JVC KD-R671 User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
ไทย
B5A-0808-00 [M]
KD-R671 / KD-R571 / KD-R476 / KD-R471
CD RECEIVER
INSTRUCTION MANUAL
เครื่องเลน CD
คู่มือการใช้งาน
JS_JVC_KD_R671_M_C.indd 1JS_JVC_KD_R671_M_C.indd 1 10/7/2015 4:55:03 PM10/7/2015 4:55:03 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2
CONTENTS BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important
that you read and observe Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
Warning
Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded
data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short
circuit.
• If a disc error occurs due to condensation on the laser lens, eject the disc and wait for the moisture to
evaporate.
Remote control (RM-RK52):
• Do not leave the remote control in hot places such as on the dashboard.
• The Lithium battery is in danger of explosion if replaced incorrectly. Replace it only with the same or
equivalent type.
• The battery pack or batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• Keep the battery out of reach of children and in its original packaging when not in used. Dispose of used
batteries promptly. If swallowed, contact a physician immediately.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Cancel the demonstration
2 Set the clock
3 Set the basic settings
CD / USB / iPod / ANDROID 5
RADIO 7
AUX 8
Pandora® (for
KD-R671 )9
AUDIO SETTINGS 10
DISPLAY SETTINGS 12
REFERENCES 13
Maintenance
More information
TROUBLESHOOTING 15
INSTALLATION /
CONNECTION 17
SPECIFICATIONS 19
How to read this manual
• Operations are explained mainly using buttons on the faceplate of KD-R571 .
• English indications are used for the purpose of explanation. You can select the display language from the
menu. (
4 )
•
[XX] indicates the selected items.
• (
XX ) indicates references are available on the stated page.
JS_JVC_KD_R671_M_EN_5.indd 2JS_JVC_KD_R671_M_EN_5.indd 2 24/7/2015 5:14:59 PM24/7/2015 5:14:59 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
3
ENGLISH
ST
KD-R671
BASICS
To On the faceplate On the remote control
Turn on the power Press .
• Press and hold to turn off the power. ( Not available )
Adjust the volume Turn the volume knob. Press or .
Press the volume knob to mute the sound or pause playback.
• Press again to cancel. Press to mute the sound or pause playback.
• Press again to cancel.
Select a source • Press repeatedly.
• Press , then turn the volume knob within 2 seconds.
Press SOURCE repeatedly.
Change the display
information
Press repeatedly.
( 15)
( Not available )
Attach
How to reset
Detach
Your preset adjustments
will be erased except
stored radio stations.
Remote control (RM-RK52)Faceplate
Volume knob Loading slot
Detach button Display window How to replace the battery
Pull out the insulation sheet
when using for the first time.
Remote sensor (Do not expose
to bright sunlight.)
JS_JVC_KD_R671_M_EN_4.indd 3JS_JVC_KD_R671_M_EN_4.indd 3 14/7/2015 4:48:58 PM14/7/2015 4:48:58 PM

4
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
When you turn on the power (or after you reset the unit), the display
shows: “CANCEL DEMO” “PRESS” “VOLUME KNOB”
1 Press the volume knob.
[
YES ] is selected for the initial setup.
2 Press the volume knob again.
“DEMO OFF” appears.
Set the clock
1 Press and hold .
2 Turn the volume knob to select [ CLOCK ], then press the knob.
3 Turn the volume knob to select [ CLOCKSET ], then press the knob.
4 Turn the volume knob to make the settings, then press the
knob.
Day Hour Minute
5 Turn the volume knob to select [ 24H/ 12H ], then press the knob.
6 Turn the volume knob to select [ 12 HOUR ] or [ 24 HOUR ], then
press the knob.
7 Press to exit.
To return to the previous setting item, press .
1
2
Set the basic settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
SETTINGS
BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
SRC SELECT
AM
*
ON :Enables AM in source selection.; OFF :Disables.
SW1 * ON :Enables SW1 in source selection.; OFF :Disables.
SW2 * ON :Enables SW2 in source selection.; OFF :Disables.
PANDORA
*
(For KD-R671 ) ON :Enables PANDORA in source selection.; OFF :Disables.
AUX
*
BTADAPTER :Selects when the KS-BTA100 Bluetooth adapter is connected to the
AUX jack. (
8 ); ON :Enables AUX in source selection.; OFF :Disables.
F/W UPDATE
SYSTEM
F/W xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not activated).
For details on how to update the firmware, see: <http://www.jvc.net/cs/car/>.
CLOCK
CLOCK SYNC AUTO
:The clock time is automatically set using the Clock Time (CT) data in FM
Radio Data System signal.;
OFF :Cancels.
CLOCK DISP ON :The clock time is shown on the display even when the unit is turned off.;
OFF :Cancels.
ENGLISH
Select the display language for menu and music information if applicable.
By default,
ENGLISH is selected.
ESPANOL
* Not displayed when the corresponding source is selected.
3
JS_JVC_KD_R671_M_EN_5.indd 4JS_JVC_KD_R671_M_EN_5.indd 4 24/7/2015 5:15:07 PM24/7/2015 5:15:07 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD / USB / iPod / ANDROID
KD-R671
To directly select USB/ USB-IPOD/ ANDROID source, press or
.
To On the faceplate On the remote control
Reverse / Fast-forward*3Press and hold . Press and hold .
Select a track/file Press .Press .
Select a folder*4Press . Press .
Repeat play*5Press repeatedly.
TRACK RPT / ALL RPT : Audio CD
TRACK RPT / FOLDER RPT / ALL RPT : MP3/WMA/WAV/FLAC file
ONE RPT / ALL RPT / RPT OFF : iPod or ANDROID
Random play*5Press repeatedly.
ALL RND / RND OFF : Audio CD
FOLDERRND / ALL RND / RND OFF : MP3/WMA/WAV/FLAC file
SONG RND / ALL RND / RND OFF : iPod or ANDROID
*1
Do not leave the cable inside the car when not using.
*2
When connecting an Android device, “Press [VIEW] to install JVC MUSIC PLAY APP” is shown. Follow the instructions to install
the application. You can also install the latest version of JVC MUSIC PLAY application on your Android device before connecting.
(
13 )
*3
For ANDROID: Applicable only when [ AUTO MODE ] is selected. ( 6 )
*4
For CD: Only for MP3/WMA files. This does not work for iPod/ ANDROID.
*5
For iPod/ ANDROID: Applicable only when [ HEAD MODE ]/ [ AUTO MODE ] is selected. ( 6 )
Start playback
The source changes automatically and
playback starts.
CD
Eject disc Label side
USB input terminal
USB 2.0 cable
*1
(commercially available)
Micro USB 2.0 cable
*1
(commercially available)
(Accessory of the
iPod/iPhone)*
1
USB
iPod/iPhone
ANDROID*2
Selectable source:
KD-R671
:
CD/ USB/ USB-IPOD/ ANDROID
KD-R571 / KD-R476 / KD-R471 :
CD/ USB/ ANDROID
JS_JVC_KD_R671_M_EN_3.indd 5JS_JVC_KD_R671_M_EN_3.indd 5 10/7/2015 4:55:51 PM10/7/2015 4:55:51 PM

6
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select control mode
While in USB-IPOD source, press repeatedly.
HEAD MODE : Control iPod from this unit.
IPHONE MODE : Control iPod using the iPod itself. However, you can still play/
pause or file skip from this unit.
While in ANDROID source, press repeatedly.
AUTO MODE : Control Android device from this unit via JVC MUSIC PLAY
application installed in the Android device.
AUDIO MODE : Control Android device using the Android device itself via
other media player applications installed in the Android device.
However, you can still play/pause or file skip from this unit.
Select music drive
Press repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass Storage Class).
• Selected drive of a multiple drives device.
Change the playback speed of the Audiobook
(For KD-R671 )
While listening to the iPod and [ HEADMODE ] is selected....
1 Press and hold .
2 Turn the volume knob to select [ IPOD ], then press the knob.
3 Press the volume knob to select [ AUDIOBOOKS ].
4 Turn the volume knob to select an item, then press the knob.
0.5×SPEED / 1×SPEED / 2×SPEED : Select the desired playback speed of the
Audiobooks sound file in your iPod/iPhone.
(Default: Depends on your iPod/iPhone setting.)
5 Press to exit.
To return to the previous setting item, press .
Select a file from a folder/list
1 Press .
2 Turn the volume knob to select a folder/list, then press the
knob.
3 Turn the volume knob to select a file, then press the knob.
Quick Search
If you have many files, you can search through them quickly.
Turn the volume knob quickly to browse through the list
quickly.
– Not applicable for iPod.
Alphabet search (applicable only for iPod):
You can search for a file according to the first character.
Press or turn the volume knob quickly to select the
desired character (A to Z/ 0to9/ OTHERS).
– Select “OTHERS” if the first character is other than Ato Z, 0 to 9.
• To return to the previous setting item, press .
• To cancel, press and hold .
• For iPod, applicable only when [
HEADMODE ] is selected.
• For ANDROID, applicable only when [
AUTO MODE ] is selected.
CD / USB / iPod / ANDROID
JS_JVC_KD_R671_M_EN_4.indd 6JS_JVC_KD_R671_M_EN_4.indd 6 14/7/2015 4:49:05 PM14/7/2015 4:49:05 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
“ST” lights up when receiving an FM stereo broadcast with sufficient signal strength.
Search for a station
1 Press repeatedly to select FM, AM, SW1 or SW2.
2 Press (or press on RM-RK52) to search for a station automatically.
(or)
Press and hold (or press and hold on RM-RK52) until “M” flashes,
then press repeatedly to search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM/SW1/SW2.
Store a station
While listening to a station....
Press and hold one of the number buttons (1to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE” flashes.
2 Turn the volume knob to select a preset number, then press the knob.
The preset number flashes and “MEMORY” appears.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob to
confirm.
Other settings
1 Press and hold .
2 Turn the volume knob to select [ TUNER ], then press the
knob.
3 Turn the volume knob to select an item ( see the
following table
) , then press the knob.
4 Repeat step 3until the desired item is selected/
activated or follow the instructions stated on the
selected item.
5 Press to exit.
To return to the previous setting item, press .
Default:
XX
RADIO TIMER Turns on the radio at a specific time regardless of the
current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the
timer will be turned on.
2 FM / AM / SW1 / SW2 :Select the FM, AM, SW1 or SW2
band.
3 01 to 18 (for FM)/ 01 to 06 (for AM/SW1/SW2):Select
the preset station.
4 Set the activation day*
1
and time.
“
M ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
• [
OFF ] is selected for [ AM/SW1/SW2 ] in [ SRCSELECT ]
after Radio Timer for AM/SW1/SW2 is selected. (
4 )
SSM SSM01–06 / SSM07–12 / SSM13–18 : Automatically
presets up to 18 stations for FM. “SSM” stops flashing
when the first 6 stations are stored. Select
SSM07–12 /
SSM13–18 to store the following 12 stations.
*1
Selectable only when [ ONCE ] or [ WEEKLY ] is selected in step 1 .
JS_JVC_KD_R671_M_EN_3.indd 7JS_JVC_KD_R671_M_EN_3.indd 7 10/7/2015 4:55:52 PM10/7/2015 4:55:52 PM

8
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
Default: XX
LOCAL SEEK ON :Searches only AM/SW1/SW2 stations with good reception.;
OFF :Cancels.
• Settings made are applicable only to the selected source/station. Once
you change the source/station, you need to make the settings again.
IF BAND AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not
be degraded and the stereo effect will remain.
MONO ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
NEWS-STBY *2 ON :The unit will temporarily switch to News Programme if available.;
OFF :Cancels.
REGIONAL *2 ON : Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET *2 ON : Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF : Cancels.
TI SET *2 ON : Allows the unit to temporarily switch to Traffic Information if
available (“TI” lights up). ;
OFF :Cancels.
PTY SEARCH *2 Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
PTY code : NEWS , AFFAIRS , INFO , SPORT , EDUCATE , DRAMA , CULTURE , SCIENCE ,
VARIED , POP M (music), ROCK M (music), EASY M (music), LIGHT M (music),
CLASSICS , OTHER M (music), WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION ,
PHONE IN , TRAVEL , LEISURE , JAZZ , COUNTRY , NATION M (music), OLDIES , FOLK M
(music),
DOCUMENT
*2
Only for FM source.
Use a portable audio player
1 Connect a portable audio player (commercially available).
2 Select [ ON ] for [ AUX ] in [ SRC SELECT ]. ( 4 )
3 Press repeatedly to select AUX.
4 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
Use a Bluetooth® device
1 Connect the Bluetooth adapter, KS-BTA100 (separately purchased).
2 Register (pair) the Bluetooth device with KS-BTA100.
3 Select [ BT ADAPTER ] for [ AUX ] in [ SRC SELECT ]. ( 4 )
4 Press repeatedly to select BT AUDIO.
5 Start using the Bluetooth device.
For details, refer to the instruction manual of KS-BTA100.
3.5mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
Auxiliary input jack
AUX
Auxiliary input jack
Blue/white Blue/white: Remote
Black Black: Ground
Brown Brown: Tel muting
Wiring harness of the unit
(
18 )
JS_JVC_KD_R671_M_EN_3.indd 8JS_JVC_KD_R671_M_EN_3.indd 8 10/7/2015 4:55:52 PM10/7/2015 4:55:52 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Pandora® (for KD-R671 )
Preparation:
Install the latest version of the Pandora application on your device
(iPhone/ iPod touch), then create an account and log in to Pandora.
• Select [
ON ] for [ PANDORA ] in [ SRC SELECT ]. ( 4)
Start listening
1 Open the Pandora application on your device.
2 Connect your device to the USB input terminal.
The source changes to PANDORA and broadcast starts.
To On the faceplate On the remote control
Playback / pause Press the volume knob. Press .
Skip a track Press T. Press I.
Thumbs up or
thumbs down*2
Press . Press .
*1
Do not leave the cable inside the car when not using.
*2
If thumbs down is selected, the current track is skipped.
Create and save a new station
1 Press .
2 Turn the volume knob to select [ NEW STATION ], then press the knob.
3 Turn the volume knob to select [ FROM TRACK ] or [ FROM ARTIST ], then
press the knob.
A new station is created based on the current song or artist.
4 Press and hold number button 3, 4, 5or 6to store.
To select a stored station, press number button 3, 4, 5or 6.
Search for a registered station
1 Press .
2 Turn the volume knob to select an item, then press the knob.
[
BYDATE ]: According to the registered date.
[
A-Z ]: Alphabetical order.
3 Turn the volume knob to select the desired station, then press the
knob.
To cancel, press and hold .
Bookmark current song information
Press and hold the volume knob.
“BOOKMARKED” appears and the information is stored to your device.
The bookmark is available on your Pandora account but not on this unit.
USB input terminal
(Accessory of the iPod/iPhone)
*1
JS_JVC_KD_R671_M_EN_3.indd 9JS_JVC_KD_R671_M_EN_3.indd 9 10/7/2015 4:55:52 PM10/7/2015 4:55:52 PM

10
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Default: XX
EQSETTING
EQPRESET
Select a preset equalizer suitable to the music genre. (Select [ USER ] to use the
settings made in [
EASY EQ ].)
FLAT 
(
default)/ HARD ROCK / HIP HOP / JAZZ / POP / R&B / TALK / USER /
VOCALBOOST / BASSBOOST / CLASSICAL / DANCE
EASYEQ
Adjust your own sound settings. The settings are stored to [ USER ].
SUB.W SP
*1*2
: 00 to +06 (Default: 03
SUB.W
*1*3
: –08 to +08 00
BASS
 LVL : –06 to +06 00
MID
 LVL : –06 to +06 00
TRE
 LVL : –06 to +06 00 )
PRO EQ 1 BASS / MIDDLE / TREBLE :Select a sound tone.
2 Adjust the sound elements of the selected sound tone.
BASS Frequency: 60 / 80 / 100 / 200HZ
(
Default: 80HZ
Level: –06 to +06 00
Q: Q1.0 / Q1.25 / Q1.5 / Q2.0 Q1.0 )
MIDDLE Frequency: 0.5 / 1.0 / 1.5 / 2.5KHZ (Default: 1.0KHZ
Level: –06 to +06 00
Q: Q0.75 / Q1.0 / Q1.25 Q1.25 )
TREBLE Frequency: 10.0 / 12.5 / 15.0 / 17.5KHZ (Default: 10.0KHZ
Level: –06 to +06 00
Q: QFIX QFIX )
*1
Displayed only when [ SUB.W ] is set to [ ON ]. (  11 )
*2
Displayed only when [ SPK/PRE  OUT ] is set to [ SUB.W/SUB.W ]. (  11 )
*3
Displayed only when [ SPK/PRE  OUT ] is set to [ REAR/SUB.W ] or [ SUB.W/SUB.W ]. (  11 )
Select a preset equalizer
Press repeatedly.
(or)
Press , then turn the volume knob within 5seconds.
Preset equalizer : FLAT (default), HARD ROCK , HIP HOP , JAZZ , POP , R&B , TALK , USER ,
VOCAL BOOST , BASS BOOST , CLASSICAL , DANCE
Store your own sound settings
1 Press and hold to enter EASY EQ setting.
2 Turn the volume knob to select an item, then press the knob.
Refer to [ EASYEQ ] for setting and the result is stored to [ USER ].
• To return to the previous setting item, press .
• To exit, press .
Other settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
JS_JVC_KD_R671_M_EN_6.indd 10JS_JVC_KD_R671_M_EN_6.indd 10 30/7/2015 4:45:06 PM30/7/2015 4:45:06 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO
BASS BOOST +01
— +05 ( +01 ): Selects your preferred bass boost level.;
OFF :Cancels.
LOUD 01 / 02 :Boosts low or high frequencies to produce a well-balanced
sound at low volume.;
OFF :Cancels.
SUB.W LEVEL
*4
SPK-OUT
*5
00 to +06 ( +03 ):Adjusts the output level of the
subwoofer connected via speaker lead. (
 18 )
PRE-OUT
*6
–08 to +08 ( 00 ):Adjusts the output level of the
subwoofer connected to the lineout terminals (REAR/
SW) through an external amplifier. (
 18 )
SUB.W
*6
ON / OFF : Turns on or off the subwoofer output.
SUB.W  LPF
*4
THROUGH :All signals are sent to the subwoofer. ; LOW  55HZ /
MID  85HZ / HIGH120HZ :Audio signals with frequencies lower than
55Hz/ 85Hz/ 120Hz are sent to the subwoofer.
SUB.WPHASE
*4
REVERSE (180°)/ NORMAL (0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than [
THROUGH ] is selected for
[
SUB.W  LPF ].)
FADER R06 — F06 ( 00 ):Adjusts the front and rear speaker output balance.
BALANCE
*7
L06 — R06 ( 00 ):Adjusts the left and right speaker output balance.
VOL ADJUST –15 — +06 ( 00 ):Preset the initial volume level of each source
(compared to the FM volume level). Before adjustment, select the
source you want to adjust. (“VOLADJFIX” appears if FM is selected.)
AMP GAIN LOW  POWER :Limits the maximum volume level to 25. (Select if
the maximum power of each speaker is less than 50W to prevent
damaging the speakers.);
HIGHPOWER :The maximum volume level
is 35.
D.T.EXP
(Digital Track
Expander)
ON :Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF :Cancels.
TEL  MUTING
*8
ON :Mutes the sounds while using the cellular phone (not connected
through KS-BTA100).;
OFF :Cancels.
SPK/PRE  OUT Depending on the speaker connection method, select the appropriate
setting to get the desired output. ( 
Speaker output settings )
*4
Displayed only when [ SUB.W ] is set to [ ON ].
*5
Displayed only when [ SPK/PRE  OUT ] is set to [ SUB.W/SUB.W ].
*6
Displayed only when [ SPK/PRE  OUT ] is set to [ REAR/SUB.W ] or [ SUB.W/SUB.W ].
*7
This adjustment will not affect the subwoofer output.
*8
Does not work if [ BT  ADAPTER ] is selected for [ AUX ] in [ SRC  SELECT ]. (  4 )
Speaker output settings
Select the output setting for the speakers [ SPK/PRE OUT], base on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. (  18 )
(For KD-R671 )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR/SW
REAR/REAR Front speakers output Rear speakers output
REAR/SUB.W Front speakers output Subwoofer output
SUB.W/SUB.W Front speakers output Subwoofer output
AUDIO SETTINGS
JS_JVC_KD_R671_M_EN_5.indd 11JS_JVC_KD_R671_M_EN_5.indd 11 24/7/2015 5:15:21 PM24/7/2015 5:15:21 PM

12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
(For KD-R571 / KD-R476 / KD-R471 )
Setting on
[ SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR Rear speakers output
REAR/SUB.W Subwoofer output
SUB.W/SUB.W Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output. ( 
18 )
Setting on
[ SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [ SUB.W/SUB.W ] is selected:
– [
HIGH120HZ ] is selected in [ SUB.W  LPF ] and [ THROUGH ] is not available.
– [
R01 ] is selected in [ FADER ] and selectable range is [ R06 ]to [ 00 ]
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
DISPLAY
DIMMER
Dim the display and buttons illumination.
OFF :Dimmer is turned off.
ON :Dimmer is turned on. Brightness changes to [ NIGHT ] setting. ( 13 ,
[
BRIGHTNESS ] )
DIMMER TIME
:Set the dimmer on and off time.
1 Turn the volume knob to adjust the [ ON ] time, then press the knob.
2 Turn the volume knob to adjust the [ OFF ] time, then press the knob.
(Default: [
ON ]: 18:00 or 6:00 PM
[
OFF ]: 6:00 or 6:00 AM)
AUTO :Dimmer turns on and off automatically when you turn off or on the car
headlights.*
1
*1
The illumination control wire connection is required. ( 18)
DISPLAY SETTINGS
JS_JVC_KD_R671_M_EN_5.indd 12JS_JVC_KD_R671_M_EN_5.indd 12 24/7/2015 5:15:21 PM24/7/2015 5:15:21 PM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BRIGHTNESS Set the button, display and USB input terminal brightness for day and night
separately.
1 DAY / NIGHT :Select day or night.
2 Select a zone. ( 12)
3 Set the brightness level ( 00 to 31 ). (Default: DAY : 31 ; NIGHT : 15 )
SCROLL * 2 ONCE :Scrolls the display information once.; AUTO :Repeats scrolling at
5-second intervals.;
OFF :Cancels.
COLOR (for KD-R571 )
PRESET Select a color for the buttons illumination.
•
COLOR01 to COLOR49 [ COLOR08 ]
•
USER : The color you have created for [ DAYCOLOR ] or [ NIGHTCOLOR ]
is shown.
•
COLORFLOW01 to COLORFLOW03 : Color changes at different
speeds.
DAY COLOR Make your own day and night colors for the buttons illumination.
1 RED / GREEN / BLUE :Select a primary color.
2 00 to 31 :Select the level.
Repeat steps
1 and 2 for all primary colors.
• Your setting is stored to
[USER] in [PRESET] .
NIGHT COLOR
MENU COLOR ON
:Changes the button illumination in menu mode or when selecting a
music file from a folder/list.;
OFF :Cancels.
[ NIGHTCOLOR ] or [ DAYCOLOR ] is changed by turning on or off your car’s
headlight.
*2
Some characters or symbols will not be shown correctly (or will be blanked).
DISPLAY SETTINGS
Maintenance
Cleaning the unit
Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Cleaning the connector
Detach the faceplate and clean the connector
gently with a cotton swab, being careful not to
damage the connector.
Handling discs:
• Do not touch the recording surface of the disc.
• Do not stick tape etc. on the disc, or use a disc with tape stuck on it.
• Do not use any accessories for the disc.
• Clean from the center of the disc and move outward.
• Clean the disc with a dry silicone or soft cloth. Do not use any solvents.
• When removing discs from this unit, pull them out horizontally.
• Remove burrs from the center hole and disc edge before inserting a disc.
More information
Visit also the following website <http://www.jvc.net/cs/car/> for:
– Latest firmware updates and latest compatible item list
– Android™ application JVC MUSIC PLAY
– Any other latest information
About discs and audio files
• This unit can only play the following CDs:
• This unit can play back multi-session discs; however, unclosed sessions will be skipped
during playback.
•
Unplayable discs:
- Discs that are not round.
- Discs with coloring on the recording surface or discs that are dirty.
- Recordable/ReWritable discs that have not been finalized.
- 8 cm CD. Attempting to insert using an adapter may cause malfunction.
REFERENCES
Connector (on the reverse
side of the faceplate)
JS_JVC_KD_R671_M_EN_6.indd 13JS_JVC_KD_R671_M_EN_6.indd 13 30/7/2015 4:45:12 PM30/7/2015 4:45:12 PM

14
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
• DualDisc playback: The Non-DVD side of a “DualDisc” does not comply with the “Compact
Disc Digital Audio” standard. Therefore, the use of Non-DVD side of a DualDisc on this product
cannot be recommended.
•
Playable files:
- File extensions: MP3(.mp3), WMA(.wma)
- Bit rate: MP3: 8kbps — 320kbps
WMA: 32kbps — 192kbps
- Sampling frequency:
MP3: 48kHz, 44.1kHz, 32kHz, 24kHz, 22.05kHz, 16kHz, 12kHz, 11.025kHz, 8kHz
WMA: 8kHz — 48kHz
- Variable bit rate (VBR) files.
•
Maximum number of characters for file/folder name:
It depends on the disc format used (includes 4 extension characters—<.mp3> or <.wma>.
- ISO 9660 Level 1 and 2: 32 characters
- Romeo: 32 characters
- Joliet: 32 characters
- Windows long file name: 32 characters
About USB devices
• This unit can play MP3/WMA/WAV/FLAC files stored on a USB mass storage class device.
• You cannot connect a USB device via a USB hub.
• Connecting a cable whose total length is longer than 5m may result in abnormal playback.
• The maximum number of characters for:
- Folder names: 64 characters
- File names: 64 characters
- MP3 Tag: 64 characters
- WMA Tag: 64 characters
- WAV Tag: 64 characters
- FLAC Tag: 64 characters
• This unit can recognize a total of 15 000 files, 500 folders (999 files per folder including folder
without unsupported files), and of 8 hierarchies.
• This unit cannot recognize a USB device whose rating is other than 5V and exceeds 1A.
About iPod/iPhone
Made for
- iPod touch (2nd, 3rd, 4th, and 5th generation)
- iPod classic
- iPod nano (3rd, 4th, 5th, 6th, and 7th generation)
- iPhone 3G, 3GS, 4, 4S, 5, 5S, 5C, 6, 6 Plus
• It is not possible to browse video files on the “Videos” menu in
[HEAD MODE] .
• The song order displayed on the selection menu of this unit may differ from that of the iPod/
iPhone.
About Android device
• This unit supports Android OS 4.1 and above.
• Some Android devices (with OS4.1 and above) may not fully support Android Open Accessory
(AOA)2.0.
• If the Android device supports both mass storage class device and AOA2.0, this unit always
playback via AOA2.0 as priority.
About Pandora
• Pandora is only available in certain countries.
Please visit <http://www.pandora.com/legal> for more information.
• Because Pandora is a third-party service, the specifications are subject to change without
prior notice. Accordingly, compatibility may be impaired, or some or all of the services may
become unavailable.
• Some functions of Pandora cannot be operated from this unit.
• For issues using the application, please contact Pandora at [email protected].
REFERENCES
JS_JVC_KD_R671_M_EN_5.indd 14JS_JVC_KD_R671_M_EN_5.indd 14 24/7/2015 5:15:29 PM24/7/2015 5:15:29 PM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Change the display information
Each time you press , the display information changes.
• If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or other
information (eg. station name) appears.
FM or AM Frequency Day/Clock
(For FM Radio Data System stations only)
Station name (PS) Frequency Program type (PTY) Radiotext+
Day/Clock (back to the beginning)
CD or USB (For CD-DA)
Playing time Day/Clock Disc name Track title
(backtothebeginning)
(For MP3/WMA/WAV/FLAC files)
Playing time Day/Clock Album title/Artist Track title
Folder/filename (back to the beginning)
USB-IPOD
or ANDROID
Playing time Day/Clock Album title/Artist Track title
(backtothebeginning)
PANDORA Station name Shared/Radio Album title Artist Track title
Playing time Day/Clock (back to the beginning)
AUX AUX Day/Clock
BT AUDIO BT AUDIO Day/Clock
TROUBLESHOOTINGREFERENCES
Symptom Remedy
General
Sound cannot be heard. • Adjust the volume to the optimum level.
• Check the cords and connections.
“MISWIRING CHECK
WIRING THEN PWR ON”
appears.
Turn the power off, then check to be sure the terminals of
the speaker wires are insulated properly. Turn the power
on again.
“PROTECTING SEND
SERVICE” appears.
Send the unit to the nearest service center.
Source cannot be selected. Check the [
SRCSELECT ] setting. ( 4)
Radio
• Radio reception is poor.
• Static noise while
listening to the radio.
Connect the antenna firmly.
CD / USB / iPod
Disc cannot be ejected. Press and hold to forcibly eject the disc. Be careful not
to drop the disc when it is ejected.
“IN DISC” appears. Make sure nothing is blocking the loading slot when you
eject the disc.
“PLEASE” and “EJECT”
appear alternately.
Press , then insert the disc correctly.
Playback order is not as
intended.
The playback order is determined by the file name (USB)
or the order in which files were recorded (disc).
Elapsed playing time is not
correct.
This depends on the recording process earlier.
JS_JVC_KD_R671_M_EN_3.indd 15JS_JVC_KD_R671_M_EN_3.indd 15 10/7/2015 4:55:54 PM10/7/2015 4:55:54 PM

16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TROUBLESHOOTING
Symptom Remedy
CD / USB / iPod
“NOT SUPPORT” appears
and track skips.
Check whether the track is a playable format. ( 13 , 14)
“READING” keeps flashing. • Do not use too many hierarchical levels and folders.
• Reload the disc or reattach the USB device.
“CANNOT PLAY” flashes
and/or connected device
cannot be detected.
• Check whether the connected device is compatible with
this unit and ensure the files are in supported formats.
(
13 , 14 )
• Reattach the device.
The iPod/iPhone does not
turn on or does not work.
• Check the connection between this unit and iPod/iPhone.
• Detach and reset the iPod/iPhone using hard reset.
Correct characters are not
displayed.
This unit can only display uppercase letters, numbers,
and a limited number of symbols.
ANDROID
• Sound cannot be heard
during playback.
• Sound output only from
the Android device.
• Reconnect the Android device.
• If in [
AUDIO MODE ], launch any media player
application on the Android device and start playback.
• If in [
AUDIO MODE ], relaunch the current media player
application or use another media player application.
• Restart the Android device.
• If this does not solve the problem, the connected Android
device is unable to route the audio signal to unit. (
14 )
Cannot playback at [
AUTO
MODE
].
• Make sure JVC MUSIC PLAY APP is installed on the
Android device. ( 5 )
• Reconnect the Android device and select the appropriate
control mode. (
6 )
• If this does not solve the problem, the connected Android
device does not support [
AUTO MODE ]. ( 14 )
“NO DEVICE” or “READING”
keeps flashing.
• Switch off the developer options on the Android device.
• Reconnect the Android device.
• If this does not solve the problem, the connected Android
device does not support [
AUTO MODE ]. ( 14 )
Symptom Remedy
ANDROID
Playback is intermittent or
sound skips.
Turn off the power saving mode on the Android device.
“CANNOT PLAY” • Make sure Android device contains playable audio files.
• Reconnect the Android device.
• Restart the Android device.
Pandora
“ADDERROR” New station creation is unsuccessful.
“CHKDEVICE” Check the Pandora application on your device.
“NOSKIPS” The skip limit has been reached.
“NOSTATIONS” No stations are found.
“STATIONLMT” The number of registered stations has reached its limit.
Retry after deleting unnecessary stations from your
device.
“UPGRADEAPP” Make sure you have installed the latest version of the
Pandora application on your device.
“CONNECT ERR” Communication is unstable.
“RATING ERR” Registration of thumbs up/thumbs down has failed due
to insufficient network connectivity.
“THUMBS N/A” Registration of thumbs up/thumbs down is not allowed.
“LICENSE ERR” You try to access from a country which Pandora is not
deliverable.
If you still have troubles, reset the unit. ( 3)
JS_JVC_KD_R671_M_EN_6.indd 16JS_JVC_KD_R671_M_EN_6.indd 16 30/7/2015 4:45:22 PM30/7/2015 4:45:22 PM

ENGLISH 17
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Warning
• The unit can only be used with a 12V DC power supply, negative ground.
• Disconnect the battery’s negative terminal before wiring and mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the car
chassis or Ground wire (black) to prevent a short circuit.
• Insulate unconnected wires with vinyl tape to prevent a short circuit.
• Be sure to ground this unit to the car’s chassis again after installation.
Caution
• For safety’s sake, leave wiring and mounting to professionals. Consult the
car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal parts
of this unit during and shortly after use of the unit. Metal parts such as the
heat sink and enclosure become hot.
• Do not connect the wires of speakers to the car chassis or Ground wire
(black), or connect them in parallel.
• Connect speakers with a maximum power of more than 50W. If the
maximum power of the speakers is lower than 50W, change the
[AMPGAIN] setting to avoid damaging the speakers. (  11)
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal, connect
Ignition wire (red) to the terminal on the vehicle’s fuse box which provides
12 V DC power supply and is turned on and off by the ignition key.
• Keep all cables away from heat dissipate metal parts.
• After the unit is installed, check whether the brake lamps, blinkers, wipers,
etc. on the car are working properly.
• If the fuse blows, first make sure the wires are not touching car’s chassis,
then replace the old fuse with one that has the same rating.
Basic procedure
1 Remove the key from the ignition switch, then
disconnect the terminal of the car battery.
2 Connect the wires properly.
See Wiring connection.
(  18)
3 Install the unit to your car.
See Installing the unit (in-dash mounting).
4 Connect the terminal of the car battery.
5 Reset the unit. (  3)
INSTALLATION / CONNECTION
How to remove the unit
When installing without the mounting sleeve
1 Remove the mounting sleeve and trim plate
from the unit.
2 Align the holes in the unit (on both sides) with
the vehicle mounting bracket and secure the
unit with screws (commercially available).
Use only the specified screws. Using wrong screws might damage
the unit.
Installing the unit (in-dash mounting)
Do the required wiring.
(  18)
Bend the appropriate tabs to
hold the sleeve firmly in place.
Hook on the top side
Orientate the trim plate as
illustrated before fitting.
Dashboard of
your car
JS_JVC_KD_R671_M_EN_3.indd 17JS_JVC_KD_R671_M_EN_3.indd 17 10/7/2015 4:55:57 PM10/7/2015 4:55:57 PM

1818
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
STEERING
WHEEL
REMOTE
KD-R671 KD-R571 / KD-R476 /
KD-R471
Car fuse block
Ignition switch
Recommended connection
Light blue/yellow
Blue/white: To amplifier
Blue: To power antenna
Make this connection if your
vehicle factory wiring harness
does not have “12V ignition
switch” wire.
Separate red wire
Signal cord
(not supplied)
Remote wire
(not supplied)
To the steering
wheel remote
control adapter
Fuse (10A)
Antenna terminal
JVC Amplifier
* 1
Factory wiring
harness (vehicle)
Vehicle
dashboard
Black: Ground
Yellow: Battery 12V
White: Front speaker (left)
White/black
Gray: Front speaker (right)
Gray/black
Purple: Rear speaker (right)
Purple/black
Join the same color wires together.
Red: Ignition 12V
Orange/white: Illumination
Blue/white: Remote (200mA max.)
Part list for
installation
(A) Faceplate
(C) Mounting sleeve
(B) Trim plate
(D) Wiring harness
(E) Extraction key
Wiring connection
Green: Rear speaker (left) * 2
Green/black * 2
*2
You can also connect
a subwoofer speaker
directly using this
lead without an
external subwoofer
amplifier. For setting,
 11 , 12 .
Brown: Tel muting
*1
Firmly connect the ground
wire of the amplifier to
the car’s chassis to avoid
damaging the unit.
IMPORTANT
We recommend installing the unit with
a commercially available custom wiring
harness specific for your car and leave
this job to professionals for your safety.
Consult your car audio dealer.
Custom wiring harness
(separately purchased)
Front output
Rear/subwoofer
output
Rear/
subwoofer
output
JS_JVC_KD_R671_M_EN_3.indd 18JS_JVC_KD_R671_M_EN_3.indd 18 10/7/2015 4:55:58 PM10/7/2015 4:55:58 PM

ENGLISH 19
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
CD player
Laser Diode GaAIAs
Digital Filter (D/A) 8 times over sampling
Spindle Speed 500 rpm — 200 rpm (CLV)
Wow & Flutter Below measurable limit
Frequency Response (±1dB) 20 Hz — 20 kHz
Total Harmonic Distortion (1 kHz) 0.01 %
Signal-to-Noise Ratio (1 kHz) 105 dB
Dynamic Range 90 dB
Channel Separation 85 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
USB
USB Standard USB1.1, USB2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/16/32
Maximum Supply Current DC5V 1A
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear-PCM
FLAC Decode FLAC files
Auxiliary
Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1000mV
Input Impedance 30kΩ
SPECIFICATIONS
Tuner
FM Frequency Range 87.5MHz — 108.0MHz (50kHz step)
Usable Sensitivity (S/N=26dB) 8.2dBf (0.71μV/75Ω)
Quieting Sensitivity
(DINS/N=46dB)
17.2dBf (2.0μV/75Ω)
Frequency Response (±3dB) 30Hz — 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
AM Frequency Range Band 1 (MW): 531kHz — 1611kHz
(9kHz step)
Band 2 (SW1): 2940kHz — 7735kHz
(5kHz step)
Band 3 (SW2): 9500kHz — 10135kHz /
11580kHz — 18135kHz
(5kHz step)
Channel Space Selection Band 1: 9kHz
Band 2/3: 5kHz
Usable Sensitivity (S/N=20dB) MW: 29dBμ (28.2μV)
SW: 30dBμ (32μV)
JS_JVC_KD_R671_M_EN_3.indd 19JS_JVC_KD_R671_M_EN_3.indd 19 10/7/2015 4:55:58 PM10/7/2015 4:55:58 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
20
Audio
Maximum Output Power 50W×4 or
50W×2 + 50W×1 (Subwoofer = 4Ω)
Full Bandwidth Power
(at less than 1% THD)
22W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (CD/USB) 2500mV/10kΩ load
Preout Impedance ≤600Ω
General
Operating Voltage
(10.5V—16V allowable)
14.4V
Maximum Current Consumption 10A
Operating Temperature Range –10°C — +60°C
Installation Size (W×H×D) 182mm×53mm×158mm
Weight 1.1k
g
Subject to change without notice.
SPECIFICATIONS
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to
connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to
meet Apple performance standards. Apple is not responsible for the operation of this device or its
compliance with safety and regulatory standards. Please note that the use of this accessory with
iPod or iPhone may affect wireless performance.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in
the U.S. and other countries.
• Lightning is a trademark of Apple Inc.
• Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks
of Pandora Media, Inc., used with permission.
• Android is trademark of Google Inc.
libFLAC
Copyright (C) 2000,2001,2002,2003,2004,2005,2006,2007,2008,2009 Josh Coalson
Redistribution and use in source and binary forms, with or without modification, are permitted
provided that the following conditions are met:
- Redistributions of source code must retain the above copyright notice, this list of conditions and
the following disclaimer.
- Redistributions in binary form must reproduce the above copyright notice, this list of conditions
and the following disclaimer in the documentation and/or other materials provided with the
distribution.
- Neither the name of the Xiph.org Foundation nor the names of its contributors may be used to
endorse or promote products derived from this software without specific prior written permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND ONTRIBUTORS “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
The marking of products using lasers
The label is attached to the chassis/case and says that the component uses laser
beams that have been classified as Class 1. It means that the unit is utilizing laser
beams that are of a weaker class. There is no danger of hazardous radiation outside
the unit.
JS_JVC_KD_R671_M_EN_6=F.indd 20JS_JVC_KD_R671_M_EN_6=F.indd 20 11/8/2015 2:28:50 PM11/8/2015 2:28:50 PM
