Journey 08569 User manual

Deluxe Bedside Assist
Wave Handle with Legs
PRODUCT MANUAL

2
CAUTIONS & WARNINGS
Prior to use, please read all instructions and inspect all parts carefully
for damage prior to assembly.
1. Please read these instructions carefully before installing and using the
bedrail.
2. This bar is not designed to support the entire weight of a person and
has a weight capacity of 300 lbs.
3. Narrow beds may tilt if user puts full body weight on the handle.
4. The adjustable bed bar is not intended for those with reduced
mobility or people who are permanently bedridden.
Additional safety measures and precautions should be taken with high-
risk patients.
5. The bedrail must not be attached to a medical bed that can move or
be lifted.
6. The mattress must be tight against the grab bar, without leaving
any space, to prevent a person from getting trapped. This should be
checked frequently, if not daily.
7. For added safety, we recommend that you install two bedrails, one
on each side of the bed, to help hold the mattress in place, without
leaving any space.
Warning: If the box spring is wider than the mattress, two bedrails will
not work.
Deluxe Bedside Assist
Wave Handle with Legs

3
ASSEMBLY INSTRUCTIONS
1. Remove all parts from carton and safely dispose of plastic wrapping,
keeping it away from children and infants.
2. Insert part A into part B on each side.
3. Connect part C into part D on each side, using the provided Allen key.
Do not tighten.
4. Insert part E into part D, making sure that all spring buttons are in
place. Tighten all screws snugly.
5. Insert parts F into part D on each side, making sure spring buttons
are in place.
6. Once installed, the handle height adjusts by raising or lowering the
legs. Parts A and B will slide up and down part D.
*Tip: If connecting part D to part E is difcult, slightly loosen the screws
connecting part C.
Reinsert part E into part D, making sure the spring buttons are in place,
and then retighten screws.
Deluxe Bedside Assist
Wave Handle with Legs

4
INSTALLATION INSTRUCTIONS Deluxe Bedside Assist
Wave Handle with Legs
1. For easier installation, remove the mattress and place the assembled
rail on top of the box spring.
2. Run the long webbing (part H) around the bottom of the box spring
and back to the bottom of the handle.
3. Feed the webbing through the buckle (part G) and lock the buckle to
secure the strap at the desired length. Repeat on the other side.
4. Replace the mattress.
5. For positioning, lie on the bed and move the bedrail to the desired
position where it’s easy to use the rail.
6. To make sure the webbing straps are straight and parallel, tighten
them securely against the box spring. *
7. Loop and tuck the loose end of the webbing directly below the
buckle to prevent tripping hazards.
IMPORTANT: For your safety, the part H safety strap set provided
with this bedrail MUST be installed as shown above.

5
CARE AND MAINTENANCE
Persons with severe disabilities or persons who are unable to walk without
an aide should not attempt to use this product without assistance.
Deluxe Bedside Assist
Wave Handle with Legs
• Clean frame with soap and water and dry with towel.
• Check straps and handles periodically to make sure they are not torn,
worn or missing.
• Replace if necessary.

If you have any questions, call us at our toll free number:
1-877-421-3724
