Juniper QFX5130 User manual

Day One+
QFX5130-32CD
IN THIS GUIDE
Step 1: Begin | 1
Step 2: Up and Running | 6
Step 3: Keep Going | 9
Step 1: Begin
IN THIS SECTION
Meet the QFX5130-32CD Ethernet Switch | 2
Install the QFX5130-32CD | 2
Power On | 4
In this guide, we provide a simple, three-step path, to quickly get you up and running with your new QFX5130-32CD
switch. We’ve simplified and shortened the installation and configuration steps, and included how-to videos. You’ll learn
how to install the QFX5130 in a rack, power it up, and deploy it on your network.
NOTE: Are you interested in getting hands-on experience with the topics and operations covered in this guide?
Visit Juniper Networks Virtual Labs and reserve your free sandbox today! You’ll find the Junos Day One Experience
sandbox in the stand alone category.

Meet the QFX5130-32CD Ethernet Switch
The QFX5130-32CD Ethernet Switches are an optimally designed solution for spine-and-leaf deployments in enterprise,
service provider, and cloud data centers. The switches come in a low-profile 1-U form factor and support a bandwidth of
12.8 Tbps.
With 32 400GbE ports, the switches enable a wide variety of configurations that include support for 10-Gbps, 25-Gbps,
40-Gbps, 100-Gbps, and 400-Gbps speeds. The QFX5130-32CD switches are available with either a front-to-back or
back-to-front airflow and with dual AC power supplies.
Install the QFX5130-32CD
IN THIS SECTION
What’s in the Box? | 2
What Else Do I Need? | 3
Install the QFX5130-32CD in a Four-Post Rack | 3
What’s in the Box?
•QFX5130-32CD switch
•Two power cords appropriate for your geographic location
•RJ-45 Ethernet cable
•RJ-45 to DB-9 serial port adapter
•Rack mount kit with:
•Twelve flat-head M4x6-mm Phillips mounting screws
•One pair of mounting blades
•One pair of mounting rails
2

What Else Do I Need?
You'll need to provide:
•Someone to help you secure the switch to the rack
•Eight rack mount screws
•Panduit LCD10-10A-L grounding lug or equivalent
•Two 10-32 x 0.25 screws with #10 split-lock washers
•A number two Phillips (+) screwdriver
•A serial-to-USB adapter (If your laptop or desktop PC doesn't have a serial port)
Install the QFX5130-32CD in a Four-Post Rack
Here’s how to install the QFX5130-32CD in a four-post rack:
1. Review the General Safety Guidelines and Warnings.
2. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to a site ESD
point.
3. Decide which end of the switch you want to place at the front of the rack. Position the switch so that the AIR IN labels
are next to the cold aisle and the AIR OUT labels are next to the hot aisle.
4. Attach the mounting rails to the sides of the switch using the twelve flat-head screws.
g051310
5. Lift the switch and position it in the rack. Line up the bottom hole in each mounting rail with a hole in each rack rail,
making sure the switch is level.
3

6. While you’re holding the switch in place, have a second person insert and tighten the rack mount screws to secure the
mounting rails to the rack rails. Make sure they tighten the screws in the two bottom holes first and then tighten the
screws in the two top holes.
g051311
7. Continue holding the switch in place and have the second person slide the mounting blades into the channel of the
mounting rails.
8. Screw the mounting blades to the rack using the rack mount screws (and cage nuts and washers if your rack requires
them).
g051312
9. Check that the mounting brackets on each side of the rack are level.
NOTE: If you have unused ports, plug them using dust covers to prevent dust from entering the switch.
Power On
Now that you’ve installed your QFX5130-32CD in the rack, you’re ready to connect it to power.
4

1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other end to one of the
ESD grounding points on the switch.
2. Use two 10-32 x 0.25 screws with #10 split-lock washers to secure the grounding lug and attached cable to the chassis.
Attach the lug through the left rail and blade assembly to the chassis.
g051317
3. Connect the remaining end of the grounding cable to a proper earth ground, such as the rack. Dress the grounding
cable and ensure that it doesn’t touch or block access to other device components and that it doesn’t drape where
people could trip over it.
4. Ensure that the power supplies are fully inserted in the chassis and the latches are secure.
5. For each power supply, ensure that the loop on the power cord retainer is open and there’s enough space to insert
the power cord coupler into the inlet. If the loop is closed, press the small tab on the retainer to loosen the loop.
g051289
6. Thread the power cord coupler through the power cord retainer loop.
7. Plug the power cord into the AC inlet on the power supply faceplate.
8. Slide the power cord retainer loop toward the power supply until it is snug against the base of the coupler.
5

9. Press the tab on the loop and draw out the loop to enclose the power cord.
g051290
WARNING: Ensure that the power cord does not block access to device components or drape
where people can trip on it.
10. If the AC power source outlet has a power switch, turn it off.
NOTE: The switch powers on as soon as you connect it to power. It doesn’t have a power switch.
11. Plug in the power cord to the AC power source outlet.
12. If the AC power source outlet has a power switch, turn it on.
13. Verify that the AC LEDs on each power supply are lit green.
Step 2: Up and Running
IN THIS SECTION
Plug and Play | 7
Customize the Basic Configuration | 7
Now that the QFX5130-32CD is powered on, let’s do some initial configuration to get it up and running on the network.
It’s simple to provision and manage the QFX5130 using the CLI.
6

Plug and Play
The QFX5130-32CD switch ships with factory-default settings that enable plug-and-play operation. The default settings
enable the Link Layer Discovery Protocol (LLDP). These settings load as soon as you power on the QFX5130-32CD switch.
Customize the Basic Configuration
You can easily customize the factory-default configuration using CLI commands. Initially, you must make changes through
the console port. After you configure the management port, you can access the device using SSH to make additional
configuration changes. You can revert to the factory-default configuration whenever you want.
Have the following information ready before you begin to configure custom settings for the switch:
•Hostname
•Root authentication password
•Management port IP address
•Default gateway IP address
•(Optional) SNMP read community, location, and contact information
1. Verify that your laptop or desktop PC has these default serial port settings:
•Baud Rate—9600
•Flow Control—None
•Data—8
•Parity—None
•Stop Bits—1
•DCD State—Disregard
2. Connect the console port on the QFX5130-32CD to a laptop or desktop PC using the supplied RJ-45 cable and RJ-45
to DB-9 adapter. The console (CON) port is located on the upper right corner of the port panel.
NOTE: If your laptop or desktop doesn't have a serial port, use a serial-to-USB adapter (not provided).
3. At the Junos OS login prompt, type root to log in. You don't need to enter a password. If the software booted before
you connected the laptop or desktop to the console port, you might need to press the Enter key for the prompt to
appear.
login: root
4. Start the CLI.
7

root@% cli
5. Enter configuration mode.
root> configure
6. Add a password for the root administration user account.
[edit]
root@# set system root-authentication plain-text-password
New password: password
Retype new password: password
7. (Optional) Configure the name of the switch. If the name includes spaces, enclose the name in quotation marks (“ ”).
[edit]
root@# set system host-name host-name
8. Configure the IP address and prefix length for the management port on the switch. On the QFX5130-32CD, the
management port re0:mgmt-0 is the lower RJ-45 port on the right side of the port panel and is labeled MGMT.
NOTE: Although the CLI permits you to configure two management Ethernet interfaces within the same
subnet, only one interface is usable and supported at any point of time.
[edit]
root@# set interfaces re0:mgmt-0 unit 0 family inet address address/prefix-length
9. Create a routing instance.
[edit]
root@# edit routing-instances mgmt_junos
root@# set routing-instances mgmt_junos routing-options static route 0.0.0.0/0 next-hop 10.102.70.254
10. Configure the static routes to remote prefixes.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip
11. Enable the management instance.
[edit]
root@# set system management-instance
12. Enable Telnet service if needed.
[edit]
8

root@# set system services telnet
NOTE: When Telnet is enabled, you cannot log in to the QFX5130-32CD through Telnet using root credentials.
Root login is allowed only for SSH access.
13. Enable SSH service.
[edit]
root@# set system services ssh
14. To allow users to log in to the switch as root through SSH, include the root-login statement.
[edit system services ssh]
root@# root-login (allow | deny | deny-password)
NOTE: By default, users are not allowed to log in to the switch as root through SSH.
15. Commit the configuration. Your changes become the active configuration for the switch.
[edit]
root@# commit
Step 3: Keep Going
IN THIS SECTION
What’s Next? | 10
Learn With Videos | 10
Congratulations! Your QFX5130 is configured and ready to go. Here are some things you can do next.
9

What’s Next?
ThenIf you want to
See Activate Junos OS Licenses in the Juniper Licensing
Guide
Download, activate, and manage your software licenses to
unlock additional features for your QFX series switch
See the QFX5130-32CD Documentation in the Juniper
Networks TechLibrary.
See all documentation available for the QFX5130-32CD
See the QFX5130-32CD Hardware Installation Guide.Find more in-depth information about how to install and
configure the QFX5130-32CD
See Installing Software on QFX Series Devices.Manage software upgrades for your QFX5130-32CD
See the Junos OS Evolved Release Notes.Stay up-to-date on new and changed features and known
and resolved issues
Visit the Security Design Center.See, automate, and protect your network with Juniper
Security
Visit Juniper Networks Virtual Labs and reserve your
free Junos Day One Experience sandbox today! You’ll
find the sandbox in the stand alone category.
Get hands-on experience with the procedures covered in
this guide
Learn With Videos
Our video library continues to grow! We’ve created many, many videos that demonstrate how to do everything from
install your hardware to configure advanced Junos OS network features. Here are some great video and training resources
that will help you expand your knowledge of Junos OS.
ThenIf you want to
QFX5130 Ethernet Switch (WBT)View a Web-based training video which provides an
overview of the QFX5130 and describes how to install
and configure it
See Learning with Juniper on Juniper Networks main
YouTube page
Get short and concise tips and instructions that provide
quick answers, clarity, and insight into specific features
and functions of Juniper technologies
Visit the Getting Started page on the Juniper Learning
Portal
View a list of the many free technical trainings we offer
at Juniper
10
