JUKI MO-735 User manual

Instruction Manual
Gebruiksaanwijzing
Bedienungsanleitung
Manuel d’instructions
MO-735
2-Needle, 2/3/4/5-Thread Overlock+Cover Stitch Sewing Machine
2-naalds, 2/3/4/5-draadsOvelock- en coversteekmachine
Überwendlich-Nähmaschine Mit 2 Nadeln, 2/3/4/5 Fäden+Cover Stich
Surjeteuse-Raseuse 2 Aiguilles, 2/3/4/5 Fils+Point Enveloppant
WICHTIG:
Alle sicherheitsvorschriften vor gebrauch der
nähmaschinesorgfältigdurchlesen.
BewahrenSiediesebedienungsanleitungfürweitere
bezüge auf.
BELANGRIJK:
Leesalle veiligheidsvoorschriftenzorgvuldig door
en zorg ervoor dat u deze begrijpt voordat u deze
naaimachinegaatgebruiken.
Bewaar deze instructies voor later gebruik.
IMPORTANT:
Avant de mettre la machine en marche, lire
attentivement et assimiler les regles de securite de
cemanuel.
Conserver le manuel afin de pouvoir le consulter ul
terieurement.
IMPORTANT:
Read all safety regulations carefully and under-
stand them before using your sewing machine.
Retain this instruction manual for future reference.

1
“IMPORTANT SAFETY INSTRUCTIONS”
When using an electrical appliance, basic safety precautions should always be followed, including the following: Read all instructions before
using this overlock sewing machine.
“DANGER_____To reduce the risk of electric shock:”
1. The appliance should never be left unattended when plugged in.
2.Always unplug this appliance from the electric outlet immediately after using and before cleaning.
3.Always unplug before re-lamping. Replace bulb with same type rated max.15W (120V), max.10W (220-240V) for model MO-735.
“WARNING_____To reduce the risk of burns, fire, electric shock, or injury to persons:”
1. Do not allow this appliance to be used as a toy. Close attention is necessary when this appliance is used by or near children and infirm
persons.
2. Use this appliance only for its intended use as described in this manual. Use only attachments recommended by the manufacturer as
contained in this manual.
3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or dropped
into water. Return the appliance to the nearest authorized dealer or service center for examination, repair, electrical or mechanical
adjustment.
4. Never operate the appliance with any air openings blocked. Keep ventilation openings of the sewing machine and foot control free from
the accumulation of lint, dust, and loose cloth.
5. Keep fingers away from all moving parts. Special care is required around the sewing machine needle and knife.
6. Always use the proper stitch plate. The wrong plate can cause the needle to break.
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deflect the needle causing it to break.
9. Switch the sewing machine off ''O'' when making any adjustments in the needle area, such as threading needle, changing needle,
threading looper, or changing presser foot and the like.
10. Always unplug the machine from the electrical outlet when removing covers, when covers are opened to raise the knife or thread the
loopers, when lubricating or when making any other user servicing adjustments mentioned in the instruction manual.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
14. To disconnect, turn all controls to the off ''O'' position, then remove plug from outlet.
15. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
16. Basically, the machine should be disconnected from the electricity supply when not in use.
17. If the power cord of this appliance is damaged, it must be replaced with a special cord by your nearest authorized dealer or service
center.
18. This appliance is provided with double insulation. (except USA/CAN)
Use only identical replacement parts. See instructions for servicing double insulated appliances.
19. If oil gets in eyes, immediately, rinse the oil out with water. If you swallow oil by mistake, immediately consult a medical doctor.
“SERVICINGDOUBLE-INSULATED PRODUCTS
(USA and Canada version excepted)”
In a double-insulated product, two systems of insulation are provided instead of grounding. No grounding means is provided on a double-
insulated product nor should a means for grounding be added to the product. Servicing a double-insulated product requires extreme care
and knowledge of the system and should only be done by qualified service personnel. Replacement parts for a double-insulated product
must be identical to those parts in the product. A double-insulated product is marked with the words DOUBLE INSULATION or DOUBLE
INSULATED.
The symbol may also be marked on the product.
“SAVE THESE INSTRUCTIONS”
''This overlock sewing machine is intended for household use only.''

2
“BELANGRIJKE VEILIGHEIDSINSTRUCTIES”
Alsu eenelektrisch apparaat gebruikt, moet u altijd de basis veiligheidseisen in het oog houden, inclusief deze:
Leesalleinstructies voordat udeze naaimachine gaat gebruiken.
“GEVAAR!_____Voorkom een elektrische schok.”
1.Laat hetapparaat nooitalleen met de stekker in het stopcontact.
2.Haal destekker van het apparaat altijd uit het stopcontact na gebruik en voor reiniging.
3. Haal de stekker van het apparaat altijd uit het stopcontact voordat u het lampje (max 10 Watt) verwisselt.
“WAARSCHUWING!_____Voorkom brand, een elektrische schok of andere verwondingen.”
1. Laat dit apparaat niet als speelgoed gebruiken. Let goed op als u dit apparaat in de buurt van kinderen gebruikt.
2. Gebruik het apparaat alleen voor de doelen waarvoor het gemaakt is, zoals beschreven in deze gebruiksaanwijzing.
Gebruik alleen toebehoren aanbevolen door de fabrikant en beschreven in deze gebruiksaanwijzing.
3. Gebruik dit apparaat nooitals de snoerenof de stekker beschadigd zijn,het niet goedfunctioneert, is gevallen of beschadigdof nat geworden
is. Laat het apparaat nakijken bij de dichtstbijzijnde dealer of servicepunt voor onderzoek en reparatie.
4.Gebruik het apparaat nooitmetgeblokkeerdeluchtopeningen.
Houd de ventilatieopeningen van de machine en de voetpedaal vrij van stof, kleding en afval.
5. Houdt uw vinger weg bij bewegende delen. U moet vooral opletten in de buurt van de naalden en het mes.
6.Gebruikaltijd de juiste steekplaat.Eenverkeerde steekplaat kan naaldbreukveroorzaken.
7. Gebruik geen verbogen naalden.
8. Duw of trek niet aan de stof terwijl u naait. Hierdoor kan de naald verbuigen en breken.
9.Schakel de machine uit“O”als u aanpassingenuitvoertin de buurt vandenaald, zoals naaldverwisselenof draad inrijgen vannaaldof grijper,
of bij het verwisselen van de naaivoet en dergelijke.
10. Haal de stekker van het apparaat altijd uit het stopcontact bij het openen van de machine, bij het opstellen van het mes, of het bedraden van
de grijpers, bij het smeren, of andere onderhoudswerkzaamheden beschreven in deze gebruiksaanwijzing.
11. Stop nietsin welkeopening dan ook.
12.Gebruikdemachine nietbuiten.
13. Gebruik de machine niet terwijl er spuitbussen of zuurstof gebruikt worden.
14. Bij het uitschakelen zet u eerst de hoofdschakelaar op “O” en vervolgens trekt u de stekker uit het stopcontact.
15. Trek aan de stekker, niet aan het snoer.
16.Als de machine niet gebruikt wordt, hoort de stekker niet in het stopcontact.
17.Als het snoer is beschadigd, moet het vervangen worden door de dichtstbijzijnde dealer of servicepunt.
18.Dit apparaat isvoorzien vandubbele isolatie.
Gebruikalleen identiekevervangingsonderdelen. Ziede instructiesvoor hetonderhoud vandubbel geïsoleerdeapparaten.
19.Als er olie in uw ogen komt, spoel dan meteen met water.Als u olie naar binnen krijgt, consulteer direct uw huisarts.
“ONDERHOUD VAN DUBBEL
GEÏSOLEERDE PRODUCTEN”
In een dubbel geïsoleerd product zijn er twee isolatie systemen geïnstalleerd in plaats van de gewone aarde.
Er is geen gewoon aardingsysteem aangebracht en hoeft niet aangebracht te worden. Onderhoud op een dubbel geïsoleerd product moet zeer
zorgvuldig en met verstand van zaken worden gepleegd. Gebruik alleen identieke vervangingsonderdelen. Een dubbel geïsoleerd product is
gemerkt met de woorden Double insulation of Double insulated.
Het symbool bevindt zich meestal op het betreffende apparaat.
“BEWAAR DEZE INSTRUCTIES”
DezeOverlocknaaimachineis alleenbedoeldvoorhuishoudelijkgebruik.

3
“WICHTIGE SICHERHEITSHINWEISE”
BeimGebraucheineselektrischenGerätes sind folgende Sicherheitsmassnahmenzubeachten:
“GEFAHR_____Zum Schutz vor elektrischem Schlag:”
1.Die Overlockmaschine nieunbeaufsichtigt stehen lassen,solange sie am Stromnetz angeschlossenist.
2.NachGebrauchundvoreinerReinigungdieMaschineimmervom Stromnetz trennen.
3.VoreinemGlühlampenwechselimmerNetzsteckerherausziehen.MO-735:max.15W(120V),max.10W(220-240V), Glühlampenverwenden.
“ACHTUNG_____Zum Schutz vor Verbrennungen, Brand, elektrischem Schlag und Verletzungen
von Personen:”
1. Die Overlockmaschine nicht als Spielzeug benutzen. Erhöhte Vorsicht ist geboten, wenn die Maschine von Kindern oder in der Nähe von
Kindern gebraucht wird.
2. DieOverlockmaschine nurzu dem in diesemAnleitungsbuchbeschriebenenZweck benutzen. Es ist nur das vomHersteller empfohlene
Zubehör zu verwenden.
3. Die Overlockmaschine nicht benutzen, falls Kabel oder Stecker beschädigt sind, die Maschine nicht störungsfrei näht, sie auf den Boden
oder ins Wasser fallengelassen oder beschädigt wurde. Bringen Sie Ihre Overlockmaschine zum nächstgelegenen Händler oder
entsprechenden Fachmann zur Überprüfung oder Reparatur.
4. Bei Gebrauch der Overlockmaschine Lüftungsschlitze nicht blockieren und diese freihalten von Fusseln, Staub und Stoffrückständen.
5. Fingervon allen beweglichenTeilen fernhalten. Spezielle Vorsicht ist im Bereichder Overlock-Nadelnund-Messer geboten.
6.ImmereineoriginalOverlock-Stichplatte benutzen. Eine falscheStichplattekannzu Nadelbruch führen.
7.KeinekrummenNadelnbenutzen.
8. Während des Nähens den Stoff weder ziehen noch stossen. Das kann zu Nadelbruch führen.
9. Hauptschalter immer auf „O“ stellen bei Tätigkeiten im Bereich der Nadeln wie Einfädeln, Nadeln wechseln, Nähfuss wechseln, usw.
10.Bei denimAnleitungsbuch aufgeführten Unterhaltsarbeiten bei geöffneter Maschine, wie Greifer einfädeln, Messer hochstellen,Ölen,
Glühlampen wechseln usw. die Overlockmaschine vorher immer vom Stromnetz trennen.
11.Keine Gegenständein Öffnungen an derMaschine stecken.
12.DieOverlockmaschinenichtimFreienbenutzen.
13. Die Overlockmaschine nicht benutzen wo Treibgasprodukte (Sprays) oder Sauerstoff verwendet werden.
14. ZumAusschalten Hauptschalter auf „O“ stellen und Stecker herausziehen.
15.BeimTrennenvomStromnetzimmeramSteckerundnichtamKabelziehen.
16. Grundsätzlich sollte das Gerät bei Nichtgebrauch durchAusziehen des Steckers vom Stromnetz getrennt werden.
17.Wenn das elektrischeKabel beschädigt ist,muss es durch ein originalKabel von Ihremnächstgelegenen Händler oderService Center
ersetzt werden.
18. Wenn Öl insAuge eindringt, dann sofort das Öl mit wasser ausspülen. Wenn Sie Öl versenentlich schlucken,dann sofort einen
Art beraten.
“WARTUNG DOPPELISOLIERTER PRODUKTE”
EindoppelisoliertesProduktistmitzweiIsolationseinheitenanstelleeinerErdungausgestattet.EinErdungsmittelistineinemdoppelisoliertenProdukt
nicht enthalten und sollte auch nicht eingesetzt werden. Die Wartung eines doppelisolierten Produktes erfordert höchste Sorgfalt und beste
Kenntnissedes Systemsund solltedaher nurvon qualifiziertemPersonal vorgenommenwerden. Verwenden Sie für Service und Reparatur nur
Original-Ersatzteile.EindoppelisoliertesProduktistfolgendermassen gekennzeichnet:„Doppelisolierung“oder„Doppeltisoliert“.
Das Symbol kann ebenfalls ein solches Produkt kennzeichnen.
“SICHERHEITSHINWEISE SORGFÄLTIG
AUFBEWAHREN”
DieseOverlockmaschineistnurfürdenHaushaltgebrauchbestimmt.

4
“PRESCRIPTIONS DE SECURITE IMPORTANTES”
L’emploi d’un appareil électrique exige d’observer les mesures de sécurité suivantes:
“DANGER_____Pour la protection contre tout choc électrique:”
1. Ne pas laisser la surjeteuse sans surveillance tant qu’elle est raccordée au réseau.
2.Après usage et avant un nettoyage, séparer toujours la machine du réseau.
3.Retirerlaficheduréseaupourchangeruneampoule.EmployerdesampoulespourmodèleMO-735:max.15W(120V),max.10W(220-240V).
“ATTENTION_____Pour éviter des brûlures, un feu, un choc électrique ou des blessures de
personnes:”
1. Ne pas prendre la surjeteuse pour un jouet. La plus grande prudence est de mise quand la machine est utilisée par des enfants ou se trouve
à leur proximité.
2.Utiliserlasurjeteuseseulementdanslebutd’accomplirlestravauxdécritsdanscemoded’emploi.N’employerquelesaccessoiresrecommandés
par le fabricant.
3. Ne pas employer lasurjeteuse, si les cordons oules prises sont abîmés, sielle ne fonctionne pas sansproblèmes, si elleest tombée par terre
ou dans l’eau, ou bien a été endommagée.Apporter votre surjeteuse pour réparation ou vérification auprès de l’agent le plus proche ou du
spécialiste correspondant.
4. Durant l’emploi de la surjeteuse, ne pas boucher les fentes d’aération ainsi que la pédale par des bouts de fil, de la poussière et des déchets
de tissu.
5. Eloigner les doigts detoute pièce en mouvement. Uneprudence toute particulières’impose àproximité des aiguilleset des couteaux de la
surjeteuse.
6. Utiliser toujours la plaqueà aiguille originalede la surjeteuse. Une plaqueerronée peut provoquerla cassure de l’aiguille.
7. Ne pas utiliser d’aiguilles courbées.
8. Durant la couture, ne pas tirer sur le tissu, ni le pousser, cela peut provoquer la cassure de l’aiguille.
9.Placerl’interrupteurprincipalsur«O» lors de toute activitéàproximitédesaiguilles, par ex. pour enfiler, changer d’aiguilleoudepied-de-biche,
etc.
10.Prièredetoujoursretirerlapriseduréseaulorsquevous effectuez, sur la surjeteuse ouverte,destravauxd’entretienmentionnésdanslemode
d’emploi,commel’enfilage des boucleurs,lerelèvement du couteau,l’huilage,le changement desampoules,etc.
11. Ne pas introduire d’objets dans les ouvertures dela machine.
12.Ne pas employer lasurjeteuse en pleinair.
13. Ne pas employer la surjeteuse dans un local où l’on utilise des produits avec gaz propulseur (spray) ou de l’oxygène.
14. Pour la mise hors service, placer le commutateur principal sur «O» et retirer la fiche du réseau.
15. Débrancher en tirant sur la fiche et non sur le cordon.
16. En cas de non utilisation, l’appareil doit, en principe, être séparé du réseau en retirant la prise.
17. Si le câble électrique est endommagé, il doit être remplacé par un câble original chez l’agent le plus proche ou dans un centre du service
après-vente.
18.Si de I’huilevienten cntact avecles yeux, lesrincer immëdiatement avecde I’eau. Encasd’absorption accidentelle d’huile,
consulterimmëdiatementunmëdecin.
“ENTRETIEN DES PRODUITS A DOUBLE ISOLATION ”
Unproduità double isolationest équipé de deuxisolations au lieud’unemise à laterre. La mise àla terre n’estpasprévue sur unproduit à double
isolationetnedevraitdoncpasêtreemployée.L’entretiend’unproduitàdoubleisolationquiexigedegrandssoinset desconnaissancespoussées
surlesystème,doitdonc être réalisé seulementpardupersonnelqualifié. N’employer que des piècesderechangeoriginalespourl’entretien et la
réparation.Unproduitàdouble isolation est désignédelamanièresuivante: “Isolation double” ou“Adoubleisolement”.
Le symbole peut également caractériser un tel produit.
“PRIERE DE CONSERVER SOIGNEUSEMENT LES
PRESCRIPTIONS DE SECURITE”
Cettesurjeteuseest destinée seulement àunusage familial.

5
Contents / inhoud
Safetyregulations·········································1
Contents··························································5
Detailsofthemachine·······························7,8
•Accessories···············································8
Preparingthe machine ································9
•Attaching the footcontrol ·························· 9
•Threadstand·············································10
• Placing the spool holder for the chain
thread····························································10
• Thread, cones, spools ····························11
Using the machine
•Power/light switch···································12
• Raising the upper knife ·························· 12
• Two step presser foot lifter with
integratedfront foot lift····························· 13
• Changing the presser foot ····················· 13
•Loopercover·············································14
•Clothplate·················································14
•Handwheel················································14
• Inserting needles / Needles
/Threads·············································15-17
Adjustments and settings
•Stitchlength··············································18
•Cuttingwidth·············································18
•Differentialfeed·········································19
•Gathering·················································20
• Upperlooper converter··························· 21
•Rollhemming···········································21
• Presser foot pressure····························· 22
•Sewingintape··········································22
Setting/Practical sewing
•Threadbreakage······································23
•Unpickingseams······································23
•Preparation/Tips········································24
Stitchchart··············································25,26
Threading 4/3 Thread OL
•Upperlooper·············································33
•Lowerlooper············································ 34
•Rightneedle·············································35
•Leftneedle················································36
• ThreadingChain looper··························37
Threadingchainstitch needle···················· 38
Threading Chainstitch and OL ················· 39
Trial sewing, thread tension ·············· 40-42
Cover/chainstitchfunctions·······················43
• General operating instructions ············· 44
• Knife guard / cover and chain stitch
extensionplate··········································45
Cover stitch threading
• Threading cover stitch looper ··············· 46
• Cover stitch R needle ····························· 47
• Cover stitch C needle ····························· 48
• Cover stitch Lneedle ······························ 49
Threading 3 thread cover stitch (wide) ··· 50
Threading 3 thread cover stitch (narrow) 51
Threadingchainstitch·································52
Coverstitch sewingtest····························· 53
Chainstitchsewingtest ······························53
Tensionadjustments···································54
Belangrijke veiligheidsinstructies ············· 2
Inhoud·······························································5
Detailsvandemachine·····························7,8
•Accessoires················································8
Hetvoorbereidenengebruikvandemachine ·········9
• Het aansluiten van de voetpedaal ·········· 9
•Dedraadgeleider······································10
• Het plaatsen van de extra garenkloshouder
voor de kettingsteek draad ····················· 11
•Garenklosopzetten··································11
Gebruik van de machine
• Stroom-licht schakelaar ·························12
• Het instellen van het bovenmes ··········· 12
• Tweestaps naaivoethefboom met
geïntegreerdevoorvoetheffer··················13
• Verwisselen van de naaivoet ················ 13
•Grijperbeschermkap·······························14
•Werkvlak·······················································14
•Handwiel······················································14
• Bevestigen van de naalden /
Naald en garen ··································15-17
Instellingen en gebruik
•Steeklengte·················································18
•Snijbreedte··················································18
•Differentieeltransport·······························19
•Rimpelen·····················································20
•Bovengrijperconverter·····························21
•Rolzomen···················································21
•Naaivoetdruk·············································22
•Innaaienvanband····································22
De coverstitch in de praktijk
• Veiligstellen van het zoomeinde bij de
coverstitch ···················································55
• Uithalen van de coverstitch ···················· 55
•Eenvoudigezoom·····································56
•Platteverbindingsnaad····························56
•Zomen metelastiek································· 57
•Band······························································57
• Zoom, strook, belegsel of garnering
opstikken·····················································58
De kettingsteek in de praktijk
• Rimpelen met de kettingsteek ············· 59
•Band······························································59
Onderhoud
• Het bovenmes vervangen······················ 60
• Hetondermes vervangen······················· 60
• Vervangen van hetlampje ······················ 61
• Schoonmaken en smeren ····················· 61
Verhelpenvan storingen····························63
Technischegegevens··································66
Optioneleaccessoires······························· 68
Bedienen en praktisch naaien
• Draadbreuk tijdens het naaien ············· 23
•Zoomuithalen············································23
• Voorbereiden van het inrijgen, tips ······ 24
Stekenoverzicht·······································27,28
Inrijgen 4/3 draads overlock
•Bovengrijper················································33
•Ondergrijper················································34
•Rechternaald·············································35
•Linkernaald················································36
• Inrijgen van de kettingsteekgrijper ······· 37
Inrijgen van de kettingsteeknaald ············ 38
Inrijgen, kettingsteek en overlock ············· 39
Proefnaaien, draadspanning ············· 40-42
Coverstitch en kettingsteek functies ········ 43
•Algemene bedieningsaanwijzingen ····· 44
• Mesbeschermer en cover- en
kettingsteek aanschuifplaat···················· 45
Inrijgen van de coverstitch
• Inrijgen van de coverstitch grijper ········· 46
• Coverstitch rechter (R) naald ················ 47
• Coverstitch middel (C) naald ················ 48
• Coverstitch linker (L) naald ··················· 49
Inrijgen van de 3-draads coverstitch
(breed) ·························································50
Inrijgen van de 3-draads coverstitch
(smal)····························································51
Inrijgen van de 2-draads kettingsteek ···· 52
Coverstitchnaaitest······································53
Kettingsteeknaaitest···································53
Aanpassing van de spanningen ·············· 54
Practical sewing-Cover stitch
• Securing the seam end ·························· 55
•Unpickingseams······································55
•Simplehem···············································56
•Flatjoiningseam······································56
•Edgewithelastic ······································57
•Binding······················································57
• Top stitching seams/ribbing/yokes ······ 58
Practical sewing-chain stitch
•Gathering···················································59
•Binding·····················································59
Maintenance
• Changing the upper knife ······················ 60
• Changing the lower knife ······················· 60
•Replacingthebulb ···································61
• Cleaning and lubricating ························ 61
Troubleshootingguide·······························62
Technicaldata··············································66
Optionalaccessories··································68

6
Inhalt / Table des matières
Sicherheitsvorschriften·································3
Inhalt·································································6
DetailsderMaschine··································7,8
•Zubehöre·····················································8
Maschine bereitstellen / Inbetriebnahme ···· 9
• Fussanlasser anschliessen ·················· 9
•Fadenführung···········································10
• Befestigen des Spulenhalters für
Kettenfaden···············································10
•Fadenspulenaufsetzen···························11
Inbetriebnahme
• Haupt- und Lichtschalter ························ 12
• Zweistufen Nähfusslifterhebel mit
integriertem Nähfussspitzen -Anheber ··· 13
• Nähfuss auswechseln···························· 13
•Greiferdeckel············································14
•Stoffauflagedeckel····································14
•Handrad····················································14
• Obermesser hochstellen/senken ········· 12
• Nadeln einsetzen / Nadlen / Faden ···· 15-17
Einstellen und Bedienen
•Stichlänge··················································18
•Messerposition··········································18
•Differentialtransport···································19
•Einreihen···················································20
•Obergreiferabdeckung·····························21
•Rollsäumen···············································21
•Nähfussdruck············································22
•Bandannähen···········································22
Cover Stich Nähprobe und
Sticheinstellung········································53
KettenstichNähprobe··································53
Fadenspannung anpassen ······················ 54
Cover Stich praktisches Nähen
• Nähende, Stiche sichern························ 55
•Sticheauftrennen·····································55
•EinfacherSaum········································56
•FlacheVerbindungsnaht·························56
• Saum mit eingenähtem Elast ··············· 57
•Einfassungen············································57
• Naht / Bund / Besatz absteppen ··········· 58
Kettenstich Praktisches Nähen
• Kräuseln mit Kettenstich ························ 59
•Einfassungen············································59
Wartung
• Achtung: Beachten Sie die
Sicherheitshinweise!······························· 60
• Untermesser auswechseln ··················· 60
•Glühlampewechseln·······························61
•ReinigenundÖlen··································· 61
HilfebeiStörungen······································64
TechnischeDaten········································67
Sonderzubehör·············································68
Bedienen, Praktisches Nähen
• Fadenreissen während des Nähens ······ 23
•Sticheauftrennen······································23
• Einfädeln vorbereiten / Tipps ················ 24
Stichübersicht·········································29,30
Einfädeln 4/3 Faden OL
•ObererGreiferfaden··································33
•UntererGreiferfaden·································34
•RechteNadel············································35
•LinkeNadel···············································36
• Kettenstich Greifer einfädeln ················ 37
EinfädelnkettenstichNadel ·······················38
Kettenstich einfädeln und OL ·················· 39
Nähprobe, Fadenspannung ··············· 40-42
CoverStichFunktionen······························43
•Allgemeine Bedienungshinweise ········· 44
• Messerabdeckung / Cover-/ Kettenstich-
Abdeckung wechseln ····························· 45
Cover Stich einfädeln
• Cover Stich Greifer einfädeln ················ 46
• Cover Stich Nadel R einfädeln ·············· 47
• Cover Stich Nadel C einfädeln ·············· 48
• Cover Stich Nadel L einfädeln ·············· 49
3 Faden Cover Stitch einfädeln (Breit) ···· 50
3 Faden Cover Stitch einfädeln (Schmal) ··· 51
2 Faden Kettenstich einfädeln ·················· 52
Consignes de sécurité ································ 4
Table des matières ····································· 6
Détailsdelamachine ································7,8
•Accessoires···············································8
Préparation de la machine
/mise enservice ········································ 9
• Raccordement de la pédale ···················· 9
•Guide-fil·····················································10
• Fixer le support de bobine prévu pour
le fil de point chaînette ···························· 10
• Mise en place des bobines de fil ·········· 11
Mise en service
• Commutateur principal et interrupteur
delumière··················································12
• Levier du pied-de-biche à deux positions
avec releveur intégré des pointes du
pied-de-biche··········································· 13
• Remplacement du pied-de-biche ········ 13
•Couvercle duboucleur ····························14
•Plateaudetravail·····································14
•Volant····························································14
• Relever et abaisser le couteau
supérieur·················································· 12
• Mettre les aiguilles en place
/Aiguilles / Fill ···································· 15-17
Réglage et utilisation
•Longueurdepoint····································18
•Positiondu couteau·································18
•Entraînementdifférentiel·························19
•Fronçage···················································20
• Recouvrement du boucleur supérieur ···· 21
•Ourletsroulés···········································21
• Pression du pied-de-biche ···················· 22
•Posederuban··········································22
Enfilage pour le point enveloppant
à 3fils (étroit)············································ 51
Enfilage du point de chaînette à 2 fils ····· 52
Test de couture et réglages du point
enveloppant··············································53
Test dupoint de chaînette ························· 53
Adapterlatension········································54
Couture pratique avec le point enveloppant
• Extrémité de la couture, arrêter les
points,point enveloppant ························55
•Défairelespoints·····································55
•Ourletsimple············································56
• Couture d’assemblage plate ················ 56
• Ourlet avec un élastique fixé par une
couture······················································57
•Entourages················································57
• Couture / Ceinture / Surpiquer une
parmenture················································58
Couture pratique avec le point de chaînette
• Fronces avec point de chaînette ·········· 59
•Entourages···············································59
Maintenance
• Attention: respecter les prescriptions
desécurité················································60
• Remplacement du couteau inférieur ·· 60
• Remplacement de l’ampoule ··············· 61
•Nettoyageethuilage································61
Commentéliminersoi-mêmelespannes ············65
Caractéristiques··········································67
Accessoiresspéciaux··································68
Couture pratique
• Cassure du fil durant la couture ··········· 23
• Découdreune couture···························· 23
• Préparer l’enfilage / conseils ················ 24
Récapitulationdes points····················· 31,32
Enfilage du point de surjet à 4/3 fils
• Fil de boucleur supérieur ······················· 33
• Fil de boucleur inférieur ························· 34
•Aiguillededroite·······································35
•Aiguilledegauche····································36
• Enfiler le boucleur pour le point
dechaînette···············································37
Enfilagepoint dechaînette ························38
Enfilage point de chaînette et surjet ······· 39
Essai de couture, tension de fil ········· 40-42
Fonctions du point enveloppant ··············· 43
• Chaînette et indications générales sur
sonutilisation·············································44
• Plaquette de recouvrement du point
enveloppant/dechaînette ························45
Enfilage pour le point enveloppant
• Enfilage du boucleur pour le point
enveloppant··············································46
• Enfiler l’aiguille (droite) R pour le point
enveloppant··············································47
• Enfiler l’aiguille (centre) C pour le point
enveloppant··············································48
• Enfiler l’aiguille (gauche) L pour le point
enveloppant··············································49
Enfilage pour le point enveloppant
à 3fils (large)············································ 50

7
Details of the machine / Details van de machine
Details der Maschine / Détails de la machine
1
2
3
4
5
678910
11
12
15 16
17
18
19
20
21
22
23
24
25
13
14
1
2
3
4
5
6
Details of the machine
1. Looper cover with built in knife guard
2. Looper cover opening indent
3.Cloth plate
4. Sewing light
5. Thread take-up cover
6. Presser foot pressure regulating
knob
7. Left needle thread tension dial
8. Right needlethread tension dial
9. Upper looper thread tension dial
10. Lower looper thread tension dial
11.Retractable supportrod
12.Threadguidesupport
13.Openthreadguide
14.Spoolholderpin
15.Foampad
16.Anti - vibration cone
17.Threadstand
18.Stitchlengthadjustmentdial
19.Differentialfeedadjustment dial
20.Handwheel
21.Side cover
22.Matchingupmarks
23.Machinesocket
24. Power/Light switch
25.Knife guard
Details of the machine
1.Thread cutter
2. Presser foot lifter
3.Stitchplate
4. Presser foot
5.Upperknife
6.Needleclamp
Details der Maschine
1. Greiferdeckelmit integrierter
Messerabdeckung
2. Führung zum öffnen des
Greiferdeckels
3. Stoffauflagedeckel
4. Nählicht
5.Fadenhebel-Abdeckung
6. Nähfussdruck- Regulierknopf
7.LinkeNadelfadenspannung
8.RechteNadelfadenspannung
9. Obergreifer Fadenspannung
10.UntergreiferFadenspannung
11.Ausziehbarer Fadenführungsstab
12.Fadenführungsaufsatz
13.Offene Fadenführung
14.Spulenhalterstift
15.Schaumstoffauflage
16.Vibrationshemmer
17.Garnrollenständer
18.Wahlknopf für Stichlänge
19.Wahlknopf fürDifferentialtransport
20.Handrad
21.Seitenabdeckung
22.MarkierunganHandrad und
Seitenabdeckung
23.Maschinensteckdose
23.Haupt- und Lichtschalter
25.Messerabdeckung
Onderdelen van de machine
1.Draadafsnijder
2.Naaivoethefboom
3.Steekplaat
4.Naaivoet
5.Bovenmes
6.Naaldklem
Details der Maschine
1.Fadenabschneider
2.Nähfusslifterhebel
3.Stichplatte
4. Nähfuss
5.Obermesser
6.Nadelhalter
Détails de la machine
1.Coupe-fil
2.Levier dupied-de-biche
3.Plaqueàaiguille
4.Pied-de-biche
5.Couteausupérieur
6.Porte-aiguille
Détails de la machine
1. Couvercle des boucleurs avec
recouvrement du couteau intégré
2. Guide pour ouvrir le couvercle des
boucleurs
3. Plateau detravail
4.Eclairage/ampoule
5. Couvercle du tendeur de fil
6. Bouton de réglage de la pression du
pied
7.Tension dufil d’aiguillede gauche
8.Tension dufil d’aiguillede droite
9. Tension supérieure du fil de boucleur
10. Tension inférieure du fil de boucleur
11.Support de guide-filtélescopique
12.Garnituredeguidage
13.Guide-fil ouvert
14.Broche
15.Socle en mousse
16.Antivibreurs
17. Support de broches à bobines
18.Sélecteur pour longueurde point
19.Sélecteurpourentraînementdifférentiel
20.Volant
21.Capotlatéral
22.Repèressurlevolantet le capot latéral
23.Prisedelamachine
24.Commutateurprincipaletinterrupteur
de lumière
25.Recouvrementducouteau
Onderdelen van de machine
1.Grijper beschermkap met
geïntegreerdemesbescherming
2.Grijperbeschermkapopeningsplek
3. Werkvlak
4. Verlichting
5.Draadhefboombeschermkap
6.Naaivoetdruk-regelknop
7.Linkernaald draadspanningsregelaar
8.Rechternaalddraadspanningsregelaar
9.Bovengrijper draadspanningsregelaar
10.Ondergrijperdraadspanningsregelaar
11.Uitschuifbaredraadgeleiderstang
12.Draadgeleiderbevestiging
13.Draadgeleider
14.Garenpen
15.Schuimrubberonderlegmat
16.Garenklosrechthouder
17.Garenkloshouder
18.Steeklengteknop
19.Differentieel transport knop
20.Handwiel
21.Zijkap
22.Markering van zijkapen handwiel
23.Stekkeringang
24.Stroom-enlicht schakelaar
25.Mesbeschermingskap

8
1
23
45
6
15
18
Details of the machine / Details van de machine
Details der Maschine / Détails de la machine
1
23
1
2
34
6
7
8
9
5
79
8
10 11 14
17
12
13
16
Accessories
1.Needleset130/705H(SCHMETZ)
2. Small screwdriver
3. Tweezers
4. Upper looper converter
5. Needle threader
6. Brush/needle inserter
7. Electronic foot control
8. Oiler
9. Nets
10. Lower knife
11.Spoolcaps
12.Accessory bag
13. Dust cover
14. Large screwdriver
15.Cover/chain stitchextension plate
16. Cover stitch presser foot
17. Waste collector
18.Spoolholder
19.Needle set JLx2(3xNo.80)
Accessoires
1.Naaldenset130/705H(SCHMETZ)
2. Kleineschroevendraaier
3.Pincet
4. Bovengrijperconverter
5.Draadinrijger
6. Borstel, naaldinzetter
7. Voetpedaal
8.Oliespuitje
9.Garennetje
10.Ondermes
11.Garenklostegenhouder
12. Accessoiren tasje
13. Stofhoes
14.Grote schroevendraaier
15. Ketting- en coverstitch aanschuifplaat
16.Coverstitch naaivoet
17.Snij-afvalbakje
18.Extrakloshouder
19.Naalden set JLx2 (3xNo.80)
View with cloth plate open
1.Chain-looperauto-threader
2.Chain-looperthreadtensiondial
3.Threadingdiagramforchain-looperthread
Beeld met opengeklapt werkvlak
1.Automatischekettingsteekgrijper
draadinrijger
2.Kettingsteekgrijperdraadspanning
3.Inrijgschemavoordekettingsteekgrijper
draad
View with looper cover open
1. Selection lever for overlocking or roll
hemming
2. Lower knife
3.Cuttingwidthadjustingdial
4. Lower looper auto threader
5. Lower knife setscrew
6. Lower looper
7.Upperlooper
8.Threadingdiagram
9.Slit typelooper threadingsystem
Beeldmetopengrijperbeschermkap
1. Selectie hefboom voor overlock- of
rolzoomsteek
2.Ondermes
3.Snijbreedte-afstelknop
4.Automatischeondergrijper-draadinrijger
5.Stelschroef ondermes
6.Ondergrijper
7.Bovengrijper
8.Inrijgdiagram
9.Draadgeleidingsysteem
Ansicht bei geöffnetem
Greiferdeckel
1. Stichwahlhebel für Overlocken oder
Rollsäumen
2.Untermesser
3.Wahlknopffür Messerposition
4.Untergreifer-Einfädelautomatik
5. Stellschraube für unteres Messer
6.Untergreifer
7.Obergreifer
8.Einfädelschema
9.Schlitzführung
Vue,lecouvercle du boucleur ouvert
1. Levier sélecteur pour point de surjet
ou ourlets roulés
2.Couteauinférieur
3.Sélecteur pour la position du couteau
4.Enfilageautomatiqueduboucleurinférieur
5. Vis de réglage pour le couteau inférieur
6. Crochet inférieur
7.Crochet supérieur
8.Répertoired’enfilage
9.Guide
Ansicht bei geöffnetem
Stoffauflagedeckel
1.Kettengreifer-Einfädelautomatik
2.Fadenspannung für Kettengreifer
3.Einfädelschema für Kettengreifer
Vue de l’intérieur, récupérateur de
déchets ouvert
1.Dispositifd’enfilageautomatiquepour
boucleur de chaînette
2.Tensiondufilpourboucleurdechaînette
3.Schéma d’enfilage dufil pour boucleur
de chaînette
Zubehöre
1.Nadelset130/705H(SCHMETZ)
2. Kleiner Schraubenzieher
3. Pinzette
4. Obergreiferabdeckung
5.Nadeleinfädler
6.Pinsel/Nadeleinsetzer
7. Elektronischer Fussanlasser
8. Öler
9. Netze
10.Untermesser
11.Garnableiterscheiben
12.Zubehörtasche
13.Staubschutzhülle
14.Grosser Schraubenzieher
15.Cover-Abdeckung
16.Coverstich Nähfuss
17.Abfallbehälter
18.Garnrollenständer
19.NadelsatzJLx2 (3xNr.80)
Accessoires
1.Jeud’aiguilles130/705H(SCHMETZ)
2. Petit tournevis
3. Pincette
4. Recouvrement du boucleursupérieur
5.Enfile-aiguille
6.Pinceau / pose-aiguille
7.Pédaleélectronique
8. Huileur
9. Réseaux
10.Couteauinférieur
11.Rondellesdemaintien
12.Pochette d’accessoires
13.Housse de protection
14.Grand tournevis
15.Plaquederecouvrementpourpoint
enveloppant
16.Piedpourpointenveloppant
17.Récupérateur de chutes
18.Supportde bobine
19.Ensembled’aiguilleJLx2(3xNº80)

9
Attaching the foot control
Plug foot control into the machine socket (A) and then into main socket (B). The foot
control regulates the sewing speed. The sewing speed can be adjusted by increasing
or decreasing the pressure on the foot control.
“WARNING’’
This appliance has a polarized plug (one blade wider than the other).
To reduce the risk of electric shock, thisplug isintended tofit ina polarizedmain socket
only one way.
Iftheplugdoesnotfitfullyinthepolarizedmainsocket,reversethe plug. If it still doesnot
fit,contactaqualifiedelectriciantoinstalltheproperpolarizedmainsocket.Donotmodify
the plug in any way.(for USA, Canada only)
*ForMO-735useonlythefootcontrolmodel YC-482(USA,CANADA),
YC-483N(220-240V)
Het aansluiten van de voetpedaal
Steekdestekkervandevoetpedaalindemachine(A)envervolgensdenetstekkerinhet
stopcontact.Devoetpedaal regelt de naaisnelheid.De snelheid kan veranderdworden
doorde pedaal meerofminder in tedrukken.
Fussanlasseranschliessen
Fussanlasser-Kabel in Overlockmaschinensteckdose stecken (A) und anschliessend
denNetzsteckermitder Netzsteckdose (B) verbinden.Durchmehroder weniger Druck
aufdieTrittflächedes Fussanlassers kann dieNähgeschwindigkeitstufenlosverändert
werden.
Raccordement de la pédale
Introduire la fiche de la pédale dans la prise de la surjeteuse (A), puis relier la prise
secteur (B) au réseau. Une pression plus ou moins grande sur la surface d’appui de la
pédalepermetdemodifier progressivement la vitessedela machine.
Preparing the machine / Using the machine
Het voorbereiden en gebruik van de machine
Maschine bereitstellen / Inbetriebnahme
Préparation de la machine / mise en service
A
B
Waste collector
Clipthe waste collectorinto the openingon the looper cover.It catches the cut-off fabric
as you sew, keeping your working area neat and tidy.
Snij-afvalbakje
Klikhetbakjeaandeopeningopdegrijperbeschermkap.
Het bakje vangt het afsnijsel op terwijl u naait.
Abfallbehälter
DenAbfallbehälter in dieAussparung am Greiferdeckel einhängen. Der Behälter fängt
den Stoffabschnitt nach dem Schneiden auf. Der Arbeitsplatz bleibt sauber und
übersichtlich.
Récupérateur de chutes
Suspendre le récupérateur de chutes dans l’évidement du couvercle du boucleur. Le
récipient récupère les déchets après la coupe du tissu. Le poste de travail reste propre
etbienordonné.
Polarized plug
(for USA, Canada only)
Polarized main socket
