Service Manual
Classic Mobile Lis
Mini 140
Midi 180
Major 200
Maxi 180

2
Oxford®
Classic Mobile Lis
Pages 3 - 5
Inspection Criteria for Oxford Classic Mobile Lifts
Pages 6 - 9
Testing of Oxford Classic Mobile Lifts
Pages 10 - 23
Service and Maintenance Schedule for Oxford Classic Mobile Lifts
Page 24
Fault Finding on Oxford Classic Mobile Lifts
Page 25
Torque Settings for Oxford Classic Mobile Lifts
Page 26
LOLER (UK only): Thorough Examination Report
Page 27
Blank Notes Page
Contents

Oxford®
Classic Mobile Lis
3
Joerns Healthcare Ltd recommends a thorough inspection and test of Oxford Classic mobile lifts and
their lifting accessories, slings etc. are carried out every six months. The examination and test should be
conducted according to the recommendations and procedures below. Joerns Healthcare Ltd recommends
only authorised service dealers should carry out maintenance, inspection and certied testing.
NOTE: These recommendations are in compliance with the requirements of 1998 No2307 Health
and Safety: The Lifting Operations and Lifting Equipment Regulations 1998. (LOLER) This is a UK
regulation. Outside the UK please check your local requirements.
Spreader Bar
1Check the spreader bar for freedom of rotation and swing.
2Check for wear on the spreader bar to boom fulcrum pin. Lubricate with a light mineral based grease.
3Check for wear on the central pivot. Lubricate as necessary with a light mineral based grease
or food grade spray lubricant.
4Check for secure attachment to the boom.
5 Examine sling strap retainers. Check for e󰀨ective function.
6Check the padded rubber moulding is not damaged (infection control).
7Inspect for excessive wear on the sling hooks and any side suspenders used in conjunction with the
spreader bar.
Boom
1Check for secure attachment of the boom to the mast/boom pivot and ensure the boom/mast pivot is
fully tightened.
2Make sure there is only minimal side movement of the mast/boom pivot and that it is free to rotate in
the mast. Lubricate with a light mineral based grease or food grade spray lubricant.
3Check the security and for wear on the actuator unit and mounting bracket on the boom. Any
excessive movement or play of the actuator must be investigated. Lubricate the fulcrum pin with a
light mineral based grease or food grade spray lubricant.
4Ensure the circlips are properly located in the groove and not deformed.
Mast
1Check the operation of the mast-locking device.
2Make sure the mast fully engages into the base socket.
3Check for wear on the bottom actuator unit and mounting bracket on the mast. Any excessive
movement or play of the actuator must be investigated. Lubricate the fulcrum pin with a light mineral
based grease or food grade spray lubricant.
4Ensure the circlips are properly located in the groove and not deformed.
5 Check for presence of the ‘fool proong’ pin in the mast socket.
Power Pack and Control Box
1Check for secure attachment of the power pack mounting plate to the mast.
2Check the function of the Emergency Stop button.
3Check the hand control for correct functioning in both directions.
4 Check the t of the hand control plug and socket.
5 Inspect the actuator plug for correct tting.
6Check the operation of the emergency raise and lowering function.
Inspection Criteria

4
Oxford®
Classic Mobile Lis
Leg Adjustment
1Operate the foot pedal and check the legs open and close correctly.
2Check the legs lock into place when in both the open and closed positions.
3 Check the legs are parallel to each other in the closed position.
4Check for wear and security of the linkages and lubricate as necessary with a light mineral based
grease or food grade spray lubricant.
5Check for wear/damage on the leg adjustment mechanism. Lubricate with a light mineral based grease
or food grade spray lubricant.
6Check the presence and condition of the acetyl wear washer between the foot pedal mechanism and the
boss on the cross-member. Lubricate with a light mineral based grease or food grade spray lubricant.
Leg Pivots
1 Ensure the leg pivots are retained securely and the legs pivot freely. Any sti󰀨ness must be investigated.
2Make sure there is no excessive play in the leg pivots. Any excessive play must be investigated.
3Lubricate as necessary with a light mineral based grease or food grade spray lubricant.
Castors
1 Check all castors for rm attachment to the legs.
2Check for free rotation of the castor wheels and that the castors swivel.
3 Where possible remove any build up of threads, hair or u󰀨.
4Lubricate the swivel and axle bearings if necessary with a light mineral based grease or food grade
spray lubricant.
5 Check all four castors are seated rmly on the ground.
6Check correct operation of the brakes.
Raise and Lower Actuator (Electric Variants Only)
1The actuator is a sealed unit and should require no maintenance.
2Check for correct operation when raising and lowering.
3 Check for correct operation of mechanical emergency lowering device (Midi, Major & Maxi models only).
4 Conrm anti-crush precautions are operational.
5 Conrm power cut-out at the ends of travel, both upper and lower.
6Listen for unusual noise which may indicate imminent breakdown.
7Check for wear on the mounting boss top and bottom. Any excessive movement or play of the
actuator mountings must be investigated.
NOTE: The actuator body lifts by 2mm on the lower central mounting pivot. This is a normal
characteristic and should not be interpreted as wear.
8Lubricate the upper and lower mounting fulcrum pins with a light mineral based grease or food grade
spray lubricant.
9Ensure the upper and lower actuator mounting fulcrum pin retaining devices are in position and secure.
Leg Opening Actuator (Electric Leg Variants Only)
1 The actuator is a sealed unit and should require no maintenance.
2 Check for correct operation when opening and closing the legs.
3 Conrm power cut-out at the ends of travel, both open and closed.
4 Listen for unusual noise which may indicate imminent breakdown.

Oxford®
Classic Mobile Lis
5
5 Check for wear on the upper and lower mounting bosses. Any excessive movement or play in the
actuator mounting must be investigated.
6 Lubricate the upper mounting fulcrum pin and the lower clevis pin with a light mineral based grease or
food grade spray lubricant.
7 Ensure the upper mounting fulcrum pin is secure. Conrm the set-pin is tightened to 20Nm.
8 Conrm the lower clevis pin is securely retained by the ‘R’ clip.
Batteries
1The batteries are housed in the power pack and should not require maintenance other than regular
charging as detailed in the charging instructions.
2 Conrm the lift is not sounding low battery during operation.
Charging Unit
1 Conrm the charger unit is charging the battery pack.
2 Check mains plug is tted with the correct rated fuse (5 Amp).
3 Check the safety of the input and output lead wiring.
Hydraulic Pump Unit (Hydraulic Variants Only)
1 Check the hydraulic unit for uid leakage.
2 Conrm that the unit operates correctly in both directions.
3Check the ram for trapped air (sponginess).
4 Check for rm tting of the valve release knob.
5Check for damage to the pump handle.
6Check that the unit can rotate correctly on the trunnion and that it can be operated from both the left
and right hand sides of the lift.
7Check for wear on the upper and lower mounting bosses.
8 Check for wear on the upper and lower mounting fulcrum pins and lubricate as necessary with a light
mineral based grease or food grade spray lubricant.
9Ensure the upper and lower hydraulic unit mounting fulcrum pin retaining devices are in position and
secure.
Cleaning
1Clean with ordinary soap and water and/or any hard surface disinfectant. Harsh chemical cleaners or
abrasives should be avoided as these may damage the surface nish of the lift. Ensure the lift is
thoroughly dried after cleaning.
2Avoid wetting any of the electrical parts.

6
Oxford®
Classic Mobile Lis
Load Testing (Electrical Variants Only)
The load test should be carried out in accordance with the manufacturers test procedures and the
directive detailed in EN ISO 10535:2006 - Annex B - Periodic Inspection B1 - see excerpt below. It is
strongly recommended that an authorised service dealer carry out the test.
EN ISO 10535:2006
Annex B
(Informative)
Periodic Inspection
B. 1 Periodic inspection of the hoist should be undertaken at the time intervals stated by the manufacturer,
but at least once a year. By periodic inspection is meant a visual examination (particularly of the hoist’s
load bearing structure and lifting mechanism with attachments, brakes, controls, safety devices and
person-support devices) and whatever function tests and maintenance measures may be required, e.g.
adjustment of brakes, tightening of fasteners.
Every inspection should include a working load test of one (1) lifting cycle with the maximum load.
Oxford electric lifts have been designed to the requirements of:
1 BS EN ISO 10535 2006 Hoists for the transfer of disabled persons
The hoists are designed to lift the Safe Working Load only. The load lifting capability is set
electronically and must not be increased as this causes excessive loading when the actuator reaches
the limits of travel. This will a󰀨ect the actuator’s useful life.
2 BS EN ISO 10535 Load Raising Test
This test is a straight forward lift of a load equivalent to the Safe Working Load, from the lowest
position to highest position of the hoist. Check that the hoist is not capable of lifting much more than
the safe working load. (A small additional lifting capability is allowable but should be no more than
15% of the SWL).
3 BS EN ISO 10535 Operator E󰀨ort Test
This test is conducted with the Safe Working Load only.
Using a force gauge (0-500N is a suitable range) push the foot pedals down and note the amount of
force necessary to open or close the legs. Maximum permissible force is 300N (30kgf / 67lbf).
Checking Welds For Fractures
NOTE: During the load testing procedure, while the lift is loaded with the safe working load, check ALL
welded joints on the lift for signs of fracture. If fractures are evident, the lift should be taken out of service
and not used until damaged components of the frame are replaced.
Oxford Classic Mobile Lis Test and Calibration Loads
Test Loads
MINI 140: 140 kgs / 308 lbs
MIDI 180: 180 kgs / 396 lbs
MAJOR 200: 200 kgs / 440 lbs
MAXI 180: 180 kgs / 396 lbs
Testing
Calibration Loads
MINI 140: 125 kgs / 275 lbs
MIDI 180: 165 kgs / 364 lbs
MAJOR 200: 185 kgs / 407 lbs
MAXI 180: 165 kgs / 364 lbs

Oxford®
Classic Mobile Lis
7
CONTINUED >
Certification
An authorised service dealer will issue an examination certicate after satisfactory completion of the
thorough examination.
This certicate will be valid for six months.
Thorough Examination Report
Lifting Operations and Lifting Equipment Regulations 1998 (LOLER UK ONLY)
LOLER requires certain information to be included on the report given to a customer after a thorough
examination. The information can be found in Schedule 1 (page 59) in the LOLER L113 publication.
Joerns Healthcare Ltd has prepared a Thorough Examination Report that includes all the required
information and a copy can be found later in this manual.
Please feel free to use this as the basis of your own report.

8
Oxford®
Classic Mobile Lis
Load Testing (Hydraulic Variants Only)
The load test should be carried out in accordance with the manufacturers test procedures and the
directive detailed in EN ISO 10535:2006 - Annex B - Periodic Inspection B1 - see excerpt below. It is
strongly recommended that an authorised service dealer carry out the test.
EN ISO 10535:2006
Annex B
(Informative)
Periodic Inspection
B. 1 Periodic inspection of the hoist should be undertaken at the time intervals stated by the manufacturer,
but at least once a year. By periodic inspection is meant a visual examination (particularly of the hoist’s
load bearing structure and lifting mechanism with attachments, brakes, controls, safety devices and
person-support devices) and whatever function tests and maintenance measures may be required, e.g.
adjustment of brakes, tightening of fasteners.
Every inspection should include a working load test of one (1) lifting cycle with the maximum load.
Oxford hydraulic lifts have been designed to the requirements of:
1 BS EN ISO 10535 2006 Hoists for the transfer of disabled persons
The hoists are designed to lift the Safe Working Load only.
2 Load Raising Test
This test is a straight forward lift of a load the equivalent to 125% of the Safe Working Load from the
lowest position to highest position of the hoist.
3 BS EN ISO 10535 Leak Test
This test is conducted with a load the equivalent to 125% of the Safe Working Load. With the hoist
in the highest working position, the hoist must maintain the lift for 15 mins. The maximum downward
movement of the hydraulic pump ram must not exceed 3mm over the 15 mins.
4 BS EN ISO 10535 Operator E󰀨ort
This test is conducted with the SWL only. Attach a spring balance (0-20 kg is a suitable range) to
the end of the crank handle and note the amount of pull necessary to operate the handle stroke.
Maximum permissible force is 120N (12.25 kg / 27 lbs).
5 BS EN ISO 10535 Descent Test
This test is conducted with the SWL only. Take the test load to the highest operating position and
measure the height of the weight from the oor. Open the release valve 1/8th of a turn. With a
stopwatch, time the descent until the weight is just clear of the oor. Stop the watch and close the
valve at the same time. Measure the distance travelled by the weight. The rate of fall must not exceed
108mm/second. Return the weight to the highest position and check that the speed of descent
increases as the valve is progressively opened.
6 BS EN ISO 10535 Operator E󰀨ort Test
This test is conducted with the SWL only. Using a force gauge (0 - 500N is a suitable range), push
the foot pedals down and note the amount of force necessary to open or close the legs. Maximum
permissible force is 300N (30 kg / 67 lbs).
7 Horizontal Boom Test
This is not a requirement of BS EN ISO 10535 but is required by users and specied by Joerns Healthcare.
With the release valve closed, pump up the unit until the boom is horizontal. Fully open the release valve.
Check: The boom must remain in the horizontal position and not descend under its own weight. Conrm the
boom will descend when additional pressure is applied by hand to the end of the boom.

Oxford®
Classic Mobile Lis
9
Checking Welds For Fractures
NOTE: During the load testing procedure, while the lift is loaded with the safe working load, check ALL
welded joints on the lift for signs of fracture. If fractures are evident, the lift should be taken out of service
and not used until damaged components of the frame are replaced.
Test Loads - Oxford Classic Mobile Lis
MINI 140: 140 kgs / 308 lbs
MIDI 180: 180 kgs / 396 lbs
MAJOR 200: 200 kgs / 440 lbs
MAXI 180: 180 kgs / 396 lbs
Certification
An authorised service dealer will issue an examination certicate after satisfactory completion of the
thorough examination.
This certicate will be valid for six months.
Thorough Examination Report
Lifting Operations and Lifting Equipment Regulations 1998 (LOLER UK ONLY)
LOLER requires certain information to be included on the report given to a customer after a thorough
examination. The information can be found in Schedule 1 (page 59) in the LOLER L113 publication.
Joerns Healthcare Ltd has prepared a Thorough Examination Report that includes all the required
information and a copy can be found later in this manual.
Please feel free to use this as the basis of your own report.

10
Oxford®
Classic Mobile Lis
Tools Required
• Calibration Handset
• Circlip pliers
• No. 2 pozi drive screwdriver (for the battery mounting bracket securing screws)
• 3mm hex key (for the control box securing screw)
• 4mm hex key (for the foot pedal mechanism)
• 5mm hex key (for the boom to mast pivot, front castors and for leg actuator retainer bolt Electric leg
variant only)
• 6mm hex key (for the leg linkage tie rods and rear castors)
• 8mm hex key (for the leg to cross member xing bolt)
• Socket wrench
• 13mm socket (for the front castors)
• 17mm socket (for the rear castors)
• 24mm A/F spanner or 24mm socket (for the M16 binx nut on the leg operating mechanism)
• Small at blade screwdriver (to aid removal of the spreader bar fulcrum pin protective plastic caps
• Medium strength threadlock (Blue)
• Calibrated torque wrench (0 - 25 Nm / 25 - 60 Nm)
Spreader Bar
CAUTION
It is not necessary to remove the spreader bar on every 6 monthly LOLER inspection.
The spreader bar should only be removed if wear is suspected on the spreader bar to boom fulcrum pin
or if wear is suspected on the main spreader bar central pivot and spreader bar central boss or if it is
necessary to replace the padded rubber moulding.
1Check the spreader bar for freedom of rotation and swing.
2Check for wear on the spreader bar to boom fulcrum pin. It is not necessary to dismantle the
spreader bar from the boom. To check for wear, whilst holding the upper portion of the central
pivot, move the pivot up and down and look for excessive movement between the spreader bar
central pivot and the fulcrum pin. If excessive wear is suspected, the spreader bar will need to be
removed for further detailed examination - see 'Spreader Bar Removal' later in this manual.
3Lubricate the joint between the spreader bar central pivot and the fulcrum pin with a light mineral
based grease or food grade spray lubricant.
4Check for excessive wear between the spreader bar and the spreader bar central pivot. To
achieve this, hold the upper portion of the central pivot steady and move the spreader bar up and
down and feel for excessive movement between the central pivot and the underside of the spreader
bar. If excessive wear is suspected, the spreader bar will need to be removed for further detailed
examination - see 'Spreader Bar Removal' later in this manual.
5Lubricate the joint between the spreader bar central pivot and the boss on the underside of the
spreader bar with a light mineral based grease or food grade spray lubricant. Take care not to
contaminate the padded rubber moulding with excessive lubricant.
6Check the spreader bar for secure attachment to the boom. Carefully examine the underside of the
boom/spreader bar assembly to conrm the spreader bar fulcrum pin has been correctly inserted
through the holes in the boom, boom end cap and the spreader bar central pivot.
Service & Maintenance

Oxford®
Classic Mobile Lis
11
7 Examine the sling strap retainers. Check the plastic discs are tted and move smoothly on the central
shafts. Check the plastic discs for damage. Check the screw through the central shafts for tightness.
If any discrepancies are identied, the hoist must be taken out of service until remedial action is
performed.
8Examine the padded rubber moulding for damage/cuts. If damage is evident, the moulding must be
replaced (infection control). See 'Spreader Bar Removal' later in this manual.
9Inspect for damage/excessive wear on the sling hooks, particularly if used in conjunction with
side suspenders. The sling hooks are manufactured from 9.5mm diameter material. Reduction in
diameter due to wear should not exceed 1mm. If damage/wear is evident the hoist must be
taken out of service until the spreader bar is replaced.
10 Examine all welded joints on the spreader bar for fractures/hairline cracks. If fractures/hairline
cracks are evident the hoist must be taken out of service until the spreader bar is replaced.
11 IMPORTANT: Side suspenders are often used in conjunction with the lift spreader bar. These may
be stored away from the lift. It is important that the side suspenders are checked for wear. Side
suspenders are made from 9.5mm material. Reduction in diameter by wear at the suspension
point or the hooks should not exceed 1mm before replacement.
Spreader Bar - Removal
1 Remove the white plastic protective covers from the spreader bar fulcrum pin. A small at blade
screwdriver will aid removal.
2Using circlip pliers, remove one of the circlips from the spreader bar fulcrum pin.
WARNING: The removed circlip must not be re-used. A new circlip must be tted each time it is
removed.
3Remove the white plastic retaining washer and retain for re-assembly.
4Whilst supporting the spreader bar, withdraw the fulcrum pin.
5Examine the fulcrum pin for signs of wear. The diameter of the fulcrum pin is 10mm. Reduction in
diameter due to wear must not exceed 1mm before replacement.
6Remove the padded rubber moulding from the spreader bar. The moulding is split along the bottom
edge and will pull o󰀨 the spreader bar quite easily.
7Examine the padded rubber moulding for damage. If damage is evident, the padded moulding must be
renewed (infection control).
8Examine all welded joints on the spreader bar for hairline cracks. If any welds are suspect replace the
spreader bar.
9 Take o󰀨 and retain the “O” ring that holds the main spreader bar central pivot in the spreader bar
central boss.
10 Examine the main pivot and the central boss for wear. If any of the components show signs of wear or
damage they must be renewed.
11 Check the presence and condition of the acetyl wear washer that sits on the central pivot shoulder.
The wear washer is there to stop metal to metal contact between the pivot shoulder and the central
boss on the spreader bar assembly. If the washer shows any signs of deformation or wear it must
be replaced.
12 Main pivot: Check for wear on the cross-hole for the fulcrum pin. The hole is 10mm in diameter;
wear should not exceed 1mm on diameter or 2mm elongation before replacement.
13 Check for wear on the cross hole in the end of the boom. The hole is 10mm in diameter; wear
should not exceed 1mm on diameter or 2mm elongation. If wear exceeds this, the boom must
be replaced.
14 Spreader bar sling hooks: Check for wear, particularly if used in conjunction with side suspenders. The
sling hooks are made from 9.5mm diameter material. Reduction in diameter by wear should not
exceed 1mm before replacement.

12
Oxford®
Classic Mobile Lis
15 IMPORTANT: Side suspenders are often used in conjunction with the lift spreader bar. These may be
stored away from the lift. It is important that side suspenders are checked for wear. Side suspenders
are made from 9.5mm material. Reduction in diameter by wear at the suspension point or the
hooks should not exceed 1mm before replacement.
16 Examine the sling strap retainers. Check that the plastic discs are tted and move smoothly on the
central shafts. Check the plastic discs for damage. Check the screw through the central shafts for
tightness.
WARNING: If the retainers are missing they must be replaced.
Re-Assembly of the Spreader Bar
After performing the actions and checks in 'Spreader Bar - Removal', re-assemble the spreader bar as
follows:
1Lubricate the main central pivot and fulcrum pin with any light mineral based grease or food grade
spray lubricant, paying particular attention to the pivot shoulder, wear washer and the fulcrum pin
cross-hole.
2Fit the main central pivot to the spreader bar central boss. Ensure the wear washer is present prior to
assembly. Ret the retaining “O” ring. Check rotation of the pivot in the boss.
3Replace the padded rubber moulding.
4Position the boom end cap over the spreader bar central pivot ensuring the holes align with the holes
in the central pivot.
5Insert the boom end cap/spreader bar assembly into the boom end ensuring the holes in the boom,
boom end cap and spreader bar central pivot point are aligned. NOTE: It is suggested a drift or 6mm
hex key are inserted through the holes in the boom, boom end cap and spreader bar central pivot to
ensure all holes are aligned.
6 Ensure the one circlip and plastic retaining washer are tted to the one end of the fulcrum pin.
7Insert the spreader bar fulcrum pin through the holes in the boom, boom end cap and spreader bar
central pivot, pushing the drift out in the process.
8 Re-t the plastic retaining washer to the fulcrum pin.
9 Fit a new retaining circlip to the fulcrum pin and ret the plastic protective cap. WARNING: Once the
circlip is tted in position, ensure it has not become deformed or over-expanded during the
tting process. If it has, it must be replaced.
WARNING: Following re-assembly of the spreader bar to the boom, it is critical that the underside
of the boom/spreader bar is carefully examined to conrm the spreader bar fulcrum pin has been
correctly inserted through the holes in the boom, boom end cap and spreader bar central pivot.
Failure to do so could result in serious injury or death.
ûü

Oxford®
Classic Mobile Lis
13
Boom
1 Ensure there is no excessive side movement of the boom and that it is centred and free to rotate.
NOTE: Due to the characteristics of the mast/boom pivot joint, up to 25mm total side movement
measured at the spreader bar end of the boom can be expected (under light sideways pressure).
Movement exceeding this gure should be investigated.
2 Check for wear and security of the actuator mounting.
3Lubricate the mast/boom pivot and actuator fulcrum pin with a light mineral based grease or food
grade spray lubricant.
4Check the mast/boom pivot is fully tightened using a 5mm hex key.
5If the mast/boom pivot is not fully tightened, remove the grey decorative inserts and dismantle the
mast to boom fulcrum pin using a 5mm hex key. Examine the fulcrum pin for signs of wear. The
fulcrum pin in 12mm in diameter. Reduction in diameter due to wear should not exceed 1mm
before replacement.
6 If the mast/boom pivot does not display signs of wear, apply medium strength thread lock (blue) to the
fulcrum pin securing screws prior to assembly. Re-assemble and tighten to 25Nm.
7Examine the actuator mounting point. Without taking the mounting apart check for signs of wear on
the fulcrum pin. Check for excessive vertical and horizontal movement in the mounting. This will give a
good indication of wear but if there is any doubt the assembly should be stripped down as follows:
8Remove one of the circlips that secures the actuator fulcrum pin to the bracket and extract the fulcrum pin.
9 Examine the fulcrum pin for signs of wear and for rm attachment of the remaining circlip. The
diameter of the fulcrum pin is 10mm. Reduction in diameter due to wear must not exceed 1mm
before replacement.
10 Examine the actuator mounting on the boom for wear on the bore of the bracket. Wear should not
exceed 2mm.
11 Examine the actuator top mounting boss for wear/security. Wear should not exceed 1mm.
12 Lubricate the fulcrum pin using a light mineral based grease or food grade spray lubricant.
13 Replace the fulcrum pin through the actuator and boom bracket.
14 Fit a new circlip to the fulcrum pin.
NOTE: Joerns Healthcare recommends the following:
• NEVER reuse circlips.
• ALWAYS use circlip pliers for tting.
• ENSURE the circlip is properly located in the groove and not deformed.
Mast/Boom Pivot
1Check the pivot for lateral, vertical and horizontal play that would indicate excessive wear. Signs of
excessive wear must be investigated and the pivot stripped down. Lateral play at the pivot point
must not exceed 1mm before replacement.
2 Construction of the mast/boom pivot comprises of 11 components: 2 o󰀨 self adhesive screw covers,
2 o󰀨 M8 x 20mm counter sunk head screws, 2 o󰀨 25mm counter sunk steel caps, 1 o󰀨 12mm inner
fulcrum pin and 1 o󰀨 19mm outer sleeve, 2 o󰀨 plastic pivot bearing washers and 1 o󰀨 pivot casting.

14
Oxford®
Classic Mobile Lis
Removal of the Mast/Boom Pivot
1 Remove the 2 o󰀨 self-adhesive screw covers.
2The mast/boom pivot fulcrum pin is held in place with two M8 x 20mm counter sunk head screws.
Remove one of the screws from the fulcrum pin and leaving the other in place, withdraw the fulcrum pin.
3 Examine the fulcrum pin for signs of wear and for rm attachment of the remaining screw. The
diameter of the fulcrum pin is 12mm. Reduction in diameter due to wear must not exceed 1mm
before replacement.
4Withdraw the outer sleeve bush from the boom end (hold the boom while doing this as it may fall
forwards). Inspect the sleeve for wear as per the fulcrum pin.
5 Remove the plastic bearing washers (2 o󰀨) from the pivot and examine for any wear or damage.
Lateral movement at the pivot is most likely to be caused by wear on these washers.
6Examine the through holes in the mast and the boom end for wear or damage. The bore and holes
are 19mm in diameter. Wear should not exceed 1mm on diameter or 2mm elongation before
replacement.
Re-Assembling the Mast/Boom Pivot
After performing all the actions and checks in the previous section, reassemble the Mast/Boom pivot as
follows:
1Lubricate the fulcrum pin and sleeve with any light mineral based grease or food grade spray lubricant,
paying particular attention to the bearing washers and the mast/boom pivot internal bore.
2Insert the 19mm outer sleeve into the through hole in the boom end.
3Position the boom between the mast pivot brackets.
4Position one of the plastic pivot bearing washers between the boom and the mast pivot bracket,
ensuring the holes in the mast pivot bracket, the plastic bearing washer and the boom outer sleeve
are aligned.
5 Insert the fulcrum pin with the 1 o󰀨 counter sunk steel cap and the 1 o󰀨 M8 x 20mm counter sunk
head screw still assembled, through the mast pivot bracket, a plastic bearing washer and boom outer
sleeve until it is inside the boom outer sleeve but does not protrude.
6Whilst supporting the boom in the mast pivot bracket, position the second plastic bearing washer
between the boom and the mast pivot bracket, ensuring the hole in the washer aligns with the holes in
the boom outer sleeve and mast pivot bracket.
7Further insert the fulcrum pin so that it passes through the plastic bearing washer and the mast pivot
bracket.
8Assemble the remaining 25mm diameter counter sunk steel cap to the remaining M8 x 20mm counter
sunk screw.
9Apply medium strength thread lock (blue) to the thread of the M8 x 20mm counter sunk screw.
10 Assemble the M8 x 20mm counter sunk screw to the fulcrum pin and tighten using a 5mm hex key to 25Nm.
11 Fit replacement self adhesive screw cover to the heads of the M8 x 20mm counter sunk screws.
NOTE 1: Joerns Healthcare recommends the following:
• NEVER t a new fulcrum pin or sleeve to a worn or damaged boom.
• ALWAYS tighten the fulcrum pin to the correct torque setting.
• ALWAYS assemble the M8 screws with thread lock.
• CHECK the assembled Mast/Boom pivot for unacceptable movement.
NOTE 2: Before applying thread lock to any screw or bolt, check it can be screwed into the
component without hindrance from old remaining thread lock as this could a󰀨ect the proper
torque setting.

Oxford®
Classic Mobile Lis
15
Mast
1 Make sure the mast is fully engaged into the mast socket.
2 Check for presence of the mast ‘fool proong’ pin.
3Check the operation of the mast locking device.
4Check the security of the actuator unit mounting and lubricate with a light mineral based grease or
food grade spray lubricant.
5 Examine all the welded joints on the mast fabrication for hair-line cracks, paying particular attention to
the joints between the positioning handles and the mast and the mast pivot brackets to the mast.
6Examine the actuator mounting point for damage or wear. Without taking the mounting apart check
for signs of wear on the fulcrum pin. Check for excessive vertical and horizontal movement in the
mounting. This will give a good indication of wear but if there is any doubt the assembly should be
stripped down as follows:
7Remove one of the circlips that secures the actuator fulcrum pin to the bracket and whilst supporting
the boom/actuator, extract the fulcrum pin.
8 Examine the fulcrum pin for signs of wear and for rm attachment of the remaining circlip. The
diameter of the fulcrum pin is 8mm. Reduction in diameter due to wear must not exceed 1mm
before replacement.
9Examine the actuator mounting bracket on the mast for wear on the bore of the bracket. Wear should
not exceed 2mm.
10 Examine the actuator bottom mounting boss for wear. This should not exceed 1mm.
11 Lubricate the fulcrum pin using a light mineral based grease or food grade spray lubricant.
12 Replace the fulcrum pin through the mast bracket and actuator.
13 Fit a new circlip to the fulcrum pin.
NOTE 1: It is most important that fulcrum pins are re-assembled carefully. Check to ensure
complete security.
NOTE 2: Joerns Healthcare recommends:
• NEVER reuse circlips.
• ALWAYS use circlip pliers for tting.
• ENSURE the circlip is properly located in the groove and not deformed.
14 Conrm the presence and proper location of the mast engagement label.
15 Check the correct operation of the mast-locking knob. Conrm the mast will lift from the mast socket
when the locking knob is unscrewed.
16 Check the presence and condition of the positioning handle end caps and replace if necessary.

16
Oxford®
Classic Mobile Lis
Battery Pack & Control Unit (Electric Variants)
1 Conrm the mounting bracket is rmly attached to the mast. Three no. 2 pozi drive head screws
secure the mounting bracket. Conrm the screws are fully tightened to 5Nm.
2Check the engagement of the battery pack with the mounting. The battery pack should snap into place
and be retained by a latch at the top of the pack. Make sure the latch is functioning correctly and holds
the battery pack rmly in place.
3Check that the actuator and hand control plugs are inserted fully into the appropriate socket on the
base of the control unit. The plugs, particularly the hand control plug, are a tight t in the sockets and
must be pushed fully home. The hand control plug is indexed and can only be tted in one position.
The ‘raise/lower’ actuator plug is not indexed and can be tted with a straight push. The ‘raise/lower’
actuator jack plug connects to the socket marked ‘1’ in the base of the control box.
4Inspect the hand control and coiled lead for any obvious signs of damage. Damage to the hand control
and particularly to the lead can cause intermittent faults. The hand control should be replaced if
damage is evident.
5 Check the operation of the hand control. Press the raise and lower buttons and conrm the boom
moves in the correct direction.
6Check the operation of the Emergency stop switch. Push in the red button; this will latch and remain
depressed and cut o󰀨 all power to the lift. Conrm by looking at the LED panel that should now be
blank. Conrm the boom does not operate when depressing the raise and lower buttons on the hand
control. Return power to the lift by twisting the red button clockwise and releasing. The LED panel
should no longer be blank and battery power should now be displayed instead.
7 Check the operation of the redundant control raise and lower buttons. These are two raised ‘soft push’
buttons on the front of the control unit under the Emergency stop switch identied by up and down
arrows.
Smart Monitor
Please refer to the following document for service and maintenance guidance:
Oxford Smart Monitor
Engineer’s Service & Installation Manual
(Document no.294000.10380)
Contact Joerns Healthcare on [phone] should you require a copy.

Oxford®
Classic Mobile Lis
17
Cross-Member
To perform a service inspection of the cross-member, it is recommended the mast and boom assembly
is rst removed. Unscrew the mast locking knob completely from the cross-member. The mast and boom
assembly can then be lifted out of the mast socket on the cross-member.
1Inspect the mast locking knob for damage and/or wear, paying particular attention to the threads which
engage with the mast. If wear or damage are evident, the mast locking knob should be replaced.
2 Inspect the mast fool proong post, positioned inside the mast socket for presence and for wear and/
or damage. If wear or damage are evident, the mast fool proong post should be replaced. If the mast
fool proong post is not present, the lift should be taken out of service and not returned to service until
it has been replaced.
3Inspect the mast socket on the cross-member for damage, wear or splits/cracks in the metal, paying
particular attention to the front corners. If damage, wear or splits are evident the lift should be taken
out of service and not used until the cross-member has been replaced.
4 Maintenance: Lubricate the ‘W’ prole and the corresponding pin with a light mineral based grease or
food grade spray lubricant.
5 Conrm presence and condition of the acetyl wear washer between the foot pedal mechanism and the
boss on the cross-member.
Foot Pedal (Non-Electric Leg Variants)
1Inspect the foot pedal rubber grip pads for presence, wear and/or damage. If wear or damage are
evident or either pad is missing, the pads should be renewed.
2Check the leg adjustment mechanism locates/locks correctly in the open and closed positions.
3Examine the foot pedal mechanism for excessive play, wear or damage. If excessive play, wear
or damage is evident, the foot pedal mechanism should be replaced. To replace the foot pedal
mechanism, follow the procedure outlined below:
4Dismantle the leg ends of the tie rods from the legs using a 6mm hex key. Take care not to lose the
2 o󰀨 white acetyl washers on each leg.
5Examine the white acetyl washers for damage or wear. If damage or wear is evident, the washers
should be replaced.
6 Unscrew and completely remove the mast locking knob.
7Remove the plastic moulding which shrouds the foot pedal/leg opening mechanism. The moulding
is a push t, however, to aid removal, position a wide at blade screw driver or similar between the
moulding and one of the foot pedal levers and gently prise o󰀨 the moulding.
8 Unscrew the M16 binx nut using a 24mm A/F ring spanner or socket.
NOTE: If the foot pedal leg opening mechanism is being renewed, the binx nut can be discarded
as a replacement is included with the foot pedal mechanism kit.
9Withdraw the complete foot pedal leg opening mechanism from the mounting spigot and examine for
damage and/or wear. If damage or wear is evident the mechanism should be replaced.
10 Remove the acetyl wear washer which sits between the foot pedal mechanism and the boss on the
cross-member.
11 Examine the washer for wear and/or damage. If wear and/or damage are evident, the washer
should be replaced.
12 Dismantle the left and right hand tie rods from the foot pedal mechanism using a 6mm hex key, taking
care not to lose the white acetyl washers - 2 o󰀨 on each tie rod.
13 Examine the washers for wear and/or damage. If wear and/or damage are evident, the washers
should be replaced.
NOTE: If the cross-member is damaged and/or worn and requires replacement, the legs should
be dismantled from the cross-member as detailed in the leg/leg pivot section of this manual.

18
Oxford®
Classic Mobile Lis
Re-Assembly of the Leg Opening Mechanism to the Cross-Member
(Non-Electric Leg Variants)
1Lubricate all acetyl wear washers, the leg opening mechanism and both ends of the left and right tie
rods with a light mineral based grease or food grade spray lubricant.
2 Position the acetyl wear washer on the cross-member mounting spigot.
3 Assemble the left and right hand tie rods to the leg opening mechanism, ensuring the 2 o󰀨 white acetyl
wear washers are tted at the ends of each tie rod. Use a 6mm hex key to tighten the xing bolts to
30Nm.
NOTE: The tie rods are identied on the leg end with the following markings:
Mini & Midi:
Right hand = 1 / Left hand = 2
Major & Maxi:
Right hand = 3 / Left hand = 4
4Fit the leg opening mechanism to the cross-member mounting spigot, ensuring it is assembled in the
correct orientation.
5Assemble the M16 binx nut to the cross-member mounting spigot using a 24mm A/F ring spanner or
socket and tighten to 55 - 60Nm.
6 Re-t the leg opening mechanism plastic shroud, ensuring it snaps securely onto the leg opening
mechanism.
7 Re-assemble the leg ends of the left and right tie rods to the legs, ensuring the 2 o󰀨 white acetyl
washers are tted at the ends of each tie rod. Use a 6mm hex key to tighten the xing bolts to 35Nm.
8 Re-t the boom and mast assembly into the mast socket on the cross-member, ensuring the mast is
fully inserted into the socket. This is conrmed by the datum line sitting immediately above the mast
socket.
9Re-assemble the mast locking knob to the thread in the cross-member and tighten securely by hand.

Oxford®
Classic Mobile Lis
19
Leg Opening (Electric Leg Variants)
1 Operate the leg opening and closing from the handset and conrm the legs operate correctly in both directions.
2 Conrm the legs lock correctly when the open/close button is released.
3 Conrm the leg actuator mounting bracket is rmly attached to the mast (2 o󰀨 4mm Hex drive screws).
Conrm the screws are tightened to 10Nm.
4 Conrm the leg actuator is rmly attached to the mounting bracket. (1 o󰀨 5mm Hex drive set-pin).
Conrm the set pin is tightened to 20Nm.
5 Conrm the leg actuator and hand control plugs are inserted fully into the appropriate sockets on
the base of the control unit. The plugs, particularly the hand control plug, are a tight t and must be
pushed fully home.
6 The hand control plug is indexed and can only be tted in one position. The leg actuator jack plug is
not indexed and can be tted with a straight push. The leg actuator jack plug connects to the socket
marked ‘2‘ in the base of the control box.
7Inspect the hand control and coiled lead for any obvious signs of damage. Damage to the hand control
and particularly to the lead can cause intermittent faults. The hand control should be replaced if
damage is evident.
8Check the operation of the emergency stop switch. Push in the red button; this will latch and remain
depressed and cut o󰀨 all power to the lift. Conrm by looking at the LED panel, this should now be
blank. Conrm the legs do not operate when depressing the open and close buttons on the hand
control. Return power to the lift by twisting the red button clockwise and releasing. The LED panel
should no longer be blank and battery power should now be displayed instead.
9 Check the operation of the redundant control open and close buttons. These are two raised ‘soft push’
buttons on the front of the control unit under the emergency stop switch identied by open and closed
leg symbols.
10 Examine the leg opening mechanism for excessive play, wear or damage. If excessive play, wear or
damage is evident, the leg opening mechanism should be replaced.
To replace the leg opening mechanism follow the procedure outlined below:
11 Remove the leg actuator clevis pin retaining ‘R’ clip and withdraw the clevis pin.
12 Lightly tap the bottom of the leg actuator towards the left hand rear castor to release it from the leg
mechanism.
13 Dismantle the leg ends of the tie rods from the legs using a 6mm Hex key. Take care not to lose the
2 o󰀨 white acetyl washers on each leg.
14 Examine the white acetyl washers for damage or wear. If damage or wear is evident, the washers
should be replaced.
15 Unscrew and completely remove the mast locking knob.
16 Remove the plastic moulding which shrouds the leg opening mechanism. The moulding is a ‘push t’
however, to aid removal, position a wide at blade screwdriver or similar between the moulding and
the rear leg opening mechanism plate and gently prise o󰀨 the moulding.
17 Unscrew the M16 Binx nut using a 24mm A/F ring spanner or socket.
NOTE: If the leg opening mechanism is being renewed, the Binx nut can be discarded as a
replacement is included with the replacement leg mechanism kit.
18 Withdraw the complete leg opening mechanism from the mounting spigot and examine for damage/
wear. If damage or wear is evident the mechanism should be replaced.
19 Remove the acetyl wear washer which sits between the leg opening mechanism and the boss on the
cross-member.
20 Examine the washer for wear and/or damage. If wear and/or damage are evident, the washer
should be replaced.

20
Oxford®
Classic Mobile Lis
21 Dismantle the left and right hand tie rods from the leg opening mechanism using a 6mm Hex key,
taking care not to lose the white Acetyl washers (2 o󰀨 on each tie rod end).
22 Examine the washers for wear and/or damage. If wear and/or damage are evident the washers
should be replaced.
NOTE: If the cross-member is damaged and/or worn and requires replacement, the legs should be
dismantled from the cross-member as detailed in the leg/leg pivot section of this manual.
Re-Assembly of the Leg Opening Mechanism to the Cross-Member
(Electric Leg Variants)
1Lubricate all acetyl wear washers, the leg opening mechanism and both ends of the left and right tie
rods with a light mineral based grease or food grade spray lubricant.
2Position the acetyl wear washer on the cross-member mounting spigot.
3 Assemble the left and right hand tie rods to the leg opening mechanism ensuring the 2 o󰀨 white acetyl
wear washers are tted at the ends of each tie rod. Use a 6mm Hex key to tighten the xing bolts to
30Nm.
NOTE: The tie rods are identied on the leg end with the following markings:
Mini & Midi:
Right hand = 1 / Left hand = 2
Major & Maxi:
Right hand = 3 / Left hand = 4
4Fit the leg opening mechanism to the cross-member mounting spigot, ensuring it is assembled in the
correct orientation.
5Assemble the M16 binx nut to the cross-member mounting spigot using a 24mm A/F ring spanner or
socket and tighten to 55 - 60Nm.
6 Re-t the leg opening mechanism plastic shroud, ensuring it snaps securely onto the leg opening
mechanism.
7 Re-assemble the leg ends of the left and right tie rods to the legs, ensuring the 2 o󰀨 white acetyl
washers are tted at the ends of each tie rod. Use a 6mm hex key to tighten the xing bolts to 35Nm.
8 Re-t the boom and mast assembly into the mast socket on the cross-member, ensuring the mast is
fully inserted into the socket. This is conrmed by the datum line sitting immediately above the mast
socket.
9Re-assemble the mast locking knob to the thread in the cross-member and tighten securely by hand.
10 Re-locate the lower end of the leg opening actuator over the leg opening mechanism lever, ensuring
the holes in both components align.
NOTE: Manoeuvring the left leg of the hoist may aid alignment.
11 Lubricate the clevis pin with a light mineral based grease or food grade spray lubricant.
12 Insert the clevis pin through holes in the leg opening actuator and leg opening mechanism lever.
13 Insert the clevis pin securing ‘R’ clip through the hole in the clevis pin.
14 Operate the legs by depressing the open and close buttons on the handset and ensure the legs open
and close satisfactorily.
