>"?B>$
^% W=%B=>%EJ?%I%JH"B#%EBH?JJ%">%"J%<?F=@@?BM?M%R=<%EJ?%Q">C%>C?%F<IMH?gH"R>$
^% 7HQIOJ%FC?FG%>CI>%>C?%JH"B#%"J%JE">INH?%R=<%>C?%KI<>"FEHI<%KI>"?B>%IBM%"J%=R%>C?%F=<<?F>%
J"h?%IBM%FIKIF">O$
^% 2?A?<%EJ?%I%JH"B#%>CI>%"J%R<IO?M%=<%MI@I#?M$
^% 7HQIOJ%R">%>C?%JH"B#%IFF=<M"B#%>=%>C?%EJ?<%"BJ><EF>"=BJ%K<=A"M?M%bJH"B#%EJ?<%
"BJ><EF>"=BJc$
^% 7HQIOJ%KHIB%O=E<%H"R>"B#%=K?<I>"=BJ%N?R=<?%F=@@?BF"B#$
^% 7HQIOJ%FC?FG%>CI>%O=E<%*aR=<M%:`K="B>%7MIK>"A?%;=Q?<%5<IMH?%"J%"B%#==M%Q=<G"B#%
=<M?<%K<"=<%>=%IBO%H"R>"B#%=K?<I>"=B$
^% 7HQIOJ%EJ?%>C?%:`K="B>%7MIK>"A?%;=Q?<%5<IMH?%"B%I%FH?IBL%M<O%IBM%>?@K?<I>E<?%
F=B><=HH?M%"BM==<%?BA"<=B@?B>$

Oxford®
Adaptive Power Cradle
8
English
6. Cradle Operation
Hand Control:
Operating the 4-point Adaptive Power Cradle is a very easy process. Once the patient has been
placed in the sling and the sling has been attached to the Adaptive Power Cradle, the cradle is
positioned by using the hand control located in the cradle handle (see fig. 10).
Pressing the Y4KZ arrow button will move the patient into a reclined or lying position.
Pressing the YW=QBZ arrow button will move the patient into an upright or sitting position.
The 4-point Adaptive Power Cradle can be positioned in incremental movements or in one
constant motion. This ensures the patient is positioned in the optimum profile for their maximum
comfort.
,73212ST
,C?B%KHIF"B#%>C?%F<IMH?%IBM%JH"B#%"B%>C?%@=J>%EK<"#C>%K=J">"=B%M=%B=>%H?IA?%>C?%KI>"?B>%
EBI>>?BM?M$%-C?%KI>"?B>%F=EHM%JHE@K%R=<QI<M%"B%>C?%JH"B#L%QC"FC%F=EHM%<?JEH>%"B%IB%"BPE<O%
>=%>C?%KI>"?B>$
Battery & Control Box:
The 4-point Adaptive Power Cradle requires a minimum of maintenance but it is very important to
perform regular maintenance and to have a thorough understanding of the control system.
The control box has been designed to provide audible signals. The signals are indicated with
long, short or multiple “beeps”.
&$ ;=Q?<%*B (Power is on when the battery is inserted)9 One extended “BEEP”
'$ 0H??K%U=M?9 Two short “BEEPS”
($ +=Q%_I>>?<O9 Two short “BEEPS” repeated every 24 seconds. (charge battery)
:$ 0>I<>%*K?<I>"=B9 Two “BEEPS” (low voltage, charge battery soon)
)$ WE<"B#%*K?<I>"=B9 One long BEEP (the battery charge is too low; only a reclined position
can be achieved). Replace the battery with a fully charged battery.
!"#$%&i
Reclined
Upright

Oxford®
Adaptive Power Cradle
9
English
Charging Instructions:
To charge the battery, follow the instruction below:
&$ Remove the battery from the cradle (see fig. 11). The battery is retained by a magnetic force.
Simply pull the battery straight out of the control box on the cradle.
'$ Connect the power lead into the charger.
($ Place the battery in the charging unit (see fig. 12). The battery is held in place by a magnetic
force and will automatically align itself in the charger unit.
:$ Plug the charger into the mains power outlet (see fig. 13). An amber light will illuminate,
indicating there is power to the charger.
)$ A green light will begin to “flash” indicating that the battery is being charged. The amber light
remains constantly illuminated.
]$ Once the green indicator light stops flashing and remains illuminated, the battery is fully
charged and may be returned to service.
\$ To return the battery to service, switch off (UK/EU) the mains supply and remove the battery
from the charging unit. Fit the battery into the control box on the cradle. One long “BEEP” will
indicate that the battery has been properly placed in the control box and the cradle is ready
for use.
2*-/9%/BJE<?%>C?%NI>>?<"?J%I<?%REHHO%FCI<#?M%K<"=<%>=%EJ"B#%O=E<%:`K="B>%7MIK>"A?%;=Q?<%
5<IMH?%R=<%>C?%R"<J>%>"@?$
2*-/9%-C?%F<IMH?%Q"HH%J=EBM%I%J"B#H?%YN??KZ%IR>?<%>C?%NI>>?<O%CIJ%N??B%<?@=A?M$%-C?%%%
YN??KZ%Q"HH%=FFE<%=B%I%<?#EHI<%"B>?<AIH%R=<%J?A?<IH%C=E<J$
,73212ST
^% V//;%>C?%NI>>?<O%REHHO%FCI<#?M$%;HIF?%>C?%NI>>?<O%=B%FCI<#?%QC?B?A?<%">%"J%B=>%"B%EJ?$%
1R%">%"J%@=<?%F=BA?B"?B>%>=%M=%J=L%KHIF?%=B%FCI<#?%?A?<O%B"#C>$%-C?%FCI<#?<%,1++%2*-%
IHH=Q%>C?%NI>>?<O%>=%=A?<FCI<#?$
^% _I>>?<O%=<%FCI<#?<%"J%B=>%>=%N?%=K?B?M%NO%EBIE>C=<"h?M%K?<J=BB?H$%b5=B>IF>%j=?<BJ%
.?IH>CFI<?%=<%O=E<%M"J><"NE>=<%R=<%QI<<IB>O%IBM%<?KI"<Jc$
^% W=%B=>%>=EFC%NI>>?<OgFCI<#?<%>?<@"BIHJ$
!"#$%&& !"#$%&' !"#$%&(
(UK version shown)

Oxford®
Adaptive Power Cradle
10
English
^% 2?A?<%<EB%>C?%NI>>?<O%F=@KH?>?HO%RHI>$%7J%J==B%IJ%>C?%IEM"NH?%QI<B"B#%J=EBMJL%
F=@KH?>?%>C?%H"R>"B#%=K?<I>"=B%"B%CIBM%IBM%KHIF?%=B%FCI<#?$
^% 574-1*29%2?A?<%J>=<?%>C?%NI>>?<O%R=<%H=B#%K?<"=MJ%Q">C=E>%<?#EHI<%FCI<#"B#%
>C<=E#C=E>%>C?%J>=<I#?%K?<"=M$%-C"J%FIB%<?JEH>%"B%MI@I#?%>=%>C?%NI>>?<O%K<?A?B>"B#%">%
R<=@%N?"B#%FCI<#?M%F=<<?F>HO$
^% 7HQIOJ%@IG?%JE<?%>C?%@I"BJ%K=Q?<%"J%JQ">FC?M%=RR%N?R=<?%F=BB?F>"B#%=<%
M"JF=BB?F>"B#%>C?%NI>>?<O%b4Vg/4c$
^% 574-1*29%2?A?<%H?IA?%>C?%NI>>?<O%"B%>C?%FCI<#"B#%EB">%Q">C%@I"BJ%K=Q?<%=RR%b4Vg/4c%
=<%EB`KHE##?M%R<=@%>C?%QIHH%=E>H?>%b40c$
^% 574-1*29%2?A?<%H?IA?%>C?%NI>>?<O%FCI<#?<%JQ">FC?M%=B%Q">C%>C?%NI>>?<O%<?@=A?M$
^% W=%B=>%KEHH%=B%>C?%K=Q?<%H?IM%FINH?%QC?B%M"JF=BB?F>"B#%R<=@%>C?%FCI<#?<$%7HQIOJ%
<?@=A?%NO%#<IJK"B#%R"<@HO%>C?%F=BB?F>=<%KHE#%I>%>C?%FCI<#?<%?BM$

Oxford®
Adaptive Power Cradle
11
English
7. Service and Maintenance Schedule
Cleaning
The Oxford 4-point Adaptive Power Cradle will when necessary require cleaning. It can be cleaned
with warm water or a disinfectant cleaning uid.
574-1*29 Harsh chemicals may dull or remove the paint/finish from the cradle.
,73212S
W*%2*-%JK<IO%=<%JEN@?<#?%>C?%H"R>%"B%IBO%H"DE"M$
Initially Before Use Service Intervals
&$%Check for freedom of rotation (power cradle) üüü
'$ Check for wear on the central pivot point (the pivot pin located in the
cradle frame) ü ü
($ Check for rm attachment to the boom of the lift üüü
:$ Check for wear of the boom and quick release pin on the lift ü ü
)$ Check the actuator for correct operation listen for unusual noise üüü
]$%Lubricate the pivot joints, including boom and cradle ü
\$ Inspect pivot joints, including boom and cradle for excessive wear.
Replace as required ü
e$ Check power cable is rmly attached to the charger ü

Oxford®
Adaptive Power Cradle
12
English
Service Parts:
!"#$%&:

Oxford®
Adaptive Power Cradle
13
English
2=$ ;I<>%2=$ W?JF<"K>"=B
1 0Y0457 Actuator
2 0Y0459 Battery charger with UK lead
3 0Y0460 Battery charger with EU lead
4 0Y0458 Battery charger with US lead
5 0Y0461 Control box
6 0Y0462 Battery
7 0Y0463 Hand switch assembly
8 0Y0464 Wire harness between conrol box, actuator and switch
9 0Y0465 Hardware (xings)
10 0Y0380 Washer and O-ring kit
11 0Y0761 Battery charger with AU lead

Oxford®
Adaptive Power Cradle
14
English
8. Electrical Specification
Batteries .................................................................24VDC, rechargeable NiMH sealed
Battery capacity……………………................ .........1400mAh
Charger rated Input………………….............. .........100 - 240V AC// 24 VDC 50/60 Hz Max. 75mA
Charger rated Output………………............... .........Max 28,4VDC
/H?F><"F%0C=FG%;<=>?F>"=B
Charger………………………………............... ........Class II
W?#<??%=R%JC=FG%K<=>?F>"=B
Charger………………………………............... ........TYPE B
/BA"<=B@?B>IH%5=BM">"=BJ
Outside this environment functionality and safety may be compromised
*K?<I>"B#
Temperature………………………….............. .........-5C to +70C
0>=<I#?
Temperature………………………….............. .........-40C to +85C
1;%3I>"B#J
Control Box……………………….................... ........IP50 (with battery inserted)
Actuator………………………..……................ .........IP66
Charger………………………….…….............. ........No rating (not to be used in wet environment)
Battery…………………………..……............... ........IP50
Control Switch ………………..……................ ........IP67
WE>O%5OFH?
Actuator………………………………............... ........10% (2min./18min.)
Charger………………………………............... ........Approx. 6 hrs
7F=EJ>"FJ
A-Weighted sound power level .............................51.5 dB (A)
,?"#C>
Cradle including battery ........................................9.5 kg
Battery ...................................................................0.5 kg

Oxford®
Adaptive Power Cradle
15
English
9. Warranty
Joerns Healthcare has an established network of reputable sales representatives, distributors
and dealers who will be pleased to handle all your purchasing, warranty, repair and maintenance
inquiries. Our products are guaranteed for a period of 24 months from the date of manufacture or
24 months from the date of purchase if commissioned by an authorized dealer. This guarantee
covers the major structure including the 4-point cradle, actuator, control box and control switch
(Batteries are covered for a period of 90 days from purchase).
We recommend that all of our products be commissioned by your dealer, an authorized service
agent or by qualified maintenance personnel. The dealer or distributor operates the warranty
Programme; so it is important to keep a record of their name address and telephone number so
they can be contacted should any problem arise (UK customers only).
If you are in doubt where your lift was purchased, Joerns Healthcare can trace the supplier if you
provide the serial number of the cradle, which is situated under the handle that houses the control
switches.
For any details/queries relating to above please contact your customer service agent.
