JVC KW-AVX840 User manual

ENGLISHESPAÑOLFRANÇAIS
For canceling the display demonstration, see page 7.
Para cancelar la demonstración en pantalla, consulte la página 7.
Pour annuler la démonstration des affichages, référez-vous à la page 7.
KW-AVX848/KW-AVX840
For installation and connections, refer to the separate manual.
Para la instalación y las conexiones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS LVT2180-001A
[J/JW]
DVD RECEIVER WITH MONITOR
RECEPTOR DVD CON MONITOR
RÉCEPTEUR DVD ET MONITEUR
For customer Use:
Enter below the Model No. and
Serial No. which are located on
the top or bottom of the cabinet.
Retain this information for future
reference.
Model No.
Serial No.
Only for KW-AVX840
Sólo para KW-AVX840
Uniquement pour le KW-AVX840
Covers_AVX_840[JJW].indb 2 11/01/12 14:11

2
ENGLISH
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the
top cover.There are no user
serviceable parts inside the
unit; leave all servicing to
qualified service personnel.
3. CAUTION: (For U.S.A.) Visible and/or invisible class II laser radiation when open. Do not stare into beam.
(For Canada)Visible and/or invisible class 1M laser radiation when open. Do not view directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDETHE UNIT.
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in
a residential installation.This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not approved by JVC could void the user’s authority to operate the equipment.
WARNINGS: (To prevent accidents and damage)
• DO NOT install any unit or wire any cable in a location
where;
– it may obstruct the steering wheel and gearshift
lever operations.
– it may obstruct the operation of safety devices
such as air bags.
– it may obstruct visibility.
• DO NOT operate the unit while driving.
If you need to operate the unit while driving, be sure
to look around carefully.
• The driver must not watch the monitor while driving.
• The driver must not put on the headphones while
driving.
• Excessive sound pressure from earphones or
headphones can cause hearing loss when you listen
through earphones or headphones playing the rear
source.
[European Union only]
EN_KW-AVX840JJW.indb 2 11/01/19 13:19

3
ENGLISH
Cautions on the monitor:
• The monitor built in this unit has been produced with
high precision, but it may have some ineffective dots.
This is inevitable and is not considered defective.
• Do not expose the monitor to direct sunlight.
• Do not operate the touch panel using a ball-point
pen or similar tool with the sharp tip.
Touch the buttons on the touch panel with your
finger directly (if you are wearing a glove, take it off).
• When the temperature is very cold or very hot...
–
Chemical changes occur inside, causing malfunction.
– Pictures may not appear clearly or may move
slowly. Pictures may not be synchronized with
the sound or picture quality may decline in such
environments.
For safety...
• Do not raise the volume level too much, as this will
make driving dangerous by blocking outside sounds,
and may cause hearing loss.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you have parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
Caution
This product has a fluorescent lamp that
contains mercury. Disposal of these materials
may be regulated in your community due to
environmental considerations. For disposal or
recycling information, please contact your local
authorities or for USA, the Electronic Industries
Alliance: <http://www.eiae.org.>
How to read this manual:
• Illustrations of KW-AVX840 are mainly used for explanation.
• This manual mainly explains operations using the buttons on the monitor panel and touch panel. For
operations using the remote controller (RM-RK252: supplied only for KW-AVX848), page 58.
• < > indicates the variable screens/menus/operations/settings that appear on the touch panel.
• [ ] indicates the buttons on the touch panel.
• Indication language: English indications are used for the purpose of explanation.You can select the
indication language from the <Settings> menu. (page 47)
How to reset your unit
• Your preset adjustments will also be erased (except the
registered Bluetooth devices).
How to forcibly eject a disc
On the monitor panel and the source control screen:
(Hold)
(Hold)
•Be careful not to drop the disc when it ejects.
•If this does not work, reset your unit. (above)
EN_KW-AVX840JJW.indb 3 11/01/19 13:19

4
ENGLISH
Contents
How to reset your unit...........................................3
How to forcibly eject a disc....................................3
INTRODUCTIONS
Detaching/attaching the monitor panel...5
Initial Settings .......................................6
Canceling the display demonstration and
setting the clock..............................7
Common operations ...............................9
Turning on the power ...........................................9
Turning off/on the screen .....................................9
Turning off/on the AV source ................................9
Adjusting the volume .........................................10
Touch screen operation........................................10
Ejecting the disc/adjusting the monitor panel ....10
Switching screens ................................11
AV SOURCE OPERATIONS
Selecting the playback source ...............12
Listening to the radio ...........................13
Disc operations.....................................17
Playing a disc ......................................................17
Playable disc type................................................ 18
Playback operations ...........................................19
Settings for disc playback ................................... 23
USB operations.....................................24
Playing a USB device ...........................................24
Listening to the iPod/iPhone device ......26
iPod/iPhone playback operations ....................... 27
Selecting a track/video from menu on the iPod/
iPhone ................................................................28
Setting for watching video..................................28
Using other external components..........29
AV-IN................................................................... 29
Using the external navigation unit .....................30
Listening to the satellite radio
(Only for KW-AVX840).....................31
Activating subscription .......................................31
Tuning in to a channel you want ......................... 32
Listening to the HD Radio™ broadcast
(Only for KW-AVX840).....................34
Rear source operations .........................36
Sound adjustment................................37
Using the sound equalization .............................37
Adjusting the cross over frequency...................... 38
Changing display design .......................39
Setting for video playback ....................41
Picture adjustment .............................................41
Changing the aspect ratio ...................................42
Zooming picture.................................................. 42
Using a rear view camera ......................43
Setting menu items..............................44
Memorizing/recalling the settings ...................... 48
Adjusting the touch position...............................48
BLUETOOTH OPERATIONS
Information for using Bluetooth®
devices..........................................49
Bluetooth operations ...........................49
Connecting Bluetooth devices ............................ 50
Using the Bluetooth mobile phone ..................... 52
Using the Bluetooth audio player .......................56
Bluetooth device settings....................................57
REFERENCE
Using the remote controller
(Only for KW-AVX848).....................58
Operations using the remote controller
(RM-RK252) ........................................................58
Maintenance........................................61
More about this unit.............................62
Troubleshooting...................................65
Specifications.......................................70
EN_KW-AVX840JJW.indb 4 11/01/19 13:19

5
ENGLISH
Attaching
Detaching
1On the source control screen:
2
The monitor panel opens by about 50°.
• It closes automatically when no operation is
done for about 60 seconds.
Remove the monitor panel before this happens.
Cautions
• Hold the monitor panel securely so as not to drop it accidentally.
• Fit the monitor panel onto the attaching plate until it is firmly locked.
Detaching/attaching the monitor panel
3
Attaching plate
The monitor panel is
unlocked.
• The attaching plate closes automatically about
10 seconds after the monitor panel is unlocked.
4
Soft case (supplied)
INTRODUCTIONS
EN_KW-AVX840JJW.indb 5 11/01/19 13:19
