JVC KD-X252 User manual

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ENGLISH
ESPAÑOL
NEDERLANDS
PORTUGUÊS
B5A-2129-00 [E]
KD-X252 / KD-X152 / KD-X151
DIGITAL MEDIA RECEIVER
INSTRUCTION MANUAL
RECEPTOR DE MEDIOS DIGITALES
MANUAL DE INSTRUCCIONES
DIGITALE MEDIAONTVANGER
GEBRUIKSAANWIJZING
RECEPTOR MÉDIA DIGITAL
MANUAL DE INSTRUÇÕES
JS_JVC_KD_X252_E_C00.indd 1JS_JVC_KD_X252_E_C00.indd 1 20/6/2017 5:13:09 PM20/6/2017 5:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
i
Information on Disposal of Old Electrical and Electronic Equipment and Batteries (applicable
for countries that have adopted separate waste collection systems)
Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste.
Old electrical and electronic equipment and batteries should be recycled at a facility capable of handling
these items and their waste byproducts.
Contact your local authority for details in locating a recycle facility nearest to you. Proper recycling and
waste disposal will help conserve resources whilst preventing detrimental effects on our health and the
environment.
Notice: The sign “Pb” below the symbol for batteries indicates that this battery contains lead.
Información acerca de la eliminación de equipos eléctricos, electrónicos y baterías al final de
la vida útil (aplicable a los países que hayan adoptado sistemas independientes de recogida
de residuos)
Los productos y las baterías con el símbolo de un contenedor con ruedas tachado no podrán ser desechados
como residuos domésticos.
Los equipos eléctricos, electrónicos y baterías al final de la vida útil, deberán ser reciclados en
instalaciones que puedan dar el tratamiento adecuado a estos productos y a sus subproductos residuales
correspondientes.
Póngase en contacto con su administración local para obtener información sobre el punto de recogida más
cercano. Un tratamiento correcto del reciclaje y la eliminación de residuos ayuda a conservar los recursos y
evita al mismo tiempo efectos perjudiciales en la salud y el medio ambiente.
Nota: El símbolo “Pb” debajo del (contenedor con ruedas tachado) en baterías indica que dicha batería
contiene plomo.
Informatie over het weggooien van elektrische en elektronische apparatuur en batterijen
(particulieren)
Dit symbool geeft aan dat gebruikte elektrische, elektronische producten en batterijen niet bij het normale
huishoudelijke afval mogen.
Lever deze producten in bij de aangewezen inzamelingspunten, waar ze gratis worden geaccepteerd en op
de juiste manier worden verwerkt, teruggewonnen en hergebruikt.
Voor inleveradressen zie www.nvmp.nl, www.ictmilieu.nl, www.stibat.nl. Wanneer u dit product op de
juiste manier als afval inlevert, spaart u waardevolle hulpbronnen en voorkomt u potentiële negatieve
gevolgen voor de volksgezondheid en het milieu, die anders kunnen ontstaan door een onjuiste verwerking
van afval.
Opgelet: Het teken “Pb” onder het teken van de batterijen geeft aan dat deze batterij lood bevat.
Informação sobre a forma de deitar fora Velho Equipamento Eléctrico, Electrónico e baterias
(aplicável nos países que adotaram sistemas de recolha de lixos separados)
Produtos e baterias com o símbolo (caixote do lixo com um X) não podem ser deitados fora junto com o
lixo doméstico.
Equipamentos velhos eléctricos, electrónicos e baterias deverão ser reciclados num local capaz de o fazer
bem assim como os seus subprodutos.
Contacte as autoridades locais para se informar de um local de reciclagem próximo de si. Reciclagem e
tratamento de lixo correctos ajudam a poupar recursos e previnem efeitos prejudiciais na nossa saúde e
no ambiente.
Note: o símbolo “Pb” abaixo do símbolo em baterias indica que esta bateria contém chumbo.
JS_JVC_KD_X252_E_C00.indd iJS_JVC_KD_X252_E_C00.indd i 20/6/2017 5:13:09 PM20/6/2017 5:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
ii
For Israel
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
• “Made for iPod,” and “Made for iPhone” mean that an electronic accessory has been designed to
connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to
meet Apple performance standards. Apple is not responsible for the operation of this device or
its compliance with safety and regulatory standards. Please note that the use of this accessory
with iPod or iPhone may affect wireless performance.
• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in
the U.S. and other countries.
• Lightning is a trademark of Apple Inc.
• Android is trademark of Google Inc.
libFLAC
Copyright (C) 2000-2009 Josh Coalson
Copyright (C) 2011-2013 Xiph.Org Foundation
Redistribution and use in source and binary forms, with or without modification, are permitted provided
that the following conditions are met:
- Redistributions of source code must retain the above copyright notice, this list of conditions and
the following disclaimer.
- Redistributions in binary form must reproduce the above copyright notice, this list of conditions
and the following disclaimer in the documentation and/or other materials provided with the
distribution.
- Neither the name of the Xiph.org Foundation nor the names of its contributors may be used
to endorse or promote products derived from this software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL
THE FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF
SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY,
OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
JS_JVC_KD_X252_E_C00.indd iiJS_JVC_KD_X252_E_C00.indd ii 20/6/2017 5:13:09 PM20/6/2017 5:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iii
Declaration of Conformity with regard to the RE Directive 2014/53/EU
Declaration of Conformity with regard to the RoHS Directive 2011/65/EU
Manufacturer:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
EU Representative:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
Declaración de conformidad con respecto a la Directiva RE 2014/53/EU
Declaración de conformidad con respecto a la Directiva RoHS 2011/65/EU
Fabricante:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
Representante en la UE:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
Conformiteitsverklaring met betrekking tot de RE-richtlijn van de Europese Unie
(2014/53/EU)
Conformiteitsverklaring met betrekking tot de RoHS richtlijn van de Europese Unie
(2011/65/EU)
Fabrikant:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
EU-vertegenwoordiger:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
Declaração de conformidade relativa à Directiva RE 2014/53/EU
Declaração de conformidade relativa à Directiva RoHS 2011/65/EU
Fabricante:
JVC KENWOOD Corporation
3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN
Representante na UE:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel, GERMANY
English
Hereby, JVCKENWOOD declares that the radio
equipment “KD-X252/KD-X152/KD-X151” is in
compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is
available at the following internet address:
http://www.jvc.net/cs/car/eudoc/
Français
Par la présente, JVCKENWOOD déclare que
l’équipement radio « KD-X252/KD-X152/KD-X151 » est
conforme à la directive 2014/53/UE.
L’intégralité de la déclaration de conformité UE est
disponible à l’adresse Internet suivante :
http://www.jvc.net/cs/car/eudoc/
Deutsch
Hiermit erklärt JVCKENWOOD, dass das Funkgerät
“KD-X252/KD-X152/KD-X151” der Richtlinie
2014/53/EU entspricht.
Der volle Text der EU-Konformitätserklärung steht
unter der folgenden Internetadresse zur Verfügung:
http://www.jvc.net/cs/car/eudoc/
Nederlands
Hierbij verklaart JVCKENWOOD dat de radioapparatuur
“KD-X252/KD-X152/KD-X151” in overeenstemming is
met Richtlijn 2014/53/EU.
De volledige tekst van de EU-verklaring van
overeenstemming is te vinden op het volgende
internetadres:
http://www.jvc.net/cs/car/eudoc/
Italiano
Con la presente, JVCKENWOOD dichiara che
l΄apparecchio radio “KD-X252/KD-X152/KD-X151” è
conforme alla Direttiva 2014/53/UE.
Il testo integrale della dichiarazione di conformità UE è
disponibile al seguente indirizzo internet:
http://www.jvc.net/cs/car/eudoc/
Español
Por la presente, JVCKENWOOD declara que el equipo de
radio “KD-X252/KD-X152/KD-X151” cumple la Directiva
2014/53/EU.
El texto completo de la declaración de conformidad
con la UE está disponible en la siguiente dirección de
internet:
http://www.jvc.net/cs/car/eudoc/
Português
Deste modo, a JVCKENWOOD declara que o
equipamento de rádio “KD-X252/KD-X152/KD-X151”
está em conformidade com a Diretiva 2014/53/UE.
O texto integral da declaração de conformidade da UE
está disponível no seguinte endereço de internet:
http://www.jvc.net/cs/car/eudoc/
Polska
Niniejszym, JVCKENWOOD deklaruje, że sprzęt radiowy
“KD-X252/KD-X152/KD-X151” jest zgodny z dyrektywą
2014/53/UE.
Pełny tekst deklaracji zgodności EU jest dostępny pod
adresem:
http://www.jvc.net/cs/car/eudoc/
Český
Společnost JVCKENWOOD tímto prohlašuje, že rádiové
zařízení “KD-X252/KD-X152/KD-X151” splňuje
podmínky směrnice 2014/53/EU.
Plný text EU prohlášení o shodě je dostupný na
následující internetové adrese:
http://www.jvc.net/cs/car/eudoc/
Magyar
JVCKENWOOD ezennel kijelenti, hogy a „KD-X252/
KD-X152/KD-X151“ rádióberendezés megfelel a
2014/53/EU irányelvnek.
Az EU konformitási nyilatkozat teljes szövege az alábbi
weboldalon érhető el:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_X252_E_C00.indd iiiJS_JVC_KD_X252_E_C00.indd iii 20/6/2017 5:13:09 PM20/6/2017 5:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
iv
Svenska
Härmed försäkrar JVCKENWOOD att
radioutrustningen “KD-X252/KD-X152/KD-X151”
är i enlighet med direktiv 2014/53/EU.
Den fullständiga texten av EU-försäkran
om överensstämmelse finns på följande
Internetadress :
http://www.jvc.net/cs/car/eudoc/
Suomi
JVCKENWOOD julistaa täten, että radiolaite
“KD-X252/KD-X152/KD-X151” on direktiivin
2014/53/EU mukainen.
EU-vaatimustenmukaisuusvakuutusvaatimus
löytyy kokonaisuudessaan seuraavasta internet-
osoitteesta:
http://www.jvc.net/cs/car/eudoc/
Slovensko
S tem JVCKENWOOD izjavlja, da je radijska oprema
»KD-X252/KD-X152/KD-X151« v skladu z Direktivo
2014/53/EU.
Celotno besedilo direktive EU o skladnosti je
dostopno na tem spletnem naslovu:
http://www.jvc.net/cs/car/eudoc/
Slovensky
Spoločnosť JVCKENWOOD týmto vyhlasuje, že
rádiové zariadenie „KD-X252/KD-X152/KD-X151“
vyhovuje smernici 2014/53/EÚ.
Celý text EÚ vyhlásenia o zhode nájdete na
nasledovnej internetovej adrese:
http://www.jvc.net/cs/car/eudoc/
Dansk
Herved erklærer JVCKENWOOD, at
radioudstyret “KD-X252/KD-X152/KD-X151” er i
overensstemmelse med Direktiv 2014/53/EU.
EU-overensstemmelseserklæringens fulde ordlyd
er tilgængelig på følgende internetadresse:
http://www.jvc.net/cs/car/eudoc/
Ελληνικά
Με το παρόν, η JVCKENWOOD δηλώνει ότι ο
ραδιοεξοπλισμός «KD-X252/KD-X152/KD-X151»
συμμορφώνεται με την Οδηγία 2014/53/ΕΕ.
Το πλήρες κείμενο της δήλωσης συμμόρφωσης
της ΕΕ είναι διαθέσιμο στην ακόλουθη διεύθυνση
στο διαδίκτυο:
http://www.jvc.net/cs/car/eudoc/
Eesti
Käesolevaga JVCKENWOOD kinnitab, et „KD-X252/
KD-X152/KD-X151“ raadiovarustus on vastavuses
direktiiviga 2014/53/EL.
ELi vastavusdeklaratsiooni terviktekst on
kättesaadav järgmisel internetiaadressil:
http://www.jvc.net/cs/car/eudoc/
Latviešu
JVCKENWOOD ar šo deklarē, ka radio aparatūra
„KD-X252/KD-X152/KD-X151” atbilst direktīvas
2014/53/ES prasībām.
Pilns ES atbilstības deklarācijas teksts ir pieejams
šādā tīmekļa adresē:
http://www.jvc.net/cs/car/eudoc/
Lietuviškai
Šiuo JVCKENWOOD pažymi, kad radijo įranga
„KD-X252/KD-X152/KD-X151“ atitinka 2014/53/EB
direktyvos reikalavimus.
Visą EB direktyvos atitikties deklaracijos tekstą
galite rasti šiuo internetiniu adresu:
http://www.jvc.net/cs/car/eudoc/
Malti
B’dan, JVCKENWOOD jiddikjara li t-tagħmir
tar-radju “KD-X252/KD-X152/KD-X151” huwa
konformi mad-Direttiva 2014/53/UE.
It-test kollu tad-dikjarazzjoni ta’ konformità huwa
disponibbli fl-indirizz intranet li ġej:
http://www.jvc.net/cs/car/eudoc/
HRVATSKI / SRPSKI JEZIK
JVCKENWOOD ovim izjavljuje da je radio oprema
“KD-X252/KD-X152/KD-X151” u skladu s
Direktivom 2014/53/EU.
Cjeloviti tekst deklaracije Europske unije o
usklađenosti dostupan je na sljedećoj internet
adresi:
http://www.jvc.net/cs/car/eudoc/
ROMÂNĂ
Prin prezenta, JVCKENWOOD declară că
echipamentul radio “KD-X252/KD-X152/KD-X151”
este în conformitate cu Directiva 2014/53/UE.
Textul integral al declarației de conformitate UE
este disponibil la urmatoarea adresă de internet:
http://www.jvc.net/cs/car/eudoc/
БЪЛГАРСКИ
С настоящото JVCKENWOOD декларира, че
радиооборудването на “KD-X252/KD-X152/
KD-X151” е в съответствие с Директива
2014/53/ЕС.
Пълният текст на ЕС декларацията за
съответствие е достъпен на следния интернет
адрес:
http://www.jvc.net/cs/car/eudoc/
Turkish
Burada, JVCKENWOOD “KD-X252/KD-X152/
KD-X151” radyo ekipmanının 2014/53/AB
Direktifine uygun olduğunu bildirir.
AB uyumluluk deklarasyonunun tam metni
aşağıdaki internet adresinde mevcuttur.
http://www.jvc.net/cs/car/eudoc/
Русский
JVCKENWOOD настоящим заявляет, что
радиооборудование «KD-X252/KD-X152/
KD-X151» соответствует Директиве 2014/53/EU.
Полный текст декларации соответствия
ЕС доступен по следующему адресу в сети
Интернет:
http://www.jvc.net/cs/car/eudoc/
Українська
Таким чином, компанія JVCKENWOOD заявляє,
що радіообладнання «KD-X252/KD-X152/
KD-X151» відповідає Директиві 2014/53/EU.
Повний текст декларації про відповідність ЄС
можна знайти в Інтернеті за такою адресою:
http://www.jvc.net/cs/car/eudoc/
JS_JVC_KD_X252_E_C00.indd ivJS_JVC_KD_X252_E_C00.indd iv 20/6/2017 5:13:09 PM20/6/2017 5:13:09 PM

Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
2ENGLISH
CONTENTS BEFORE USE
IMPORTANT
• To ensure proper use, please read through this manual before using this product. It is especially important
that you read and observe Warning and Caution in this manual.
• Please keep the manual in a safe and accessible place for future reference.
Warning
Do not operate any function that takes your attention away from safe driving.
Caution
Volume setting:
• Adjust the volume so that you can hear sounds outside the car to prevent accidents.
• Lower the volume before playing digital sources to avoid damaging the speakers by the sudden increase of
the output level.
General:
• Avoid using the external device if it might hinder safe driving.
• Make sure all important data has been backed up. We shall bear no responsibility for any loss of recorded
data.
• Never put or leave any metallic objects (such as coins or metal tools) inside the unit, to prevent a short
circuit.
BEFORE USE 2
BASICS 3
GETTING STARTED 4
1 Cancel the demonstration
2 Set the clock and date
3 Set the basic settings
USB/iPod/ANDROID 5
RADIO 7
AUX 8
AUDIO SETTINGS 9
DISPLAY SETTINGS 11
REFERENCES 12
Maintenance
More information
TROUBLESHOOTING 13
INSTALLATION/
CONNECTION 14
SPECIFICATIONS 17
How to read this manual
• Operations are explained mainly using buttons on the faceplate of KD-X252 .
• English indications are used for the purpose of explanation. You can select the display language from the
menu.
( 4)
•
[XX] indicates the selected items.
•
( XX) indicates references are available on the stated page.
JS_JVC_KD_X252_E_EN_1.indd 2JS_JVC_KD_X252_E_EN_1.indd 2 20/6/2017 5:12:54 PM20/6/2017 5:12:54 PM

ENGLISH 3
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
BASICS
To On the faceplate
Turn on the power Press .
• Press and hold to turn off the power.
Adjust the volume Turn the volume knob.
Press the volume knob to mute the sound or pause playback.
• Press again to cancel. The volume level returns to the previous level before muting or pause.
Select a source • Press repeatedly.
• Press , then turn the volume knob within 2 seconds.
Change the display information Press repeatedly.
( 13)
Attach
How to reset
Detach
Your preset adjustments
will be erased except stored
radio stations.
Faceplate
Volume knob
Detach button
Display window
JS_JVC_KD_X252_E_EN_1.indd 3JS_JVC_KD_X252_E_EN_1.indd 3 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

4ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
GETTING STARTED
Cancel the demonstration
When you turn on the power for the first time (or after you reset the
unit), the display shows:
“CANCEL DEMO” “PRESS” “VOLUME KNOB”
1 Press the volume knob.
[YES] is selected for the initial setup.
2 Press the volume knob again.
“DEMO OFF” appears.
Set the clock and date
1 Press and hold .
2 Turn the volume knob to select [CLOCK] , then press the knob.
To adjust the clock
3 Turn the volume knob to select [CLOCK ADJUST] , then press the
knob.
4 Turn the volume knob to make the settings, then press the knob.
Hour Minute
5 Turn the volume knob to select [CLOCK FORMAT], then press the knob.
6 Turn the volume knob to select [12H] or [24H], then press the knob.
To set the date
7 Turn the volume knob to select [DATE SET] , then press the knob.
8 Turn the volume knob to make the settings, then press the knob.
Day Month Year
9 Press to exit.
To return to the previous setting item, press .
1
2
Set the basic settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table), then
press the knob.
3 Repeat step 2until the desired item is selected or activated.
4 Press to exit.
To return to the previous setting item, press .
Default: XX
SYSTEM
KEY BEEP ON
:Activates the keypress tone.; OFF :Deactivates.
SOURCE SELECT
AM SRC
*
ON :Enables AM in source selection.; OFF :Disables. ( 7)
BUILT-IN AUX
*
ON :Enables AUX in source selection.; OFF :Disables. ( 8)
F/W UPDATE
UPDATE SYSTEM
F/W UP xxxx YES
:Starts upgrading the firmware.; NO :Cancels (upgrading is not
activated).
For details on how to update the firmware, see:
<http://www.jvc.net/cs/car/> .
CLOCK
TIME SYNC ON
:The clock time is automatically set using the Clock Time (CT) data in FM
Radio Data System signal.;
OFF :Cancels.
CLOCK DISPLAY ON :The clock time is shown on the display even when the unit is turned off.;
OFF :Cancels.
ENGLISH
Select the display language for menu and music information if applicable.
By default,
ENGLISH is selected.
РУССКИЙ
ESPANOL
*
Not displayed when the corresponding source is selected.
3
JS_JVC_KD_X252_E_EN_1.indd 4JS_JVC_KD_X252_E_EN_1.indd 4 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

ENGLISH 5
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
USB/iPod/ANDROID
Selectable sources:
KD-X252 : USB/iPod/ANDROID
KD-X152/KD-X151 : USB/ANDROID
• To directly select USB/iPod/ANDROID source, press or .
To On the faceplate
Reverse/Fast-forward*3Press and hold .
Select a file Press .
Select a folder*4Press .
Repeat play*5Press repeatedly.
TRACK REPEAT / FOLDER REPEAT / ALL REPEAT : MP3/WMA/WAV/FLAC file
ONE REPEAT / ALL REPEAT / REPEAT OFF : iPod or ANDROID
Random play*5Press repeatedly.
FOLDER RANDOM / ALL RANDOM / RANDOM OFF : MP3/WMA/WAV/FLAC file
SONG RANDOM / ALL RANDOM / RANDOM OFF : iPod or ANDROID
*1
Do not leave the cable inside the car when not using.
* 2
When connecting an Android device, “Press [VIEW] to install JVC MUSIC PLAY APP” is shown. Follow the instructions to install
the application. You can also install the latest version of JVC MUSIC PLAY application on your Android device before connecting.
For more information, visit <http://www.jvc.net/cs/car/>.
*3
For ANDROID: Applicable only when [AUTO MODE] is selected. ( 6)
*4
Only for MP3/WMA/WAV/FLAC files. This does not work for iPod/ANDROID.
*5
For iPod/ANDROID: Applicable only when [HEAD MODE] / [AUTO MODE] is selected. ( 6)
Start playback
The source changes automatically and
playback starts.
USB input terminal
USB 2.0 cable
*1
(commercially available)
USB cable
*1
(commercially available)
USB
ANDROID*2
iPod/iPhone
Accessory of the
iPod/iPhone
*1
JS_JVC_KD_X252_E_EN_1.indd 5JS_JVC_KD_X252_E_EN_1.indd 5 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

6ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Select control mode
While in iPod source, press repeatedly.
HEAD MODE : Control iPod from this unit.
IPHONE MODE : Control iPod using the iPod itself. However, you can still
play/pause or file skip from this unit.
While in ANDROID source, press repeatedly.
AUTO MODE : Control Android device from this unit via JVC MUSIC PLAY
application installed in the Android device.
AUDIO MODE : Control Android device using the Android device itself via
other media player applications installed in the Android
device. However, you can still play/pause or file skip from
this unit.
Select music drive
While in USB source, press repeatedly.
Stored songs in the following drive will be played back.
• Selected internal or external memory of a smartphone (Mass Storage
Class).
• Selected drive of a multiple drives device.
Select a file from a folder/list
For iPod/ANDROID, applicable only when [HEAD MODE] / [AUTO MODE] is
selected.
1 Press .
2 Turn the volume knob to select a folder/list, then press the knob.
3 Turn the volume knob to select a file, then press the knob.
Quick search (applicable only for USB and ANDROID source)
If you have many files, you can search through them quickly.
Turn the volume knob quickly to browse through the list quickly
Alphabet search (applicable only for iPod and ANDROID source)
You can search for a file according to the first character.
For iPod source
Press or turn the volume knob quickly to select the
desired character (A to Z, 0to9, OTHERS).
• Select “OTHERS” if the first character is other than AtoZ, 0to9.
For ANDROID source
1 Press to enter character search.
2 Turn the volume knob to select the desired character.
^A^ : Upper case letters (A to Z)
_A_ : Lower case letters (a to z)
-0- : Numbers (0 to 9)
-OTHERS- : Character other than AtoZ, 0to9
3 Press the volume knob to start searching.
• To return to the previous setting item, press .
• To cancel, press and hold .
USB/iPod/ANDROID
JS_JVC_KD_X252_E_EN_1.indd 6JS_JVC_KD_X252_E_EN_1.indd 6 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

ENGLISH 7
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
“STEREO” lights up when receiving an FM stereo broadcast with
sufficient signal strength.
Search for a station
1 Press repeatedly to select FM or AM.
2 Press to search for a station automatically.
(or)
Press and hold until “M” flashes, then press
repeatedly to search for a station manually.
Settings in memory
You can store up to 18 stations for FM and 6 stations for AM.
Store a station
While listening to a station....
Press and hold one of the number buttons (1to 6).
(or)
1 Press and hold the volume knob until “PRESETMODE”
flashes.
2 Turn the volume knob to select a preset number, then press
the knob.
The preset number flashes and “MEMORY” appears.
Select a stored station
Press one of the number buttons (1to6).
(or)
1 Press .
2 Turn the volume knob to select a preset number, then press the knob.
Other settings
1 Press and hold .
2 Turn the volume knob to select an item ( see the following table ) , then
press the knob.
3 Repeat step 2until the desired item is selected/activated or follow the
instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
TUNER SETTING
RADIO TIMER
Turns on the radio at a specific time regardless of the current source.
1 ONCE / DAILY / WEEKLY / OFF :Select how often the timer will be turned on.
2 FM / AM :Select the band.
3 01 to 18 (for FM)/ 01 to 06 (for AM):Select the preset station.
4 Set the activation day
*1
and time.
“
M ” lights up when complete.
Radio Timer will not activate for the following cases.
• The unit is turned off.
• [OFF] is selected for [AM SRC] in [SOURCE SELECT] after Radio Timer for AM is
selected.
( 4)
SSM SSM 01–06
/ SSM 07–12 / SSM 13–18 : Automatically presets up to 18 stations for
FM. “SSM” stops flashing when the first 6 stations are stored. Select
SSM 07–12 /
SSM 13–18 to store the following 12 stations.
*1
Selectable only when [ONCE] or [WEEKLY] is selected in step 1 .
JS_JVC_KD_X252_E_EN_1.indd 7JS_JVC_KD_X252_E_EN_1.indd 7 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

8ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
RADIO
LOCAL SEEK ON :Searches only FM stations with good reception.; OFF :Cancels.
• Settings made are applicable only to the selected source/station. Once
you change the source/station, you need to make the settings again.
IF BAND AUTO :Increases the tuner selectivity to reduce interference noises from
adjacent FM stations. (Stereo effect may be lost.);
WIDE :Subjects to
interference noises from adjacent FM stations, but sound quality will not be
degraded and the stereo effect will remain.
MONO SET ON :Improves the FM reception, but the stereo effect will be lost.;
OFF :Cancels.
NEWS SET
*2
ON :The unit will temporarily switch to News Programme if available.;
OFF :Cancels.
REGIONAL
*2
ON : Switches to another station only in the specific region using the “AF”
control.;
OFF :Cancels.
AF SET
*2
ON : Automatically searches for another station broadcasting the same
program in the same Radio Data System network with better reception
when the current reception is poor.;
OFF : Cancels.
TI ON : Allows the unit to temporarily switch to Traffic Information if available
(“TI” lights up) while listening to all sources except in AM. ;
OFF :Cancels.
PTY SEARCH
*2
Select a PTY code (see below).
If there is a station broadcasting a program of the same PTY code as you
have selected, that station is tuned in.
*2
Only for FM source.
PTY code
NEWS , AFFAIRS , INFO , SPORT , EDUCATE , DRAMA , CULTURE , SCIENCE , VARIED , POP
M
(music), ROCK M (music), EASY M (music), LIGHT M (music), CLASSICS , OTHER
M
(music), WEATHER , FINANCE , CHILDREN , SOCIAL , RELIGION , PHONE IN , TRAVEL ,
LEISURE , JAZZ , COUNTRY , NATION M (music), OLDIES , FOLK M (music), DOCUMENT
Use a portable audio player
1 Connect a portable audio player (commercially available).
2 Select [ON] for [BUILT-IN AUX] in [SOURCE SELECT] . ( 4)
3 Press repeatedly to select AUX.
4 Turn on the portable audio player and start playback.
Use a 3-core plug head stereo mini plug for optimum audio
output.
3.5mm stereo mini plug with “L” shaped connector
(commercially available)
Portable audio player
Auxiliary input jack
AUX
JS_JVC_KD_X252_E_EN_1.indd 8JS_JVC_KD_X252_E_EN_1.indd 8 20/6/2017 5:12:55 PM20/6/2017 5:12:55 PM

ENGLISH 9
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
Default: XX
EQ SETTING
PRESET EQ
Select a preset equalizer suitable to the music genre.
• Select [USER] to use the settings made in [EASY EQ] or [PRO EQ] .
FLAT / DRVN 3 / DRVN 2 / DRVN 1 / HARD ROCK / HIP HOP / JAZZ / POP / R&B / TALK /
USER / VOCAL BOOST / BASS BOOST / CLASSICAL / DANCE
EASY EQ
Adjust your own sound settings.
• The settings are stored to [USER] .
• The settings made may affect the current settings of [PRO EQ] .
SUB.W SP
*1*2:
00 to +06 (Default: +03
SUB.W
*1*3:
–08 to +08 00
BASS
: LVL–06 to LVL+06 LVL 00
MID
: LVL–06 to LVL+06 LVL 00
TRE
: LVL–06 to LVL+06 LVL 00 )
PRO EQ 1 BASS / MIDDLE / TREBLE :Select a sound tone.
2 Adjust the sound elements of the selected sound tone.
• The settings are stored to [USER] .
• The settings made may affect the current settings of [EASY EQ] .
BASS Frequency: 60HZ / 80HZ / 100HZ / 200HZ (Default: 80HZ
Level: LVL–06 to LVL+06 LVL 00
Q: Q1.0 / Q1.25 / Q1.5 / Q2.0 Q1.0 )
MIDDLE Frequency: 0.5KHZ / 1.0KHZ / 1.5KHZ / 2.5KHZ (Default: 1.0KHZ
Level: LVL–06 to LVL+06 LVL 00
Q: Q0.75 / Q1.0 / Q1.25 Q1.25 )
TREBLE Frequency: 10.0KHZ / 12.5KHZ / 15.0KHZ / 17.5KHZ (Default: 10.0KHZ
Level: LVL–06 to LVL+06 LVL 00
Q: Q FIX Q FIX )
AUDIO CONTROL
BASS BOOST LEVEL +01
to LEVEL +05 ( LEVEL +01 ): Selects your preferred bass boost level.;
OFF :Cancels.
*1, *2, *3:
( 10)
Select a preset equalizer directly
Press repeatedly.
(or)
Press , then turn the volume knob within 5seconds.
Preset equalizer :
FLAT (default), DRVN 3 , DRVN 2 , DRVN 1 , HARD ROCK , HIP HOP , JAZZ , POP , R&B ,
TALK , USER , VOCAL BOOST , BASS BOOST , CLASSICAL , DANCE
Drive equalizer ( DRVN 3 / DRVN 2 / DRVN 1 ) boosts specific frequencies in
the audio signal to reduce the noise heard from outside the car or
running noise of the tyres.
Store your own sound settings
1 Press and hold to enter EASY EQ setting.
2 Turn the volume knob to select an item, then press the knob.
Refer to [EASY EQ] for setting and the result is stored to [USER] .
• To return to the previous setting item, press .
• To exit, press .
Other settings
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or
follow the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
JS_JVC_KD_X252_E_EN_2.indd 9JS_JVC_KD_X252_E_EN_2.indd 9 17/7/2017 5:29:36 PM17/7/2017 5:29:36 PM

10 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
AUDIO SETTINGS
LOUDNESS LEVEL 01 / LEVEL 02 :Boosts low or high frequencies to produce a well-
balanced sound at low volume.;
OFF :Cancels.
SUB.W LEVEL
*1
SPK-OUT
*2
SUB.W 00 to SUB.W +06 ( SUB.W +03 ):Adjusts the
output level of the subwoofer connected via speaker lead.
(16)
PRE-OUT
*3
SUB.W –08 to SUB.W +08 ( SUB.W 00 ):Adjusts the
output level of the subwoofer connected to the lineout
terminals (REAR/SW) through an external amplifier.
( 16)
SUBWOOFER SET
*3
ON : Turns on the subwoofer output.; OFF : Cancels.
SUBWOOFER  LPF
*1
FRQ THROUGH :All signals are sent to the subwoofer;
FRQ 55HZ / FRQ 85HZ / FRQ 120HZ :Audio signals with frequencies lower
than 55Hz/85Hz/120Hz are sent to the subwoofer.
SUB.W PHASE
*1*4
REVERSE (180°)/ NORMAL (0°):Selects the phase of the subwoofer output
to be in line with the speaker output for optimum performance.
FADER POSITION R06 to POSITION F06 ( POSITION 00 ):Adjusts the front and
rear speaker output balance.
BALANCE
*5
POSITION L06 to POSITION R06 ( POSITION 00 ):Adjusts the left and
right speaker output balance.
VOLUME  ADJUST LEVEL –15 to LEVEL +06 ( LEVEL 00 ):Preset the initial volume level of
each source (compared to the FM volume level). Before adjustment, select
the source you want to adjust. (“VOLADJFIX” appears if FM is selected.)
AMP  GAIN LOW POWER :Limits the maximum volume level to 25. (Select if the
maximum power of each speaker is less than 50W to prevent damaging
the speakers.);
HIGH POWER :The maximum volume level is 35.
* 1
Displayed only when [SUBWOOFER SET] is set to [ON] .
*2
Displayed only when [SPK/PRE OUT] is set to [SUB.W/SUB.W] .
*3
Displayed only when [SPK/PRE OUT] is set to [REAR/SUB.W] or [SUB.W/SUB.W] .
*4
Selectable only if a setting other than [FRQ THROUGH] is selected for [SUBWOOFER LPF] .
*5
This adjustment will not affect the subwoofer output.
D.T.EXPANDER
(Digital Track
Expander)
ON :Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF :Cancels.
SPK/PRE OUT Depending on the speaker connection method, select the appropriate
setting to get the desired output. ( 
Speaker output settings )
Speaker output settings
Select the output setting for the speakers [SPK/PRE OUT] , base on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. ( 16)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
REAR/SW
REAR/REAR Rear speakers output
REAR/SUB.W (default) Subwoofer output
SUB.W/SUB.W Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with
this settings you can also enjoy the subwoofer output.
( 16)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
REAR/SUB.W Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[FRQ 120HZ] is selected in [SUBWOOFER LPF] and [FRQ THROUGH] is not
available.
–
[POSITION R01] is selected in [FADER] and selectable range is
[POSITION R06] to [POSITION 00] .
JS_JVC_KD_X252_E_EN_1.indd 10JS_JVC_KD_X252_E_EN_1.indd 10 20/6/2017 5:12:56 PM20/6/2017 5:12:56 PM

ENGLISH 11
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Zone identification for brightness setting
1 Press and hold .
2 Turn the volume knob to select an item (see the following table),
then press the knob.
3 Repeat step 2until the desired item is selected/activated or follow
the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
Default:
XX
DISPLAY
DIMMER
Dim the illumination.
OFF :Dimmer is turned off. Brightness changes to [DAY] setting.
ON :Dimmer is turned on. Brightness changes to [NIGHT] setting.
(
 [BRIGHTNESS] )
DIMMER TIME :Set the dimmer on and off time.
1 Turn the volume knob to adjust the [ON] time, then press the knob.
2 Turn the volume knob to adjust the [OFF] time, then press the knob.
(Default:
[ON] : 18:00 ; [OFF] : 6:00 )
DIMMER AUTO :Dimmer turns on and off automatically when you turn off or
on the car headlights.
*1
DISPLAY SETTINGS
BRIGHTNESS Set the brightness for day and night separately.
1 DAY / NIGHT :Select day or night.
2 Select a zone. (See the illustration on the left column.)
3 LEVEL 00 to LEVEL 31 : Set the brightness level.
TEXT SCROLL
*2
SCROLL ONCE :Scrolls the display information once.;
SCROLL AUTO :Repeats scrolling at 5-second intervals.;
SCROLL OFF :Cancels.
*1
The illumination control wire connection is required. ( 16)
*2
Some characters or symbols will not be shown correctly (or will be blanked).
JS_JVC_KD_X252_E_EN_1.indd 11JS_JVC_KD_X252_E_EN_1.indd 11 20/6/2017 5:12:56 PM20/6/2017 5:12:56 PM

12 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Maintenance
Cleaning the unit
Wipe off dirt on the faceplate with a dry silicone or soft cloth.
Cleaning the connector
Detach the faceplate and clean the connector
gently with a cotton swab, being careful not to
damage the connector.
More information
For: – Latest firmware updates and latest compatible item list
– Any other latest information
Visit <http://www.jvc.net/cs/car/>.
Playable files
• For detailed information and notes about the playable audio files, visit
<http://www.jvc.net/cs/car/>.
• Playable audio file: MP3 (.mp3), WMA (.wma), WAV (.wav), FLAC (.flac)
• Playable USB device file system: FAT12, FAT16, FAT32
Even when audio files comply with the standards listed above, playback may be impossible
depending on the types or conditions of media or device.
About USB devices
• You cannot connect a USB device via a USB hub.
• Connecting a cable whose total length is longer than 5m may result in abnormal playback.
• This unit cannot recognize a USB device whose rating is other than 5V and exceeds 1A.
REFERENCES
About iPod/iPhone
Made for
– iPod touch (2nd, 3rd, 4th, 5th and 6th generation)
– iPod classic
– iPod nano (3rd, 4th, 5th, 6th and 7th generation)
– iPhone 3G, 3GS, 4, 4S, 5, 5S, 5C, 6, 6 Plus, 6S, 6S Plus, SE, 7, 7 Plus
• It is not possible to browse video files on the “Videos” menu in
[HEAD MODE] .
• The song order displayed on the selection menu of this unit may differ from that of the iPod/
iPhone.
• Depending on the version of the operating system of the iPod/iPhone, some functions may
not operate on this unit.
About Android device
• This unit supports Android OS 4.1 and above.
• Some Android devices (with OS4.1 and above) may not fully support Android Open Accessory
(AOA)2.0.
• If the Android device supports both mass storage class device and AOA2.0, this unit always
playback via AOA2.0 as priority.
Connector (on the reverse
side of the faceplate)
Available Cyrillic letters
Available characters
Display indications
JS_JVC_KD_X252_E_EN_1.indd 12JS_JVC_KD_X252_E_EN_1.indd 12 20/6/2017 5:12:56 PM20/6/2017 5:12:56 PM

ENGLISH 13
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
Change the display information
Each time you press , the display information changes.
• If the information is unavailable or not recorded, “NO TEXT”, “NO NAME”, or
other information (eg. station name) appears or display will be blank.
Source name Display information
FM
or AM Frequency Clock (back to the beginning)
(For FM Radio Data System stations only)
Station name (PS)/Program type (PTY) Radio text Radio
text+
Radio text+ title/Radio text+ artist Frequency
Clock (back to the beginning)
USB (For MP3/WMA/WAV/FLAC files)
Song title/Artist Album name/Artist Folder name
File name Playing time Clock (back to the
beginning)
iPod or
ANDROID
When [HEAD MODE] / [AUTO MODE] is selected (  6) :
Song title/Artist Album name/Artist Playing time
Clock (back to the beginning)
AUX AUX Clock (back to the beginning)
REFERENCES TROUBLESHOOTING
Symptom Remedy
General
Sound cannot be heard. • Adjust the volume to the optimum level.
• Check the cords and connections.
“MISWIRING CHECK WIRING
THEN PWR ON” appears.
Turn the power off, then check to be sure the terminals of the
speaker wires are insulated properly. Turn the power on again.
“PROTECTING SEND SERVICE”
appears.
Send the unit to the nearest service center.
Source cannot be selected.
Check the [SOURCE SELECT] setting. ( 4)
Radio
• Radio reception is poor.
• Static noise while listening
to the radio.
Connect the antenna firmly.
USB/iPod
Playback order is not as
intended.
The playback order is determined by the file name .
Elapsed playing time is not
correct.
This depends on the recording process earlier.
“NOT SUPPORT” appears and
file skips.
Check whether the file is a playable format. ( 12)
“READING” keeps flashing. • Do not use too many hierarchical levels and folders.
• Reattach the USB device.
“CANNOT PLAY” flashes and/
or connected device cannot
be detected.
• Check whether the connected device is compatible with this unit and
ensure the files are in supported formats.
( 12)
• Reattach the device.
The iPod/iPhone does not
turn on or does not work
• Check the connection between this unit and iPod/iPhone.
• Disconnect and reset the iPod/iPhone using hard reset.
Correct characters are not
displayed.
• This unit can only display uppercase letters, numbers, and a limited
number of symbols.
• Depending on the display language you have selected ( 4) ,
some characters may not be displayed correctly.
JS_JVC_KD_X252_E_EN_1.indd 13JS_JVC_KD_X252_E_EN_1.indd 13 20/6/2017 5:12:56 PM20/6/2017 5:12:56 PM

14 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
TROUBLESHOOTING INSTALLATION/CONNECTION
Warning
• The unit can only be used with a 12V DC power supply, negative ground.
• Disconnect the battery’s negative terminal before wiring and mounting.
• Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
• To prevent short circuit:
– Insulate unconnected wires with vinyl tape.
– Be sure to ground this unit to the car’s chassis again after installation.
– Secure the wires with cable clamps and wrap vinyl tape around the wires that comes into
contact with metal parts to protect the wires.
Caution
• For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
• Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during
and shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
• Do not connect the wires of speakers to the car chassis or Ground wire (black), or connect
them in parallel.
• Connect speakers with a maximum power of more than 50W. If the maximum power of
the speakers is lower than 50W, change the
[AMP GAIN] setting to avoid damaging the
speakers.
( 10)
• Mount the unit at an angle of less than 30º.
• If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red)
to the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned
on and off by the ignition key.
• Keep all cables away from heat dissipate metal parts.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
• If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old
fuse with one that has the same rating.
Symptom Remedy
ANDROID
• Sound cannot be heard
during playback.
• Sound output only from
the Android device.
• Reconnect the Android device.
• If in [AUDIO MODE] , launch any media player
application on the Android device and start playback.
• If in [AUDIO MODE] , relaunch the current media player
application or use another media player application.
• Restart the Android device.
• If this does not solve the problem, the connected
Android device is unable to route the audio signal to
unit.
( 12)
Cannot playback at
[AUTO MODE] .
• Make sure JVC MUSIC PLAY APP is installed on the
Android device.
( 5)
• Reconnect the Android device and select the appropriate
control mode.
( 6)
• If this does not solve the problem, the connected
Android device does not support
[AUTO MODE] .
( 12)
“NO DEVICE” or “READING”
keeps flashing.
• Switch off the developer options on the Android device.
• Reconnect the Android device.
• If this does not solve the problem, the connected
Android device does not support
[AUTO MODE] .
( 12)
Playback is intermittent or
sound skips.
Turn off the power saving mode on the Android device.
“CANNOT PLAY”
• Make sure Android device contains playable audio files.
• Reconnect the Android device.
• Restart the Android device.
If you still have troubles, reset the unit. ( 3)
JS_JVC_KD_X252_E_EN_1.indd 14JS_JVC_KD_X252_E_EN_1.indd 14 20/6/2017 5:12:56 PM20/6/2017 5:12:56 PM

ENGLISH 15
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION/CONNECTION
How to remove the unitWhen installing without the mounting
sleeve
1 Remove the mounting sleeve and trim plate from the
unit.
2 Align the holes in the unit (on both sides) with the
vehicle mounting bracket and secure the unit with
screws (commercially available).
Use only the specified screws. Using wrong screws might
damage the unit.
Installing the unit (in-dash mounting)
Do the required wiring.
( 16)
Bend the appropriate tabs to
hold the sleeve firmly in place.
Hook on the top side
Orientate the trim plate as
illustrated before fitting. Dashboard of your car
Part list for installation
(C) Mounting sleeve
(B) Trim plate
(D) Wiring harness
(E) Extraction key
(A) Faceplate
Basic procedure
1 Remove the key from the ignition switch, then disconnect
the
[ terminal of the car battery.
2 Connect the wires properly.
See Wiring connection.
( 16)
3 Install the unit to your car.
See Installing the unit (in-dash mounting).
4 Connect the terminal of the car battery.
5 Reset the unit. ( 3)
JS_JVC_KD_X252_E_EN_1.indd 15JS_JVC_KD_X252_E_EN_1.indd 15 20/6/2017 5:12:57 PM20/6/2017 5:12:57 PM

16 ENGLISH
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
When connecting to an external amplifier,
connect its ground wire to the car’s chassis to
avoid damaging the unit.
Wiring connection
Fuse (10A) Antenna terminal
Light blue/yellow
(Steering remote control
wire)
To the steering wheel remote control adapter
Yellow (A4)
Red (A7)
Yellow (Battery wire)
Pin Color and function
A4 Yellow : Battery
A5 Blue/White : Power control (12V 350mA)
A6 Orange/white : Car light control switch
A7 Red : Ignition (ACC)
A8 Black : Earth (ground) connection
B1 Purple
]
: Rear speaker (right)
B2 Purple/black
[
B3 Gray
]
: Front speaker (right)
B4 Gray/black
[
B5 White
]
: Front speaker (left)
B6 White/black
[
B7 Green
]
: Rear speaker (left)
*
B8 Green/black
[
*
You can also connect a subwoofer speaker directly without an external
subwoofer amplifier. For setting, 10.
Unit
Connecting the ISO connectors on some VW/
Audi or Opel (Vauxhall) automobiles
You may need to modify the wiring of the supplied
wiring harness as illustrated below.
Vehicle
A7 (Red)
Ignition wire
(Red)
A4 (Yellow)
Default wiring
Battery wire
(Yellow)
ISO connectors
If your car does not have an ISO terminal
We recommend installing the unit with a commercially
available custom wiring harness specific for your car and
leave this job to professionals for your safety. Consult
your car audio dealer.
INSTALLATION/CONNECTION
Rear/subwoofer output
Red (Ignition wire)
JS_JVC_KD_X252_E_EN_1.indd 16JS_JVC_KD_X252_E_EN_1.indd 16 21/6/2017 10:41:50 AM21/6/2017 10:41:50 AM
