JVC KD-SV3706 User manual

ENGLISH
For installation and connections, refer to the separate manual.
INSTRUCTIONS
LVT1955-001A
[U/US]
KD-SV3706/KD-SV3705
VCD/CD RECEIVER KD-SV3706/KD-SV3705
KD-SV3706/KD-SV3705
EN_KD-SV3706[US].indb 1EN_KD-SV3706[US].indb 1 08.12.11 3:09:52 PM08.12.11 3:09:52 PM

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to
qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation when open. Do not view directly with optical
instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
Warning:
If you need to operate the unit while driving, be sure to
look around carefully or you may be involved in a traffic
accident.
For safety...
• Do not raise the volume level too much, as this will
block outside sounds, making driving dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
Caution on volume setting:
Discs produce very little noise compared with other
sources. Lower the volume before playing a disc to
avoid damaging the speakers by the sudden increase of
the output level.
To prevent accidents and damage
• DO NOT install any unit in locations where;
– it may obstruct the steering wheel and
gearshift lever operations.
– it may obstruct the operation of safety
devices such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
• If you need to operate the unit while
driving, be sure to look around carefully.
• The driver must not watch the monitor
while driving.
If the parking brake is not engaged,
“PARKING” flashes on the display, and
no playback picture will be shown on the
monitor.
– This warning appears only when the
parking brake wire is connected to the
parking brake system built in the car
(refer to the Installation/Connection
Manual).
EN_KD-SV3706[US].indb 2EN_KD-SV3706[US].indb 2 08.12.11 3:09:55 PM08.12.11 3:09:55 PM

ENGLISH
3
CONTENTS
Detaching/attaching control panel .............. 3
How to reset your unit ................................. 3
OPERATIONS
Basic operations........................................... 4
• Using the control panel............................... 4
• Using the remote controller (RM-RK121).... 5
• Changing the display information .............. 7
Preparation.................................................. 7
Listening to the radio................................... 8
Disc operations............................................. 9
Listening to the other external components ... 14
SETTINGS
Sound and monitor settings......................... 15
REFERENCES
More about this unit .................................... 16
Troubleshooting........................................... 18
Maintenance................................................ 20
Specifications............................................... 21
Detaching/attaching control panel
Detaching...
Attaching...
How to reset your unit
• Your preset adjustments will also be erased.
In this manual, operations using the control panel
are mainly explained; however, you can use the
buttons and controls on the remote control if they
have the same (or similar) name and marks.
EN_KD-SV3706[US].indb 3EN_KD-SV3706[US].indb 3 08.12.11 3:09:57 PM08.12.11 3:09:57 PM

ENGLISH
4
Basic operations
Using the control panel
tActivate/deactivate the loudness setting.
yPreset the station automatically [Hold].
uPlays/pauses.
iChange playback mode—INT, RPT, RND.
o• Select preset station.
• Preset a station manually [Hold].
;Change the color system.
aChange the VCD audio channel.
sAUX (auxiliary) input jack
dChange the tuner reception mode.
• Select stereo or monaural reception.
• Select local or distance-extreme reception
[Hold].
*1While the sound is attenuated, no operations are
available. To operate the unit, deactivate the sound
attenuation by pressing ATT again.
*2You cannot select this source if no disc is inserted.
1Select folder.
2• Turn on the power.
• Turn off the power.
3Select the FM/AM band.
4• Control the volume or select items [Turn].
• Confirm the selection.
• Adjust the sound settings.
5Remote sensor
6Loading slot
7Display window
8Eject disc.
9Attenuate the sound.*1
p• Change the display information.
• Enters the clock setting mode [Hold].
qDetach the panel.
wSelect the source.
Tuner =Disc*2=AUX IN =(back to the
beginning)
e• Tuner: Search for station.
• Disc: Select track.
rSelect the sound mode.
67 89p
o; sadwe tryuiq
12345
EN_KD-SV3706[US].indb 4EN_KD-SV3706[US].indb 4 08.12.11 3:09:58 PM08.12.11 3:09:58 PM

ENGLISH
5OPERATIONS
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bright light
(direct sunlight or artificial lighting).
Installing the lithium coin battery (CR2025)
Caution:
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
• Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
decreases, replace the battery.
Display window
1Preset number / track (F), folder (d) indication
2Tuner reception indicators—ST (stereo), MONO
(monaural)
3LOUD (loudness) indicator
4Playback mode indicators—INT (intro),
RPT (repeat), RND (random)
5LO (local) indicator
6Disc type—CD, MP3, VCD
7Tr (track) indicator
8Main display
9EQ (equalizer) indicator and sound mode
indicators—ROCK, POPS, CLASSIC, FLAT
Using the remote controller (RM-RK121)
Continued on the next page
Remote sensor
12 3 4 5
67 98
EN_KD-SV3706[US].indb 5EN_KD-SV3706[US].indb 5 08.12.11 3:09:59 PM08.12.11 3:09:59 PM

ENGLISH
6
1Attenuate the sound.
2• Turn on the power.
• Turn off the power.
3Play repeatedly.
4Turn on and off the OSD (On-Screen Display) on the
monitor.
5• Audio CD/VCD: Select a track.
• VCD: Select the desired position.
6Make selection/settings.
7• Play/pause.
• Confirm the selection.
8• Tuner: Select the FM/AM band.
• VCD: Change the color system.
9Select the sound mode.
pSelect the sound setting item.
q• Enter numbers. (See also “How to use number
buttons” on the right column.)
• Tuner:
– Select preset station (1 – 6).
– Preset a station manually (1 – 6) [Hold].
wActivate/deactivate the PBC (Playback Control)
function.
eSelect the source.
Tuner =Disc * =AUX IN =(back to the
beginning)
rChange the VCD audio channel.
t• Adjust the volume level.
• Adjust the sound settings.
yActivate/deactivate the loudness setting.
uStop playback.
i• Tuner: Search for station.
• Disc: Select track.
oReverse/Forward search.
;Display the program screen.
*You cannot select this source if no disc is inserted.
Warning (to prevent accidents and damage):
• Do not install any battery other than CR2025 or its
equivalent.
• Do not leave the remote controller in a place (such
as dashboards) exposed to direct sunlight for a long
time.
• Store the battery in a place where children cannot
reach.
• Do not recharge, short, disassemble, heat the battery,
or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar
tools.
• Wrap the battery with tape and insulate when
throwing away or saving it.
6
7
8
9
p
q
o
;
e
r
t
y
u
i
w
1
2
3
4
5
How to use number buttons
• For selecting track number/item number on PBC
menu:
To select 5:
To select 15: ==
To select 125:
====
• For selecting program number and specifying
time to start playback:
To select 5:
To select 15: =
EN_KD-SV3706[US].indb 6EN_KD-SV3706[US].indb 6 08.12.11 3:10:00 PM08.12.11 3:10:00 PM

ENGLISH
7OPERATIONS
Preparation
Setting the clock
On the Unit ONLY:
1Turn on the power.
2Change the source to tuner.
Press the button repeatedly until the tuner frequency is
displayed.
3
[Turn] =[Press]
[Hold] Adjust the hour.
4
[Turn]
Adjust the minute.
• You can go back to the adjustment of the hour by pressing the
button.
5Finish the procedure.
• To display the clock, press DISP repeatedly until the clock is displayed (see “Changing the display information”
above).
Changing the display information
On the Unit ONLY:
• When the power is turned on: The display information of the current source changes as follows:
Tuner Frequency and the band (F1, F2, F3, A1 or A2) =Clock =(back to the beginning)
Disc • Audio CD/WMA/VCD:
Current track number with the elapsed playing time =Clock =(back to the beginning)
• MP3:
Album name/performer (folder name)* =Track title (file name)* =Current track number
with the elapsed playing time =Clock =(back to the beginning)
AUX IN Source name (AUX IN) =Clock =(back to the beginning)
*If an MP3 le does not have Tag information, folder name and le name appear.
EN_KD-SV3706[US].indb 7EN_KD-SV3706[US].indb 7 08.12.11 3:10:01 PM08.12.11 3:10:01 PM

ENGLISH
8
Listening to the radio
1Change the source to tuner.
Press the button repeatedly until the tuner frequency is displayed.
2Select the band.
F(FM) 1 F2 F3
A(AM) 1
A2
3Search for a station to listen—Auto Search.
When a station is tuned in, searching stops. To stop searching, press the same
button again.
• You can also search a station manually—Manual Search. Hold either one of
the buttons until “M” appears on the display, then press it repeatedly.
• When receiving an FM stereo broadcast with sufficient signal strength, the ST
indicator lights up on the display.
Improving the FM reception
When an FM stereo broadcast is hard to receive,
activate monaural mode for better reception.
On the Unit ONLY:
Reception improves, but stereo effect will be lost.
• The MONO indicator lights up on the display.
To restore the stereo effect, repeat the same
procedure to select “MONO OFF.” The MONO
indicator goes off.
To tune in FM stations only with
strong signals—LO/DX (Local/
Distance-extreme)
If received signals are weak, you may only hear
noises. You can make this unit detect only stations
with sufficient signal strength while searching for FM
stations.
On the Unit ONLY:
Only stations with sufficient signal strength will be
detected.
• The LO indicator lights up on the display.
To tune in to all receivable stations, repeat the
same procedure to select “DX.”
• The LO indicator goes off.
MONO ON
LOCAL
[Hold]
EN_KD-SV3706[US].indb 8EN_KD-SV3706[US].indb 8 08.12.11 3:10:03 PM08.12.11 3:10:03 PM

ENGLISH
9OPERATIONS
Storing stations in memory
You can preset 6 stations for each band.
Automatic presetting —SSM (Strong-station
Sequential Memory)
On the Unit ONLY:
1Select the band you want to store into.
2
Local stations with the strongest signals are searched
and stored automatically.
[Hold]
Manual presetting
Ex.: Storing FM station of 92.50 MHz into preset number
“4.”
1Tune in to the station you want to preset.
2
Selecting preset station
Disc operations
1Turn on the power.
2Insert a disc.
All tracks will be played repeatedly until you change the source or eject
the disc.
• If a disc menu appears on the monitor while playing a VCD with PBC,
see page 10.
Before performing any operations, make sure the following...
• Turn on the monitor and select the appropriate monitor input before playing a VCD.
• If you turn on the monitor, you can also control the MP3/WMA playback by referring to the monitor screen
(see page 12).
• Select the color system suitable for your monitor (see page 15).
F(FM) 1 F2 F3
A(AM) 1
A2
[Hold]
92.50 F1
92.50 F1
4
Preset number
EN_KD-SV3706[US].indb 9EN_KD-SV3706[US].indb 9 08.12.11 3:10:04 PM08.12.11 3:10:04 PM

ENGLISH
10
Selecting a track
On the Unit:
On the Remote:
• For audio CD, MP3 disc* or VCD without PBC only
• For details about using number buttons, see page 6.
• You can also use 4/ ¢to select a track.
*You can specify the tracks in the current folder.
Selecting the next or previous folders (only
for MP3 or WMA discs)
• For MP3/WMA discs, see also “MP3/WMA control
screen operations” on page 12.
Playback Control (PBC) operations
On the Remote ONLY:
1While playing a VCD...
The current setting is shown on the monitor.
ON: You can play the disc interactively using
the menu.
OFF: Cancels.
• A menu may be a list of items, submenus, or
some moving pictures.
Stop playing and ejecting the disc
On the Unit ONLY:
The disc is ejected and the source is changed to the
previous source.
Stop playing
On the Remote ONLY:
• The unit memorizes the position where the playback
has been stopped, and when you start playback again
by pressing 6, it starts from the position where
you have stopped—Resume Play.
To clear the memorized position, press 7twice.
Pause playing
• Press the button again to start playback.
Fast-forwarding or reversing the track
On the Unit:
On the Remote:
[Hold]
OFF
ON
EN_KD-SV3706[US].indb 10EN_KD-SV3706[US].indb 10 08.12.11 3:10:06 PM08.12.11 3:10:06 PM

ENGLISH
11OPERATIONS
2Select the item you want.
• For details about using number buttons, see
page 6.
• To select an item from the submenus, repeat this
step.
• To move to the next or previous page of the
current menu, press 4/¢.
• To return to the menu, press 7on the remote
controller.
On-Screen operations
Displaying the On-Screen information
You can check the track number and elapsed playing
time if the monitor is turned on.
On the Remote ONLY:
While playing a disc...
Ex.: When playing back a VCD
1Disc type
2Current track number/total number of tracks in the
current folder (for MP3/WMA)/disc (audio CD/VCD)
3The status of PBC
• When PBC is deactivated, the indication is in
gray.
4Repeat mode (See also page 13.)
• : Repeats current track.
• : Repeats all tracks on a disc.
5Elapsed playing time
• To turn off the On-Screen bar, press the button
again.
Specifying the playback point by time — for
VCD only
On the Remote ONLY:
1
On-screen bar appears on the screen.
2Highlight the position of the time you want
to change.
3Enter the number.
• For details about using number buttons, see
page 6.
4Repeat steps 2 and 3 to specify the desired
point.
5Confirm the entry.
Playback starts from the position you specified.
Specifying the track — for audio CD/VCD
only
Perform the above procedure to select the track
number.
• Highlight the track number in step 2, then enter the
desired track number in step 3.
EN_KD-SV3706[US].indb 11EN_KD-SV3706[US].indb 11 08.12.11 3:10:07 PM08.12.11 3:10:07 PM

ENGLISH
12
1Current folder name/track name*1
2Folder name (ROOT)*1/track name (FILE)*1/track
title (TITLE)*1 *2/performer (ARTIST)*1 *2/album
name (ALBUM)*1 *2
3Folder name*1(only for MP3 discs)
4Highlighted bar for the selected folder
5Track name*1
6Highlighted bar for the selected file
*1Some symbols will not be shown (or will be
substituted with others) on the control screen.
*2Only for MP3: Appears only when an MP3 le have
Tag information.
• The monitor can show up to 10 folders and 10 tracks
at a time and a maximum of 255 tracks for a disc.
Switching between the folder selection and
the file selection
On the Remote ONLY:
To select an item
On the Remote ONLY:
[ 1 ]GREEN .MP3
01.1
02.2
03.3
04.4
01.THUNDER
02.TYPHOON
03.SUMMER
ROOT: 1
3542 61
STEREO MONO L
MONO R
Selecting the audio channel
You can select the audio channel to play. (This is
convenient when playing a Karaoke VCD.)
The current setting is shown on the monitor.
STEREO: To listen to normal stereo (left/right)
playback.
MONO L: To listen to the L (left) audio channel.
MONO R: To listen to the R (right) audio channel.
• The audio channel is automatically set to “STEREO”
when you change the disc.
MP3/WMA control screen
operations
You can also control the playback of an MP3/WMA disc
by referring to the monitor.
• The control screen automatically appears on the
monitor when you insert an MP3/WMA disc.
EN_KD-SV3706[US].indb 12EN_KD-SV3706[US].indb 12 08.12.11 3:10:08 PM08.12.11 3:10:08 PM

ENGLISH
13OPERATIONS
2Highlight the program number.
3Enter track number.
• For MP3/WMA: Enter a folder number (F), press
#, then enter a track number (T).
• For VCD/audio CD: Enter a track number.
4Repeat steps 2 and 3 to program other
tracks.
5Start program play.
• To clear the program, select “CLEAR” on the
program screen, then press ENTER. The program
is cleared, and the unit return to normal playback.
Pressing 7also clears the program. (The playback
stops.)
Selecting the playback modes
You can use only one of the following playback modes
at a time.
• This function is not available for VCD with PBC.
Playing the beginning 15 seconds of all
tracks of the current disc — Intro Play
On the Unit ONLY:
To return to normal playback, press the button again.
Playing a track repeatedly — Repeat Play
RPT ON: Repeats the current track.
RPT OFF: Cancels. ( Repeats all tracks on a disc.)
Playing tracks at random — Random Play
On the Unit ONLY:
RND ON: Randomly plays all tracks.
RND OFF: Cancels.
Programing the playing order — Program
Play
On the Remote ONLY:
1PROG
1[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PLAY CLEAR
PROG
1[ 08
]
[ 02
]
[ 11
]
[ 05
]
[
-- ]
[
-- ]
[
-- ]
[
-- ]
2
3
4
5
6
7
8
PLAY
RPT ON
RPT OFF
RND ON
RND OFF
Folder number
Track number
PROG
FT
1 02:05
FT
-- : -- 5
FT
-- : -- 9
FT
-- : -- 13
INT ON
INT OFF
EN_KD-SV3706[US].indb 13EN_KD-SV3706[US].indb 13 08.12.11 3:10:09 PM08.12.11 3:10:09 PM

ENGLISH
14
Listening to the other external components
You can connect an external component to AUX (auxiliary) input jack on the control panel.
Connecting an external component to the AUX input jack
1Select “AUX IN.”
2—Turn on the connected component and start playing the
source.
3
[Turn]
Adjust the volume.
4—Adjust the sound as you want (see page 15).
• You can adjust the output level setting for the external component. See “Adjusting the sound settings” on
page 15.
3.5 mm stereo mini plug
(not supplied)
Portable audio player, etc.
EN_KD-SV3706[US].indb 14EN_KD-SV3706[US].indb 14 08.12.11 3:10:11 PM08.12.11 3:10:11 PM

ENGLISH
15SETTINGS
Sound and monitor settings
Selecting a sound mode
You can select a preset sound mode suitable to the
music genre.
• Preset value for each sound mode is as follows:
Mode Bass
(BAS)
Treble
(TRE)
Loudness
(LOUD)
ROCK +2 +3 ON
POPS +3 +1 OFF
CLASSIC +1 -3 OFF
FLAT 0 0 OFF
EQ OFF
(Canceled) 00—
• Sound mode is automatically canceled (“EQ OFF” is
selected) in the following cases:
– When activating/deactivating loudness (see
“Activating loudness” below).
– When adjusting bass/treble setting (see “Adjusting
the sound settings” on the right column).
Activating loudness
You can boost low and high frequencies to produce a
well-balanced sound at low volume level.
Loudness is activated and “LOUD ON” appears on
the display.
To cancel loudness, press the button again. “LOUD
OFF” appears on the display.
Adjusting the sound settings
You can adjust the sound characteristics to your
preference.
1
2
VOL Adjusts the volume. (0 to 50)
BAS Adjusts the bass. (–6 to +6)
TRE Adjusts the treble. (–6 to +6)
BAL Adjusts the left and right speaker balance.
(L6 to R6)
FAD*2Adjusts the front and rear speaker balance.
(R6 to F6)
ADJ*1Adjusts the output level of the external
component. (0 to 3)
*1This item is shown only when “AUX IN” is selected as
the source.
*2If you are using a two-speaker system, set the fader
level to “0.”
Selecting the color system
Select the appropriate color system according to the
type of the monitor connected.
While playing a VCD...
The setting appears on the monitor.
PAL For the PAL monitor
NTSC For the NTSC monitor
PAL60 For watching an NTSC disc on a PAL monitor
AUTO Automatically selects the appropriate color
system.
PAL NTSC PAL60
AUTO
[Turn]
EN_KD-SV3706[US].indb 15EN_KD-SV3706[US].indb 15 08.12.11 3:10:11 PM08.12.11 3:10:11 PM

ENGLISH
16
Basic operations
Turning on the power
• By pressing SRC on the unit, you can also turn on the
power. If the source is ready, playback also starts.
Turning off the power
• If you turn off the power while listening to a disc,
playback will start from where it had been stopped
previously next time you turn on the power.
For MP3/WMA discs, playback will start from the
beginning of the last playing track.
General
• If you change the source while listening to a disc,
playback stops.
Next time you change the source to play a disc,
playback will start from where it had been stopped
previously.
Tuner operations
Storing stations in memory
• During SSM search...
– All previously stored stations are erased and
stations are stored newly.
– Received stations are preset in No. 1 (lowest
frequency) to No. 6 (highest frequency).
– When SSM is over, the station stored in No. 1 will
be automatically tuned in.
• When storing a station manually, the previously
preset station is erased when a new station is stored
in the same preset number.
Disc operations
Caution for DualDisc playback
• The Non-DVD side of a “DualDisc” does not comply
with the “Compact Disc Digital Audio” standard.
Therefore, the use of Non-DVD side of a DualDisc on
this product may not be recommended.
General
• This unit has been designed to reproduce CDs/CD
Texts, and CD-Rs (Recordable)/CD-RWs (Rewritable)
in audio CD (CD-DA), MP3 and WMA formats.
• This unit cannot play back DVDs, SVCDs, CD-Gs, or CD-
I discs.
• When a disc is inserted upside down, the disc
automatically ejects.
• While fast-forwarding or reversing on an MP3 or
WMA disc, you can only hear intermittent sounds.
• “INVALID KEY” appears on the monitor when the
operation is unacceptable.
Playing a CD-R or CD-RW
• Use only “finalized” CD-Rs or CD-RWs.
• This unit can only play back files of the same type as
those detected first if a disc includes both audio CD
(CD-DA) files and MP3/WMA files.
• This unit can play back multi-session discs; however,
unclosed sessions will be skipped while playing.
• Some CD-Rs or CD-RWs may not play back on this
unit because of their disc characteristics, or for the
following reasons:
– The storage capacity of the CD-R/CD-RW is 700 MB
or more.
– Discs are dirty or scratched.
– Moisture condensation has occurred on the lens
inside the unit.
– The pickup lens inside the unit is dirty.
– The files on the CD-R/CD-RW are written using the
“Packet Write” method.
– There are improper recording conditions (missing
data, etc.) or media conditions (stained, scratched,
warped, etc.).
More about this unit
EN_KD-SV3706[US].indb 16EN_KD-SV3706[US].indb 16 08.12.11 3:10:13 PM08.12.11 3:10:13 PM

ENGLISH
17REFERENCES
• CD-RWs may require a longer readout time since the
reflectance of CD-RWs is lower than that of regular
CDs.
• Do not use the following CD-Rs or CD-RWs:
– Discs with stickers, labels, or a protective seal stuck
to the surface.
– Discs on which labels can be directly printed by an
ink jet printer.
Using these discs under high temperature or high
humidity may cause malfunctions or damage to the
unit.
Playing a VCD disc
• The PBC function is not available for some VCDs.
• The PBC function is automatically canceled when you
change the source or turn off the unit. Playback starts
from the beginning of the disc when you play the VCD
again.
• The On-Screen Display (OSD) will automatically
canceled when you change the source or turn off the
unit.
Playing an MP3/WMA disc
• This unit can play back MP3/WMA files with the
extension code <.mp3> or <.wma> (regardless of
the letter case—upper/lower).
• This unit can show the names of albums, artists
(performer), and Tag (Version 1.0, 1.1, 2.2, 2.3, or
2.4) for MP3 files.
• This unit can display only one-byte characters. No
other characters can be correctly displayed.
• This unit can play back MP3/WMA files meeting the
conditions below:
– Bit rate: MP3: 32 kbps — 320 kbps
WMA: 48 kbps — 192 kbps
– Sampling frequency:
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
48 kHz, 44.1 kHz, 32 kHz (for WMA)
– Disc format: ISO 9660 Level 1/Level 2, Romeo,
Joliet, Windows long file name
• The maximum number of characters for folder names
is 10 characters.
• The maximum number of characters for file names
vary among the disc format used (includes 4
extension characters—<.mp3> or <.wma>).
– ISO 9660 Level 1: up to 12 characters
– ISO 9660 Level 2: up to 31 characters
– Romeo: up to 40 characters
– Joliet: up to 40 characters
– Windows long file name: up to 40 characters
• This unit can play back files recorded in VBR (variable
bit rate).
Files recorded in VBR have a discrepancy in elapsed
time display, and do not show the actual elapsed
time. Especially, after performing the search function,
this difference becomes noticeable.
• This unit can recognize a total of 255 files, of 99
folders, and of 8 hierarchies.
• This unit cannot play back the following files:
– MP3 files encoded with MP3i and MP3 PRO format.
– MP3 files encoded in an inappropriate format.
– MP3 files encoded with Layer 1.
– WMA files encoded with lossless, professional, and
voice format.
– WMA files which are not based upon Windows
Media® Audio.
– WMA files copy-protected with DRM.
– Files which have the data such as WAVE, ATRAC3,
etc.
• The search function works but search speed is not
constant.
Ejecting a disc
• If the ejected disc is not removed within 10 seconds,
it is automatically inserted into the loading slot again
to protect it from dust.
Sound and monitor settings
Adjusting the sound settings
• If no operation is done for about 5 seconds, the
operation will be canceled.
EN_KD-SV3706[US].indb 17EN_KD-SV3706[US].indb 17 08.12.11 3:10:14 PM08.12.11 3:10:14 PM

ENGLISH
18
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service center.
Symptoms Remedies/Causes
General
• Sound cannot be heard from the speakers. • Adjust the volume to the optimum level.
• Check the cords and connections.
• The unit does not work at all. Reset the unit (see page 3).
FM/AM
• SSM automatic presetting does not work. Store stations manually.
• Static noise while listening to the radio. Connect the antenna firmly.
Disc playback
• Disc automatically ejects. Insert the disc correctly.
• CD-R/CD-RW cannot be played back.
• Tracks on the CD-R/CD-RW cannot be
skipped.
• Insert a finalized CD-R/CD-RW.
• Finalize the CD-R/CD-RW with the component which
you used for recording.
• Sound and pictures are sometimes
interrupted or distorted.
• Stop playback while driving on rough roads.
• Change the disc.
• Check the cords and connections.
• No playback picture appears on the
monitor.
Parking brake wire is not connected properly.
(See Installation/Connection manual.)
• No picture appears on the monitor at all. • Connect the video cord correctly.
• Select a correct input on the monitor.
EN_KD-SV3706[US].indb 18EN_KD-SV3706[US].indb 18 08.12.11 3:10:16 PM08.12.11 3:10:16 PM

ENGLISH
19REFERENCES
Symptoms Remedies/Causes
MP3/WMA playback
• Disc cannot be played back. • Use a disc with MP3/WMA tracks recorded in a format
compliant with ISO 9660 Level 1, Level 2, Romeo, or
Joliet.
• Add the extension code <.mp3> or <.wma> to the
file names.
• Noise is generated. Skip to another track or change the disc. (Do not add the
extension code <.mp3> or <.wma> to non-MP3 or
WMA tracks.)
• Tracks do not play back in the order you
have intended them to play.
The playback order is determined when the files are
recorded.
• The elapsed playing time is not correct. This sometimes occurs during playback. This is caused by
how the tracks are recorded on the disc.
• The correct characters are not displayed
(e.g. album name).
This unit can only display letters (upper case), numbers,
and a limited number of symbols.
EN_KD-SV3706[US].indb 19EN_KD-SV3706[US].indb 19 08.12.11 3:10:17 PM08.12.11 3:10:17 PM

ENGLISH
20
Do not use the following discs:
Single CD
—8 cm disc Warped disc
Sticker and sticker residue Stick-on label
Unusual shape
C-thru Disc (semi-
transparent disc)
Transparent or semi-
transparent parts on its
recording area
How to clean the connectors
Frequent detachment will deteriorate the connectors.
To minimize this possibility, periodically wipe the
connectors with a cotton swab or cloth moistened with
alcohol, being careful not to damage the connectors.
Moisture condensation
Moisture may condense on the lens inside the unit in
the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the unit may malfunction. In this
case, eject the disc and leave the unit turned on for a
few hours until the moisture has evaporated.
How to handle discs
When removing a disc from its
case, press down the center holder
of the case and lift the disc out,
holding it by the edges.
• Always hold the disc by the edges. Do not touch its
recording surface.
When storing a disc in its case, gently insert the
disc around the center holder (with the printed surface
facing up).
• Make sure to store discs in cases after use.
Connectors
Center holder
To keep discs clean
A dirty disc may not play correctly.
If a disc does become dirty, wipe it with
a soft cloth in a straight line from center
to edge.
• Do not use any solvents (for example, conventional
record cleaner, spray, thinner, benzine, etc.) to clean
discs.
To play new discs
New discs may have some rough spots
around the inner and outer edges. If
such a disc is used, this unit may reject
the disc.
To remove these rough spots, rub the edges with a
pencil or ball-point pen, etc.
Maintenance
EN_KD-SV3706[US].indb 20EN_KD-SV3706[US].indb 20 08.12.11 3:10:17 PM08.12.11 3:10:17 PM
