Joyoung DJ13E-D79 Technical manual

01-17-1309-0032-A
CCC certification of product
Our company has passed
ISO9001 Quality management
system certification
Joyoung Company Limited
No.999 Meili Road, Huaiyin District, Jinan City
Post code: 250118 Fax: [phone]
www.joyoung.com
Sunshine Service Hotline
400-6186-999

Jiuyang
Operation Instruction
Full-automatic Domestic Soy Milk Machine
DJ13E-D79
Please read this manual carefully before using the product and keep it properly.

Thank you for purchasing Jiuyang products. Please read this manual carefully before
using to ensure that you use this product correctly and safely.
Pictures are for reference only. Please refer to the actual product.
Contents
Chapter I Precautions for Safe Use … … … 1
Chapter II Parts and Accessories........ 4
Chapter III Application method......... 6
Pre-use Instructions … … … 6
Operating Steps and Instructions … … … … 6
Booking Instructions...... 7
Altitude Adaptive Operation … … … … 8
Chapter IV Maintenance
Chapter V Failure Analysis and Removal... 9
Chapter VI Model Specification Parameters … … … 10
Chapter VII Functions and Recipes
Food Contact Material Information...... 14
Hazardous Substances Restriction Use Identification List … … … 15
After-sales Service...... 16

- 1 -
Chapter I Precautions for Safe Use
Warning
Be vigilant against the risks that may lead to personnel danger, serious injury
and major property losses.
Attention
Attention should be paid to the risk of injury to persons or damage to goods.
Represents “Prohibited”, unavailable content.
Represents “Force”, what must be executed
● In order to prevent electric shock, fire, scald and other accidents, please observe the
following contents.
Warning
Please clean the cup body, blade, anti-spill electrode and temperature sensor in
time. The blade edge is sharp. Take out, wipe and clean carefully. Wear protective
gloves.
When the product is boiling, the temperature inside the cup, the lower cover, the
blade and other parts are high before cooling after the work is finished. Please do
not touch them to avoid scald.
Attention
Do not plug or unplug the power cord with wet hands to prevent electric shock.
In the pulping process, do not lift the machine head or move the product quickly to
avoid being scalded by steam, or overflow of food materials, resulting in scalding,
electric shock and other accidents.
Do not lift the whole machine with the nose to avoid slipping of the cup.
Do not use damaged power cords or plugs to prevent accidents or fires caused by

- 2 -
electric shock or short circuit. If the power cord is damaged, you must go to
Jiuyang After-sales Service Department to purchase the special power cord for
replacement.
Do not fill hot water above 70℃to make pulp, so as not to affect the taste or cause
pulverized bad slurry overflow and other anomalies.
Please do not drink until the pulping is finished. Drinking undercooked soy milk
can be harmful to the human body.
Do not overflow the head or cup into the liquid. Do not spray the head, vent holes,
strong electrical couplers, power sockets, and do not water the bottom of the cup.
If water enters, pause and use again to avoid short circuit or electric shock
Care should be taken of children to ensure that they are not likely to play with or
approach the product in order to avoid personal injury from scald or misoperation.
Use this product only with experienced guardians or coaches who have abnormal
or no independent capacity.
Please make sure that the local power supply is in accordance with the marked
power supply of the product before use, otherwise the product will be damaged or
fire will occur.
Operate on a stable horizontal table and stay away from the green side of the table
to prevent falls. Do not use this product under or near the curtains and other
combustible materials (e.g. under the wall), otherwise it may cause the fire engine
head to buckle vertically onto the cup body and the power cord to be inserted into
the power outlet. Make sure that it is installed in place to prevent loosening, power
failure or overheating.
When the product is working, keep a certain distance from the charged object such
as the socket, so that the plug is in the accessible range and away from the easily
explosive object. At the same time, the grounding wire of the power socket must
be kept in good grounding.
After the product starts to work, if any other abnormality occurs in case of power
failure, please pay attention to the replacement of food ingredients and
remanufacture, otherwise it will cause overflow of paste bottom slurry, alarm and
other faults.
After the production, please cut off the power first, remove the machine head and
pour the slurry again. Slide off the machine head or splash out the drink, causing

- 3 -
damage to the products or scald.
The temperature of the newly-made beverages is higher, please use heat-resistant
utensils and pay attention to safety to prevent the beverages from spattering and
scald.
If filtering is necessary, please pay attention to the residues attached to the filter
screen with high temperature. When cleaning the filter screen, do not face people
and pay attention to safety to prevent the residues from spattering and scald.

- 4 -
Tips
This product is only suitable for domestic use, not for commercial use.
When used for the first time (including the first time after adaptation), the pulping time
may be prolonged.
Some food ingredients contain natural pigments, which may cause dyeing of the lower
cover and anti-spill electrode. It is normal and will not affect the beverage. Please feel
free to drink without damage to your health.
In order to fully pulverize and release nutrients, it is normal for intermittent rapid and
slow sounds to occur during machine beating.
Do not continue pulping for a long time, otherwise the motor may start the automatic
protection function, and the electric opportunity will not work temporarily, and the motor
cannot be used normally until it is completely cooled down.
After pulping is completed, the next pulping should be carried out at intervals of more
than 8 minutes, otherwise, the service life of the product will be affected.
Infants, people with renal failure and gastrointestinal dysfunction should choose low
concentrations of beans or reduce consumption as appropriate.
Heat preservation, motor agitation is normal phenomenon, can be ready to drink after
power failure.

- 5 -
Chapter II Parts and Accessories
Control Panel Diagram
Pre-set, Display Area, Start/Cancel
Shortcut function, Function selection, Shortcut function
Function selection: Functions for selecting the display area.
Shortcut features: With the function selection key displayed, it will start automatically for 3
seconds after touching and pressing.
Reservation settings: It is used to set the booking time (3-114 hours) and select the booking
temperature (hot drink or warm drink).
Start/Cancel: Used to start or cancel a function.
Complete machine diagram
1Vent hole (at handle)
2Operating Keys
3Operating status indication
4Nose gasket
5Nose
6Anti-spill electrode
7Lower cover
8Temperature sensor
9High suction finis grinder
10 Blade
11 Strong electric coupler
12 Cup body
13 Water level scale (engraved in the cup)
14 Power outlet

- 6 -
Accessories (1
each)
Power cord Measuring cup Grouting cup Grouting cup
handle
Warm Tips
1Press Figure 1 to remove all objects from the cup.
2Please assemble the cup and its handle correctly in the direction of arrow in
Figure 2 to prevent the cup from slipping off when serving hot drinks and causing scald.

- 7 -
Chapter III Application Method
Pre-use Instructions
1 This product is only used in areas below 2000 meters above sea level on the Chinese
mainland. If the altitude difference is more than 1500 meters after the change of the place of
use, the operation shall be self-adaptive according to the altitude.
2 Clean the machine before use.
3 It is suggested that the beans should be used for the first time.
Operating Steps and Instructions
1 Fill ingredients and water
Fill the cleaned ingredients according to the recipe and fill water between the upper and lower
water levels (see figure on the right).
2Switch on the power supply
①Place the machine head vertically into the cup body. ②Plug in the power cord, ③
Switch on the power, and when the power is turned on, prompt "tick" and the light is on.
Warm Tips
Close the nose and press tight; Please level out when there are more ingredients; Make
sure the nose and strong electrical couplers are in place.
3Select and start the function
Press the “Select” to select the function, and then press the “Start/Cancel” to start the
function.
Select Features
"Tick" a corresponding function lamp flashing
Start-up function
"Tick" two corresponding function lights on (no longer flashing)

- 8 -
Warm Tips
1After the function is selected, the “Start/Cancel” is not pressed, and the function
starts automatically after approximately 30 seconds.
2After the function is started, the “Start/Cancel” can be pressed to cancel the
function within 1 minute.

- 9 -
4Production Completed
Prompt "tick" …"tick" …" (stop after about 1 minute), the corresponding function light
flashes. Please unplug the power cord and lift the nose for drinking.
Finish!
Warm Tips
This machine has the function of automatic heat preservation (see “Function and Recipe”
for heat preservation function).
5Cleaning and storage
After the machine is cooled, please clean, dry or air-dry it and store it in a dry and ventilated
place.
Warm Tips
Do not clean the machine with a steel ball. If difficult to clean, it is recommended to soak
in hot water and detergent before cleaning.
Reservation Operation Instructions
1 Power on
Digital screen display on power-on
2 Select the booking function (see recipe for booking function)
Digital screen display
3 Press the "Appointment Time" key (can make an appointment for 3-11 hours), press once
each time, the appointment time increases by 30 minutes.
Indicates that the production is complete in 11 hours
4 Set reservation temperature
Press the "Appointment Temperature" button to select a hot or warm drink.
5 Start Reservation
Touch the “Start/Cancel” and prompt "tick" to enter the reservation.
6 Digital screen and pulping status
Finish making or heat preservation
Exception Alert (see Exception Alert Prompt)

-
10 -
Warm Tips
1The temperature is higher than 30 ℃. Please make an appointment for no more
than 8 hours.
2Do not use soaked ingredients when making an appointment.
3Please do not cut off the power during the appointment, otherwise please change
the ingredients and remake.
④There is a deviation between the prompting time and the booking time, which is a normal
phenomenon. Please feel free to drink.
Altitude Adaptive Operation
In order to fully ensure the altitude adaptation effect, when the product is moved to an area
with great altitude change (altitude difference of more than 1500 meters) after use, please
follow the following steps before use, prompting to finish pulping.
1 Plug in and complete Step 2 in 30 seconds.
2 Press the “Start/Cancel”for 3 seconds.
3 Prompt "tick, tick, tick" and instruct to flash three times to complete that operation.
(Attention, please! If you do not have the above tips, repeat the operation after power-down).
Chapter IV Maintenance
●After cleaning, it is recommended to dry or air-dry, and then assemble the whole machine
for storage.
●Please store the product in a dry and ventilated place.
Warm Tips
1Do not disinfect or dry in disinfector or dryer.
2If after pulping, the inside of the cup and other stainless steel surface local
discoloration, blue, is a normal phenomenon harmless to the human body, please feel

-
11 -
free to drink. (Phosphate ions in the food and calcium, magnesium plasma,
crystallization at a certain temperature conditions lead to blue, can be wiped away
vinegar).
3Please wipe or dry the machine head after cleaning, and put it in the cup body
again to avoid peculiar smell.

-
12 -
Chapter V Failure Analysis and Removal
Faults Reason Countermeasure
Indicator not on The nose is not set straight. Reposition the nose
Power cord not plugged in Plug the power cord to the bottom
The light is on and the
machine is not working
Feature not selected Select the appropriate function
Too little water is filled to
the cup when no water is
poured into the cup
Fill between the upper and lower water
level scale lines
Temperature sensor faulty Send to local after-sales service
department for maintenance
The motor is working
without stopping. Inlet water into the nose Send to local after-sales service department for maintenance
Heat incessantly
Unfed Fill ingredients according to the recipe
dosage requirements in the manual
Inlet water into the nose Send to local after-sales service
department for maintenance
In normal heat Wait a few minutes
No response to key
System not reset after power
failure
Power off for 3 minutes and then
power on
Machine itself faulty Send to local after-sales service
department for maintenance
Food ingredients can't
be broken, overflow pot
Wrong selection function Choose the right function
Too much or too little
ingredients
Fill ingredients according to the recipe
dosage requirements in the manual
Machine itself faulty Send to local after-sales service
department for maintenance
Paste
Uncleaned dryness inside
cup Clean the inside of the cup
Too many ingredients filled Fill ingredients according to the recipe
dosage requirements in the manual
Too long working
hours, no other
abnormalities
Water temperature too low Use warm water
Wrong selection function Choose the right function

-
13 -
Abnormal Alarm Prompt
Digital
screen
display
Reason Countermeasure
E1 Anhydrous alarm Please refer to the water level of the cup body to fill food
and water correctly or send after-sales service for
maintenance
E3 Anti-spill abnormal
report
E4 Heating Timeout
Alarm
Digital screen
display Reason Countermeasure
E5 Input voltage abnormality Plug in again to confirm whether it is
normal or send it for after-sales service
E6 Zero crossing signal loss alarm
E7 Communication abnormal alarm
E8 Temperature detection
abnormality alarm
Send after-sales service for
maintenance
E9
Alarm for excessive food
ingredients or high motor
temperature
Please fill food ingredients and water
correctly or send them for after-sales
service according to the instructions
EA Main board temperature
detection abnormal alarm
Send after-sales service for
maintenance
Warm Tips
1If the problem cannot be solved, do not dismantle the machine without
permission. Please send the machine to the local after-sales service department for
repair. For details, please refer to the "after-sales service" in the manual or dial the
sunshine service hotline: [phone].
2If the above contents are inconsistent with the real object due to the model or
parts inspection, please take the real object as the standard, without further notice,
please understand!

-
14 -
Chapter VI Model Specification Parameters
Implementation criteria: Q/3700YJY002-2016
Rated voltage: 220V
Rated frequency: 50Hz
Product
Model
Rated
Power/Motor
Power
Capacity Range Net
Weight
Product Size (Length X
Width X Height)
DJ13E-ME 1000W/300W 900mL~1300mL 2.9kg 242mmX185mmX300m
m
