Bluetooth®Wireless Technology DVD/CD/USB Receiver
with Proximity Sensor and Touch Pad
Radio Ready
SAT
The Proximity Sensor and Touch Pad offer intuitive operation with your finger strokes on the 3.5-inch widescreen
monitor. The stylish monitor becomes totally black when the power is off. Enjoy hands-free calling and audio
streaming on the multimedia system with built-in Bluetooth®Wireless Technology. You can play both audio and
video* from your iPod/iPhone or USB devices. Multilingual display is available in 10 languages. HD Radio®and SAT
Radio can also be enjoyed with optional tuners.
* KS-U30 required for iPod/iPhone video playback. Compatibility depends on iPod.
20W x 4
RMS
Multilingual
Display
MOS-FET
50W x 4
Touch Pad
Unique and intuitive control with a
flick of your finger — circular strokes
for volume control, vertical to move
up/down folders, and horizontal to
skip forward/backward.
MP3/WMA/WAV
GIGA MP3 MULTI
Full Digital
Full Speed
Charging
for iPod
Front AUX
AUDIO
Touch
Pad
Touch
Pad
Proximity
Sensor
Proximity
Sensor
Built-in
Bluetooth®
Wireless Technology
3.5” WIDE
3.5” WIDE
HD Radio®
Ready
Ready for
iPodAdapter
iPod/iPhone
USB G3
Built-in Bluetooth®Wireless Technology
Enjoy hands-free calling, voice-recognition dialing,
or music streaming with compatible devices.
Wired MIC included
for flexible settings
Line Output
Hi-Volt

2009 JVC Product Tech Guide
C M Y K
KD-AVX40
KD-AVX40 Bluetooth®Wireless Technology DVD/CD/USB Receiver
with Proximity Sensor and Touch Pad
NTK-9520-15
Steering Wheel Remote Ready
With an optional adapter, you can control an advanced JVC
headunit from the steering wheel remote control that comes
factory standard with your car.
GIGA MP3 MULTI
Thousands of MP3/WMA music files burned on a
single DVD disc can be played. Also compatible with
uncompressed WAV format.
7-Band iEQ
Boost or cut the level by up to 10dB on each of 7
bandwidths (60, 150, 400, 1k, 2.4k, 6k and 15kHz).
Even customize the overall response with the 7-Band
iEQ, which offers 1 user- and 5 factory-preset
patterns. (POPS, ROCK, HIPHOP, JAZZ, and CLASSIC)
ROCK
JAZZ USER
POPS
CLASSIC
HIP
HOP
Connections
KT-HD300
USB Memory
Portable HDD iPod iPhone
J-BUS
Rear USB
KS-PD100
iPod
Portable HDD iPod iPhone
Cell phone iPhone
J-BUS Terminal
You can connect JVC’s optional adapters or changers to this terminal. Available
functions depend on the headunit.
KT-HD300
KS-PD100
iPod
Compatible iPod/iPhone Models
✔
USB ✔ USB ✔ USB ✔ USB ✔ USB ✔ USB ✔ USB ✔ USB
✔
USB
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100 ✔
USB
USB Connection (G3 iPod/iPhone Audio)
Enjoy digital audio/video from your iPod, iPhone, or USB
devices at full-speed transfer (USB 2.0).
You can also charge your iPod/iPhone.
* USB playback not supported for NTFS formatted devices. When partitions are
created, only the first partition can be read. (Maximum current supply 0.5A)
** DivX®files must be less than 2Mbps for playback on USB
*** For iPod/iPhone video playback, KS-U30 cables are required. Please visit
www.jvc-exad.com for iPod/iPhone compatibility details.
Bluetooth®Compatible Functions
In addition to hands-free calling, voice recognition dialing, and audio streaming,
you can transfer up to 100 contact
numbers to the headunit.
Hands-Free Calls
Voice Dialing
Audio Streaming
Text Message Display
Phonebook Transfer
✔
✔
✔
✔
✔
So Many Features!
Cell phone
Maximum Power Output 50W x 4
Continuous Power Output (RMS) 20W RMS X 4CH at 4Ω
* Total Harmonic Distortion ; 1.0% THD* + N
HPF** (Front/Rear) off / 80 / 120 / 150Hz (-12dB/oct)
LPF (Subwoofer) off / 80 / 120 / 150Hz (-12dB/oct)
AV Input ✔(Gold-Plated)
Video Input (Camera) -
Line Preout Terminals (Pair) 1 pairs (Gold-Plated)
Center Channel Output -
Second Audio Output -
Subwoofer Output with
Level/Frequency Control ✔(Gold-Plated)
Subwoofer Output Level 2.5V
Subwoofer Gain Control 0 - 16dB
Composite Video Output ✔(Gold-Plated)
Digital Output ✔
Load Impedance 4Ω(4 - 8Ωallowable)
Pre-output Level/Impedance 2.5V/20kΩ
Video Output 1.0Vp-p/75Ω
2nd Audio Output -
Video Input 1.0Vp-p/75Ω
Audio Input 1.5V/20kΩ
Dimentions (W x H x D)
Installation Size 7 3/16” x 2 1/16” x 6 5/16” 182 x 52 x 160 mm
Panel Size 7 7/16” x 2 5/16” x 1/2” 188 x 58 x 12 mm
Detachable Face Plate 6 11/16” x 2 5/16” x 13/16” 169 x 58 x 20 mm
