KD-A525
Headunits
KD-A525
USB/CD Receiver with Dual AUX
With dual AUX inputs, the unit offers flexible options including Bluetooth®connection with an optional adapter, as well as front USB
connection for iPod/iPhone music. App sound can also be enjoyed with External Mode for iPod/iPhone, while control is available from
both the player and the headunit side. Searching songs is quick and easy – with the menu key/volume knob and Accelerated Search.
Enjoy quality sound with MOS-FET power amp and 24-bit DAC. Other features include High-Pass Filter, HS-IVi tuner, and 3-band
parametric iEQ.
Recommended Features
Key Benefits
20W x 4
RMS
MOS-FET
50W x 4 2-Way Control
for iPod/iPhone
iPod Headunit
MP3/WMA
External Mode
for
iPod/iPhone
iPod/iPhone
USB G3
Radio Ready
SAT
Phone Book
Access Profile
Dual
AUX
2 Phones
(Full Time)
Connects
Ready for
Bluetooth
®
Adapter
✹USB Audio for iPod/iPhone
Connect your iPod/iPhone to the unit’s USB port with
the iPod/iPhone dock connector, and enjoy music in clear,
digital sound with full-speed transfer. Your iPod/iPhone’s
battery will be charged during connection.
✹Ready for Bluetooth®Adapter (KS-BTA100)
With the optional KS-BTA100 adapter,
you can enjoy the safety and
convenience of Bluetooth®Wireless
Technology such as hands-free
calling, voice dialing, and audio
streaming. The compact all-in-one
adapter has microphone/keys/LED
functions, and can be easily
connected via the AUX.
Cell phone
KS-BTA100
(optional)
(Front+Rear+Subwoofer)
3 Pre-Output
Full Digital
Full Speed Charging
Hands-Free Calls
- Voice Dialing
- Redial Call
- Private Mode
Audio Streaming
- Noise/Echo Cancellation
Ready for
KT-HD300

2011 JVC Product Tech Guide
C M Y K
KD-A525
KD-A525 USB/CD Receiver with Dual AUX
NTK-0786-26
*4
*5
N/A
✔USB ✔USB ✔USB ✔USB ✔USB ✔USB ✔USB ✔USB ✔USB
Quick Reference of iPod/iPhone Compatibility*1
Playback
Connection
*2*3
*6
*1 Please visit www.jvc.co.jp/english/car/ for iPod/iPhone compatibility details. *2 Same compatibility applies for the following 4th generation and earlier iPod models: iPod with dock connector, iPod mini, and iPod with color display. *3 Same compatibility
applies for iPod nano (1st generation) *4 Same compatibility applies for iPod classic (160GB (2007) only). *5 Same compatibility applies for iPod touch (1st, 2nd, and 3rd generation) *6 Same compatibility applies for iPhone, and iPhone 3G.
✔USB
Maximum Power Output 50W x 4
Continuous Power Output (RMS) 20W RMS x 4 Channels at 4Ω;
*1Total Harmonic Distortion 1.0% THD*1+ N
HPF*2(Front/Rear) Off/On
LPF (Subwoofer) off / 55 / 85 / 120Hz (-12dB/oct)
Line Pre-Output Terminals 3 (Front + Rear + Subwoofer)
Subwoofer Output with
Level/Frequency Control ✔
Line Output Level 2.5V
Subwoofer Output Level 2.5V
Subwoofer Gain Control INF - 0dB*3
Load Impedance 4Ω(4 - 8Ωallowable)
Line Output Impedance ; 600Ω
*2 Set according to LPF figures *3 MUTE / -14dB / -12dB / -10dB / -8dB / -6dB / -4dB / -2dB / 0dB
Dimentions (W x H x D)
Installation Size 7 3/16” x 2 1/16” x 6 5/16” 182 x 52 x 159 mm
Panel Size 7 7/16” x 2 3/8” x 3/8” 188 x 59 x 8.5 mm
Detachable Face Plate 6 3/4” x 1 13/16” x 13/16” 170 x 46.4 x 20.6 mm
Key Specifications
✹High-Pass Filter
High-Pass Filter lets you control high-frequency sound settings by filtering out
frequencies below the cutoff level.
ConnectionsConnections
USB Memory
iPod
iPod
iPhone
Cell phone
Portable
Audio Players
USB
iPhone
KS-BTA100
(Optional)
AUX-IN
Front
AUX-IN
Rear
✹2-Way Control for iPod/iPhone
The 2-way control for iPod/iPhone lets you easily operate on your iPod/iPhone or
the headunit. Just hold down the BACK key to switch operation. The basic functions
can be controlled on the headunit
even during iPod/iPhone mode.
The song information is shown on
the display for both modes.
* Compatibility with 2-way control for iPod/iPhone
differs by model. Please visit
www.jvc.co.jp/english/car/ for details.
Headunit ModeiPod/iPhone Mode
•Display Song
Information
•Headunit
Direct Control
Play/Pause Skip/Forward
Switchable
Rear Panel
✹Dual AUX-IN
AUX inputs are available on both front and rear panels. By connecting the optional
adapter, Bluetooth®Wireless Technology will be available on the headunit.
Front Rear
iPod* Bluetooth®
Adapter
Front Rear
Music
Source*
Music
Source*
Front Rear
Style A Style B
✹3-Band Parametric iEQ
Adjusts the center frequency, bandwidth and levels at each of 3 bands. Plus 5
factory and 1 user EQ presets. With Pro mode, the EQ can customize the sound for
your ears. A separate setting for the subwoofer level is also available.
PRO EQ mode
<PRO EQ> <BASS>
<MIDDLE>
<TREBLE>
[Hold]
Control Range Bass: 60Hz, 80Hz, 100Hz, 200Hz
Mid-range :500Hz, 1kHz, 1.5kHz, 2.5kHz
Treble: 10kHz,
12.5kHz, 15kHz, 17.5kHz
Level -6~+6dB
Q (band with) 0.75~2.0Q
✹Separated Brightness Control (32 steps)
With JVC’s CD receivers, you can easily control the brightness separately for left and
right in 32 steps, for increased safety or to suit the car environment.
✹External Mode for
iPod/iPhone
You can listen to the sound of
iPod/iPhone apps, such as games,
web radio, and YouTube, with high
current ready power supply.
* For sound only.
