Joysway WARRIOR B-JS-9301BR User manual

‘93’ Series RTR Brushless EP Racing Boat1
1) Transmitter
2) Boat Stand
3) Clear Plastic Cover
4) Waterproofing Tape
5) Spare Propeller
6) 2.0mm Allen Key (for Coupler)
2.5mm Allen Key (for Turn Fins, etc.)
7) Deans Connector w/Heatshrink - Fit to LiPo
battery if not already fitted
CONTENTS OF SET
THESE INSTRUCTIONS SHOULD BE READ BY A SUPERVISING ADULT, IN CONJUNCTION
WITH THE SEPARATELY INCLUDED RADIO CONTROL INSTRUCTIONS
INSTRUCTION MANUAL THIS MODEL IS NOT A TOY!
‘93’ SERIES RTR BRUSHLESS EP RACING BOAT
1
REQUIRED FOR (NOT INCLUDED)
1) 11.1V, 2200mAh (or greater) 20C LiPo Battery Pack
2) LiPo Battery Charger
3) 5.5 and 7mm Nut Drivers
4) 8 x AA Batteries (for Transmitter)
Note:LiPo battery should have Deans-type connector fitted.If not supplied with LiPo battery,solder
included Deans connector to LiPo battery wires noting correct polarity (+/-).
OFFSHORE WARRIOR RTR
PART NO:
B-JS-9301BR/2-4G
B-JS-9301RR/2-4G
B-JS-9301YR/2-4G
OFFSHORE SEA RIDER RTR
PART NO:
B-JS-9302BR/2-4G
B-JS-9302RR/2-4G
B-JS-9302YR/2-4G
OFFSHORE SEA DRIFTER RTR
PART NO:
B-JS-9303RR/2-4G
B-JS-9303YR/2-4G
2
5
3
47
6
7mm & 5.5mm Spanner (Not Included)

2 ‘93’ Series RTR Brushless EP Racing Boat
IMPORTANT
Before using this ‘93’ series model and its radio control system, and to ensure the safety of yourself and
others, it is very important that you read these instructions thoroughly and understand them.
‘93’ series models are capable of speeds in excess of 50km/h! Care should be taken to avoid the
possibility of injury and/or property damage.
‘93’ series models are designed for use in fresh water only. They are not designed for use in salt water!
‘93’ series models are not intended for persons under 14 years of age, unless closely supervised by an
adult.
Note: The ‘Offshore Warrior’, ‘Offshore Sea Rider’ and ‘Offshore Sea Drifter’ will also be referred to as
‘Warrior’, ‘Sea Rider and ‘Sea Drifter’ in these instructions, as well as “93’ series models’.
ASSEMBLING THE BOAT STAND
Assemble the included boat stand by slotting the
pieces together as shown (Warrior stand shown for
reference). Apply cyanoacrylate glue or 2-part epoxy
to secure the joints and allow the glue to completely
set before placing your ‘93’ series model on it.
(Model should be placed on its supplied boat stand with the transmitter switched 'ON', having previously
read and understood the radio control instructions)
1) Remove the '93' series model’s upper deck by unscrewing the knurled knob at its rear section.
2) Remove the clear plastic cover.
3) Insert the battery pack into the hull as shown below and secure with the hook and loop strap inside
the hull.
4) Attach the LiPo battery pack’s connector to the matching connector in the model. Do not force them
together - they only attach one way!
5) Replace the clear plastic cover (seal with the provided waterproof tape) and re-position the upper
deck, securing with the knurled knob.
Attention: Before replacing the '93' series model's clear plastic cover and upper deck, check to ensure
that the water-cooling tubing that connects to the motor is not obstructed or kinked, as this can cause
the motor and speed controller to overheat and potentially burn out.
Note 1: ‘93’ series models will typically run for around 8 minutes on a fully charged LiPo battery pack,
although this will vary depending on the type and capacity of LiPo pack you choose. As soon as you
notice a drop off in speed you should bring the model back to shore or control may be lost.
Note 2: If you want to run your ‘93’ series model for extended periods, you can purchase additional LiPo
battery packs. However, continuous running of the model will generate high heat levels, which will lead
to premature wear of the brushless motor. Once your LiPo battery pack is exhausted, we recommend
that you let the model cool down for 5~10 minutes before installing a fresh one.
INSTALLING THE BATTERY PACK IN '93' SERIES MODELS

‘93’ Series RTR Brushless EP Racing Boat3
WATERPROOFING TIPS
You should take steps to ensure that your ‘93’ series model and its radio control equipment are adequately
protected against the possibility of water damage. We recommend that you place your model’s receiver
inside a rubber bag (balloon) and tie the end off with a cable tie or similar.
Use the clear plastic sheet and waterproofing tape provided to seal the hull as shown after you have
connected the LiPo battery pack, before placing your ‘93’ series model on the water.
Ensure the propeller’s flexible shaft is properly lubricated
(see below) as this too will reduce the possibility of water
entering the hull during operation.
LUBRICATING THE PROPELLER SHAFT
Lubricating the '93' series model's flexible propeller shaft is vital to its
smooth operation and lifespan. The lubricant also acts as a water seal,
helping to prevent water from entering the hull via the propeller tube.
It is recommended that you lubricate the propeller shaft and tube every
2~3 hours.
1) Use the 2.0mm Allen key provided to loosen the grub screws that
secure the flexible shaft to the coupler, then slide the flexible shaft out
of the propeller tube.
2) Lubricate the flexible shaft and propeller tube with waterproof marine
grease and reinstall the flexible shaft, re-tightening the grub screws in
the coupler.
Note: Never apply grease to the '93' series model's brushless motor.
HOW TO CONTROL/OPERATE YOUR ‘93’ SERIES BOAT
1) Forward Throttle Trigger
Your '93' series boat can be driven forward by pulling the throttle trigger.
Release the trigger and the model will stop.
2) Left/Right Steering Wheel
The steering wheel controls the '93' series model's left and right movement.
Turn the wheel to the left to steer to the left. Turn the wheel to the right to
steer to the right. Release the wheel to go straight.
Racing Tip: '93' series models are designed for racing, and will be less
responsive to steering inputs at high speed. Decrease your speed to allow
tighter turning.
Note: For full details of the operation of your transmitter, refer to the
separately included radio control instruction manual.
2
1

4 ‘93’ Series RTR Brushless EP Racing Boat
The Warrior and Sea Rider feature adjustable turn fins to aid in turning. These can
be adjusted using the included Allen key. The optimum angle of adjustment is 45
degrees to the hull.
TURN FINS
(Model should be placed on its supplied boat stand)
1) Check that the turn fins are adjusted correctly (for
Warrior/Sea Rider).
2) Switch ‘ON’ the transmitter. Check that the transmitter’s
power LED glows green.
3) Plug the LiPo battery into the ESC - you will hear three
continuous audible beeps.
4) Pull the throttle trigger on the transmitter - the boat’s
propeller should turn anticlockwise.
5) Check that the rudder responds correctly to transmitter
inputs.
6) Seal the clear plastic cover with the included waterproof
tape, taking care to ensure the water-cooling tubing is not
kinked.
7) Fit the upper deck and secure with the included fixing
knob.
GETTING READY TO USE YOUR '93' SERIES MODEL
1) When you have finished using your '93' series model, you should first switch ‘OFF’ the model
(disconnect the LiPo battery pack), then switch ‘OFF’ your transmitter.
2) Remove all batteries from the transmitter and model.
3) Leave the '93' series model’s upper deck and clear plastic cover off to allow moisture to evaporate. If
fitted, also temporarily remove the receiver from its rubber bag. Ideally, place the model in this way in a
warm and dry place, like an airing cupboard, until you are sure it is dry and then store it away.
4) Periodically grease the '93' series model’s propeller shaft and tube as this will reduce wear and also
help prevent water from entering the hull.
AFTER USE

‘93’ Series RTR Brushless EP Racing Boat5
Calibration:
1) First, ensure the brushless motor and receiver are properly connected to the ESC.
2) Next, pull and hold the transmitter's throttle trigger at maximum, then switch 'ON' the transmitter.
3) Whilst continuing to hold the throttle trigger at maximum, connect a fully charged LiPo battery to the
ESC - you will hear 4 high pitched tones.
4) Now, push the throttle trigger fully forward - you will hear 3 repeat monotones.
5) Disconnect the LiPo battery from the ESC.
Note: You only need follow this procedure if your speed controller is not responding correctly to throttle
inputs or if you are re-installing an existing or new ESC, as it is already factory set.
Specification:
Max Continuous Current: 30A
Peak Current: 35A for 35 Seconds
LiPo: 2~3 Cells (3.7~11.1V)
BEC Output: Continuous 2A/Peak 2.5A
Thermal Protection: Activated at 120˚C
Low Voltage Protection: Engaged when LiPo battery pack (per cell) drops to 3V.
Note: These adjustments should be carried out in conjunction with the separately included radio control
instructions.
If your '93' series model does not run in a straight line when not being steered, you can adjust it by using
the steering trim located on the transmitter.
1) Run your '93' series model on calm water when adjusting the steering. If your model runs to the right
when not being steered, adjust the trim control a little to the left, re-centre the model and see if this has
corrected the problem. Keep making small adjustments in this way until the model runs straight.
Adjust the trim control to the right to correct if your model steers to the left without being steered in the
same way as detailed above.
2) You can also adjust the '93' series model's throttle response using the Throttle Trim, located on the
transmitter.
If, when you connect the LiPo battery pack, the '93' series model’s propeller starts turning without
transmitter input, you can adjust it back to neutral (stopped) moving the Throttle Trim control to the left.
You should adjust this trim so that the propeller starts to turn as soon as you depress the transmitter’s
trigger, but the propeller stops turning immediately the trigger is released.
IF THE ‘93’ SERIES MODEL DOES NOT RUN IN A STRAIGHT LINE
CIRCUIT & COOLING SYSTEM DIAGRAM FOR '93' SERIES BOATS
ESC (ELECTRONIC SPEED CONTROLLER) CALIBRATION & SPECIFICATION
Each '93' series model is supplied from the factory with radio and cooling systems already set up.
However, if you have cause to maintenance, repair or replace parts in your model in the future, this chart
can be of help when it comes time to re-install/re-connect everything.

6 ‘93’ Series RTR Brushless EP Racing Boat
Please observe the following warnings.
DURING OPERATION
• Ensure that all batteries are correctly installed and that the LiPo battery pack is fully charged.
• Do not operate your '93' series model in areas with strong currents, in salt water or areas of water with
large waves.
• Do not touch moving parts during operation, especially the propeller.
• The metal hardware (rudder, turn fins, etc.) on the boat can be sharp, so take care to avoid injuring
yourself on them.
• The brushless motor can get hot in use. Be careful not to touch it before it has cooled.
• Do not let your '93' series model run aground, as this can cause damage.
• If you lose control of your '93' series model, never wade into deep water or water with strong currents to
retrieve it. First, hold the transmitter as high as you can to try to re-establish control. If this does not
work, find another way to move closer to the model, but do not endanger yourself in the process!
CAUTION!
STORING YOUR ‘93’ SERIES MODEL SAFELY
• Always remove all batteries before storing your '93' series model and its transmitter.
• Never store your '93' series model near naked flames, in high temperatures (including radiators) or in
direct sunlight.
• Never store your '93' series model near water, outdoors or in the rain.
• Ideally, store your '93' series model and transmitter in the box in which they were supplied.
CARE WITH RECHARGEABLE BATTERIES (THE LIPO BATTERY PACK)
Care must be taken when handling rechargeable batteries (the LiPo battery pack) to avoid the possibility
of injury and/or damage to property. Do not short circuit, disassemble or incinerate rechargeable
batteries. It is very dangerous to disregard these warnings.
Please follow these simple rules to ensure safe operation and gain the maximum enjoyment from
your model.
• This model is not a toy and should not be treated as such. Children under 14 years of age should not
use this product unless closely supervised by an adult.
• Because this model is operated by radio control, it is important to ensure you always use fresh and/
or fully charged batteries. Never allow the batteries to run low or you could lose control of the model!
• Avoid overloading your model. Never run it in areas where its movement will be restricted, e.g. areas
where there is pond weed, etc., as this can over stress the motor and ESC.
• Ensure nothing prevents the smooth running of moving parts.
• Do not run your model in confined spaces.
• Never run your model in a public space where it might upset or endanger people or wildlife.
• Immediately switch ‘OFF’ your model and transmitter if you see lightning or hear thunder. Never use
your model in the rain.
Do not dismantle or tamper in any way with this R/C vehicle and its transmitter. The manufacturer and
distributor will accept no responsibility, expressed or implied, for accidents or injuries caused as a result
of disassembly, modification and/or usage against the Instructions for this product.
Tampering or modification will also invalidate the guarantee.
GENERAL INFORMATION FOR THE SAFE OPERATION OF YOUR ‘93’ SERIES MODEL

‘93’ Series RTR Brushless EP Racing Boat7
TROUBLE SHOOTING
Check using the chart below before returning your '93' series model for repair as many problems can
be easily solved.
PROBLEM CAUSE REMEDY
Model will not move No battery in transmitter/model
Battery installation is incorrect
Weak batteries in transmitter
Weak batteries in model
Install batteries
Install batteries correctly,
checking polarity (+/-)
Replace/recharge batteries
Recharge LiPo battery pack
No control of model Weak batteries in transmitter Replace/recharge batteries
Limited radio range Weak batteries in transmitter Replace/recharge batteries
SPARE PARTS
ITEM NO. ITEM NAME PICTURE
93001 B2445 Water Cooled Brushless Motor
93002 Water Cooling Jacket - For 93001
93003 30A Water Cooled ESC w/BEC
93004 Water Cooling Plate - For 93003
93005 Motor Mount - Offshore Warrior
93006 Motor Mount - Offshore Sea Rider/Sea Drifter
93009 Rudder Connecting Rod - 93 Series
93010
93010T
Flexible Propeller Shaft & Coupler - Warrior/Sea Rider
Flexible Propeller Shaft & Coupler - Sea Drifter

8 ‘93’ Series RTR Brushless EP Racing Boat
ITEM NO. ITEM NAME PICTURE
93011
93011A
93011B
93011C
2Bl Propeller (30mm Dia) - 93 Series (Standard)
2Bl Propeller (27mm Dia) - 93 Series (Option)
2Bl Propeller (32mm Dia) - 93 Series (Option)
2Bl Propeller (35mm Dia) - 93 Series (Option)
93016 Knurled Brass Fixing Knob (Pk2)
93017 Waterproof Bellows (Pk2) - 93 Series
93018 R/C & Battery Mounts - 93 Series
93019 Alu Rudder & Support - 93 Series
93020 Propeller Shaft Support w/BB - 93 Series
93021 Stainless Steel Turn Fins/Mounts - Warrior/Sea Rider
93025A
93025B
93025C
Hull-Black/Upper Deck-Yellow - Offshore Warrior
Hull-Red/Upper Deck-White - Offshore Warrior
Hull-Yellow/Upper Deck-White - Offshore Warrior
93026A
93026B
Upper Deck Only (Yellow) - Offshore Warrior
Upper Deck Only (White) - Offshore Warrior
93027A
93027B
93027C
Hull-Black/Upper Deck-Yellow - Offshore Sea Rider
Hull-Red/Upper Deck-White - Offshore Sea Rider
Hull-Yellow/Upper Deck-White - Offshore Sea Rider
93028A
93028B
Upper Deck Only (Yellow) - Offshore Sea Rider
Upper Deck Only (White) - Offshore Sea Rider
93029A
93029B
Hull-Red/Upper Deck-White - Offshore Sea Drifter
Hull-Yellow/Upper Deck-White - Offshore Sea Drifter
93030A Upper Deck Only (White) - Offshore Sea Drifter
This instruction manual and its contents
may be subject to change without notice.
Distributed in the UK/Europe by; Ripmax Ltd., 241 Green Street, Enfield, EN3 7SJ
