JVC KD-ADV5490 User manual

KD-ADV5490/KD-DV5400 •
KD-ADV5490/KD-DV5400
KD-ADV5490/KD-DV5400
-~
~
c IJ UlII6 A 11662'3 UlAV [][)IDDLBVI 'RADIQ.-I
tJ' FFltrI_ IFlr, FF_ D I QI TAL REA D Y
fr •. 1i"
BDl §~ [Q]~® ~~ !M?
U L T R R [OlGITALVCECI Digital Out vI D I! 0
RECEPTEUR DVD/CD
RECEPTOR CON DVD/CD
DVD/CD RECEIVER
..Ive
-
For canceling the display demonstration, see page 7.
Para cancelar la demostraci6n en pantalla, consulte la pagina 7.
Pour annuler la demonstration des affichages, referez-vous a la page 7.
For installation and connections, referto the separate manual.
Para la instalaci6n y las conexiones, refierase al manual separado.
Pour I'installation et les raccordements, se referer au manuel separe.
INSTRUCTIONS
MANUAL OEINSTRUCCIONES
MANUEL O'INSTRUCTIONS
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
GET0510-001A
[J]

Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A."
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radiolTV technician for help.
Caution
Changes or modifications not approved by JVC could void the user's authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.s.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
CAUTION ATTENTION
AVISO VARNING
~. CAUTION
VISIBlf AND I OR RAYONNEMENT LASER
RADIACION LASER
SYNUG OCH I Eu.ER
;:;:tl(t:iiJl
VlSlBlf AND I OR
INVISIBlf CLASS 1M VISIBlf ETlOU
DE CLASE 1M OSYNUG J.t.l/tt:It:fiif1
INVISIBlf CLASS I
LASER RADIATION INVISIBlf DE CLASSE VISIllf Y/O INYISIBlf
LASERSTJW.NING,
M7~'M
LASER RADIATION
WHEN OPEN. 00 NOT 1M UNE FOIS OUVERT. CUANDO ESTA
KLASS 1 M, NAR DENNA
v--'f-U1ll
WHEN OPEN.
VIEW DIRECTLY WITH
NE PAS REGARDER ABIERTO. NO MIRAR DEl. All CPPNAO.
lut.
00 NOT STARE
OPTICAl. INSTRUMENTS.
DIRECTEMENT AVEC DIRECTAMENTE BETRAKTA EJ
J\;!l!'I1!a!t
INTO BEAM.
IEC60825-1:2001
DES INSTRUMENTS CON INSTRUMENTAl. STRAlfN MEO 0PT1SKA
It.l~\1! (t:~~\.
FDA 21 CFR
(ENG)
OPTIQUES. (FAA) 6PT1CO. (ESP)
INSTRUMENT. (SWE)
(JPN) (ENG)
[European Union only]
2

• How to reset your unit
• Your preset adjustments will also be erased .
• How to forcibly eject a disc
ATT
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
How to use functions mode
If you press M MODE, the unit goes into functions mode,
then the number buttons and Ji./~ buttons work as
different function buttons.
MODE
For safety ...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous .
•
Stop the car before performing any complicated
operations.
•liD •88M 11 ftPT II It.
tI/II "" "".. ~ ~
.. [Within 5 seconds ... ]
Temperature inside the car ...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
3

This product incorporates copyright protection
technology that is protected by U.s. patents and
other intellectual property rights. Use of this
copyright protection technology must be authorized
by Macrovision, and is intended for home and
other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
\.
Caution on volume setting
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc to
avoid damaging the speakers by the sudden increase of
the output level.
Caution for DualDisc playback
The Non-DVD side of a "DualDisc" does not comply with
the "Compact Disc Digital Audio" standard. Therefore,
the use of Non-DVD side of a DualDisc on this product
may not be recommended.
KD-ADV5490 is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
volume) for connection.
4
Detaching the control panel
Attaching the control panel

5

Playable disc type
Disc type
DVD
DVD Recordable/Rewritable
(DVD-R/-RW *2, +R/+RW *3)
• DVD Video: UDF bridge
• DVD-VR
• DivX/MPEG-l/MPEG-2/MP3/
WMAIWAV: ISO 9660 levell,
level 2, Romeo, Joliet
Dual Disc
CDNCD
Recording format, file type, etc
DVD-Video (Region Code: 1) *1
(1)(1)(1)(1)
DVD-Video
DVD-VR
DivX/MPEG1/MPEG2
MP3IWMAIWAV
Playable
~OK
~OK
CD Recordable/Rewritable CD-DA
(CD-R/-RW) VCD (Video CD)
• ISO 9660 levell, level 2, Romeo, 1-------------------1
Joliet DivX/MPEG 1 /MPEG2
MP3IWMAIWAV
~OK
*1 If you insert a DVD Video disc of an incorrect Region (ode, "REGION CODE ERROR" appears on the monitor.
*2 DVD-R recorded in multi-border format is also playable (except for dual layer discs). DVD-RW dual layer discs are not
playable.
*3 It is possible to play back finalized +R/+RW (Video format only) discs. +RW double layer discs are not playable.
*4 To reproduce DTS sound, use the DIGITAL OUT terminal (see also pages 37 and 36).
6

Preparation
Cancel the display demonstration and set the clock
• See also page 28.
Turn on the power.
Enter the PSM settings.
Cancel the display demonstrations
Select "DEMO," then "DEMO OFF."
[Tum] Set the clock
Select "ClOCK HOUR," then adjust the hour.
Select "ClOCK MIN" (minute), then adjust the minute.
Finish the procedure.
• When the power is turned off: Check the current clock time
DISP When the power is turned on: Change the display information
INTRODUCTIONS 7

Basic operations
Using the control panel _
OJ • FMlAM: Select preset station.
• SIRIUSIXM: Select category.
• DISC: Select title/program/playlist/folder.
• IPOD: Enter the main menu/Pause playback/
Confirm selection.
rn Eject disc.
W • Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the power is on).
W Volume control [Turn].
[[J Remote sensor
[§] • FMlAM/SIRIUSIXM: Select the band.
• DISC: Start/pause playback.
[I] Loading slot
[]] Display window
[ill Select the sound mode.
[Q] Change the display information.
IT] Detach the panel.
[J1] Select the source.
FM/AM - SIRIUSIXM* - DISC* - CD-CH*I
IPOD* (or EXT IN) - AUX IN - (back to the
beginning)
[J]] • FMlAMlSIRIUSIXM: Search for station/channel.
• DISC/CD-CH: Select chapter/track .
• IPOD: Select track.
8
[H] • Adjust the sound mode.
• Enter the PSM settings [Hold).
[J] Enter functions mode.
• Press M MODE, then one of the following buttons
(within 5 seconds) ...
MO : Turn on/off monaural reception.
SSM : Automatic station presetting [Hold].
RPT : Select repeat play.
RND : Select random play.
./T: Skip 10 chapters/tracks.
[§] • FMlAM/SIRIUSIXM: Select preset station/
channel.
• DISC/CD-CH: Select chapter/title/program/
folder/track/disc (for CD changer).
[]] AUX (auxiliary) input jack
* You cannot se/ea these sources if they are not ready or
not conneaed.

Display window
OJ Tr (track) indicator
rn Source display / Track number / Folder number /
Disc number / Title number / PBC indicator / Time
countdown indicator
W Playback source indicators-CH (CD changer), DISC
W Sound mode (c-EQ: custom equalizer) indicators
-CLASSIC, HIP HOP, JAZZ, ROCK, POPS, USER
[[] Playback mode / item indicators- RND (random),
., (disc),. (folder), RPT (repeat)
[]] Tuner reception indicators-ST (stereo),
MO (monaural)
[l] LOUD (loudness) indicator
[]] EQ (equalizer) indicator
~ Disc information indicators-
TAG (Tag information), fiij (folder), J' (track/file)
[!Q] Main display (Time, menu, playback information)
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Using the remote controller (RM-RK2S2) _
Installing the battery • If the effectiveness of the remote controller
decreases, replace both batteries.
Insert the batteries into the remote controller by
matching the polarity (+ and -) correctly.
Caution:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
Continued on the next page
OPERATIONS
9

10
IT] 011 A IT button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
rn ./T buttons
• FMlAM: Selects the preset stations.
• SI RIUSIXM: Selects the categories.
• DISC:
- DVD-Video: Selects the title.
- DVD-VR: Selects the program/playlist.
- DivX/MPEG Video/MP3/WMA/WAV: Selects
the folders if included.
• IPOD:
- .: Enters the main menu (then ./T /
~ v /~ A. work as menu
selecting buttons.)
.: Returns to the previous menu.
T: Confirms the selection.
- T: Pauses or resumes playback.
~ v / ~ A. buttons
• FMlAM:
- Searches for stations automatically if pressed
briefly.
- Searches for stations manually if pressed and
held.
• SIRIUSIXM:
- Changes the channels if pressed briefly.
- Changes the channels rapidly if pressed and
held.
• DISC:
- Reverse skip/forward skip if pressed briefly.
- Reverse search/forward search if pressed and
held.
• IPOD:
- Reverse skip/forward skip if pressed briefly.
- Reverse search/forward search if pressed and
held.
In menu selecting mode:
- Selects an item if pressed briefly. (Then, press
T to confirm the selection.)
- Skips 10 items at a time if pressed and held.
