Joy-it rb-camera-WW2 User manual

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
5 MP WIDEANGLE CAMERA FOR RASPBERRY PI
rb-camera-WW2
1. GENERAL INFORMATION
Dear customer,
thank you very much for choosing our product.
In following, we will introduce you to what to observe while starting up
and using this product.
Should you encounter any unexpected problems during use, please do
not hesitate to contact us .
When using it, it is particularly important to observe the personal rights
and the right to informational self-determination which is applied in
Germany .

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
2. CONNECTION
Connect the camera module as shown in the picture with the CSI
interface of your Raspberry Pi. Pay attention to the orientation of the cab-
le. The connection via the CSI interface is suicient, so that no further
connection is required.
3. INSTALLATION OF THE SYSTEM
If you are already using the latest Raspbian soware on your Raspberry
Pi, you can skip this step and immediately proceed to the next step.
Otherwise, please follow the instructions below.
Please install the latest Raspbian soware on your SD card. You can
download it here.
With a suitable program (e.g. Win 32 Disk Imager) you can transfer the
image to your SD card.
Now select the downloaded image, as well as the microSD card you want
to be written on and write with the button Write .

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
4. INSTALLATION OF THE CAMERA
First open a terminal window and start the Raspberry Pi configuration
menu by typing the following command.
sudo raspi-config
In the menu that now opens, navigate to menu 5 Interfacing Options .
Here, you select the P1 Camera option and activate it.
Then you can leave the menu via Finish and restart your Raspberry Pi.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
5. USAGE OF THE CAMERA
1. Taking pictures
To take pictures with the camera , the following console command can
be used:
raspistill -o image.jpg
The image is then saved under the name image.jpg in the user directory
( /home/pi).
2. Video recording
Videos can be recorded with the following command:
The annex -t 10000 defines the duration of the recorded video. In this
case the video is 10 seconds long.
The video is then saved under the name video.h264 in the user directory
( /home/pi).
raspivid -o video.h264 -t 10000
6. OTHER INFORMATION
Our information and take-back obligations according to the
Electrical and Electronic Equipment Act (ElektroG)
Symbol on electrical and electronic equipment:
This crossed-out dustbin means that electrical and electronic appliances
do not belong in the household waste. You must return the old
appliances to a collection point.
Before handing over waste batteries and accumulators that are not
enclosed by waste equipment must be separated from it.
Return options:
As an end user, you can return your old device (which essentially fulfils
the same function as the new device purchased from us) free of charge
for disposal when you purchase a new device.
Small appliances with no external dimensions greater than 25 cm can be
disposed of in normal household quantities independently of the
purchase of a new appliance.
Possibility of return at our company location during opening hours:
Simac Electronics GmbH, Pascalstr. 8, D-47506 Neukirchen-Vluyn, Germa-
ny
Possibility of return in your area:
We will send you a parcel stamp with which you can return the device to
us free of charge. Please contact us by e-mail at [e-mail] or by
telephone.
Information on packaging:
If you do not have suitable packaging material or do not wish to use your
own, please contact us and we will send you suitable packaging.

www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
PR
7. SUPPORT
If there are still any issues pending or problems arising aer your
purchase, we will support you by e-mail, telephone and with our ticket
support system.
E-Mail: [e-mail]
Ticket system: http://support.joy-it.net
Telephone: [phone] (10-17 o‘clock)
For further information please visit our website:
www.joy-it.net
Published: 03.03.2020
