Jofran 2125-370KD Instruction Manual

ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL # 2125-370KD
jOFRAN INC.
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may have come loose
inside the carton during shipment
No
1
2
3
4
2125-370KDP40 1 pc.
1 pc.
1 pc.
Chair Parts Key
Description
1 pc.
1 pc.
5
Q'ty
Code
2125-370KDP41
2125-370KDP42
2125-370KDP44
2125-370KDP45
4pcs.
2125-370P01F
6
1 pc.
2125-370KDP43
7
RUSTIC SHORES DESK CHAIR
GRAY WASH
MADE IN VIETNAM Page 1 of 1
Chair Back
Complete Seat
Right Facing Front Leg
Left Facing Stretcher
Right Facing Stretcher
Floor glide
Left Facing Front Leg
D
E
F
GKey Wrench
Long Bolt 1/4"x 3''.
No
B
C
Hardware kit 1615-370KDP46
Description
Lock Washer 5/16"
Short Bolt 1/4"x 1''1/2.
Allen Key
H
Flat Washer 5/16"
A
11 pcs.
11 pcs.
1 pc.
Q'ty
4 pcs.
1 pc.
4 pcs.
Wood Screw 1/6''x 38
3 pcs.
Hexa Nut 5/16" 4 pcs.
STEP 2
STEP 1
ABC
G
F
E
B
C
H
H
CBD
F
- Carefully turn Chair upside down.
Insert the right stretcher into the back
right leg,then position right front leg in
to the front corner block and connect
the stretcher to the front leg
- Place Flat Washer (C), Lock Washer
(B) and Nut (A) on each bolt, and
hand tighten at this point
- Fasten Stretchers with Wood Screws
(H) by hand using a Philips screwdriver
(not provider) ( See Detail C).
Fully tighten the nuts for the front leg.
-Check to be sure all screws and nuts
are tight prior to using Chair.
- Insert the left stretcher into the back
left leg, then position left front leg in to
the front corner block and connect the
stretcher to the front leg.(See Detail C)
- Carefully lay chair back flat on a smooth flat
surface to prevent scratches
- Attach Complete Seat to Chair back by inserting a
Flat Washer (C) Lock Washer (B) with Short Bolt
(E) into each of the hole on the back rail of the
seat, and Long Bolt (D) a Flat Washer (C) and Lock
Washer (B) into each of 2 holes in the Complete
Seat corners. (See Detail A & B)
- Tighten screws with provided Allen Key (F) by turning
clockwise until secure
Detail D Detail C
Detail C Detail A
Detail B
4
6
5
3
6
5
21
FABRIC CARE INTRUCTIONS: Blot gently using a clean
soft damp cloth an mild detergent DO NOT SATURATE
FABRIC CONTENT: 100% POLYESTER-CLEANING CODE W

MADE IN VIETNAM Page 1 of 1
jOFRAN INC.
No
1
2
3
4
Desk Parts Key
Description
Middle Drawer Complete
Drawer Stop
5
Q'ty
Code
2125-5620P04
6
Floor glide
2125-5620P01
7
Power outlet
2125-5620P01E
8
Lift top
2125-5620P22
9
Lift top Hinge
2125-5620P22H
10
Drawer glide
2125-5620P06
Knob w/ screw
11
4 pc.
1 pc.
2 pcs.
5 pc.
4pcs.
1pc.
1pc.
2pcs.
2 pcs.
5 pc.
10 pc.
D
No
B
C
Hardware kit (2125-5620P01)
Description
Lock Washer 1/4"
Bolt 1/4"x 2''
Allen Key
Flat Washer 1/4"
A
8 pcs.
8 pcs.
1 pc.
Q'ty
8 pcs.
2125-5620P02
2125-5620P05M
Legs
2125-5620P05TS Top Side Drawer Complete
2125-5620P05BS
2125-5620P05A
Bottom Side Drawer Complete
ASSEMBLY INSTRUCTIONS &
PARTS IDENTIFICATION
MODEL # 2125-5620
RUSTIC SHORES DESK - GREY WASH
AC
B
D
STEP 1
STEP 2
