JVC KD-DB98BT User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
FRANÇAIS
DEUTSCH
B5A-1376-00 [E]
KD-DB98BT
CD RECEIVER
INSTRUCTION MANUAL
RÉCEPTEUR CD
MANUEL D’INSTRUCTIONS
CD-RECEIVER
BEDIENUNGSANLEITUNG
JS_JVC_KD_DB98BT_E_C_00_02.indd 1JS_JVC_KD_DB98BT_E_C_00_02.indd 1 11/28/2016 12:13:09 PM11/28/2016 12:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
i
Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable
for countries that have adopted separate waste collection systems)
Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste.
Old electrical and electronic equipment and batteries should be recycled at a facility capable of handling
these items and their waste byproducts.
Contact your local authority for details in locating a recycle facility nearest to you. Proper recycling and
waste disposal will help conserve resources whilst preventing detrimental effects on our health and the
environment.
Notice: The sign “Pb” below the symbol for batteries indicates that this battery contains lead.
Information sur l’élimination des anciens équipements électriques et électroniques et piles
électriques (applicable dans les pays qui ont adopté des systèmes de collecte sélective)
Les produits et piles électriques sur lesquels le pictogramme (poubelle barrée) est apposé ne peuvent pas
être éliminés comme ordures ménagères.
Les anciens équipements électriques et électroniques et piles électriques doivent être recyclés sur des sites
capables de traiter ces produits et leurs déchets.
Contactez vos autorités locales pour connaître le site de recyclage le plus proche. Un recyclage adapté et
l’élimination des déchets aideront à conserver les ressources et à nous préserver des leurs effets nocifs sur
notre santé et sur l’environnement.
Remarque: Le symbole “Pb“ ci-dessous sur des piles électrique indique que cette pile contient du plomb.
Entsorgung von gebrauchten elektrischen und elektronischen Geräten und Batterien
(anzuwenden in Ländern mit einem separaten Sammelsystem für solche Geräte)
Das Symbol (durchgestrichene Mülltonne) auf dem Produkt oder seiner Verpackung weist darauf hin, dass
dieses Produkt nicht als normaler Haushaltsabfall behandelt werden darf, sondern an einer Annahmestelle
für das Recycling von elektrischen und elektronischen Geräten und batterien abgegeben werden muss.
Durch Ihren Beitrag zur korrekten Entsorgung dieses Produktes schützen Sie die Umwelt und die
Gesundheit Ihrer Mitmenschen.
Unsachgemässe oder falsche Entsorgung gefährden Umwelt und Gesundheit. Weitere Informationen
über das Recycling dieses Produktes erhalten Sie von Ihrer Gemeinde oder den kommunalen
Entsorgungsbetrieben.
Achtung: Das Zeichen „Pb“ unter dem Symbol fur Batterien zeigt an, dass diese Batterie Blei enthalt.
For Israel
JS_JVC_KD_DB98BT_E_C_00_02.indd iJS_JVC_KD_DB98BT_E_C_00_02.indd i 11/28/2016 12:13:10 PM11/28/2016 12:13:10 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ii
The marking of products using lasers
The label is attached to the chassis/case and says that the component uses laser beams that have been
classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no
danger of hazardous radiation outside the unit.
Marquage des produits utilisant un laser
L’étiquette est attachée au châssis/boîtier de l’appareil et indique que l’appareil utilise des rayons laser
de classe 1. Cela signifie que l’appareil utilise des rayons laser d’une classe faible. Il n’y a pas de danger de
radiation accidentelle hors de l’appareil.
Kennzeichnung von Geräten mit Laser-Abtastern
Das Etikett ist am Chassis/Gehäuse angebracht und besagt, dass sich die Komponente Laserstrahlen
bedient, die als Laserstrahlen der Klasse 1 klassifiziert wurden. Dies weist darauf hin, dass sich das Gerät
Laserstrahlen bedient, die einer schwächeren Klasse angehören. Das bedeutet, dass durch den sehr
schwachen Laserstrahl keine Gefahr durch gefährliche Strahlungen außerhalb des Geräts besteht.
JS_JVC_KD_DB98BT_E_C_00_02.indd iiJS_JVC_KD_DB98BT_E_C_00_02.indd ii 11/28/2016 12:13:10 PM11/28/2016 12:13:10 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iii
Declaration of Conformity with regard to the RE Directive 2014/53/EU
Declaration of Conformity with regard to the RoHS Directive 2011/65/EU
Manufacturer:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
EU Representative:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
Déclaration de conformité se rapportant à la directive RE 2014/53/EU
Déclaration de conformité se rapportant à la directive RoHS 2011/65/EU
Fabricant:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
Représentants dans l’UE:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
Konformitätserklärung in Bezug auf die RE-Vorschrift 2014/53/EU
Konformitätserklärung in Bezug auf die RoHS-Vorschrift 2011/65/EU
Hersteller:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
EU-Vertreter:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
English
Hereby, JVCKENWOOD declares that the radio equipment
“KD-DB98BT” is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available
at the following internet address:
http://www.jvc.net/cs/car/eudoc/
Français
Par la présente, JVCKENWOOD déclare que l’équipement
radio «KD-DB98BT» est conforme à la directive 2014/53/UE.
L’intégralité de la déclaration de conformité UE est
disponible à l’adresse Internet suivante :
http://www.jvc.net/cs/car/eudoc/
Deutsch
Hiermit erklärt JVCKENWOOD, dass das Funkgerät
“KD-DB98BT” der Richtlinie 2014/53/EU entspricht.
Der volle Text der EU-Konformitätserklärung steht unter der
folgenden Internetadresse zur Verfügung:
http://www.jvc.net/cs/car/eudoc/
Nederlands
Hierbij verklaart JVCKENWOOD dat de radioapparatuur
“KD-DB98BT” in overeenstemming is met Richtlijn
2014/53/EU.
De volledige tekst van de EU-verklaring van
overeenstemming is te vinden op het volgende
internetadres:
http://www.jvc.net/cs/car/eudoc/
Italiano
Con la presente, JVCKENWOOD dichiara che l΄apparecchio
radio “KD-DB98BT” è conforme alla Direttiva 2014/53/UE.
Il testo integrale della dichiarazione di conformità UE è
disponibile al seguente indirizzo internet:
http://www.jvc.net/cs/car/eudoc/
Español
Por la presente, JVCKENWOOD declara que el equipo de radio
“KD-DB98BT” cumple la Directiva 2014/53/EU.
El texto completo de la declaración de conformidad con la UE
está disponible en la siguiente dirección de internet:
http://www.jvc.net/cs/car/eudoc/
Português
Deste modo, a JVCKENWOOD declara que o equipamento de
rádio “KD-DB98BT” está em conformidade com a Diretiva
2014/53/UE.
O texto integral da declaração de conformidade da UE está
disponível no seguinte endereço de internet:
http://www.jvc.net/cs/car/eudoc/
Polska
Niniejszym, JVCKENWOOD deklaruje, że sprzęt radiowy
“KD-DB98BT” jest zgodny z dyrektywą 2014/53/UE.
Pełny tekst deklaracji zgodności EU jest dostępny pod
adresem:
http://www.jvc.net/cs/car/eudoc/
Český
Společnost JVCKENWOOD tímto prohlašuje, že rádiové
zařízení “KD-DB98BT” splňuje podmínky směrnice
2014/53/EU.
Plný text EU prohlášení o shodě je dostupný na následující
internetové adrese:
http://www.jvc.net/cs/car/eudoc/
Magyar
JVCKENWOOD ezennel kijelenti, hogy a „KD-DB98BT“
rádióberendezés megfelel a 2014/53/EU irányelvnek.
Az EU konformitási nyilatkozat teljes szövege az alábbi
weboldalon érhető el:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_DB98BT_E_C_00_02.indd iiiJS_JVC_KD_DB98BT_E_C_00_02.indd iii 11/28/2016 12:13:10 PM11/28/2016 12:13:10 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iv
Svenska
Härmed försäkrar JVCKENWOOD att
radioutrustningen “KD-DB98BT” är i enlighet med
direktiv 2014/53/EU.
Den fullständiga texten av EU-försäkran
om överensstämmelse finns på följande
Internetadress :
http://www.jvc.net/cs/car/eudoc/
Suomi
JVCKENWOOD julistaa täten, että radiolaite
“KD-DB98BT” on direktiivin 2014/53/EU
mukainen.
EU-vaatimustenmukaisuusvakuutusvaatimus
löytyy kokonaisuudessaan seuraavasta internet-
osoitteesta:
http://www.jvc.net/cs/car/eudoc/
Slovensko
S tem JVCKENWOOD izjavlja, da je radijska oprema
»KD-DB98BT« v skladu z Direktivo 2014/53/EU.
Celotno besedilo direktive EU o skladnosti je
dostopno na tem spletnem naslovu:
http://www.jvc.net/cs/car/eudoc/
Slovensky
Spoločnosť JVCKENWOOD týmto vyhlasuje,
že rádiové zariadenie „KD-DB98BT“ vyhovuje
smernici 2014/53/EÚ.
Celý text EÚ vyhlásenia o zhode nájdete na
nasledovnej internetovej adrese:
http://www.jvc.net/cs/car/eudoc/
Dansk
Herved erklærer JVCKENWOOD, at radioudstyret
“KD-DB98BT” er i overensstemmelse med Direktiv
2014/53/EU.
EU-overensstemmelseserklæringens fulde ordlyd
er tilgængelig på følgende internetadresse:
http://www.jvc.net/cs/car/eudoc/
Ελληνικά
Με το παρόν, η JVCKENWOOD δηλώνει ότι ο
ραδιοεξοπλισμός «KD-DB98BT» συμμορφώνεται με
την Οδηγία 2014/53/ΕΕ.
Το πλήρες κείμενο της δήλωσης συμμόρφωσης
της ΕΕ είναι διαθέσιμο στην ακόλουθη διεύθυνση
στο διαδίκτυο:
http://www.jvc.net/cs/car/eudoc/
Eesti
Käesolevaga JVCKENWOOD kinnitab, et
„KD-DB98BT“ raadiovarustus on vastavuses
direktiiviga 2014/53/EL.
ELi vastavusdeklaratsiooni terviktekst on
kättesaadav järgmisel internetiaadressil:
http://www.jvc.net/cs/car/eudoc/
Latviešu
JVCKENWOOD ar šo deklarē, ka radio aparatūra
„KD-DB98BT” atbilst direktīvas 2014/53/ES
prasībām.
Pilns ES atbilstības deklarācijas teksts ir pieejams
šādā tīmekļa adresē:
http://www.jvc.net/cs/car/eudoc/
Lietuviškai
Šiuo JVCKENWOOD pažymi, kad radijo įranga
„KD-DB98BT“ atitinka 2014/53/EB direktyvos
reikalavimus.
Visą EB direktyvos atitikties deklaracijos tekstą
galite rasti šiuo internetiniu adresu:
http://www.jvc.net/cs/car/eudoc/
Malti
B’dan, JVCKENWOOD jiddikjara li t-tagħmir tar-
radju “KD-DB98BT” huwa konformi mad-Direttiva
2014/53/UE.
It-test kollu tad-dikjarazzjoni ta’ konformità huwa
disponibbli fl-indirizz intranet li ġej:
http://www.jvc.net/cs/car/eudoc/
HRVATSKI / SRPSKI JEZIK
JVCKENWOOD ovim izjavljuje da je radio oprema
“KD-DB98BT” u skladu s Direktivom 2014/53/EU.
Cjeloviti tekst deklaracije Europske unije o
usklađenosti dostupan je na sljedećoj internet
adresi:
http://www.jvc.net/cs/car/eudoc/
ROMÂNĂ
Prin prezenta, JVCKENWOOD declară că
echipamentul radio “
KD-DB98BT ” este în
conformitate cu Directiva 2014/53/UE.
Textul integral al declarației de conformitate UE este
disponibil la urmatoarea adresă de internet:
http://www.jvc.net/cs/car/eudoc/
БЪЛГАРСКИ
С настоящото JVCKENWOOD декларира, че
радиооборудването на “
KD-DB98BT ” е в
съответствие с Директива 2014/53/ЕС.
Пълният текст на ЕС декларацията за
съответствие е достъпен на следния интернет
адрес:
http://www.jvc.net/cs/car/eudoc/
Turkish
Burada, JVCKENWOOD “ KD-DB98BT ” radyo
ekipmanının 2014/53/AB Direktifine uygun
olduğunu bildirir.
AB uyumluluk deklarasyonunun tam metni
aşağıdaki internet adresinde mevcuttur.
http://www.jvc.net/cs/car/eudoc/
Русский
JVCKENWOOD настоящим заявляет,
что радиооборудование «KD-DB98BT»
соответствует Директиве 2014/53/EU.
Полный текст декларации соответствия
ЕС доступен по следующему адресу в сети
Интернет:
http://www.jvc.net/cs/car/eudoc/
Українська
Таким чином, компанія JVCKENWOOD заявляє,
що радіообладнання «KD-DB98BT» відповідає
Директиві 2014/53/EU.
Повний текст декларації про відповідність ЄС
можна знайти в Інтернеті за такою адресою:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_DB98BT_E_C_00_02.indd ivJS_JVC_KD_DB98BT_E_C_00_02.indd iv 11/28/2016 12:13:11 PM11/28/2016 12:13:11 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2ENGLISH
CONTENTS BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important
that you read and observe Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
Warning
• Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded
data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short
circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to
evaporate.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Cancel the demonstration
2 Set the clock and date
3 Set the basic settings
DIGITAL RADIO 5
ANALOG RADIO 7
CD/USB/iPod/ANDROID 9
BLUETOOTH® 11
AUX 18
AUDIO SETTINGS 18
DISPLAY SETTINGS 23
REFERENCES 24
Maintenance
More information
TROUBLESHOOTING 26
INSTALLATION/
CONNECTION 28
SPECIFICATIONS 31
How to read this manual
• Operations are explained mainly using buttons on the faceplate.
• English indications are used for the purpose of explanation. You can select the display language from the
menu.
( 5)
•
[XX] indicates the selected items.
•
( XX) indicates references are available on the stated page.
JS_JVC_KD_DB98BT_E_EN_3.indd 2JS_JVC_KD_DB98BT_E_EN_3.indd 2 11/28/2016 12:13:45 PM11/28/2016 12:13:45 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
ENGLISH
BASICS
To On the faceplate
Turn on the power Press .
• Press and hold to turn off the power.
Adjust the volume Press .
• Press and hold to continuously increase the volume to 15.
Press to mute the sound or pause playback.
• Press again to cancel.
Select a source • Press repeatedly.
• Press , then press within 2 seconds.
Change the display information Press repeatedly.
( 25, 26)
Attach
How to reset
Detach
Faceplate
Loading slot
Detach button
Display window
JS_JVC_KD_DB98BT_E_EN_3.indd 3JS_JVC_KD_DB98BT_E_EN_3.indd 3 11/28/2016 12:13:47 PM11/28/2016 12:13:47 PM

ENGLISH
4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
When you turn on the power for the first time (or [FACTORY RESET] is set
to
[YES] ), the display shows: “CANCEL DEMO” “PRESS ENTER”.
1 Press .
[YES] is selected for the initial setup.
2 Press again.
“DEMO OFF” appears.
Set the clock and date
1 Press and hold .
2 Press to select [CLOCK] , then press .
To adjust the clock
3 Press to select [CLOCK ADJUST] , then press .
4 Press to make the settings, then press .
Hour Minute
5 Press to select [CLOCK FORMAT] , then press .
6 Press to select [12H] or [24H] , then press .
To set the date
7 Press to select [DATE SET] , then press .
8 Press to make the settings, then press .
Day Month Year
9 Press to exit.
To return to the previous setting item, press .
1
Set the basic settings
1 Press and hold .
2 Press to select an item (see the following table), then press
.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
SYSTEM
KEY BEEP
(Not applicable when 3-way crossover is selected.)
ON :Activates the keypress tone.; OFF :Deactivates.
SOURCE SELECT
AM SRC
*
ON :Enables AM in source selection.; OFF :Disables. ( 7)
BUILT-IN AUX
*
ON :Enables AUX in source selection.; OFF :Disables. ( 18)
F/W UPDATE
UPDATE SYSTEM/UPDATE DAB1/UPDATE DAB2
F/W UP xxxx/
F/W UP xxxxx/
F/W UP Vxxx
YES :Starts upgrading the firmware.;
NO :Cancels (upgrading is not activated).
For details on how to update the firmware, see:
<http://www.jvc.net/cs/car/>.
FACTORY RESET YES :Resets the settings to default (except the stored station).; NO :Cancels.
*
Not displayed when the corresponding source is selected.
3
2
JS_JVC_KD_DB98BT_E_EN_3.indd 4JS_JVC_KD_DB98BT_E_EN_3.indd 4 11/28/2016 12:13:52 PM11/28/2016 12:13:52 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
CLOCK
TIME SYNC ON
:The clock time is automatically set using the
Clock Time (CT) data in DAB signal.;
OFF :Cancels.
CLOCK DISPLAY ON :The clock time is shown on the display even
when the unit is turned off.;
OFF :Cancels.
ENGLISH
Select the display language for menu and music
information if applicable.
By default,
ENGLISH is selected.
РУССКИЙ
ESPANOL
DIGITAL RADIO
About DAB (Digital Audio Broadcasting)
DAB is one of the digital radio broadcasting systems available today. It can deliver digital
quality sound without any annoying interference or signal distortion. Furthermore, it can
carry text, pictures and data.
In contrast to FM broadcast, where each program is transmitted on its own frequency,
DAB combines several programs (called “services”) to form one “ensemble”.
The “primary component” (main radio station) is sometimes accompanied by a
“secondary component” which can contain extra programs or other information.
Preparation:
1 Connect a DAB antenna to the DAB antenna jack. ( 30)
2 Press DAB to select DAB directly.
3 Press and hold DAB to start the Service List update.
“DAB SORTING” appears and update starts.
Updates take up to 3 minutes. No interruption (such as traffic information) is possible
during updates.
• To cancel the Service List update: Press and hold DAB again.
Search for an ensemble
1 Press DAB to select DAB directly.
2 Press to search for an ensemble automatically.
(or)
Press and hold until “M” flashes, then press repeatedly to search for an
ensemble manually.
3 Press to select a service (either primary or secondary) to listen to.
JS_JVC_KD_DB98BT_E_EN_3.indd 5JS_JVC_KD_DB98BT_E_EN_3.indd 5 11/28/2016 12:14:03 PM11/28/2016 12:14:03 PM

ENGLISH
6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Other settings
1 Press and hold .
2 Press to select an item ( see the following table ) , then
press .
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
TUNER SETTING
RADIO TIMER
Turns on the radio at a specific time regardless of the current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the timer will be turned
on.
2 FM / AM / DAB :Select the source.
3 01 to 18 (for FM)/ 01 to 06 (for AM)/ 01 to 18 (for DAB):Select the preset
station.
4 Set the activation day
*
and time.
“
M ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
• [OFF] is selected for [AM SRC] in [SOURCE SELECT] after Radio Timer for
AM is selected.
( 4)
*
Selectable only when [ONCE] or [WEEKLY] is selected in step 1 .
AF SET ON :
While listening to DAB...
Automatically switch to FM broadcasting the same program if the DAB signal
becomes weak. It will switch back to DAB sound when the signal becomes
strong again.
While listening to FM...
Automatically switch to DAB source broadcasting the same program (if
available).;
OFF :Cancels.
DIGITAL RADIO
Settings in memory
You can store up to 18 services.
Store a service
While listening to a service....
Press and hold one of the number buttons (1to5).
(or)
1 Press and hold until “PRESETMODE” flashes.
2 Press to select a preset number, then press .
The preset number flashes and “MEMORY” appears.
Select a stored service
Press one of the number buttons (1to5).
(or)
1 Press .
2 Press to select a preset number, then press .
Select a service
1 Press DAB to enter Service Search mode.
2 Press to select a service, then press .
To cancel the Service Search mode, press or DAB.
Select a service by name
1 Press DAB to enter Service Search mode.
2 Press to select the character to be searched for.
3 Press to select a service, then press .
JS_JVC_KD_DB98BT_E_EN_3.indd 6JS_JVC_KD_DB98BT_E_EN_3.indd 6 11/28/2016 12:14:05 PM11/28/2016 12:14:05 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TI ON :Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up).;
OFF :Cancels.
PTY SEARCH Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
DAB
ANNOUCMNT
TRAVEL , WARNINGS , NEWS , WEATHER , EVENT , SPECIAL , RAD INFO ,
SPORTS , FINANCE : Press to make a selection, then press
.
“
*
” appears in front of the activated announcement type.
Automatically switch from any source to Digital radio ensembles
broadcasting an activated announcement type.
• Multiple announcement can be activated simultaneously.
• To deactivate, press again (“
*
” goes off).
LIST UPDATE UPDATE AUTO :Automatically update the DAB Service List when the power
is turned on.;
UPDATE MANUAL :Updates the DAB Service List by pressing
and holding
DAB .
PTY WATCH The unit automatically switch from any source to Digital Radio ensembles
broadcasting the selected type of program. (See the program type below.)
OFF :Cancels.
DAB L-BAND ON : Receives L-BAND ensemble during digital audio reception. ;
OFF : Cancels.
DAB ANT
POWER
ON : Supplies power to the DAB antenna. ; OFF : Does not supply power.
Selects when using passive antenna without booster.
RELATED SERV ON :Enable Soft-Link function to switch to an alternative service which is
different audio program from the current audio program.;
OFF :Disable.
PTY code/Program Type:
NEWS , AFFAIRS , INFO , SPORT , EDUCATE , DRAMA , CULTURE , SCIENCE , VARIED , POP
M
(music), ROCK M (music), EASY M (music), LIGHT M (music), CLASSICS , OTHER
M
(music), WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION , PHONE IN , TRAVEL ,
LEISURE , JAZZ , COUNTRY , NATION M (music), OLDIES , FOLK M (music), DOCUMENT
DIGITAL RADIO ANALOG RADIO
“ST” lights up when receiving an FM stereo broadcast with sufficient
signal strength.
Search for a station
1 Press repeatedly to select FM or AM.
2 Press to search for a station automatically.
(or)
Press and hold until “M” flashes, then press repeatedly to
search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1to 5).
(or)
1 Press and hold until “PRESETMODE” flashes.
2 Press to select a preset number, then press .
The preset number flashes and “MEMORY” appears.
JS_JVC_KD_DB98BT_E_EN_3.indd 7JS_JVC_KD_DB98BT_E_EN_3.indd 7 11/28/2016 12:14:12 PM11/28/2016 12:14:12 PM

ENGLISH
8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
NEWS SET
*
ON :The unit will temporarily switch to News Programme if available.;
OFF :Cancels.
REGIONAL
*
ON : Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET
*
ON : Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF : Cancels.
TI
*
ON : Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up). ;
OFF :Cancels.
• [TI] in AM band is for enabling traffic interruption to DAB source only.
PTY SEARCH
*
Select a PTY code. ( 7)
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
*
Only for FM source.
Select a stored station
Press one of the number buttons (1to5).
(or)
1 Press .
2 Press to select a preset number, then press .
Other settings
1 Press and hold .
2 Press to select an item ( see the following table ) , then
press .
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
TUNER SETTING
RADIO TIMER ( 6)
SSM SSM 01–06
/ SSM 07–12 / SSM 13–18 : Automatically presets up to 18
stations for FM. “SSM” stops flashing when the first 6 stations are stored.
Select
SSM 07–12 / SSM 13–18 to store the following 12 stations.
LOCAL SEEK ON :Searches only FM stations with good reception.; OFF :Cancels.
• Settings made are applicable only to the selected source/station. Once you
change the source/station, you need to make the settings again.
IF BAND AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not be
degraded and the stereo effect will remain.
MONO SET ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
ANALOG RADIO
JS_JVC_KD_DB98BT_E_EN_3.indd 8JS_JVC_KD_DB98BT_E_EN_3.indd 8 11/28/2016 12:14:15 PM11/28/2016 12:14:15 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD/USB/iPod/ANDROID
To On the faceplate
Reverse/Fast-forward*3Press and hold .
Select a track/file Press .
Select a folder*4Press .
Repeat play*5Press repeatedly.
TRACK REPEAT / ALL REPEAT : Audio CD
TRACK REPEAT / FOLDER REPEAT / ALL REPEAT : MP3/WMA/AAC/WAV/FLAC file
ONE REPEAT / ALL REPEAT / REPEAT OFF : iPod or ANDROID
Random play*5Press repeatedly.
ALL RANDOM / RANDOM OFF : Audio CD
FOLDER RANDOM / ALL RANDOM / RANDOM OFF : MP3/WMA/AAC/WAV/FLAC file
SONG RANDOM / ALL RANDOM / RANDOM OFF : iPod or ANDROID
*1
Do not leave the cable inside the car when not using.
*2
When connecting an Android device, “Press [VIEW] to install JVC MUSIC PLAY APP” is shown. Follow the instructions to install the
application. You can also install the latest version of JVC MUSIC PLAY application on your Android device before connecting. For
more information, visit <http://www.jvc.net/cs/car/>.
*3
For ANDROID: Applicable only when [AUTO MODE] is selected. ( 10)
*4
For CD: Only for MP3/WMA/AAC files. This does not work for iPod/ANDROID.
*5
For iPod/ANDROID: Applicable only when [HEAD MODE] / [AUTO MODE] is selected. ( 10)
Start playback
The source changes automatically and
playback starts.
CD
Eject disc Label side
USB input terminal
USB 2.0 cable
*1
(commercially available)
Micro USB 2.0 cable
*1
(commercially available)
USB
ANDROID*2
Accessory of the
iPod/iPhone
*1
iPod/iPhone
JS_JVC_KD_DB98BT_E_EN_3.indd 9JS_JVC_KD_DB98BT_E_EN_3.indd 9 11/28/2016 12:14:19 PM11/28/2016 12:14:19 PM

ENGLISH
10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select control mode
While in iPodUSB source, press repeatedly.
HEAD MODE : Control iPod from this unit.
IPHONE MODE : Control iPod using the iPod itself. However, you can still
play/pause or file skip from this unit.
While in ANDROID source, press repeatedly.
AUTO MODE : Control Android device from this unit via JVC MUSIC PLAY
application installed in the Android device.
AUDIO MODE : Control Android device using the Android device itself via
other media player applications installed in the Android
device. However, you can still play/pause or file skip from
this unit.
Select music drive
While in USB source, press repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass Storage
Class).
• Selected drive of a multiple drives device.
Settings to use JVC Remote application
JVC Remote application is designed to control the JVC car receiver’s
operations from the iPhone/iPod (via USB input terminal).
Preparation:
Install the latest version of JVC Remote application on your device before
connecting. For more information, visit <http://www.jvc.net/cs/car/>.
You can make the settings in the same way as connection via Bluetooth.
( 17)
Select a file from a folder/list
For iPod/ANDROID, applicable only when [HEAD MODE] / [AUTO MODE] is
selected.
1 Press .
2 Press to select a folder/list, then press .
3 Press to select a file, then press .
Quick search (applicable only for CD, USB and ANDROID source)
If you have many files, you can search through them quickly.
Press and hold to browse through the list quickly.
Alphabet search (applicable only for iPod USB and ANDROID source)
You can search for a file according to the first character.
For iPodUSB source
Press to select the desired character (A to Z, 0to9,
OTHERS).
• Select “OTHERS” if the first character is other than AtoZ, 0to9.
For ANDROID source
1 Press to enter character search.
2 Press to select the desired character.
^A^ : Upper case (A to Z)
_A_ : Lower case (a to z)
-0- : Numbers (0 to 9)
-OTHERS-: Character other than A to Z, 0 to 9
3 Press to start searching.
• To return to the previous setting item, press .
• To cancel, press and hold .
CD/USB/iPod/ANDROID
JS_JVC_KD_DB98BT_E_EN_3.indd 10JS_JVC_KD_DB98BT_E_EN_3.indd 10 11/28/2016 12:14:23 PM11/28/2016 12:14:23 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pair and connect a Bluetooth device for the first time
1 Press to turn on the unit.
2 Search and select “KD-DB9 BT” on the Bluetooth device.
“BTPAIRING” flashes on the display.
• For some Bluetooth devices, you may need to enter the Personal Identification Number (PIN)
code immediately after searching.
3 Perform (A) or (B) depending on what appears on the display.
For some Bluetooth devices, pairing sequence may vary from the steps described below.
(A) “[Device Name]” “XXXXXX” “ENTER–YES” “BACK–NO”.
“XXXXXX” is a 6-digit passkey randomly generated during each pairing.
Ensure that the passkeys appear on the unit and Bluetooth device are the same.
Press to confirm the passkey.
Operate the Bluetooth device to confirm the passkey.
(B) “[Device Name]” “ENTER–YES” “BACK–NO”.
Press to start pairing.
• If “PAIRING” “PIN 0000” scrolls on the display, enter the PIN code “0000” into the
Bluetooth device.
You can change to a desired PIN code before pairing.
( 15)
• If only “PAIRING” appears, operate the Bluetooth device to confirm pairing.
“PAIRING COMPLETED” appears when pairing is completed and “ ” will light up when the Bluetooth
connection is established.
• This unit supports Secure Simple Pairing (SSP).
• Up to five devices can be registered (paired) in total.
• Once the pairing is completed, the Bluetooth device will remain registered in the unit even if you
reset the unit. To delete the paired device,
15 , [DEVICE DELETE] .
• A maximum of two Bluetooth phones and one Bluetooth audio device can be connected at any
time.
However, while in BT AUDIO source, you can connect to five Bluetooth audio devices and switch
between these five devices.
( 16)
• Some Bluetooth devices may not automatically connect to the unit after pairing. Connect the
device to the unit manually.
• Refer to the instruction manual of the Bluetooth device for more information.
BLUETOOTH®
BLUETOOTH — Connection
Supported Bluetooth profiles
– Hands-Free Profile (HFP)
– Advanced Audio Distribution Profile (A2DP)
– Audio/Video Remote Control Profile (AVRCP)
– Serial Port Profile (SPP)
– Phonebook Access Profile (PBAP)
Supported Bluetooth codecs
– Sub Band Codec (SBC)
– Advanced Audio Coding (AAC)
Connect the microphone
Adjust the
microphone angle Secure using cord clamps
(not supplied) if necessary.
Microphone input jack
Microphone (supplied)
Rear panel
JS_JVC_KD_DB98BT_E_EN_3.indd 11JS_JVC_KD_DB98BT_E_EN_3.indd 11 11/28/2016 12:14:28 PM11/28/2016 12:14:28 PM

ENGLISH
12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Auto Pairing
When you connect iPhone/iPod touch/Android
device to the USB input terminal, pairing request
(via Bluetooth) is automatically activated.
Press to pair once you have confirmed
the device name.
Automatic pairing request is activated only if:
– Bluetooth function of the connected device is
turned on.
–
[AUTO PAIRING] is set to [ON] . ( 15)
– JVC MUSIC PLAY application is installed on the
Android device
( 9) and [AUTO MODE] is selected
( 10) .
BLUETOOTH — Mobile phone
Receive a call
When there is an incoming call:
• The symbolic button will blink in the color you have selected in
[RING COLOR] . ( 13)
• The unit answers the call automatically if [AUTO ANSWER] is set to a selected time. ( 13)
During a call:
• The symbolic button stop blinking and illuminate in the color you have selected in
[RING COLOR] . ( 13)
• If you turn off the unit or detach the faceplate, the Bluetooth connection is disconnected.
The following operations may differ or not available depending on the connected phone.
To On the faceplate
First incoming call...
Answer a call Press or .
Reject a call Press and hold or .
End a call Press and hold or .
While talking on the first incoming call...
Answer another incoming call and
hold the current call
Press or .
Reject another incoming call Press and hold or .
BLUETOOTH®
Symbolic button
JS_JVC_KD_DB98BT_E_EN_3.indd 12JS_JVC_KD_DB98BT_E_EN_3.indd 12 11/28/2016 12:14:34 PM11/28/2016 12:14:34 PM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
To On the faceplate
While having two active calls...
End current call and activate
held call
Press and hold or .
Swap between the current call
and held call
Press .
Adjust the phone volume*1
[00] to [35] (Default: [15] )
Press during a call.
Switch between hands-free and
private talk modes*2Press during a call.
*1
This adjustment will not affect the volume of the other sources.
*2
Operations may vary according to the connected Bluetooth device.
Improve the voice quality
While talking on the phone....
1 Press and hold .
2 Press to select an item ( see the following table ) , then press
.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
MIC GAIN LEVEL –10 to LEVEL +10 ( LEVEL –04 ): The sensitivity of the microphone increases
as the number increased.
NR LEVEL LEVEL –05 to LEVEL +05 ( LEVEL 00 ): Adjust the noise reduction level until the least
noise is being heard during a phone conversation.
ECHO CANCEL LEVEL –05 to LEVEL +05 ( LEVEL 00 ): Adjust the echo cancellation delay time until
the least echo is being heard during a phone conversation.
BLUETOOTH®
Make the settings for receiving a call
1 Press to enter Bluetooth mode.
2 Press to select an item ( see the following table ) ,
then press .
3 Repeat step 2until the desired item is selected or activated.
To return to the previous setting item, press .
Default:
XX
SETTINGS
AUTO ANSWER 01 SEC
to 30 SEC :The unit answers incoming call automatically
in the selected time (in seconds).;
OFF :Cancels.
RING COLOR COLOR 01 to COLOR 49 ( COLOR 08 ): Selects the illumination
color for the symbolic button as notification when there is an
incoming call and during a call.;
OFF :Cancels.
JS_JVC_KD_DB98BT_E_EN_3.indd 13JS_JVC_KD_DB98BT_E_EN_3.indd 13 11/28/2016 12:14:40 PM11/28/2016 12:14:40 PM

ENGLISH
14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Make a call
You can make a call from the call history, phonebook, or dialing the number. Call by
voice is also possible if your mobile phone has the feature.
1 Press to enter Bluetooth mode.
“(First device name)” appears.
• If two Bluetooth phones are connected, press again to switch to another
phone.
“(Second device name)” appears.
2 Press to select an item ( see the following table ) , then press .
3 Repeat step 2until the desired item is selected/activated or follow the
instructions stated on the selected item.
To return to the previous setting item, press .
RECENT CALL (Applicable only if the phone supports PBAP.)
1 Press to select a name or a phone number.
• “<” indicates call received, “>“ indicates call made, “M” indicates call missed.
• “NO HISTORY” appears if there is no recorded call history or call number.
2 Press to call.
PHONEBOOK (Applicable only if the phone supports PBAP.)
1 Press to select the desired letter (A to Z, 0to9, and OTHERS).
• “OTHERS” appears if the first character is other than Ato Z, 0 to 9.
2 Press to select a name, then press .
3 Press to select a phone number, then press to call.
• The phonebook of the connected phone is automatically transferred to the unit when pairing.
• This unit can display only non-accent letters. (Accent letters such as “Ú” is showns as “U”.)
DIAL NUMBER 1 Press to select a number (0 to 9) or character ( , #, +).
2 Press to move the entry position.
Repeat steps
1 and 2 until you finish entering the phone number.
3 Press to call.
VOICE Speak the name of the contact you want to call or the voice command to control the phone
functions.
( Make a call using voice recognition)
BLUETOOTH®
Make a call using voice recognition
1 Press and hold to activate the connected
phone.
2 Speak the name of the contact you want to call or the
voice command to control the phone functions.
• Supported Voice Recognition features vary for each
phone. Refer to the instruction manual of the connected
phone for details.
• This unit also supports the intelligent personal assistant
function of iPhone.
Settings in memory
Store a contact in memory
You can store up to 5 contacts into the number buttons
(1to 5).
1 Press to enter Bluetooth mode.
2 Press to select [RECENT CALL] , [PHONEBOOK] or
[DIAL NUMBER] , then press .
3 Press to select a contact or enter a phone
number.
If a contact is selected, press to show the
phone number.
4 Press and hold one of the number buttons (1to 5).
“MEMORY P(selected preset number)” appears when
the contact is stored.
To erase a contact from the preset memory, select
[DIAL NUMBER] in step 2and store a blank number.
Make a call from memory
1 Press to enter Bluetooth mode.
2 Press one of the number buttons (1to 5).
3 Press to call.
“NO PRESET” appears if there is no contact stored.
JS_JVC_KD_DB98BT_E_EN_3.indd 14JS_JVC_KD_DB98BT_E_EN_3.indd 14 11/28/2016 12:14:44 PM11/28/2016 12:14:44 PM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Bluetooth mode settings
1 Press and hold .
2 Press to select an item ( see the following table ) , then press .
3 Repeat step 2until the desired item is selected/activated or follow the instructions
stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
BT MODE
PHONE SELECT
* Selects the phone or audio device to connect or disconnect.
“” appears in front of the device name when connected.
“” appears in front of the current playback audio device.
AUDIO SELECT *
DEVICE DELETE
1 Press to select a device to delete, then press .
2 Press to select [YES] or [NO] , then press .
PIN CODE EDIT
(0000)
Changes the PIN code (up to 6 digits).
1 Press to select a number.
2 Press to move the entry position.
Repeat steps
1 and 2 until you finish entering the PIN code.
3 Press to confirm.
RECONNECT ON :The unit automatically reconnect when the last connected Bluetooth device is within
range.;
OFF :Cancels.
AUTO PAIRING ON :The unit automatically pair supported Bluetooth device (iPhone/iPod touch/Android
device) when it is connected through USB input terminal.Depending on the operating
system of the connected device, this function may not work. ;
OFF :Cancels.
INITIALIZE YES :Initializes all the Bluetooth settings (including stored pairing, phonebook, and etc.).;
NO :Cancels.
INFORMATION MY  BT  NAME : Displays the unit name (“KD-DB9 BT”).;
MY  ADDRESS : Shows address of this unit.
*
You can only connect a maximum of two Bluetooth phones and one Bluetooth audio device at any time.
Bluetooth compatibility check mode
You can check the connectivity of the supported profile
between the Bluetooth device and the unit.
• Make sure there is no Bluetooth device paired.
1 Press and hold .
“BLUETOOTH” “CHECK MODE” appears. “SEARCH
NOW USING PHONE” “PIN IS 0000” scrolls on the
display.
2 Search and select “KD-DB9 BT” on the Bluetooth
device within 3minutes.
3 Perform (A), (B) or (C) depending on what appears
on the display.
(A) “PAIRING” “XXXXXX” (6-digit passkey): Ensure
that the same passkey appears on the unit and
Bluetooth device, then operate the Bluetooth
device to confirm the passkey.
(B) “PAIRING” “PIN IS 0000”: Enter “0000” on the
Bluetooth device.
(C) “PAIRING”: Operate the Bluetooth device to
confirm pairing.
After pairing is successful, “PAIRING OK” “[Device
Name]” appears and Bluetooth compatibility check starts.
If “CONNECT NOW USING PHONE” appears, operate the
Bluetooth device to allow phonebook access to continue.
“TESTING” flashes on the display.
BLUETOOTH®
JS_JVC_KD_DB98BT_E_EN_3.indd 15JS_JVC_KD_DB98BT_E_EN_3.indd 15 11/28/2016 12:14:51 PM11/28/2016 12:14:51 PM

ENGLISH
16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
The connectivity result flashes on the display.
“PAIRING OK” and/or “HANDS-FREE OK”*1and/or
“AUD.STREAM OK”*2and/or “PBAP OK”*3: Compatible
*1
Compatible with Hands-Free Profile (HFP)
*2
Compatible with Advanced Audio Distribution Profile (A2DP)
*3
Compatible with Phonebook Access profile (PBAP)
After 30 seconds, “PAIRING DELETED” appears to
indicate that pairing has been deleted, and the unit
exits check mode.
• To cancel, press and hold to turn off the
power, then turn on the power again.
BLUETOOTH — Audio
Audio player via Bluetooth
1 Press repeatedly to select BTAUDIO.
• Pressing enters BT AUDIO directly.
2 Operate the Bluetooth audio player to start playback.
To On the faceplate
Playback/pause Press .
Select group or folder Press .
Reverse skip/Forward skip Press .
Reverse/Fast-forward Press and hold .
Repeat play Press repeatedly.
TRACK REPEAT , ALL REPEAT , REPEAT OFF
Random play Press repeatedly.
GROUP RANDOM , ALL RANDOM , RANDOM OFF
Select a file from a folder/list Refer to “Select a file from a folder/list” on page 10.
Switch between connected
Bluetooth audio devices
Press 5.*
*
Pressing the “Play” key on the connected device itself also causes switching of sound output from the device.
Operations and display indications may differ according to their availability on the
connected device.
BLUETOOTH®
While in BT AUDIO source, you
can connect to five Bluetooth
audio devices and switch
between these five devices.
JS_JVC_KD_DB98BT_E_EN_3.indd 16JS_JVC_KD_DB98BT_E_EN_3.indd 16 11/28/2016 12:14:58 PM11/28/2016 12:14:58 PM
