Jofran 1511-392KD User manual

MADE IN VIET NAM
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL #1511-392KD
CANNON VALLEY SLATBACK
UPHOLSTERED DINING CHAIR
jOFRAN INC.
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
Code Qty Description
Parts key Hardware kit (#1511-392KDP46)
Description
A
B
C
D
E
F
G
No Qty
Chair Back
Complete Seat
Front Leg
Floor Glide
Hex nut M8
Lock washer Ø8 x13mm
Flat washer Ø8 x18mm
Long bolt Ø6 x 80mm
Short bolt Ø6 x 40mm
Allen key
Key wrench
4 pcs
11 pcs
11 pcs
4 pcs
3 pcs
1 pc
1 pc
- Carefully lay Chair Back flat on a smooth flat surface to prevent scratches.
- Attach Complete Seat to Chair Back by inserting a Flat Washer, Lock
Washer and Short bolt into each of the hole on the back of the seat.
Tighten screws with provided Allen Key by turning clockwise until secure.
(See Detail A).
- Insert a Flat Washer, Lock Washer an Long screw into each of 2 holes in
the Complete Seat corners. Tighten screws with provided Key Wrench.
(See Detail B).
STEP 1
DETAIL A DETAIL B
- Carefully turn chair upside down and attach each Leg to the front
corners of the Complete Seat. Place Flat Washer, Lock Washer
and Nut on each leg bolt, tightening the Nut on each Leg using
provided Key Wrech. (See Detail C).
- Be sure to level the chair prior to tightening all the nuts/screws.
STEP 2
DETAIL C
1511-392KDP40
1511-392KDP41
1511-392KDP42
1511-392KDP01F
1 pc
1 pc
2 pcs
4 pcs
1
2
3
4
No
F
E
B
C
F
D B C
GABC
3
2
1
3
44
FABRIC CARE INSTRUCTIONS
REGULAR CARE
Blot gently using a clean soft damp cloth
and mild detergent DO NOT SATURATE
FABRIC CONTENT:
100% Polyester - Cleaning code W

MADE IN VIET NAM
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL # 1511-56KD
CANNON VALLEY 56"
UPHOLSTERED BENCH
WITH METAL STRETCHER
jOFRAN INC.
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
Code Qty Description
Parts key
Bench Seat
Leg Assembly
Stretcher
Floor Glide
Hardware kit (#1511-56KDP46)
Description
A
B
C
D
E
F
G
No Qty
8 pcs
8 pcs
8 pcs
1 pc
2 pcs
2 pcs
1 pc
Bolt M8 x 40
Lock washer M8
Flat washer M8 x 18
Allen Key K4
Big hex nut M18
Large flat washer Ø35
Key Wrench K27
1511-56KDP53
1511-56KDP11
1511-56KDP01F
1 pc
2 pcs
1 pc
4 pcs
1
2
3
4
No
G
F E
3
BA
D
C
1
4
3
2
2
FABRIC CARE INSTRUCTIONS
REGULAR CARE
Blot gently using a clean soft damp cloth
and mild detergent DO NOT SATURATE
FABRIC CONTENT:
100% Polyester - Cleaning code W

MADE IN VIET NAM
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL #1511-82
CANNON VALLEY 82"
DINING TABLE
jOFRAN INC.
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come
loose inside the carton during shipment.
Code Qty Description
Parts key
Description
Table Top
Leg Assembly
Stretcher
Drawer complete
Pull w/screws
Drawer stop w/screws
Drawer glide
Floor Glide
Hardware kit (1511-82P01)
Qty
Bolt - Long M8 x 35
Bolt - Short M8 x 30
Lock washer M8
Flat washer M8 x 18
Allen Key K4
Big hex nut M20
Large flat washer Ø45
Key Wrench K30
1511-82P24
1511-82P53
1511-82P11
1511-82P05
1511-82P04
1511-82P05A
1511-82P06
1511-82P01F
1 pc
2 pcs
1 pc
6 pcs
6 sets
6 pcs
6 sets
4 pcs
1
2
3
4
5
6
7
8
No
A
B
C
D
E
F
G
H
No
4 5 6
6
2
8
57 4 1 7
H
3
2
3
6
E
B
C
D
GF
E
A
DC
12 pcs
6 pcs
18 pcs
18 pcs
1 pc
2 pcs
2 pcs
1 pc
Long Bolt
Short Bolt
