JUKI TL-98P perfection User manual

Sewing machine for professional use
Maszyna do szycia do zastosowań profesjonalnych
Machine à coudre à usage professionnel
Macchina per cucire per l’uso professionale
INSTRUCTION MANUAL
INSTRUKCJA OBSŁUGI
MANUEL D’INSTRUCTIONS
MANUALE D’ISTRUZIONI
TL-98P
IMPORTANT:
Read all safety regulations carefully and understand
them before using your sewing machine.
Retain this instruction manual for future reference.
WAŻNE:
Przeczytaj wszystkie informacje dotyczące
bezpieczeństwa użytkowania przyswój je
zanim użyjesz maszyny.
Zachowaj instrukcję na przyszłość.
IMPORTANT:
Avant de mettre la machine en marche, lire
attentivement et assimiler les regles de securite
de ce manuel.
Conserver le manuel afin de pouvoir le consulter ul
terieurement.
IMPORTANTE:
Prima di utilizzare la macchina per cucire leggere
attentamente tutte le norme di sicurezza e
comprenderle.
Tenere questo manuale d’istruzioni per poterlo
consultare quando necessario.

“IMPORTANT SAFETY INSTRUCTIONS”
“When using an electrical appliance, basic safety precautions should always be followed, including the following:”
“Read all instructions before using this sewing machine.”
“DANGER_____To reduce the risk of electric shock:”
1. “An appliance should never be left unattended when plugged in.”
2. “Always unplug this appliance from the electric outlet immediately after using and before cleaning.”
3. “Always unplug before re-lamping. Replace bulb with same type rated 3 Watts 12V.”
“WARNING_____To reduce the risk of burns, fire, electric shock, or injury to persons:”
1. “Do not allow this appliance to be used as a toy. Close attention is necessary when this appliance is used by or near
children.”
2. “Use this appliance only for its intended use as described in this manual. Use only attachments recommended by
the manufacturer as contained in this manual.”
3. “Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped
or damaged, or dropped into water. Return the appliance to the nearest authorized dealer or service center for
examination, repair, electrical or mechanical adjustment.”
4. “Never operate the appliance with any air openings blocked. Keep ventilation openings of the sewing machine
and foot controller free from the accumulation of lint, dust and loose cloth.”
5. “Keep fingers away from all moving parts. Special care is required around the sewing machine needle.”
6. “Always use the proper throat plate. The wrong plate can cause the needle to break.”
7. “Do not use bent needles.”
8. “Do not pull or push fabric while stitching. It may deflect the needle causing it to break.”
9. “Switch the sewing machine off ("0") when making any adjustments in the needle area, such as threading needle,
changing needle, threading bobbin, or changing presser foot and the like.”
10. “Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when making any
other user servicing adjustments mentioned in the instruction manual.”
11. “Never drop or insert any object into any opening.”
12. “Do not use outdoors.”
13. “Do not operate where aerosol (spray) products are being used or where oxygen is being administered.”
14. “To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet.”
15. “Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.”
“SAVE THESE INSTRUCTIONS”
“This sewing machine is intended for household use only.”
Please use following foot control:
“This appliance has a polarized plug (one blade wider than the other).
To reduce the risk of electric shock, this plug is intended to fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician to install the proper outlet.
Do not modify the plug in any way.”
1
Sewing machine model number Used with foot controller number
TL-98P YC-485

2
“WAŻNE INSTRUKCJE BEZPIECZEŃSTWA”
“Użytkując urządzenie elektryczne powinno się stosować podstawowe środki ostrożności, zawierające poniższe:”
“Przeczytaj całą instrukcję zanim użyjesz maszyny.”
“UWAGA____By zredukować ryzyko porażenia:”
1. “ Ta maszyna do szycia nie powinna być pozostawiana bez opieki gdy jest podłączona do prądu”
2. “ Zawsze odłączaj tą maszynę z gniazdka niezwłocznie po użyciu i przed konserwacją.”
3. “ Zawsze odłączaj urządzenie przed wymianą żarówki. Żarówkę wymieniaj na tego samego typu o mocy 3 watów, 12V."
“UWAGA____By zredukować ryzyko opażeń, pożaru, porażenia elektrycznego lub obrażeń:
1. Nie pozwól by to urządzenie było używane jako zabawka. Jeżeli urządzenie jest użytkowane w pobliżu lub przez dzieci
należy zachować szczególną uwagę.
2. Używaj tego urządzenia tylko zgodnie z przeznaczeniem określonym w instrukcji. Używaj tylko rozszerzeń polecanych
przez producenta, wyszczególnionych w instrukcji.
3. Nigdy nie używaj tego urządzenia jeżeli uszkodzeniu uległ przewód zasilający lub wtyczka, nie działa ono poprawnie, jeżeli
zostało upuszczeone, uszkodzone lub wrzucone do wody. Zwróć urządzenie do najbliższego autoryzowanego dystrybutora
lub centrum serwisowego w celu dokonania naprawy bądź regulacji.
4. Nigdy nie używaj urządzenia z zasłoniętymi otworami wentylacyjnymi. Chroń otwory wentylacyjne maszyny do szycia
oraz regulatora obrotów przed akumulacją nitek, pyłu oraz luźnej tkaniny.
5. Nie zbliżaj palców do ruchomych częsci maszyny. Szczególna uwaga powinna być zachowana w okolicy igły.
6. Zawsze używaj odpowiedniej płytki ściegowej. Zła płytka może spowodować złamanie się igły.
7. Nie używaj wygiętych igieł
8. Nie popychaj ani nie ciągnij tkaniny podczas szycia. Może to odchylić igłę i spowodować jej pęknięcie.
9. Wyłącz maszynę (“O”) podczas gdy dokonujesz jakichkolwiek korekt w okolicy igły, takich jak nawlekanie nici,
zmiana igły, zmiana szpulki lub zmiana stopki i tym podobne.
10. Zawsze odłączaj maszynę od gniazdka gdy zdejmujesz osłony, smarujesz maszynę lub dokonujesz jakiekolwiek
inne oprace serwisowe wspomniane w instrukcji obsługi.
11. Nigdy nie wrzucaj i nie wkładaj żadnych przedmiotów do żadnego z otworów.
12. Nie używaj na zewnątrz
13. Nie używaj w pomieszczeniach w których rozpylane są aerozole, lub gdzie podawany jest tlen.
14. By odłączyć przełącz wszystkie przełączniki w pozycję wyłączoną (“O”), następnie wyjmij wtyczkę z gniazdka.
15. Nie odłączaj przez ciągnięcie za przewód. By odłączyć, złap za wtyczkę.
“ZACHOWAJ TĄ INSTRUKCJĘ”
“Ta maszyna do szycia jest przeznaczona wyłącznie do uzytku domowego.”

3
“NOTES DE SECURITE IMPORTANTES”
“Lorsque vous utilisez un appareil électrique, des précautions élémentaires doivent toujours être suivies, comme celles-ci.”
“Lisez attentivement ces instructions avant d’utiliser cette machine à coudre.”
“DANGER_____Pour réduire le risque d’électrocution.”
1. “Un appareil ne doit jamais être laissé sans surveillance lorsqu’il est branché.”
2. “Toujours débrancher cet appareil du secteur immédiatement après utilisation et avant de le nettoyer.”
3. “Toujours débrancher avant de changer l’ampoule. Remplacer l’ampoule par une du même type 3watts (12V).”
“ATTENTION_____Pour les risques de brûlure, électrocutions et de blessures.”
1. “Ne pas utiliser cet appareil comme un jouet. Porter une attention particulière lorsque cet appareil est utilisé per des
enfants.”
2. “N’utiliser cet appareil que dans le cadre de ses fonctions, mentionnées dans le présent manuel. N’utiliser que lespiéces
fournies ou recommandées par le fabricant dans ce manuel.”
3. “Ne pas utiliser cet appareil si une de ses prises ou cordons est endommagé, ou s’il ne fonctionne pas correctement.
S’il est tombé, a été endommagé, tombé dans l’eau, retourner l’appareil auprès de votre revendeur le plus proche pour
un réparation, ou une vérification technique ou électrique.”
4. “Ne jamais utiliser cet appareil dans un lieu dépourvu d’aération. Maintenez une ventilation suffisante autours de la
machine et du rhéostat et éviter la poussière et les chutes de tissus aux alentours des sources d’aération de la machine.”
5. “Eloigner vos doigts des pièces mobiles de la machine. Faites particulièrement aux mouvements de l’aiguille.”
6. “Toujours utiliser la plaque aiguille appropriée. Un plaque non appropriée peut faire casser l’aiguille.”
7. “Ne pas utiliser d’aiguilles courbes.”
8. “Ne pas tirer ou pousser le tissu lorsque vous cousez., cela pourrait abîmer, voire casser l’aiguille.”
9. “Mettre l’interrupteur de la machine en position <OFF> losrque vous manipulez l’aiguille, ou l’enfilez. De même lorsque
vous changez le pied presseur.”
10. “Débranchez toujours votre machine lorsque vous ôtez le capot, lorsque vous la nettoyez, ou pour tout autre manipulation
mentionnée dans le manuel d’instruction.”
11. “Ne jamais laisser d’objet entrer dans les ouvertures de la machine.”
12. “Ne pas utiliser à l’extérieur.”
13. “Ne pas utiliser lorsqu’un aérosol a été pulvérisé, ou lorsque de l’oxygène a été administré.”
14. “Avant de débrancher la machine, mettre l’interrupteur en position éteint <OFF>.”
15. “Ne pas débrancher en tirant sur le cordon. Pour débrancher, tenir la prise, pas le cordon.”
“RETENEZ CES INSTRUCTIONS”
“Cette machine à coudre est destinée à une utilisation domestique uniquement.”

4
“IMPORTANTI ISTRUZIONI PER LA SICUREZZA”
“Quando si usa l’apparecchio elettrico, osservare sempre le basilari misure di sicurezza comprese le misure qui di seguito
indicate:”
“Prima di utilizzare la macchina per cucire leggere tutte le istruzioni.”
“PERICOLO_____Per ridurre il rischio di scosse elettriche:”
1. “L’apparecchio non deve essere mai lasciato incustodito quando la spina è collegata alla presa di corrente.”
2. “Staccare sempre la spina dalla presa di corrente immediatamente dopo l’uso e prima della pulizia.”
3. “Staccare sempre la spina dalla presa di corrente prima della sostituzione della lampadina. Sostituire la lampadina con lo stesso
tipo 12V-3W nominale.”
“AVVERTIMENTO_____Per ridurre il rischio di bruciature, incendi, scosse elettriche, o ferimenti:”
1. “Non permettere che l’apparecchio venga usato come un giocattolo. É necessario prestare molta attenzione quando l’apparecchio
viene usato vicino ai bambini.”
2. “Usare l’apparecchio unicamente per gli scopi indicati in questo manuale. Usare solo accessori raccomandati dalla casa
costruttrice indicati in questo manuale.”
3. “Non azionare mai l’apparecchio se questo ha un cavo danneggiato o una spina danneggiata, se questo non funziona
correttamente, se questo è stato fatto cadere o danneggiato, o fatto cadere nell’acqua. Riportare l’apparecchio al rivenditore
autorizzato più vicino o al centro di servizio per ispezione, riparazione, regolazione elettrica o meccanica.”
4. “Non azionare mai l’apparecchio con qualsiasi apertura dell’aria bloccata. Tenere le aperture di ventilazione della macchina
per cucire e il combinatore a piede liberi dall’accumulazione di filaccia, polvere e tessuto sciolto. ”
5. “Tenere le dita lontano da tutte le parti mobili. Particolare cura è richiesta intorno all’ago della macchina per cucire.”
6. “Usare sempre la placca ago opportuna. La placca ago inopportuna può causare la rottura dell’ago.”
7. “Non usare gli aghi piegati.”
8. “Non tirare o spingere il tessuto mentre si cuce. È possibile che questo faccia deviare l’ago causando la rottura dell’ago.”
9. “Spegnere la macchina per cucire (“0”) quando si esegue qualsiasi regolazione nell’area dell’ago, come infilatura del filo
nell’ago, sostituzione dell’ago, infilatura del filo nella bobina, o sostituzione del piedino premistoffa e cose simili.”
10. “Staccare sempre la spina dalla presa di corrente quando si rimuovono i coperchi, quando si lubrifica, o quando si esegue
qualsiasi altra regolazione che va fatta dall’utente stesso accennata nel manuale d’istruzioni.”
11. “Mai fare cadere o inserire alcun oggetto in alcuna apertura.”
12. “Non usare la macchina per cucire all’aperto.”
13. “Non azionare la macchina per cucire dove si stanno usando prodotti di aerosol (spray) o dove si sta somministrando
ossigeno.”
14. “Per interrompere la corrente, mettere tutti i comandi sulla posizione off (spento)(“0”), togliere quindi la spina dalla presa di
corrente.”
15. “Non staccare la spina dalla presa di corrente tirando il cavo. Per staccare la spina dalla presa di corrente, afferrare la spina,
non il cavo.”
“CONSERVARE QUESTE ISTRUZIONI”
“Questa macchina per cucire è progettata per l’uso solo nell’ambiente domestico.”

CONTENTS / SPIS STREŚCI / TABLE DES MATIERES / INDICE
Safety regulations ······················································· 1
Specifications ···························································· 6
Accessories ······························································ 7
Principal Parts ·························································· 7,8
Name and Function of each component ························ 9-12
Installing the auxiliary table
Installing the controller and the thread trimming foot switch
Attaching the knee lifter lever
Winding the bobbin ··············································· 13-16
Installing the thread guide
Winding the bobbin
Adjusting the bobbin winder guide
Threading the machine (needle thread) ······················· 17-19
Automatic needle threader
Drawing up the bobbin thread
Test sewing ···························································· 20,21
Reverse feed stitch
When making a knot on the reverse side of the material
Adjusting the thread tension ···································· 22
Tabulated relationship between material,
thread and needle ············································· 23
Topstitching ··························································· 24
Attaching the needle ··············································· 24
Rolled hemming ····················································· 25
Attaching a zipper ·················································· 26
Changing the sewing direction
Even feed foot ······················································ 27
Compensating presser foot ······································ 27
Quilting foot ·························································· 28
Maintenance and lubricating the machine ···················· 29
Replacing the lamp ················································ 30
Introduction of optional parts ····································· 30
Troubles and Corrective measures ······························ 31
CONTENTS
Instrukcja bezpieczeńśtwa············································· 2
ESpecyfikacja ··························································· 6
Akcesoria ································································· 7
Podstawowe częsci ···················································· 7,8
Nazwy i funkcje poszczególnych części ························· 9-12
Instalacja dodatkowej półki
Instalacja regulatora obrotów i nożnego przełącznika odcinania nici
Montaż dźwigni kolankowego podnośnika stopki
Nawijanie szpuleczki ··············································· 13-16
Instalacja prowadnika nici.
Nawijanie szpuleczki
Regulacja prowadnika nawijacza szpuleczki
Nawlekanie maszyny (nić górna - igłowa) ····················· 17-19
Automatyczny nawlekacz igły
Wyciąganie nici dolnej
Szycie próbne ························································· 20,21
Ścieg wsteczny(zabezpieczający)
Wiązanie węzła na lewej stronie materiału
Regulacja napięcia nici ············································· 22
Tabela relacji między materiałem, nicią i igłą ·················· 23
Stebnowania ·························································· 24
Instalacja igły ························································ 24
Okrągłe obrębianie ·················································· 25
Wszywanie zamków ··············································· 26
Zmiana kierunku szycia
Stopka wspomagająca transport ································ 27
Stopka kompensująca ·············································· 27
Stopka do pikowania ··············································· 28
Konserwacja i smarowanie ········································ 29
Wymiana żarówki ···················································· 30
Akcesoria opcjonalne ··············································· 30
Rozwiązywanie problemów ······································· 32
63,6675(ĝ&,
5
TABLE DES MATIERES
Règles de sécurité ······················································ 3
Caractéristiques ·························································· 6
Accessoires ······························································ 7
Pièces principales ······················································ 7,8
Nomenclature et fonction des pièces ···························· 9-12
Installation de la table auxiliaire
Installation de la pedale de commande et de l'interrupteur au
pied de coupe du fil
Pose du levier de genouillère
Bobinage de la canette ··········································· 13-16
Pose du guide-fil
Bobinage de la canette
Réglage du guide de bobineur
Enfilage de la machine (fil d’aiguille) ·························· 17-19
Enfileur d’aiguille automatique
Comment faire sortir le fil de canette
Essai de couture ···················································· 20,21
Exécution de points arrière
Comment faire un noeud à l’envers du tissu
Règlage de la tension du fil ··········································· 22
Tableau des relations entre le tissu, le fil et l’aiguille ·············· 23
Surpiqûre ································································· 24
Pose de l’aiguille ························································ 24
Roulotté ···································································· 25
Pose d’une fermeture à glissière ···································· 26
Inversion du sens de la couture
Pied presseur d’entraînement supérieur ··························· 27
Pied presseur compensateur ········································· 27
Pied ouateur ····························································· 28
Nettoyage et lubrification de la machine ··························· 29
Remplacement de la lampe ··········································· 30
Présentation des pièces en option ·································· 30
Problèmes et remèdes ················································· 33

6
INDICE
Norme di sicurezza ·················································· 4
Caratteristiche tecniche ············································· 6
Accessori ······························································· 7
Parti principali ························································· 7,8
Nome e funzione di ciascun componente ···················· 9-12
Installazione del tavolo ausiliario
Installazione del combinatore e interruttore a piede di taglio del filo
Montaggio della leva alzapiedino a ginocchio
Avvolgimento della bobina ······································ 13-16
Installazione del guidafilo
Avvolgimento della bobina
Regolazione della guida dell’avvolgibobina
Infilatura del filo nella macchina (filo dell’ago) ··············· 17-19
Infilaago automatico
Estrazione del filo della bobina
Cucitura di prova ···················································· 20,21
Affrancatura
Quando si fa un nodo sul lato rovescio del materiale
Regolazione della tensione del filo ································ 22
Relazione tra materiale, filo e ago disposta in tabella ·········· 23
Ribattitura ······························································· 24
Posizionamento dell’ago ············································· 24
Orlatura arrotolato ····················································· 25
Attaccatura di una chiusura lampo ······························· 26
Modifica del senso di cucitura
Piedino premistoffa del trasporto superiore ····················· 27
Piedino premistoffa compensativo ································· 27
Piedino per trapunte ················································· 28
Pulizia e lubrificazione della macchina ·························· 29
Sostituzione della lampadina · ······································ 30
Introduzione delle parti optional ···································· 30
Inconvenienti e Rimedi ··············································· 34
Specifications / Specyfikacja / Caractéristiques / Caratteristiche tecniche
Sewing speed
Stitch length
Needle bar stroke
Lift of presser foot
Needle
Lubricating oil
Dimensions of
sewing machine
Size of bed
Description Specification
Max. 1,500 stitches/min
Max. 6mm
32mm
7mm / 9mm (12mm by knee lifter)
HAx1 or HLx5 #11, #14
New Defrix Oil No.1
45.2W x 35.0H x 21.9L (cm)
43W x 17.8L (Auxiliary table: 59W x
27.7L)(cm)
Weight of sewing
machine
Power consumption
of the lamp
11.5 kg
12V 3W
Max. 1.500 szwów/min.
Max. 6mm
Szybkość szycia
Długość ściegu
Opis Specyfikacja
Skok pręta
igły
Wznios stopki
Igła
Olej nawilżający
Wymiary
Wielkość łoża
Masa maszyny
Moc żarówki
32mm
7mm / 9mm (12mm dźwignią kolankową)
HAx1 ó HLx5 #11, #14
New Defrix Oil No.1
45,2 szer x 35,0 gł 21,9 gł. (cm)
43 szer x 17,8wys (dodatkowa półka
59 szer x 27,7 gł)(cm)
11,5 kg
12V 3W
Descrizione Caratteristiche tecniche
Velocità di cucitura
Lunghezza del punto
1.500 pnt/min max
6mm max
Corsa barra ago
Alzata piedino premistoffa
Ago
Olio lubrificante
Dimensioni della macchina
per cucire
Misura del basamento
Peso della macchina per
cucire
Assorbimento della
lampadina
32mm
7mm / 9mm (12mm tramite
l’alzapiedino a ginocchio)
HAx1 o HLx5 #11, #14
Olio JUKI New Defrix No. 1
45,2(L)x35,0(A)x21,9(P)(cm)
43(L)x17,8(P) (Tavolo ausiliario:
59(L)x27,7(P))(cm)
11,5 kg
12V 3W
Description Caractéristique
Vitesse de couture
Longueur des points
1.500 pts/mn
6mm maxi
Course de la barre à
aiguille
Hauteur de relevage du
pied presseur
Aiguille
Huile lubrifiante
Dimensions de la machine
Dimensions du bras
Poids de la machine
Consommation de la
lampe
32mm
7mm / 9mm (12mm Par genouillère)
HAx1 ou HLx5 #11, #14
New Defrix Oil N°1
45,2 I x 35,0 H x 21,9 L (cm)
43 I x 17,8 L (table auxiliaire: 59 I x
27,7 L)(cm)
11,5 kg
12V 3W

7
Accessories / Akcesoria / Accessoires / Accessori
1. Controller/Thread trimming foot switch
2. Auxiliary table
3. Exclusive screwdriver
4. Screwdriver (small)
5. Cleaning brush
6. Bobbins (4pcs.)
7. Oiler
8. Needles (HAx1)
9. Spool cap
10. Sewing machine cover
11. Power cord
12. Knee lifter lever
13. Hemming foot
14. Zipper attaching foot
15. Even feed foot
16. 1/4 Quilting foot
17. 1/5 Quilting foot
18. Compensating presser foot
1. Regulator obrotów/
nożny przełącznik odcinania nici
2. Dodatkowa półka
3. Specjalny śrubokręt
4. Srubokręt (mały)
5. Pędzelek
6. Szpuleczki (4piezas)
7. Olejnica
8. Igły (HAx1)
9. Trzymak szpulki
10. Pokrywa maszyny
11. Przewód zasilający
12. Kolankowa dźwignia stopki
13. Stopka do obrębiania
14. Stopka do wszywania zamków
15. Stopka wspomagająca transport
16. Stopka do pikowania na 1/4
17. Stopka do pikowania na 1/5
18. Stopka kompensująca
1
2
3
10
11
12
4
13
5
14
6
7
89
15
16
18
17
1. Pédale de commande/Interrupteur au
pied de coupe du fil
2. Table auxiliaire
3. Tournevis spécial
4. Tournevis (petit)
5. Princeau de nettoyage
6. Canettes (4 pc)
7. Huileur
8. Aiguilles (HAx1)
9. Chapeau de bobine
10. Housse de machine
11. Cordon d’alimentation
12. Levier de genouillère
13. Support d’ourlage
14. Pied de pose de fermetures à glissières
15. Pied presseur d’entraînement
supérieur
16. 1/4 Pied ouateur
17. 1/5 Pied ouateur
18. Pied presseur compensateur
1. Combinatore/Interruttore a piede di
taglio del filo
2. Tavolo ausiliario
3. Cacciavite esclusivo
4. Cacciavite (piccolo)
5. Spazzola per pulire
6. Bobine (4 pezzi)
7. Oliatore
8. Aghi (HAx1)
9. Tappo del rocchetto
10. Coperchio della macchina per cucire
11. Cavo di alimentazione
12. Leva alzapiedino a ginocchio
13. Piedino per orlatura
14. Piedino per attaccare chiusura lampo
15. Piedino premistoffa del trasporto
superiore
16. Piedino per trapunte 1/4
17. Piedino per trapunte 1/5
18. Piedino premistoffa compensativo
1. Prowadnik nici na drążku igłowym
2. Śruba na stopce
3. Stopka
4. Dźwignia nawlekacza igły
5. Zacisk igły
6. Igła
7. Transporter
8. Linie pomocnicze
1. Gancio del filo della barra ago
2. Vite nel piedino premistoffa
3. Piedino premistoffa
4. Leva infilaago
5. Grappatura dell’ago
6. Ago
7. Griffa di trasporto
8. Linea direttiva di cucitura
1. Needle bar thread hook
2. Screw in the presser foot
3. Presser foot
4. Needle threader lever
5. Needle clamp
6. Needle
7. Feed dog
8. Sewing guide lines
1
3
2
4
5
6
7
8
Principal Parts / Podstawowe części / Pièces principales / Parti principali
1. Crochet de fil de la barre à aiguille
2. Vis du pied presseur
3. Pied presseur
4. Levier d’enfilage de l’aiguille
5. Vis du pince-aiguille
6 . Aiguille
7. Griffe d’entraînement
8. Ligne de guidage de la couture

Principal Parts / Podstawowe części / Pièces principales / Parti principali
1. Presser foot pressure regulator
2. Indicator of the presser foot pressure
regulator
3. Face plate cover
4. Manual thread cutter
5. Thread tension dial
6. Lamp (built-in type)
7. Slide plate
8. Throat plate
9. Bobbin thread winding shaft
10. Bobbin presser
11. Stitch length adjusting dial
12. Automatic thread trimming switch
13. Needle up/down switch
1. Regolatore di pressione del piedino
premistoffa
2. Indicatore del regolatore di pressione
del piedino premistoffa
3. Coperchio della piastra frontale
4. Tagliafilo manuale
5. Manopola di regolazione della tensione
del filo
6. Lampadina (tipo incassato)
7. Piastra scorrevole
8. Placca ago
9. Albero di avvolgimento del filo della bobina
10. Pressore della bobina
11. Manopola di regolazione della
lunghezza del punto
12. Interruttore di taglio del filo automatico
13. Interruttore di sollevamento/
abbassamento dell’ago
1. Regulator nacisku stopki
2. Wskaźnik nacisku stopki
3. Pokrywa przednia
4. Ręczny obcinacz nici
5. Regulator napięcia nici
6. Lampa (wbudowana)
7. Okienko
8. Płytka gardłowa
9. Trzpień nawijania nici dolnej
(nawijania szpuleczki)
10. Docisk szpuleczki
11. Regulator długości ściegu
12. Przełącznik automatycznego
odcinania nici
13. Przycisk zmiany pozycji igły
14. Dźwignia ściegu wstecznego
15. Przełącznik opuszczania transportera
16. Dziurka na kolankową dźwignię
podnośnika stopki
17. Stożek antywibracyjny
18. Koło ręczne
19. Gniazdo przewodu zasilającego
20. Włącznik zasilania
21. Gniazdo nożnego przełącznika
odcinania nici
22. Gniazdo regulatora
obrotów
23. Drążek podtrzymujący
24. Rączka
25. Prowadnik nawijania nici szpuleczki
26. Dźwignia podnoszenia stopki
27. Szpula
14. Leva di affrancatura
15. Manopola di trasporto a caduta
16. Foro per impostazione della leva
alzapiedino a ginocchio
17. Cono antivibrazione
18. Volantino
19. Entrata del cavo di alimentazione
elettrica
20. Interruttore dell’alimentazione
21. Entrata dell’interruttore a piede di taglio
del filo
22. Entrata del combinatore
23. Asta di supporto
24. Manico
25. Guida dell’avvolgibobina
26. Leva di sollevamento del piedino
premistoffa
27. Perno del rocchetto
14. Reverse feed stitch lever
15. Drop-feed knob
16. Hole for knee lifter lever setting
17. Anti vibration cone
18. Handwheel
19. Inlet of electric power cord
20. Power switch
21. Inlet of thread trimming foot switch
22. Inlet of the controller
23. Support rod
24. Handle
25. Bobbin winder guide
26. Presser foot lifting lever
27. Spool pin
1. Controller
2. Thread trimming foot switch
1. Combinatore
2. Interruttore a piede di taglio del filo
1. Regulator obrotów
2. Nożny przełącznik odcinania nici
8
1. Pédale de commande
2. Interrupteur au pied de coupe du fil 1
2
1. Régulateur de pression du pied presseur
2. Indicateur du régulateur de pression
du pied presseur
3. Couvercle frontal
4. Coupe-fil manuel
5. Bloc-tension du fil
6. Lampe (intégrée)
7. Glissière
8. Plaque à aiguille
9. Axe de bobinage du fil de canette
10. Presseur de canette
11. Cadran de réglage de longueur des points
12. Bouton de coupe automatique du fil
13. Bouton de relevage/abaissement de
l’aiguille
14. Levier de commando d’entraînement
réversible
15. Bouton d’entraînement simple par griffe
16. Orifice pour le montage du levier de
genouillère
17. Cône anti-vibrations
18. Volant
19. Prise de raccordement de la pédale
de commande
20. Interrupteur d’alimentation
21. Prise de raccordement de l’interrupteur
de coupe du fil
22. Prise de raccordement du cordon
d’alimentation
23. Tige de support
24. Poignée
25. Guide de bobineur
26. Levier de relevage du pied presseur
27. Broche porte-bobine
18
17
19
21
20
22
23
24
25
26
27
1
3
9
2
5
7
6
8
10
11
12
13
14
15
16
4

Instalacja regulatora obrotów i nożnego przełącznika odcinania nici
(1) Włóż wtyczkę regulatora (z dwoma czarnymi paskami) do dużego gniazda po
prawej stronie maszyny.
(2) Włóż wtyczkę nożnego przełącznika odcinania nici (z jednym czarnym paskiem)
do małego gniazda po prawej stronie maszyny.
(3) Następnie włóż wtyczkę zasilającą maszynę do gniazda w ścianie.
Installation de la pedale de commande et de l'interrupteur au pied de
coupe du fil.
(1) Brancher la fiche de la pedale de commande (avec deux traits noirs) dans la
grande prise situee sur le cote droit.
(2) Brancher la fiche de l'interrupteur au pied de coupe du fil (avec un trait noir) dans
la petite prise situee du cote gauche.
(3) Brancher en dernier la fiche d'alimentation a une prise murale.
Installazione del combinatore e interruttore a piede di taglio del filo
(1) Inserire la spina del combinatore (con due linee nere) nell’entrata grande sul lato destro.
(2) Inserire la spina dell’interruttore a piede di taglio del filo (con una linea nera) nell’entrata piccola sul lato sinistro.
(3) Quindi, inserire il cavo di alimentazione alla presa di corrente.
Name and Function of each component / Nazwy i funkcje poszczególnych części /
Nomenclature et fonction des pièces / Nome e funzione di ciascun componente
Installing the auxiliary table
Raise the two latches of the table, then install the table on the sewing machine.
Open the cover of the auxiliary table when replacing the bobbin thread.
There are connecting points at [1] and [2]. Insert the table into them.
Instalacja dodatkowej półki
Unieś dwa zatrzaski półki, następnie zainstaluj półkę na maszynie.
Otwórz pokrywę dodatkowej półki gdy wymieniasz szpuleczkę.
Istnieją dwa punkty mocujące [1] i [2]. Zamontuj w nich maszynę.
Installation de la table auxiliaire
Relever les deux loquets de la table, puis installer la table sur la machine à coudre.
Pour remplacer la canette, ouvrir le couvercle de la table auxiliaire.
Il y a des points d’accouplement en [1] et [2]. Y introduire la table.
Installazione del tavolo ausiliario
Sollevare i due chiavistelli del tavolo, quindi installare il tavolo sulla macchina per cucire.
Aprire il coperchio del tavolo ausiliario quando si sostituisce il filo della bobina.
Ci sono punti di collegamento a [1] e [2]. Inserire il tavolo in questi.
Installing the controller and the thread trimming foot switch
(1) Insert the controller plug (with two black lines) into the large inlet on the right side.
(2) Insert the thread trimming foot switch plug (with one black line) into the small
inlet on the left side.
(3) Then, insert the power plug into the wall outlet.
Perform these following steps when
you are not using your sewing machine.
1. Be sure to turn OFF the power switch.
2. Be sure to remove the power plug from the wall outlet.
3. Do not place a thing on the controller.
Wykonaj następujące czynności gdy nie
używasz maszyny:
1. Wyłącz zasilanie
2. Wyjmij wtyczkę zasilającą z gniazda w ścianie.
3. Niekładź przedmiotów na regulatorze obrotów
CAUTION:
In case these power plugs are mistakenly inserted while the power cord is
inserted, it will cause the trouble.
Turn ON the power after inserting the thread trimming foot switch plug.
Do not insert the thread trimming foot switch plug when the power is turned ON.
UWAGA:
Jeżeli będziesz podłączać te wtyczki podczas gdy maszyna jest włączona
może to spowodować problemy.
Włącz zasilanie po podłączeniu nożnego przełącznika odcinania nici.
Nie podłączaj nożnego przełącznika odcinania nici gdy zasilanie jest włączone.
ATTENZIONE: Nel caso che questi cavi di alimentazione vengano inseriti erroneamente mentre il cavo di alimentazione è inserito, ciò
causerà l’inconveniente. Accendere la macchina dopo aver inserito la spina dell’interruttore a piede di taglio del filo. Non
inserire la spina dell’interruttore a piede di taglio del filo quando la macchina è accesa.
CAUTION:
UWAGA:
9
Controller cord
(Plug)
Przewód
regulatora
obrotów (wtyczka)
Cable del
controlador
(Enchufe)
Cavo (spina) del
combinatore
Thread trimming foot
switch cord (Plug)
Przewód
nożnego przełącznika
odcinania nici (wtyczka)
Cable del interruptor
de pie del cortahilos
(Enchufe)
Cavo (spina)
dell’interruttore a
piede di taglio del filo
(1)
(2)
(3)
Effettuare questi seguenti passi
quando non si sta usando la macchina per cucire.
1. Non mancare di spegnere l’interruttore
dell’alimentazione.
2. Non mancare di staccare la spina dalla presa di corrente.
3. Non mettere alcun oggetto sul combinatore.
ATTENZIONE:
AVERTISSEMENT:
Veiller a ne pas connecter incorrectement ces fiches d'alimentation lorsque le cor-
don d'alimentation est branche car ceci pourrait causer une anomalie.
Mettre la machine sous tension après avoir inséré la fiche de l’interrupteur au pied
de coupe-fil.
Ne pas insérer la fiche de l’interrupteur au pied de coupe-fil lorsque la machine est
sous tension.
[1]
[2]
(4)
[2] [1]
Effectuer ces opérations
lorsque la machine est inutilisée.
1. Placer l’interrupteur d’alimentation sur arrêt.
2. Débrancher la fiche d’alimentation de la prise murale.
3. Ne rien placer sur le contrôleur.
AVERTISSEMENT:
