JVC MA372IEN Guide

1– EN
ENGLISH ESPAÑOL
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B di ital device, pursuant to Part 15 of
the FCC Rules. These limits are desi ned to provide reasonable protection a ainst harmful interference in a residential
installation. This equipment enerates, uses, and can radiate radio frequency ener y and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
uarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turnin the equipment off and on, the user is encoura ed to
try to correct the interference by one or more of the followin measures:
– Reorient or relocate the receivin antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution
Chan es or modifications not approved by JVC could void the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicin to qualified
service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
KD-G240/KD-G140
CD RECEIVER: INSTRUCTIONS/INSTALLATION
GET0485-001A
[J]
0807DTSMDTJEIN
EN
© 2007 Victor Company of Japan, Limited
For customer Use:
Enter below the Model No. and Serial No. which
are located on the top or bottom of the cabinet.
Retain this information for future reference.
Model No.
Serial No.
arning
If you need to operate the unit while drivin , be sure to
look around carefully or you may be involved in a traffic
accident.
Caution on volume setting
Discs produce very little noise compared with other sources.
Lower the volume before playin a disc to avoid dama in
the speakers by the sudden increase of the output level.
To keep discs clean
Wipe in a strai ht line from center of disc to
ed e. Do not use liquid cleaners, thinners, or
benzene.
To play new discs
Remove any rou h areas from the inner and
outer ed es of the disc.
MAINTENANCE
How to clean the connectors
Wipe the connectors with
a cotton swab or cloth
moistened with alcohol.
Moisture condensation
Moisture may condense on the lens inside the unit. Eject
the disc and leave the unit turned on for a few hours until
the moisture has evaporated.
Do not use the following discs:
– There are improper recordin conditions (missin data,
etc.) or media conditions (stained, scratched, warped,
etc.).
• CD-RWs may require a lon er readout time since the
reflectance of CD-RWs is lower than that of re ular CDs.
Playing an MP3/ MA disc (for KD-G240)
• This unit can play back MP3/WMA files with the
extension code <.mp3> or <.wma> (re ardless of the
letter case—upper/lower).
• This unit can show the names of albums, artists
(performer), and ta (Version 1.0, 1.1, 2.2, 2.3, or 2.4) for
MP3 files and for WMA files.
• This unit can display only one-byte characters. No other
characters can be correctly displayed.
• This unit can play back MP3/WMA files meetin the
conditions below:
– Bit rate: 8 kbps — 320 kbps
– Samplin frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc format: ISO 9660 Level 1/ Level 2, Romeo, Joliet,
Windows lon file name
• The maximum number of characters for file/folder names
vary dependin on the disc format used (includes 4
extension characters—<.mp3> or <.wma>).
– ISO 9660 Level 1: up to 12 characters; ISO 9660 Level 2:
up to 31 characters; Romeo: up to 64 characters; Joliet:
up to 32 characters; Windows lon file name: up to 126
characters
• This unit can reco nize a total of 512 files, 200 folders,
and 8 hierarchical levels.
• This unit can play back files recorded in VBR (variable bit
rate).
Files recorded in VBR have a discrepancy in the elapsed
time display, and do not show the actual elapsed time.
In particular, this difference becomes noticeable after
performin the search function.
• This unit cannot play back the followin files:
– MP3 files encoded in: MP3i and MP3 PRO format, in an
inappropriate format, layer 1/2.
– WMA files: encoded in lossless, professional, and voice
format; not based upon Windows Media® Audio; copy-
protected with DRM.
– Files which have data such as WAVE, ATRAC3, etc.
• The search function works but search speed is not
constant.
Basic operations
• By pressin SRC on the unit, you can also turn on the
power. If the source is ready, playback also starts.
• If you turn off the power while listenin to a disc, disc
play will start from where it had been stopped previously
next time you turn on the power.
• When no disc is loaded in the unit, you cannot select “CD”
as the playback source.
Tuner operations
• Durin SSM search...
– All previously stored stations are erased and the
stations are stored anew.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (hi hest frequency).
– When SSM is over, the station stored in No. 1 will be
automatically tuned in.
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does not comply with
the “Compact Disc Di ital Audio” standard. Therefore, the
use of Non-DVD side of a DualDisc on this product may
not be recommended.
General
• This unit has been desi ned to reproduce CDs/CD Texts,
and CD-Rs (Recordable)/CD-RWs (Rewritable) in audio CD
(CD-DA) and MP3/WMA formats (for KD-G240).
• After ejectin a disc, “NO DISC” appears and you cannot
operate some of the buttons. Insert another disc or press
SRC to select another playback source.
Playing a CD-R or CD-R
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can play back multi-session discs; however,
unclosed sessions will be skipped while playin .
• Some CD-Rs or CD-RWs may not be played back on this
unit:
– Discs are dirty or scratched.
– Moisture condensation has occurred on the lens inside
the unit.
– The pickup lens inside the unit is dirty.
– The files on the CD-R/CD-RW are written usin the
“Packet Write” method.
MORE ABOUT THIS UNIT
For safety...
• Do not raise the volume level too much, as this will block
outside sounds, makin drivin dan erous.
• Stop the car before performin any complicated
operations.
Temperature inside the car...
If you have parked the car for a lon time in hot or cold
weather, wait until the temperature in the car becomes
normal before operatin the unit.
Warped disc Sticker and sticker residue Stick-on label
Detaching the control panel
Attaching the control panel
How to reset your unit
Reset the unit after installation is complete.
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
PREPARATIONS
Finish
Enter PSM menu.
Select an item.
Adjust.
Basic settings
Deactivate the display
demonstration.
Adjust the hour. Adjust the minute.
Cancel the display
demonstration
Set the clock
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understandin and to obtain the best
possible performance from the unit.
Installation/connection are explained at the last section of this manual (reverse page, indicated with
symbol).
Unusual shape
Sin le CD—8 cm (3-3/16”) disc
[European Union only]
Connectors
C-thru Disc (semi-transparent disc)
Transparent or semi-transparent
parts on its recordin area
EN_KD-G240_140[J]_f.indd 1EN_KD-G240_140[J]_f.indd 1 8/15/07 10:45:34 AM8/15/07 10:45:34 AM

2 – EN
INSTRUCTIONS
Sound adjustments
Indication (For)
BAS
(bass)
MID
(mid-ran e)
TRE
(treble)
LOUD
(loudness)
USER (Flat sound) 00 00 00 OFF
ROCK (Rock or disco music) +03 00 +02 OFF
CLASSIC (Classical music) +01 00 +03 OFF
POPS (Li ht music) +02 +01 +02 OFF
HIP HOP (Funk or rap music) +04 –02 +01 OFF
JAZZ (Jazz music) +03 00 +03 OFF
FM station automatic presetting —SSM (Strong-station Sequential Memory)
You can preset six stations for each band.
hen an FM stereo broadcast is hard to receive
Adjusting the sound
BAS*2 (bass) : Adjust the bass. –06 to +06
MID*2 (mid-ran e) : Adjust the middle frequencies sound level. –06 to +06
TRE*2 (treble) : Adjust the treble. –06 to +06
FAD*3 (fader) : Adjust the front and rear speaker balance. R06 to F06
BAL (balance) : Adjust the left and ri ht speaker balance. L06 to R06
LOUD*4 (loudness) : Boost low and hi h frequencies to
produce a well-balanced sound at
a low volume level.
LOUD ON or
LOUD OFF
SUB. (subwoofer) : Adjust the subwoofer output level. 00 to 08
VOL (volume) : Adjust the volume. 00 to 50
(or 00 to 30)*5
*1 Displayed only when “L O MODE” is set to “WOOFER.”
*2 When you adjust the bass, mid-range, or treble, the adjustment you have made
is stored for the currently selected sound mode (iEQ) including “USER.”
*3 If you are using a two-speaker system, set the fader level to “00.”
*4 The adjustment made (LOUD ON LOUD OFF) will be applied to all sound modes
(iEQ).
*5 Depending on the amplifier gain control setting.
Preset values
OPERATIONS
Basic operations
Select the source.
• Turn on the power.
• Turn off the power [Hold].
• Attenuate the sound (if the
power is on).
Volume control.
Detach the panel.
Check the current clock time/other information.
See also “CLK DISP“ of “General settin s—PSM.”
Control panel
Radio operations
Select preset station.
• You can also use 5 / ∞ to select preset station.
Manual presetting
Example: Storin the FM station of 92.5 MHz into preset number 4 of the FM1 band.
Display window
Disc indicator
Playback mode / item indicator
• : For KD-G240 • MO: Li hts up in monaural mode.
• ST: Li hts up when receivin an FM stereo
broadcast with sufficient si nal stren th.
• Source display
• Track number
• KD-G240: Folder number
(for MP3/WMA discs)
• Volume level indicator
• Time countdown indicator
Main display (time,
playback information)
EQ (equalizer) indicator
Sound mode (iEQ: intelli ent equalizer)
indicator
LOUD (loudness) indicator
KD-G240: Disc information indicators
Tr (track) indicator
SETTINGS
Remote controller—RM-RK50
• Turns the power on if pressed briefly or
attenuates the sound when power is on.
• Turns the power off if pressed and held.
• Chan es the FM/AM bands with 5 U.
• Chan es the preset stations with D ∞.
• KD-G240: Chan es the folders of MP3/WMA
discs.
• Adjusts the volume level.
• Selects the sound mode
(iEQ: intelli ent equalizer).
• Selects the source.
• Searches for stations if pressed briefly.
• Fast-forwards or reverses the track if
pressed and held.
• Chan es the track of the disc if pressed
briefly.
Select “FM/AM.”
Select the bands.
Search for a station—Auto Search.
Manual Search: Hold either one of the buttons until “M” flashes on the display, then press it repeatedly.
Remote sensor
DO NOT expose to strong light.
Reception improves, but the stereo effect will be lost.
• MO indicator li hts up.
To restore the stereo effect, repeat the same procedure.
7 Installing battery
arning: To prevent accidents and damage
• Do not install any battery other than CR2025 or its
equivalent.
• Store out of reach of children.
• Do not rechar e, short, or dismantle.
• Do not dispose of in fire.
• Do not carry around with other metallic materials.
Lithium coin battery (CR2025)
For USA-California Only: This product contains a CR Coin Cell Lithium Battery which contains Perchlorate Material—
special handlin may apply. See www.dtsc.ca. ov/hazardouswaste/perchlorate
7 Features
See reverse page \
Stereo mini plu
(not supplied)
Portable audio player, etc.
Turn on the connected
component and start
playing the source.
External component operations
You can connect an external component to the AUX (auxiliary) input
jack on the control panel.
Disc operations
Selecting the playback modes
After pressin M MODE, press the followin buttons to...
TRK RPT : Plays the current track
repeatedly.
FLDR RPT* : Plays all tracks of the current
folder repeatedly.
RPT OFF : Cancels.
FLDR RND* : Plays all tracks of the current
folder, then the tracks of the
next folder at random.
ALL RND : Plays all tracks of the current
disc at random.
RND OFF : Cancels.
* KD-G240: Only for MP3 WMA.
Skipping a track quickly during play
• KD-G240: For MP3/WMA disc, you can skip a track
within the same folder.
Example: Select track 32
Changing the display information
hile playing an audio
CD or CD Text
hile playing an MP3 or
a MA disc (for KD-G240)
: Clock with the current track number
: The elapsed playin time with the current track
number
*1 If the current disc is an audio CD, “NO NAME” appears.
*2 If an MP3 WMA file does not have tags or “TAG DISP” is
set to “TAG OFF,” folder name and file name appear.
Prohibiting disc ejection
You can lock a disc in the loadin slot.
To cancel the prohibition, repeat the same procedure.
Turn on the power.
Insert disc.
All tracks will be played repeatedly until you chan e the source or eject the disc.
Eject disc.
• Press SRC to
listen to another
playback source.
[Press] Select track (for CD) or folder* (for MP3/
WMA) number (01 – 06).
[Hold] Select track (for CD) or folder* (for MP3/
WMA) number (07 – 12).
* KD-G240: Folders are required to assigned with
2-digit numbers at the beginning.
• 4 / ¢
[Press] Go to the next or previous track.
[Hold] Fast-forwards or reverses the track.
• 5 / ∞ : KD-G240: Go to the next or previous
folder (for MP3/WMA discs).
EN_KD-G240_140[J]_f.indd 2EN_KD-G240_140[J]_f.indd 2 8/15/07 9:53:06 AM8/15/07 9:53:06 AM

3 – EN
WARNINGS
To prevent short circuits, we recommend that you disconnect the battery’s
ne ative terminal and make all electrical connections before installin the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specified ratin . If the fuse blows frequently,
consult your JVC car audio dealer.
• It is recommended to connect to the speakers with maximum power of more
than 50 W (both at the rear and at the front, with an impedance of 4 Ω to
8 Ω). If the maximum power is less than 50 W, chan e “AMP GAIN” settin to
prevent the speakers from bein dama ed (see “General settin s—PSM”).
• To prevent short-circuit, cover the terminals
of the UNUSED leads with insulatin tape.
• The heat sink becomes very hot after use. Be
careful not to touch it when removin this
unit.
Audio amplifier section
Power Output:
20 W RMS × 4 Channels at 4 Ω and
≤ 1% THD+N
Si nal to Noise Ratio:
80 dBA (reference: 1 W into 4 Ω )
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Ran e: Bass: ±12 dB at 60 Hz
Mid-ran e: ±12 dB at 1 kHz
Treble: ±12 dB at 7.5 kHz
Frequency Response: 40 Hz to 20 000 Hz
Line-Out Level/Impedance: 2.5 V/20 k Ω load (full scale)
Output Impedance: 1 k Ω
Subwoofer-Out Level/Impedance:
2.5 V/20 kΩ load (full scale)
If a kit is necessary for your car, consult your telephone
directory for the nearest car audio speciality shop.
PREPARATION
Symptoms Remedies/Causes
General
• Sound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• The buttons on the unit do not work as you
intended.
If you press M MODE, some buttons work differently from it
ori inal function. Wait for 5 seconds or press M MODE a ain.
• This unit does not work at all. Reset the unit.
FM/AM
• SSM automatic presettin does not work. Store stations manually.
• Static noise while listenin to the radio. Connect the antenna firmly.
Disc playback
• Disc ejects. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be
skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which you used
for recordin .
• Disc can be neither played back nor ejected. • Unlock the disc.
• Eject the disc forcibly.
• Disc sound is sometimes interrupted. • Stop playback while drivin on rou h roads.
• Chan e the disc.
• Check the cords and connections.
• “NO DISC” appears on the display.
• “PLEASE” and “EJECT” appear alternately
on the display.
Insert a playable disc into the loadin slot.
MP3/ MA playback (for KD-G240)
• Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in a format compliant
with ISO 9660 Level 1, Level 2, Romeo, or Joliet.
• Add the extension code <.mp3> or <.wma> to the file names.
• Noise is enerated. Skip to another track or chan e the disc. (Do not add the extension
code <.mp3> or <.wma> to non-MP3 or WMA tracks.)
• A lon er readout time is required
(“READING” keeps flashin on the display).
Do not use too many hierarchical levels and folders.
• Tracks are not played back in the order you
have intended.
Playback order is determined when the files are recorded.
• The elapsed playin time is not correct. This sometimes occurs durin playback. This is caused by how the
tracks are recorded on the disc.
• The correct characters are not displayed
(e. . album name).
This unit can only display alphabets (upper case), numbers, and a
limited number of symbols.
• Microsoft and Windows Media are either re istered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
Indication Item ( : Initial) Setting
DEMO • DEMO ON
• DEMO OFF
: The display demonstration will be activated automatically if no operation is
done for about 20 seconds.
: Cancels.
CLK DISP *1• ON
• OFF
: The clock time is shown on the display at all times when the power is turned
off .
: Cancels; pressin DISP will show the clock time for about 5 seconds when the
power is turned off.
CLOCK H (Hour) 1 – 12 : [Initial: 1 (1:00)]
CLOCK M (Minute) 00 – 59 : [Initial: 00 (1:00)]
DIMMER • ON
• OFF
: Dims the display and button illumination.
: Cancels.
SCROLL • ONCE
• AUTO
• OFF
: Scrolls the displayed information once.
: Repeats scrollin (at 5-second intervals).
: Cancels.
• Pressin DISP for more than one second can scroll the display re ardless of
the settin .
L/O MODE • REAR
• OOFER
: Select if the REAR LINE OUT terminals are used for connectin the speakers
(throu h an external amplifier).
: Select if the REAR LINE OUT terminals are used for connectin a subwoofer.
OOFER *2• LO
• MID
• HIGH
: Frequencies lower than 90 Hz are sent to the subwoofer.
: Frequencies lower than 135 Hz are sent to the subwoofer.
: Frequencies lower than 180 Hz are sent to the subwoofer.
AUX ADJ A.ADJ 00
– A.ADJ 05
: Adjust the auxiliary input level to avoid the sudden increase of the output
level when chan in the source from external component connected to the
AUX input jack on the control panel.
TAG DISP
(for KD-G240)
• TAG ON
• TAG OFF
: Shows the ta while playin MP3/WMA tracks.
: Cancels.
AMP GAIN *3• LO P R
• HIGH P R
: VOL 00 – VOL 30 (Select if the maximum power of each speaker is less than
50 W to prevent the speaker from bein dama ed.)
: VOL 00 – VOL 50
AREA • AREA US
• AREA EU
• AREA SA
: When usin in North/Central/South America. AM/FM intervals are set to
10 kHz/200 kHz.
: When usin in any other areas. AM/FM intervals are set to 9 kHz/50 kHz
(100 kHz durin auto search).
: When usin in South American countries. AM/FM intervals are set to 10 kHz/
100kHz.
*1 If the power supply is not interrupted by turning off the ignition key of your car, it is recommended that you select “OFF” to
save the car’s battery.
*2 Displayed only when “L O MODE” is set to “WOOFER.”
*3 The volume level automatically changes to “VOL 30” if you change to “LOW PWR” while the volume level is set higher than
“VOL 30.”
This unit is desi ned to operate on 12 V DC, NEGATIVE ground electrical
systems. If your vehicle does not have this system, a volta e inverter is required,
which can be purchased at JVC car audio dealers.
TROUBLESHOOTING
General
Power Requirement: Operatin Volta e: DC 14.4 V
(11 V to 16 V allowance)
Groundin System: Ne ative round
Allowable Operatin Temperature:
0°C to +40°C (32°F to 104°F)
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 160 mm
(7-3/16” × 2-1/16” × 6-5/16”)
Panel Size (approx.):
188 mm × 58 mm × 5 mm
(7-7/16” × 2-5/16” × 1/4”)
Mass (approx.):
1.3 kg (2.9 lbs) (excludin accessories)
Design and specifications are subject to change without
notice.
SPECIFICATIONS
INSTRUCTIONS
Tuner section
Frequency Ran e:
FM: 87.5 MHz to 107.9 MHz
(with channel interval set to 100 kHz or 200 kHz)
87.5 MHz to 108.0 MHz
(with channel interval set to 50 kHz)
AM: 530 kHz to 1 710 kHz
(with channel interval set to 10 kHz)
531 kHz to 1 602 kHz
(with channel interval set to 9 kHz)
[FM Tuner]
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω )
50 dB Quietin Sensitivity: 16.3 dBf (1.8 μV/75 Ω )
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 35 dB
[AM Tuner]
Sensitivity/Selectivity: 20 μV/35 dB
CD player section
Type: Compact disc player
Si nal Detection System: Non-contact optical pickup
(semiconductor laser)
Number of channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Ran e: 93 dB
Si nal-to-Noise Ratio: 98 dB
Wow and Flutter: Less than measurable limit
MP3 Decodin Format (for KD-G240):
MPEG1/2 Audio Layer 3
Max. Bit Rate: 320 kbps
WMA (Windows Media® Audio) Decodin Format
(for KD-G240): Max. Bit Rate: 192 kbps
Having TROUBLE with operation?
Please reset your unit
Still having trouble??
Call 1-800-252-5722 (USA ONLY)
http://www.jvc.com
TROUBLESHOOTING
• The fuse blows.
* Are the red and black leads connected correctly?
• Power cannot be turned on.
* Is the yellow lead connected?
• No sound from the speakers.
* Is the speaker output lead short-circuited?
• Sound is distorted.
* Is the speaker output lead rounded?
* Are the “–” terminals of L and R speakers rounded in common?
• Noise interfere with sounds.
* Is the rear round terminal connected to the car’s chassis usin shorter and
thicker cords?
• This unit becomes hot.
* Is the speaker output lead rounded?
* Are the “–” terminals of L and R speakers rounded in common?
• This unit does not work at all.
* Have you reset your unit?
General settings— SM
Select an item. Adjust. FinishEnter PSM menu.
Heat sink
Prepare this before installation
EN_KD-G240_140[J]_f.indd 3EN_KD-G240_140[J]_f.indd 3 8/15/07 9:53:09 AM8/15/07 9:53:09 AM

4 – EN
INSTALLATION / CONNECTION
hen using the optional stay
Install the unit at an an le of
less than 30˚.
Screw (option)
Stay (option)
Fire wall
Dashboard
* Not supplied for this unit.
Flat type screws
—M5 × 8 mm (M5 × 3/8")*
Pocket
Flat type screws—M5 × 8 mm (M5 × 3/8")*
Bracket*
Bracket*
Removing the unit
In dash-mounting
Before removin the unit, release the rear section.
hen installing the unit without using the sleeve
In a Toyota car for example, first remove the car radio and install the unit in its place.
Do the required electrical
connections.
Bend the appropriate tabs
to hold the sleeve firmly
in place.
When you stand the unit,
be careful not to dama e
the fuse on the rear.
Purple
Front speaker (left)
To the remote lead of other
equipment or automatic antenna if
any (200 mA max.)
Blue with white
stripe
Red To an accessory terminal in
the fuse block
To a live terminal in the
fuse block connectin to the
car battery (bypassin the
i nition switch) (constant
12 V)
Yellow *2
To the metallic body
or chassis of the car
Black
I nition switch
*1 Not supplied for this unit.
*2 Before checking the operation of this unit prior to installation, this
lead must be connected, otherwise the power cannot be turned on.
*3 Firmly attach the ground wire to the metallic body or to the chassis
of the car—to the place uncoated with paint (if coated with paint,
remove the paint before attaching the wire). Failure to do so may
cause damage to the unit.
*4 Signal cord (not supplied for this unit)
15 A fuse
Fuse block
Rear speaker (left)
Rear speaker (ri ht)
Front speaker (ri ht)
White with black stripe
Line out Rear round terminal
Antenna
terminal
Set “L/O MODE” to “ OOFER”
(See “General settings—PSM.”)
You can also connect a subwoofer to
the REAR LINE OUT terminals.
Rear
speakers
Remote lead
Remote lead (blue with white stripe)
To the remote lead of other equipment
or automatic antenna if any
Y-connector *1
Front speakers
Subwoofer
Set “L/O MODE” to “REAR”
(See “General settings—PSM.”)
You can connect a power amplifier for
rear speakers.
Gray with black stripe
Green
Gray
Green with black stripe
Purple with black stripe
White
JVC Amplifier
ELECTRICAL CONNECTIONS
Typical connections Connecting the external amplifier or subwoofer
INSTALLATION
The followin illustration shows a typical installation. If you have any questions or require information re ardin installation kits, consult your JVC car audio dealer or a company supplyin kits.
• If you are not sure how to install this unit correctly, have it installed by a qualified technician.
Connect only the front speakers if your
speaker system is two-speaker system.
PRECAUTIONS on power supply and speaker connections:
• DO NOT connect the speaker leads of the power cord to the car battery; otherwise, the unit will be
seriously damaged.
• BEFORE connectin the speaker leads of the power cord to the speakers, check the speaker wirin in your car.
JVC Amplifier
I
Handles
E
Washer (ø5)
F
Lock nut (M5)
G
Mountin bolt—
M4 x 5 mm (M4 x 1/4");
M5 x 15 mm (M5 x 5/8")
H
Rubber cushion
A
Control panel
B
Sleeve
C
Trim plate
D
Power cord
arts list for installation and connection
J
Remote controller
K
Battery
Before connecting: Check the wirin in the vehicle carefully. Incorrect connection may cause serious dama e to this
unit. The leads of the power cord and those of the connector from the car body may be different in color.
1 Connect the colored leads of the power cord in the order specified in the illustration below.
2 Connect the antenna cord.
3 Finally connect the wirin harness to the unit.
or
EN_KD-G240_140[J]_f.indd 4EN_KD-G240_140[J]_f.indd 4 8/15/07 9:53:11 AM8/15/07 9:53:11 AM

1
ENGLISH ESPAÑOL
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts insi e the unit; leave all servicing to qualifie
service personnel.
3. CAUTION: Visible an /or invisible class 1M laser ra iation when open. Do not view irectly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
KD-G394/KD-G244
CD RECEIVER: INSTRUCTIONS/INSTALLATION
GET0493-001A
[UI]
0907DTSMDTJEIN
EN
© 2007 Victor Company of Japan, Limited
Warning
If you nee to operate the unit while riving, be sure to
look aroun carefully or you may be involve in a traffic
acci ent.
Caution on volume setting
Discs pro uce very little noise compare with other sources.
Lower the volume before playing a isc to avoi amaging
the speakers by the su en increase of the output level.
To eep discs clean
Wipe in a straight line from center of isc to
e ge. Do not use liqui cleaners, thinners, or
benzene.
To play new discs
Remove any rough areas from the inner an
outer e ges of the isc.
MAINTENANCE
How to clean the connectors
Wipe the connectors with
a cotton swab or cloth
moistene with alcohol.
Moisture condensation
Moisture may con ense on the lens insi e the unit. Eject
the isc an leave the unit turne on for a few hours until
the moisture has evaporate .
– There are improper recor ing con itions (missing ata,
etc.) or me ia con itions (staine , scratche , warpe ,
etc.).
• CD-RWs may require a longer rea out time since the
reflectance of CD-RWs is lower than that of regular CDs.
Playing an MP3/WMA disc (for KD-G394)
• This unit can play back MP3/WMA files with the
extension co e <.mp3> or <.wma> (regar less of the
letter case—upper/lower).
• This unit can show the names of albums, artists
(performer), an tag (Version 1.0, 1.1, 2.2, 2.3, or 2.4) for
MP3 files an for WMA files.
• This unit can isplay only one-byte characters. No other
characters can be correctly isplaye .
• This unit can play back MP3/WMA files meeting the
con itions below:
– Bit rate: 8 kbps — 320 kbps
– Sampling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc format: ISO 9660 Level 1/ Level 2, Romeo, Joliet,
Win ows long file name
• The maximum number of characters for file/fol er names
vary epen ing on the isc format use (inclu es 4
extension characters—<.mp3> or <.wma>).
– ISO 9660 Level 1: up to 12 characters; ISO 9660 Level 2:
up to 31 characters; Romeo: up to 64 characters; Joliet:
up to 32 characters; Win ows long file name: up to 126
characters
• This unit can recognize a total of 512 files, 200 fol ers,
an 8 hierarchical levels.
• This unit can play back files recor e in VBR (variable bit
rate).
Files recor e in VBR have a iscrepancy in the elapse
time isplay, an o not show the actual elapse time.
In particular, this ifference becomes noticeable after
performing the search function.
• This unit cannot play back the following files:
– MP3 files enco e in: MP3i an MP3 PRO format, in an
inappropriate format, layer 1/2.
– WMA files: enco e in lossless, professional, an voice
format; not base upon Win ows Me ia® Au io; copy-
protecte with DRM.
– Files which have ata such as WAVE, ATRAC3, etc.
• The search function works but search spee is not
constant.
Basic operations
• By pressing SRC on the unit, you can also turn on the
power. If the source is rea y, playback also starts.
• If you turn off the power while listening to a isc, isc
play will start from where it ha been stoppe previously
next time you turn on the power.
• When no isc is loa e in the unit, you cannot select “CD”
as the playback source.
Tuner operations
• During SSM search...
– All previously store stations are erase an the
stations are store anew.
– Receive stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station store in No. 1 will be
automatically tune in.
Disc operations
Caution for DualDisc playbac
• The Non-DVD si e of a “DualDisc” oes not comply with
the “Compact Disc Digital Au io” stan ar . Therefore, the
use of Non-DVD si e of a DualDisc on this pro uct may
not be recommen e .
General
• This unit has been esigne to repro uce CDs/CD Texts,
an CD-Rs (Recor able)/CD-RWs (Rewritable) in au io
CD (CD-DA) formats. KD-G394 can also play back CD-Rs/
CD-RWs in MP3/WMA formats.
• After ejecting a isc, “NO DISC” appears an you cannot
operate some of the buttons. Insert another isc or press
SRC to select another playback source.
Playing a CD-R or CD-RW
• Use only “finalize ” CD-Rs or CD-RWs.
• This unit can play back multi-session iscs; however,
unclose sessions will be skippe while playing.
• Some CD-Rs or CD-RWs may not be playe back on this
unit:
– Discs are irty or scratche .
– Moisture con ensation has occurre on the lens insi e
the unit.
– The pickup lens insi e the unit is irty.
– The files on the CD-R/CD-RW are written using the
“Packet Write” metho .
MORE ABOUT THIS UNIT
For safety...
• Do not raise the volume level too much, as this will block
outsi e soun s, making riving angerous.
• Stop the car before performing any complicate
operations.
Temperature inside the car...
If you have parke the car for a long time in hot or col
weather, wait until the temperature in the car becomes
normal before operating the unit.
Detaching the control panel
Attaching the control panel
How to reset your unit
Reset the unit after installation is complete.
• Your preset adjustments will also be erased.
How to forcibly eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
PREPARATIONS
Finish
Enter PSM menu.
Select an item.
Adjust.
Basic settings
Deactivate the isplay
emonstration.
A just the hour. A just the minute.
Cancel the display
demonstration
Set the cloc
Than you for purchasing a JVC product.
Please rea all instructions carefully before operation, to ensure your complete un erstan ing an to obtain the best
possible performance from the unit.
Installation/connection are explained at the last section of this manual (reverse page, indicated with
symbol).
Connectors
[European Union only] Do not use the following discs:
Warpe isc Sticker an sticker resi ue Stick-on label
Unusual shape
Single CD (8 cm isc)
C-thru Disc (semi-transparent isc)
Transparent or semi-transparent
parts on its recor ing area
EN_KD-G394[UI]f.indd 1EN_KD-G394[UI]f.indd 1 9/12/07 5:24:17 PM9/12/07 5:24:17 PM

2
INSTRUCTIONS
Sound adjustments
Indication (For)
BAS
(bass)
MID
(mi -range)
TRE
(treble)
LOUD
(lou ness)
USER (Flat soun ) 00 00 00 OFF
ROCK (Rock or isco music) +03 00 +02 OFF
CLASSIC (Classical music) +01 00 +03 OFF
POPS (Light music) +02 +01 +02 OFF
HIP HOP (Funk or rap music) +04 –02 +01 OFF
JAZZ (Jazz music) +03 00 +03 OFF
FM station automatic presetting —SSM (Strong-station Sequential Memory)
You can preset six stations for each ban .
When an FM stereo broadcast is hard to receive
Adjusting the sound
BAS*1 (bass) : A just the bass. –06 to +06
MID*1
(mi -range)
: A just the mi -range frequencies soun
level.
–06 to +06
TRE*1 (treble) : A just the treble. –06 to +06
FAD*2 (fa er) : A just the front an rear speaker balance. R06 to F06
BAL (balance) : A just the left an right speaker balance. L06 to R06
LOUD*3 (lou ness) : Boost low an high frequencies to
pro uce a well-balance soun at
a low volume level.
LOUD ON or
LOUD OFF
VOL (volume) : A just the volume. 00 to 50
(or 00 to 30)*4
*1 When you adjust the bass, mid-range, or treble, the adjustment you ha e made
is stored for the currently selected sound mode (iEQ) including “USER.”
*2 If you are using a two-speaker system, set the fader le el to “00.”
*3 The adjustment made (LOUD ON/LOUD OFF) will be applied to all sound modes
(iEQ).
*4 Depending on the amplifier gain control setting.
Preset values
OPERATIONS
Basic operations
Select the source.
• Turn on the power.
• Turn off the power [Hol ].
• Attenuate the soun (if the
power is on).
Volume control.
Detach the panel.
Check the current clock time/other information.
See also “CLK DISP“ of “General settings—PSM.”
Control panel
Radio operations
Select preset station.
• You can also use 5 / ∞
to select preset station.
Manual presetting
Example: Storing the FM station of 92.5 MHz into preset number 4 of the FM1 ban .
Display window
Disc in icator
Playback mo e / item in icator
• : For KD-G394 • MO: Lights up in monaural mo e.
• ST: Lights up when receiving an FM stereo
broa cast with sufficient signal strength.
• Source isplay
• Track number
• KD-G394: Fol er number
(for MP3/WMA iscs)
• Volume level in icator
• Time count own in icator
Main isplay (time,
playback information)
EQ (equalizer) in icator
Soun mo e (iEQ: intelligent equalizer)
in icator
LOUD (lou ness) in icator
KD-G394: Disc information in icators
Tr (track) in icator
SETTINGS
Remote controller—RM-RK50
RM-RK50 is supplie only for KD-G394.
• Turns the power on if presse briefly or
attenuates the soun when power is on.
• Turns the power off if presse an hel .
• Changes the FM/AM ban s with 5 U.
• Changes the preset stations with D ∞.
• Changes the fol ers of MP3/WMA iscs.
• A justs the volume level.
• Selects the soun mo e
(iEQ: intelligent equalizer).
• Selects the source.
• Searches for stations if presse briefly.
• Fast-forwar s or reverses the track if
presse an hel .
• Changes the track if presse briefly.
Select “FM/AM.”
Select the bands.
Search for a station—Auto Search.
Manual Search: Hol either one of the buttons until “M” flashes on the isplay, then press it repeate ly.
Remote sensor (for KD-G394)
DO NOT expose to strong light.
Reception improves, but the stereo effect will be lost.
• MO in icator lights up.
To restore the stereo effect, repeat the same proce ure.
7 Installing battery
Warning: To prevent accidents and damage
• Do not install any battery other than CR2025 or its
equivalent.
• Store out of reach of chil ren.
• Do not recharge, short, or ismantle.
• Do not ispose in fire.
• Do not carry aroun with other metallic materials.
Lithium coin battery (CR2025)
7 Features
See re erse page \
Stereo mini plug
(not supplie )
Portable au io player, etc.
Turn on the connected
component and start
playing the source.
External component operations
You can connect an external component to the
AUX (auxiliary) input jack on the control panel.
Disc operations
Selecting the playbac modes
After pressing M MODE, press the following buttons to...
TRK RPT : Plays the current track
repeate ly.
FLDR RPT* : Plays all tracks of the current
fol er repeate ly.
RPT OFF : Cancels.
FLDR RND* : Plays all tracks of the current
fol er, then the tracks of the
next fol er at ran om.
ALL RND : Plays all tracks of the current
isc at ran om.
RND OFF : Cancels.
* KD-G394: Only for MP3/WMA.
S ipping a trac quic ly during play
• KD-G394: For MP3/WMA isc, you can skip a track
within the same fol er.
Example: Select track 32
Changing the display information
While playing an audio
CD or CD Text
While playing an MP3 or
a WMA disc (for KD-G394)
: Clock with the current track number
: The elapse playing time with the current track
number
*1 If the current disc is an audio CD, “NO NAME” appears.
*2 If an MP3/WMA file does not ha e tags or “TAG DISP” is
set to “TAG OFF,” folder name and file name appear.
Prohibiting disc ejection
You can lock a isc in the loa ing slot.
To cancel the prohibition, repeat the same proce ure.
Turn on the power.
Insert disc.
All tracks will be playe repeate ly until you change the source or eject the isc.
Eject isc.
• Press SRC to
listen to another
playback source.
[Press] Select track (for CD) or fol er* (for MP3/
WMA) number (01 – 06).
[Hold] Select track (for CD) or fol er* (for MP3/
WMA) number (07 – 12).
* KD-G394: Folders are required to assigned with
2-digit numbers at the beginning.
• 4 / ¢
[Press] Go to the next or previous track.
[Hold] Fast-forwar s or reverses the track.
• 5 / ∞ : KD-G394: Go to the next or previous
fol er (for MP3/WMA iscs).
* You cannot select “CD” as the playback
source if there is no isc in the unit.
To avoid the sudden increase of the output level when
changing the source, a just the auxiliary input level (AUX ADJ)
accor ingly.
(See “AUX ADJ” of “General settings—PSM.”)
EN_KD-G394[UI]f.indd 2EN_KD-G394[UI]f.indd 2 9/12/07 5:24:21 PM9/12/07 5:24:21 PM

3
WARNINGS
To prevent short circuits, we recommen that you isconnect the battery’s
negative terminal an make all electrical connections before installing the unit.
• Be sure to ground this unit to the car’s chassis again after installation.
Notes:
• Replace the fuse with one of the specifie rating. If the fuse blows frequently,
consult your JVC car au io ealer.
• It is recommen e to connect to the speakers with maximum power of more
than 50 W (both at the rear an at the front, with an impe ance of 4 Ω to
8 Ω). If the maximum power is less than 50 W, change “AMP GAIN” setting to
prevent the speakers from being amage (see “General settings—PSM”).
• To prevent short-circuit, cover the terminals
of the UNUSED lea s with insulating tape.
• The heat sink becomes very hot after use. Be
careful not to touch it when removing this
unit.
Audio amplifier section
Maximum Power Output:
Front/Rear: 50 W per channel
Continuous Power Output (RMS):
Front/Rear: 19 W per channel into 4 Ω, 40 Hz
to 20 000 Hz at no more than 0.8%
total harmonic istortion.
Loa Impe ance: 4 Ω (4 Ω to 8 Ω allowance)
Tone Control Range: Bass: ±12 B at 60 Hz
Mi -range: ±12 B at 1 kHz
Treble: ±12 B at 7.5 kHz
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 B
KD-G394: Line-Out Level/Impe ance:
2.5 V/20 k Ω loa (full scale)
KD-G394: Output Impe ance: 1 k Ω
Other Terminal: AUX (auxiliary) input jack
PREPARATION
Symptoms Remedies/Causes
General
• Soun cannot be hear from the speakers. • A just the volume to the optimum level.
• Check the cor s an connections.
• This unit oes not work at all. Reset the unit.
FM/AM
• SSM automatic presetting oes not work. Store stations manually.
• Static noise while listening to the ra io. Connect the antenna firmly.
Disc playbac
• Disc ejects. Insert the isc correctly.
• CD-R/CD-RW cannot be playe back.
• Tracks on the CD-R/CD-RW cannot be
skippe .
• Insert a finalize CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which you use
for recor ing.
• Disc can be neither playe back nor ejecte . • Unlock the isc.
• Eject the isc forcibly.
• Disc soun is sometimes interrupte . • Stop playback while riving on rough roa s.
• Change the isc.
• Check the cor s an connections.
• “NO DISC” appears on the isplay.
• “PLEASE” an “EJECT” appear alternately
on the isplay.
Insert a playable isc into the loa ing slot.
MP3/WMA playbac (for KD-G394)
• Disc cannot be playe back. • Use a isc with MP3/WMA tracks recor e in a format compliant
with ISO 9660 Level 1, Level 2, Romeo, or Joliet.
• A the extension co e <.mp3> or <.wma> to the file names.
• Noise is generate . Skip to another track or change the isc. (Do not a the extension
co e <.mp3> or <.wma> to non-MP3 or WMA tracks.)
• A longer rea out time is require
(“READING” keeps flashing on the isplay).
Do not use too many hierarchical levels an fol ers.
• Tracks are not playe back in the or er you
have inten e .
Playback or er is etermine when the files are recor e .
• The elapse playing time is not correct. This sometimes occurs uring playback. This is cause by how the
tracks are recor e on the isc.
• The correct characters are not isplaye
(e.g. album name).
This unit can only isplay alphabets (upper case), numbers, an a
limite number of symbols.
• Microsoft an Win ows Me ia are either registere tra emarks or tra emarks of Microsoft Corporation in the Unite
States an /or other countries.
Indication Item ( : Initial) Setting
DEMO • DEMO ON
• DEMO OFF
: The isplay emonstration will be activate automatically if no operation is
one for about 20 secon s.
: Cancels.
CLK DISP *1• ON
• OFF
: The clock time is shown on the isplay at all times when the power is turne
off
.
: Cancels; pressing DISP will show the clock time for about 5 secon s when the
power is turne off.
CLOCK H (Hour) 1 – 12 : [Initial: 1 (1:00)]
CLOCK M (Minute) 00 – 59 : [Initial: 00 (1:00)]
DIMMER • ON
• OFF
: Dims the isplay an button illumination.
: Cancels.
SCROLL • ONCE
• AUTO
• OFF
: Scrolls the isplaye information once.
: Repeats scrolling (at 5-secon intervals).
: Cancels.
• Pressing DISP for more than one secon can scroll the isplay regar less of
the setting.
AUX ADJ A.ADJ 00
– A.ADJ 05
: A just the auxiliary input level to avoi the su en increase of the output
level when changing the source from external component connecte to the
AUX input jack on the control panel.
TAG DISP
(for KD-G394)
• TAG ON
• TAG OFF
: Shows the tag while playing MP3/WMA tracks.
: Cancels.
AMP GAIN *2• LOW PWR
• HIGH PWR
: VOL 00 – VOL 30 (Select if the maximum power of each speaker is less than
50 W to prevent the speaker from being amage .)
: VOL 00 – VOL 50
*1 If the power supply is not interrupted by turning off the ignition key of your car, it is recommended that you select “OFF” to
sa e the car’s battery.
*2 The olume le el automatically changes to “VOL 30” if you change to “LOW PWR” while the olume le el is set higher than
“VOL 30.”
This unit is esigne to operate on 12 V DC, NEGATIVE ground electrical
systems. If your vehicle oes not have this system, a voltage inverter is require ,
which can be purchase at JVC car au io ealers.
TROUBLESHOOTING
General
Power Requirement:
Operating Voltage: DC 14.4 V (11 V to 16 V allowance)
Groun ing System: Negative groun
Allowable Operating Temperature: 0°C to +40°C
Dimensions (W × H × D):
Installation Size (approx.):
182 mm × 52 mm × 160 mm
Panel Size (approx.):
188 mm × 58 mm × 5 mm
Mass (approx.):
1.3 kg (exclu ing accessories)
Design and specifications are subject to change without
notice.
SPECIFICATIONS
INSTRUCTIONS
Tuner section
Frequency Range:
FM: 87.5 MHz to 108.0 MHz
AM: 531 kHz to 1 602 kHz
[FM Tuner]
Usable Sensitivity: 11.3 Bf (1.0 μV/75 Ω )
50 B Quieting Sensitivity: 16.3 Bf (1.8 μV/75 Ω )
Alternate Channel Selectivity (400 kHz): 65 B
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 B
[AM Tuner]
Sensitivity/Selectivity: 20 μV/35 B
CD player section
Type: Compact isc player
Signal Detection System: Non-contact optical pickup
(semicon uctor laser)
Number of channels: 2 channels (stereo)
Frequency Response: 5 Hz to 20 000 Hz
Dynamic Range: 93 B
Signal-to-Noise Ratio: 98 B
Wow an Flutter: Less than measurable limit
KD-G394: MP3 Deco ing Format (MPEG1/2 Au io Layer 3):
Max. Bit Rate: 320 kbps
KD-G394: WMA (Win ows Me ia® Au io) Deco ing
Format: Max. Bit Rate: 192 kbps
TROUBLESHOOTING
• The fuse blows.
* Are the re an black lea s connecte correctly?
• Power cannot be turned on.
* Is the yellow lea connecte ?
• No sound from the spea ers.
* Is the speaker output lea short-circuite ?
• Sound is distorted.
* Is the speaker output lea groun e ?
* Are the “–” terminals of L an R speakers groun e in common?
• Noise interfere with sounds.
* Is the rear groun terminal connecte to the car’s chassis using shorter an
thicker cor s?
• This unit becomes hot.
* Is the speaker output lea groun e ?
* Are the “–” terminals of L an R speakers groun e in common?
• This unit does not wor at all.
* Have you reset your unit?
General settings— SM
Select an item. Adjust. FinishEnter PSM menu.
Heat sink
Prepare this before installation
EN_KD-G394[UI]f.indd 3EN_KD-G394[UI]f.indd 3 9/12/07 5:24:25 PM9/12/07 5:24:25 PM

4
INSTALLATION / CONNECTION
When using the optional stay
Install the unit at an angle of
less than 30˚.
Screw (option)
Stay (option)
Fire wall
Dashboar
* Not supplied for this unit.
Flat type screws (M5 × 8 mm)*
Pocket
Flat type screws (M5 × 8 mm)*
Bracket*
Bracket*
Removing the unit
In dash-mounting
Before removing the unit, release the rear section.
When installing the unit without using the sleeve
In a Toyota car for example, first remove the car ra io an install the unit in its place.
Do the require electrical
connections.
Ben the appropriate tabs
to hol the sleeve firmly
in place.
When you stan the unit,
be careful not to amage
the fuse on the rear.
Purple
Front speaker (left)
To the remote lea of other equipment
(200 mA max.)—only for KD-G394
Blue
Re To an accessory terminal in
the fuse block
To a live terminal in the
fuse block connecting to
the car battery (bypassing
the ignition switch)
(constant 12 V)
Yellow *2
To the metallic bo y
or chassis of the car
Black Ignition switch
*1 Not supplied for this unit.
*2 Before checking the operation of this unit prior to installation, this lead must be connected, otherwise the power cannot be
turned on.
*3 Firmly attach the ground wire to the metallic body or to the chassis of the car—to the place uncoated with paint (if coated
with paint, remo e the paint before attaching the wire). Failure to do so may cause damage to the unit.
15 A fuse
Fuse block
Rear speaker (left)
Rear speaker (right)
Front speaker (right)
White with black stripe
Line out (only for KD-G394) Rear groun terminal
Antenna
terminal
Rear
speakers
Remote lea
Remote lea (blue with white stripe)
To the remote lea of other equipment
or automatic antenna if any
Y-connector *1
Gray with black stripe
Green
Gray
Green with black stripe
Purple with black stripe
White
JVC Amplifier
ELECTRICAL CONNECTIONS
Typical connections Connecting the external amplifier (for KD-G394)
INSTALLATION
The following illustration shows a typical installation. If you have any questions or require information regar ing installation kits, consult your JVC car au io ealer or a company supplying kits.
• If you are not sure how to install this unit correctly, have it installe by a qualifie technician.
Connect only the front speakers if your
speaker system is two-speaker system.
PRECAUTIONS on power supply and spea er connections:
• DO NOT connect the spea er leads of the power cord to the car battery; otherwise, the unit will be
seriously damaged.
• BEFORE connecting the speaker lea s of the power cor to the speakers, check the speaker wiring in your car.
Before connecting: Check the wiring in the vehicle carefully. Incorrect connection may cause serious amage to this
unit. The lea s of the power cor an those of the connector from the car bo y may be ifferent in color.
1 Connect the colore lea s of the power cor in the or er specifie in the illustration below.
2 Connect the antenna cor .
3 Finally connect the wiring harness to the unit.
Signal cor *1
Front speakers
To the automatic antenna if any
(250 mA max.)
Blue with white
stripe
For KD-G394
J
Han les
F
Washer (ø5)
G
Lock nut (M5)
H
Mounting bolt
(M4 × 5 mm;
M5 × 15 mm)
I
Rubber cushion
C
Sleeve
D
Trim plate
E
Power cor
arts list for installation and connection
A/B
Har case (for
KD-G394)/
Control panel
K
Remote controller
L
Battery
For KD-G394
EN_KD-G394[UI]f.indd 4EN_KD-G394[UI]f.indd 4 9/12/07 5:24:27 PM9/12/07 5:24:27 PM

ENGLISH
For canceling the display demonstration, see page 6.
For installation and connections, refer to the separate manual.
INSTRUCTIONS
GET0486-001A
[U/UH]
KD-G396/KD-G395/KD-G245
CD RECEIVER KD-G396/KD-G395/KD-G245
Cover_KD-G396[U_UH]f.indd 1Cover_KD-G396[U_UH]f.indd 1 8/21/07 4:34:09 PM8/21/07 4:34:09 PM

2
ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLA 1 LA ER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUT IDE THE UNIT.
How to reset your unit
• Your preset adjustments will also be erased.
How to forcib y eject a disc
• Be careful not to drop the disc when it ejects.
• If this does not work, reset your unit.
Warning:
If you need to operate the unit while driving, be
sure to look around carefully or you may be involved
in a traffic accident.
Caution on vo ume setting:
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc
to avoid damaging the speakers by the sudden
increase of the output level.
[European Union only]
The control panel illustrations used for explanation in this manual is of KD-G395/KD-G245.
EN02-07_KD-G396[U_UH]f.indd 2EN02-07_KD-G396[U_UH]f.indd 2 8/21/07 4:28:30 PM8/21/07 4:28:30 PM

ENGLISH
3
How to use the M MODE button
If you press M MODE, the unit goes into functions mode,
then the number buttons and 5/∞ buttons will work
as different function buttons.
Ex.: When number button 2 works as
MO (monaural) button.
To use these buttons for their origina functions
again after pressing M MODE, wait for 5 seconds
without pressing any of these buttons until the
functions mode is cleared, or press M MODE again.
Detaching the contro pane
Attaching the contro pane
CONTENTS
Contro pane —
KD-G396/KD-G395/KD-G245 .................. 4
Remote contro er — RM-RK50 ........... 5
Getting started ................................ 6
Basic operations ................................................... 6
Radio operations ............................. 7
Disc operations ................................ 8
Playing a disc in the unit ..................................... 8
Sound adjustments .......................... 10
Other externa component
operations ................................... 11
Genera settings — PSM .................. 11
Maintenance ................................... 13
More about this unit ........................ 14
Troub eshooting .............................. 16
Specifications .................................. 17
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• top the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
EN02-07_KD-G396[U_UH]f.indd 3EN02-07_KD-G396[U_UH]f.indd 3 8/21/07 4:28:32 PM8/21/07 4:28:32 PM

4
ENGLISH
; RND (random) button
a AUX (auxiliary) input jack
s KD-G396/KD-G395: Disc information indicators—
TAG (Tag information), (track/file), (folder)
d DI C indicator
f Playback mode / item indicators—RND (random),
(disc), KD-G396/KD-G395: (folder),
RPT (repeat)
g Tuner reception indicators—MO (monaural),
T (stereo)
h LOUD (loudness) indicator
j EQ (equalizer) indicator
k Tr (track) indicator
l ource display / Track number / Folder number /
Volume level indicator / Time countdown indicator
/ Main display
z ound mode (iEQ: intelligent equalizer)
indicators—JAZZ, ROCK, HIP HOP, CLA IC, POP ,
U ER
Parts identification
Disp ay window
Control panel — KD-G396/KD-G395/KD-G245
1 5 (up) / ∞ (down) buttons
2 0 (eject) button
3 (standby/on attenuator) button
4 KD-G396/KD-G395: Remote sensor
DO NOT e pose the remote sensor to strong light
(direct sunlight or artificial lighting).
5 Loading slot
6 Display window
7 EQ (equalizer) button
8 DI P (display) button
9 (control panel release) button
p RC (source) button
q 4 / ¢ buttons
w Control dial
e BAND button
r EL (select) button
t M MODE button
y MO (monaural) button
u M ( trong-station equential Memory) button
i Number buttons
o RPT (repeat) button
EN02-07_KD-G396[U_UH]f.indd 4EN02-07_KD-G396[U_UH]f.indd 4 8/21/07 4:28:33 PM8/21/07 4:28:33 PM

ENGLISH
5
Remote controller — RM-RK50
RM-RK50 is supplied only for KD-G396/KD-G395.
Insta ing the ithium coin battery
(CR2025)
Aim the remote contro er direct y at the remote
sensor on the unit. Make sure there is no obstac e
in between.
Warning:
• Do not install any battery other than CR2025 or
its equivalent; otherwise, it may explode.
• Do not leave the remote controller in a place
(such as the dashboard) exposed to direct
sunlight for a long time; otherwise, it may
explode.
• tore the battery in a place where children
cannot reach to avoid the risk of accidents.
• To prevent the battery from over-heating,
cracking, or starting a fire:
– Do not recharge, short, disassemble, heat the
battery, or dispose of it in a fire.
– Do not leave the battery with other metallic
materials.
– Do not poke the battery with tweezers or similar
tools.
– Wrap the battery with tape and insulate when
throwing away or saving it.
Main e ements and features
1 (standby/on/attenuator) button
• Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
2 5 U (up) / D (down) ∞ buttons
• Changes the FM/AM bands with 5 U.
• Changes the preset stations with D ∞.
• Changes the folder of the MP3/WMA discs.
3 VOL – / VOL + buttons
• Adjusts the volume level.
4 OUND button
• elects the sound mode (iEQ: intelligent
equalizer).
5 OURCE button
• elects the source.
6 2 R (reverse) / F (forward) 3 buttons
• earches for stations if pressed briefly.
• Fast-forwards or reverses the track if pressed and
held.
• Changes the track if pressed briefly.
EN02-07_KD-G396[U_UH]f.indd 5EN02-07_KD-G396[U_UH]f.indd 5 8/21/07 4:28:33 PM8/21/07 4:28:33 PM

6
ENGLISH
Basic settings
• ee also “General settings — P M” on pages 11 and
12.
1
2
1 Cance ing the disp ay demonstrations
elect “DEMO,” then “DEMO OFF.”
2 Setting the c ock
elect “CLOCK H” (hour), then adjust the hour.
elect “CLOCK M” (minute), then adjust the
minute.
3 Finish the procedure.
To check the current c ock time whi e the
power is turned off
Clock time is shown on the display for
about 5 seconds. ee also page 12.
Gettin started
Basic operations
Turn on the power.
Ÿ
* You cannot select “CD” as the playback source if
there is no disc in the unit.
! For FM/AM tuner
⁄ Adjust the vo ume.
@ Adjust the sound as you want. (See
page 10.)
To drop the vo ume in a
moment (ATT)
To restore the sound, press the
button again.
To turn off the power
Volume level appears.
EN02-07_KD-G396[U_UH]f.indd 6EN02-07_KD-G396[U_UH]f.indd 6 8/21/07 4:28:34 PM8/21/07 4:28:34 PM

ENGLISH
7
Storing stations in memory
You can preset six stations for each band.
FM station automatic presetting —
SSM (Strong-station Sequentia
Memory)
1 Se ect the FM band (FM1 – FM3) you want to
store into.
2
3
“ M” flashes, then disappears when automatic
presetting is over.
Local FM stations with the strongest signals are
searched and stored automatically in the FM band.
Manua presetting
Ex.: toring the FM station of 92.5 MHz into preset
number 4 of the FM1 band.
1
2
3
Radio operations
Ÿ
! Start searching for a station.
When a station is received,
searching stops.
To stop searching, press the
same button again.
To tune in to a station manua y
In step ! above...
1
2 Se ect a desired station frequency.
When an FM stereo broadcast is hard to
receive
Reception improves, but the stereo effect will be lost.
To restore the stereo effect, repeat the same
procedure. “MONO OFF” appears and the MO indicator
goes off.
Lights up when receiving an FM stereo
broadcast with sufficient signal strength.
Lights up when monaural mode is activated.
Preset number flashes for a while.
EN02-07_KD-G396[U_UH]f.indd 7EN02-07_KD-G396[U_UH]f.indd 7 8/21/07 4:28:35 PM8/21/07 4:28:35 PM

8
ENGLISH
To fast-forward or reverse the track
To go to the next or previous track
To go to the next or previous folder (for MP3/
WMA discs in K -G396/K -G395)
To locate a particular track (for C ) or folder
(for MP3/WMA discs in K -G396/K -G395)
directly
To select a number from 01 – 06:
To select a number from 07 – 12:
• To use direct folder access on MP3/WMA discs it
is required that folders are assigned with 2-digit
numbers at the beginning of their folder names—
01 02 03 and so on.
To select a particular track in a folder
(for MP3/WMA disc):
Listening to a preset station
1
2 Select the preset station (1 – 6) you want.
or
To check the other information while
listening to an FM or AM station
Disc operations
Playing a disc in the unit
~ Turn on the power.
Ÿ
All tracks will be played repeatedly until you
change the source or eject the disc.
To stop play and eject the disc
• Press SRC to listen to another
playback source.
Clock Ô Frequency
EN08-13_KD-G396[U_UH]f.indd 8EN08-13_KD-G396[U_UH]f.indd 8 8/21/07 4:33:13 PM8/21/07 4:33:13 PM

9
ENGLISH
Other main functions
Skipping tracks quickly during play
• KD-G396/KD-G395: For MP3 or WMA discs you can
skip tracks within the same folder
Ex.: To select track 32 while playing tracks whose
number is a single digit (1 to 9)
1
2
Each time you press the button you can skip 10
tracks.
• After the last track the first track will be selected
and vice versa.
3
Prohibiting disc ejection
You can lock a disc in the loading slot.
To cancel the prohibition, repeat the same
procedure.
Changing the display information
While playing an audio C or C Text
A = isc title/performer *1 = Track
title *1 [ ] = B = (back to the beginning)
While playing an MP3 or a WMA track
(for K -G396/K -G395)
• When “TAG ISP” is set to “TAG ON”
(see page 12)
A = Album name/performer (folder
name *2) [ ] = Track title (file
name *2) [ ] = B = (back to the
beginning)
• When “TAG ISP” is set to “TAG OFF”
A = Folder name [ ] = File name
[ ] = B = (back to the beginning)
A : Clock with the current track number
B : The elapsed playing time with the current track
number
[ ] : Corresponding indicator lights up on the display
*1 If the current disc is an audio CD, “NO NAME” appears.
*2 If an MP3/WMA fi e does not have Tag information,
fo der name and fi e name appear. In this case, the
TAG indicator wi not ight up.
Selecting the playback modes
You can use only one of the following playback modes
at a time.
1
2 Select your desired playback mode.
7 Repeat play
Mode Plays repeatedly
TRK RPT : The current track. [ ]
FL R RPT * : All tracks of the current folder.
[ ]
RPT OFF : Cancels.
Continued on the next page
EN08-13_KD-G396[U_UH]f.indd 9EN08-13_KD-G396[U_UH]f.indd 9 8/21/07 4:33:16 PM8/21/07 4:33:16 PM

10
ENGLISH
7 Random play
Mode Plays at random
FL R RN * : All tracks of the current folder
then the tracks of the next folder
and so on. [ ]
ALL RN : All tracks of the current disc.
[ ]
RN OFF : Cancels.
* KD-G396/KD-G395: On y whi e p aying an MP3 or
a WMA disc.
[ ] : Corresponding indicator lights up on the
display
Sound adjustments
You can select a preset sound mode suitable to the
music genre (iEQ: intelligent equalizer).
Indication (For)
BAS MI TRE LOU
USER
(Flat sound) 00 00 00 OFF
ROCK
(Rock or disco music) +03 00 +02 OFF
CLASSIC
(Classical music) +01 00 +03 OFF
POPS
(Light music) +02 +01 +02 OFF
HIP HOP
(Funk or rap music) +04 –02 +01 OFF
JAZZ
(Jazz music) +03 00 +03 OFF
BAS: Bass; MID: Mid-range; TRE: Treble; LOUD: Loudness
Adjusting the sound
You can adjust the sound characteristics to your
preference.
1
2
Indication, [Range]
BAS *1 (bass) [–06 to +06]
Adjust the bass.
MI *1 (mid-range) [–06 to +06]
Adjust the mid-range frequencies sound level.
TRE *1 (treble) [–06 to +06]
Adjust the treble.
FA *2 (fader) [R06 to F06]
Adjust the front and rear speaker balance.
BAL (balance) [L06 to R06]
Adjust the left and right speaker balance.
LOU *3 (loudness) [LOUD ON or LOUD OFF]
Boost low and high frequencies to produce a
well-balanced sound at a low volume level.
VOL (volume) [00 to 50 or 00 to 30] *4
Adjust the volume.
*1 When you adjust the bass, mid-range, or treb e, the
adjustment you have made is stored for the current y
se ected sound mode (iEQ) inc uding “USER.”
*2 If you are using a two-speaker system, set the fader
eve to “00.”
*3 The adjustment made (LOUD ON/LOUD OFF) wi be
app ied to a sound modes.
*4 Depending on the amp ifier gain contro setting. (See
page 12 for detai s.)
Preset values
EN08-13_KD-G396[U_UH]f.indd 10EN08-13_KD-G396[U_UH]f.indd 10 8/21/07 4:33:17 PM8/21/07 4:33:17 PM

11
ENGLISH
General settings — PSM
You can change PSM (Preferred Setting Mode) items
listed in the table on page 12.
1
2 Select a PSM item.
3 Adjust the PSM item selected.
4 Repeat steps 2 and 3 to adjust other PSM
items if necessary.
5 Finish the procedure.
Continued on the next page
Other external component
operations
You can connect an external component to the
AUX (auxiliary) input jack on the control panel.
~
Ÿ Turn on the connected component and
start playing the source.
! Adjust the volume.
⁄ Adjust the sound as you want. (See
page 10.)
To check the other information while
listening to an external component
Clock Ô AUX IN
Stereo mini plug
(not supplied)
Portable audio player etc
EN08-13_KD-G396[U_UH]f.indd 11EN08-13_KD-G396[U_UH]f.indd 11 8/21/07 4:33:18 PM8/21/07 4:33:18 PM

12
ENGLISH
Indications Item
( : Initial)
Selectable settings, [reference page]
EMO
Display demonstration
• EMO ON
• EMO OFF
: The display demonstration will be activated automatically if no
operation is done for about 20 seconds [6].
: Cancels.
CLK ISP *1
Clock display
• ON
• OFF
: The clock time is shown on the display at all times when the power
is turned off .
: Cancels; pressing DISP will show the clock time for about 5 seconds
when the power is turned off [6].
CLOCK H
Hour adjustment
1 – 12 [Initial: 1 (1:00)] [6]
CLOCK M
Minute adjustment
00 – 59 [Initial: 00 (1:00)] [6]
IMMER
Dimmer
• ON
• OFF
: Dims the display and button illumination.
: Cancels.
SCROLL *2
Scroll
• ONCE
• AUTO
• OFF
: Scrolls the displayed information once.
: Repeats scrolling (at 5-second intervals).
: Cancels.
• Pressing DISP for more than one second can scroll the display
regardless of the setting.
AUX A J
Auxiliary input level
adjustment
A.A J 00
– A.A J 05
: Adjust the auxiliary input level to avoid the sudden increase of the
output level when changing the source from external component
connected to the AUX input jack on the control panel.
TAG ISP *3
Tag display
• TAG ON
• TAG OFF
: Shows the Tag information while playing MP3/WMA tracks [9].
: Cancels.
AMP GAIN
Amplifier gain control
• LOW PWR
• HIGH PWR
: VOL 00 – VOL 30 (Select this if the maximum power of the speaker
is less than 50 W to avoid damaging the speaker.)
: VOL 00 – VOL 50
*1 If the power supp y is not interrupted by turning off the ignition key of your car, it is recommended to se ect “OFF”
that you save the car’s battery.
*2 Some characters or symbo s wi not be shown correct y (or wi be b anked) on the disp ay.
*3 For KD-G396/KD-G395.
EN08-13_KD-G396[U_UH]f.indd 12EN08-13_KD-G396[U_UH]f.indd 12 8/21/07 4:33:18 PM8/21/07 4:33:18 PM
