KD-DV4206/KD-DV4205
Installation/Connection Manual
GET0369-009A
[A]
1205DTSMDTJEIN
EN
1
This unit is designed to operate on 12 V DC, NEGATIVE ground electrical systems. If your vehicle does
not have this system, a voltage inverter is required, which can be purchased at JVC car audio dealers.
WARNINGS
To prevent accidents and damage
• DO NOT install any unit in locations where;
– it may obstruct the steering wheel and gearshift lever operations.
– it may obstruct the operation of safety devices such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
• If you need to operate the unit while driving, be sure to look ahead carefully.
• The driver must not watch the monitor while driving.
If the parking brake is not engaged, “DRIVER MUST NOT WATCH THE MONITOR WHILE
DRIVING.” appears on the monitor, and no playback picture will be shown.
– This warning appears only when the parking brake wire is connected to the parking brake
system built in the car.
PRECAUTIONS on power supply and speaker connections
• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the
unit will be seriously damaged.
• EFORE connecting the speaker leads of the power cord to the speakers, check the speaker wiring in
your car.
About sounds reproduced through the rear terminals
• Through the analog terminals (Speaker out/LINE OUT)
2-channel signal is emitted.
When playing a multi-channel encoded disc, multi-channel signals are downmixed. (AUDIO—
DOWN MIX: see page 22 of the INSTRUCTIONS.)
• Through DIGITAL OUT (optical)
Digital signals (Linear PCM, Dolby Digital*1, DTS*2, MPEG Audio) are emitted through this
terminal. (For more details, see page 28 of the INSTRUCTIONS.)
To reproduce multi-channel sounds such as Dolby Digital and DTS, connect an amplifier or a
decoder compatible with these multi-channel sources to this terminal, and set “DIGITAL AUDIO
OUTPUT” correctly. (See page 22 of the INSTRUCTIONS.)
*1 Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
*2 “DTS” and “DTS 2.0 + Digital Out” are trademarks of Digital Theater Systems, Inc.
To prevent short circuits, we recommend that you disconnect the battery’s negative terminal and make all
electrical connections before installing the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes
• Replace the fuse with one of the specified rating. If the fuse blows frequently, consult your JVC car audio
dealer.
• It is recommended to connect to the speakers with maximum power of more than 50 W (both at
the rear and at the front, with an impedance of 4 Ω to 8 Ω). If the maximum power is less than
50 W, change “AMP GAIN” setting to prevent the speakers from being damaged (see page 21 of the
INSTRUCTIONS).
• To prevent short-circuit, cover the terminals of the UNUSED leads with insulating tape.
• The heat sink becomes very hot after use. e careful not to touch it when removing this unit.
Heat sink
© 2005 Victor Company of Japan, Limited
J
Rubber cushion
F
Crimp connector
G
Washer (ø5)
H
Lock nut (M5)
I
Mounting bolt (M5 × 20 mm)
Parts list for installation and connection
The following parts are provided for this unit. If any item is missing, consult your JVC car audio dealer
immediately.
K
Handles
L
Remote controller
M
attery
A / B
Hard case/Control panel
C
Sleeve
D
Trim plate
E
Power cord
TROUBLESHOOTING
• The fuse blows.
* Are the red and black leads connected correctly?
• Power cannot be turned on.
* Is the yellow lead connected?
• No sound from the speakers.
* Is the speaker output lead short-circuited?
• Sound is distorted.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• Noise interfere with sounds.
* Is the rear ground terminal connected to the car’s chassis using shorter and thicker cords?
• Unit becomes hot.
* Is the speaker output lead grounded?
* Are the “–” terminals of L and R speakers grounded in common?
• This unit does not work at all.
* Have you reset your unit?
Instal1-2_DV4206_009A_f.indd 1Instal1-2_DV4206_009A_f.indd 1 12/21/05 2:26:26 PM12/21/05 2:26:26 PM

INSTALLATION (IN-DASH MOUNTING)
The following illustration shows a typical installation. If you have any questions or require information regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
• If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Removing the unit
efore removing the unit, release the rear section.
3
Do the required electrical connections.
end the appropriate tabs to hold the
sleeve firmly in place.
*3 When you stand the unit,
be careful not to damage
the fuse on the rear.
When installing the unit without using the sleeve
In a Toyota car for example, first remove the car radio and install the unit in its place.
When using the optional stay
Note When installing the unit on the mounting bracket, make sure to use the 8 mm-long screws. If longer screws
are used, they could damage the unit.
*4 Not supplied for this unit.
Screw (option)
Stay (option)
Fire wall
Dashboard
Install the unit at an angle of less than 30˚.
racket*4
Flat type screws (M5 × 8 mm)*4
Pocket
Flat type screws (M5 × 8 mm)*4
racket*4
Insert the two handles, then pull them as
illustrated so that the unit can be removed.
Instal1-2_DV4206_009A_f.indd 2Instal1-2_DV4206_009A_f.indd 2 12/21/05 2:26:33 PM12/21/05 2:26:33 PM

Connecting the crimp connector
C
3
To external components (see diagram )
Light green
VIDEO OUT (see diagram )
DIGITAL OUT
(see diagram )
A
B
Connecting the parking brake wire
When installing the monitor in a location where it can be seen by the driver
When installing the monitor in a location where it cannot be seen by the driver
Connect the parking brake wire to metallic body or chassis or the car.
Parking brake wire (light green)
To metallic body or chassis of the car
Parking brake switch (inside the car)
Parking brake
Parking brake wire (light green)
*3 Not supplied for this unit.
To parking brake metallic body or chassis of the car
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious damage to this unit.
The leads of the power cord and those of the connector from the car body may be different in color.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wiring harness to the unit.
15 A fuse
Black
Blue with white stripe
Red
Yellow *2
To metallic body or chassis of the car
Ignition switch
Fuse block
To an accessory terminal in the fuse block
To the remote lead of other equipment (200 mA max.)
To a live terminal in the fuse block connecting to the car battery (bypassing
the ignition switch) (constant 12 V)
*1 Not supplied for this unit.
Line out (see diagram )
Rear ground terminal
*2 Before checking the operation of this unit prior to
installation this lead must be connected otherwise
power cannot be turned on.
Left speaker (front) Right speaker (front) Left speaker (rear) Right speaker (rear)
PurplePurple with black stripe
Green
Green with black stripeGrayGray with black stripeWhiteWhite with black stripe
Wire connecting the battery and the parking brake switch.
Attach the parking brake wire to this point.
Contact the metallic part of the crimp to the wires inside.
Pinch the crimp firmly.
Blue
To automatic antenna if any (250 mA max.)
Typical connections
ELECTRICAL CONNECTIONS
Antenna connector
Instal3-4_DV4206_009A_f.indd 3Instal3-4_DV4206_009A_f.indd 3 12/21/05 2:26:05 PM12/21/05 2:26:05 PM

4
D
Other external component
CAUTION :
Before connecting the external components, make sure that the unit is turned off.
Connecting the external components
JVC CD changer
External component
3.5 mm stereo mini plug *8 Line Input Adapter KS- 57 (not supplied for this unit)
*9 A X Input Adapter KS- 58 (not supplied for this unit)
• Set “EXT IN” for the external input setting (See page 2 of the INSTRUCTIONS.)
• Set “CHANGER” for the external input setting (See page 2 of the INSTRUCTIONS.)
*6 iPod is a trademark of Apple Computer, Inc., registered in the .S. and other countries.
*7 Connecting cord supplied for your CD changer
CD changer, Apple iPod®, or JVC D. player
F
E
CD changer jack External component
Connecting the external amplifier
You can connect an amplifier to upgrade your car stereo system.
• Connect the remote lead (blue with white stripe) to the remote lead of the other equipment so that it can be controlled through this unit.
Disconnect the speakers from this unit, connect them to the amplifier. Leave the speaker leads of this unit unused.
Rear speakers
JVC Amplifier
Remote lead Y-connector (not supplied for this unit)
Remote lead (Blue with white stripe)
To the remote lead of other equipment or automatic antenna if any
Front speakers
*4 Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with
paint (if coated with paint, remove the paint before attaching the wire). Failure to do so may cause damage to
the unit.
*5 Signal cord (not supplied for this unit)
Required connections for DVD playback
Audio/video control amplifier or the decoder compatible with the
multichannel digital sources
KV-MR9010
9-INCH WIDESCREEN
MONITOR (not supplied)
Digital optical cable
(not supplied)
DIGITAL OUT
See “About sounds reproduced
through the rear terminals.”
Apple iPod
(separately purchased)
JVC D. player
(separately purchased)
CD changer jack
You can connect these components as illustrated below. The iPod*6 or D. player can be connected using an interface adapter (not supplied)—KS-PD100 (for iPod) or KS-PD500 (for D. player).
Video cord (not supplied)
or
