KD-G724
Installation/Connection Manual
1205DTSMDTJEIN
EN
1
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does
not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.
J
Handles
F
asher (ø5)
G
Lock nut (M5)
H
Mounting bolt (M5 × 20 mm)
I
Rubber cushion
A / B
Hard case/Control panel
C
Sleeve
D
Trim plate
E
Power cord
Parts list for installation and connection
The following parts are provided for this unit. If any item is missing, consult your JVC car audio
dealer immediately.
K
Remote controller
L
Battery
Do the required electrical
connections.
*1 hen you stand the unit,
be careful not to damage the
fuse on the rear.
Bend the appropriate tabs
to hold the sleeve firmly in
place.
INSTALLATION (IN-DASH MOUNTING)
The following illustration shows a typical installation. If you have any questions or require information
regarding installation kits, consult your JVC car audio dealers or a company supplying kits.
• If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Remo ing the unit
Before removing the unit, release the rear section.
Insert the two handles, then pull them as
illustrated so that the unit can be removed.
GET0356-002A
[UI]
When installing the unit without
using the slee e
In a Toyota car for example, first remove the car radio
and install the unit in its place.
When using the optional stay
Note : hen installing the unit on the mounting
bracket, make sure to use the 8 mm-long
screws. If longer screws are used, they could
damage the unit.
*2 Not supplied for this unit.
Screw (option)
Stay (option)
Fire wall
Dashboard
Install the unit at an
angle of less than
30˚.
TROUBLESHOOTING
• The fuse blows.
* Are the red and black leads connected correctly?
• Power cannot be turned on.
* Is the yellow lead connected?
• No sound from the speakers.
* Is the speaker output lead short-circuited?
• Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• Noise interfere with sounds.
* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?
• This unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• This unit does not work at all.
* Have you reset your unit?
Bracket*2
Pocket
Flat type screws
(M5 × 8 mm)*2
Bracket*2
WARNINGS
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio
dealers.
• It is recommended to connect to the speakers with maximum power of more than 50 (both at
the rear and at the front, with an impedance of 4 Ω to 8 Ω). If the maximum power is less than
50 , change “AMP GAIN” setting to prevent the speakers from being damaged (see page 14 of the
INSTRUCTIONS).
• To prevent short-circuit, cover the terminals of the UNUSED leads with
insulating tape.
• The heat sink becomes very hot after use. Be careful not to touch it
when removing this unit.
PRECAUTIONS on power supply and speaker connections:
• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit
will be seriously damaged.
• BEFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.
© 2005 Victor Company of Japan, Limited
Flat type screws
(M5 × 8 mm)*2
Heat sink
Install_KD-G724[UI]f.indd 1Install_KD-G724[UI]f.indd 1 12/13/05 6:23:27 PM12/13/05 6:23:27 PM
A
2
Typical connections
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.
Other external component
*7 Line Input Adapter KS-U57 (not supplied for this unit)
Connecting the external amplifiers and/or subwoofer
You can connect amplifiers to
upgrade your car stereo system.
• Connect the remote lead (blue
with white stripe) to the remote
lead of the other equipment so
that it can be controlled through
this unit.
•
Disconnect the speakers from
this unit, connect them to the
amplifier. Lea e the speaker
leads of this unit unused.
*3 Firmly attach the ground
wire to the metallic
body or to the chassis
of the car—to the place
uncoated with paint (if
coated with paint, remove
the paint before attaching
the wire). Failure to do so
may cause damage to the
unit.
• Set “EXT IN” for the exter al i put setti g (See page 14 of the INSTRUCTIONS.)
CAUTION:
• Before connecting the external components,
make sure that the unit is turned off.
*4
Signal cord (not supplied for this unit)
External
component
3.5 mm stereo mini plug
B
Rear speakers
JVC Amplifier
Remote lead Y-connector (not supplied for this unit)
Remote lead (Blue with white stripe) To the remote lead of other equipment or automatic antenna if any
Front speakers
External
component
ELECTRICAL CONNECTIONS
CD changer jack
Line out (see diagram )
Rear ground terminal
15 A fuse
Black
Blue with white stripe
Red
Yellow *2
To metallic body or chassis of the car
Ignition switch
Fuse block
To an accessory terminal in the fuse block
To the remote lead of other equipment (200 mA max.)
Right speaker (rear)
Purple
Left speaker (rear)
Purple with black stripeGreen
Right speaker (front)
Green with black stripe
Gray
Left speaker (front)
Gray with black stripehitehite with black stripe
To a live terminal in the fuse block connecting to the car
battery (bypassing the ignition switch) (constant 12 V)
Orange with white stripe
To car light control switch
To external components (see diagram )
*1 Not supplied for this unit.
*2
Before checking the operation of this unit prior to
installation, this lead must be connected, otherwise
power cannot be turned on.
Blue To the automatic antenna if any (250 mA
max.)
CD changer, Apple iPod®, or JVC D. player
You can connect these components as illustrated below. The iPod*5 or D. player
can be connected using an interface adapter (not supplied)—KS-PD100 (for
iPod) or KS-PD500 (for D. player).
*6 Connecting cord supplied for your CD changer
Connecting the external components
C
• Set “CHANGER” for the exter al i put setti g (See page 14 of the INSTRUCTIONS.)
Apple iPod
(separately purchased)
JVC D. player
(separately purchased)
CD changer jack
JVC CD changer
*5 iPod is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
*8 AUX Input Adapter KS-U58 (not supplied for this unit)
or
Brown
To subwoofer (see diagram )
To cellular phone system
JVC Amplifier
JVC Amplifier
Antenna connector
Front speakers Subwoofer
Install_KD-G724[UI]f.indd 2Install_KD-G724[UI]f.indd 2 12/13/05 6:23:36 PM12/13/05 6:23:36 PM
