JVC Model KD-ABT22J User manual

ENGLISHESPAÑOLFRANÇAIS
CD RECEIVER KD-ABT22
RECEPTOR CON CD KD-ABT22
RÉCEPTEUR CD KD-ABT22
For canceling the display demonstration, see page 5.
Para cancelar la demostración en pantalla, consulte la página 5.
Pour annuler la démonstration des affichages, référez-vous à la page 5.
For installation and connections, refer to the separate manual.
Para la instalación y las cone iones, refiérase al manual separado.
Pour l’installation et les raccordements, se référer au manuel séparé.
INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MANUEL D’INSTRUCTIONS
GET0527-001A
[J]
For customer Use:
Enter below the Model
No. and Serial No. which
are located on the top or
bottom of the cabinet. Retain
this information for future
reference.
Model No.
Serial No.
Cover_KD-ABT22[J]3.indd 1Cover_KD-ABT22[J]3.indd 1 12/11/07 1:45:54 PM12/11/07 1:45:54 PM

ENGLISH
2
Thank you for purchasing a JVC product.
Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best
possible performance from the unit.
INFORMATION (For U.S.A.)
This equipment has been tested and found to comply with the limits for a Class B digital de ice, pursuant to Part
15 of the FCC Rules. These limits are designed to pro ide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Howe er, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or tele ision reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the recei ing antenna.
– Increase the separation between the equipment and recei er.
– Connect the equipment into an outlet on a circuit different from that to which the recei er is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Caution:
Changes or modifications not appro ed by JVC could oid the user’s authority to operate the equipment.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. CAUTION: Do not open the top co er. There are no user ser iceable parts inside the unit; lea e all ser icing to
qualified ser ice personnel.
3. CAUTION: (For U.S.A.) Visible and/or in isible class II laser radiation when open. Do not stare into beam.
(For Canada) Visible and/or in isible class 1M laser radiation when open. Do not iew directly with
optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED OUTSIDE THE UNIT.
[European Union only]
This unit is equipped with the steering wheel
remote control function.
• See the Installation/Connection Manual (separate
olume) for connection.
EN02-07_KD-ABT22[J]3.indd 2EN02-07_KD-ABT22[J]3.indd 2 12/11/07 1:43:59 PM12/11/07 1:43:59 PM

ENGLISH
3
How to reset our unit
• Your preset adjustments will also be erased (except the
registered Bluetooth device, see pages 13 and 14).
How to forcibl eject a disc
“Please Eject” appears on the display.
• Be care ul not to drop the disc when it ejects.
• I this does not work, reset your unit.
For safet ...
• Do not raise the olume le el too much, as this will
block outside sounds, making dri ing dangerous.
• Stop the car before performing any complicated
operations.
Temperature inside the car...
If you ha e parked the car for a long time in hot or cold
weather, wait until the temperature in the car becomes
normal before operating the unit.
CONTENTS
INTRODUCTIONS
Preparation .................................................. 5
OPERATIONS
Basic operations ........................................... 6
• Using the control panel ............................... 6
• Using the remote controller (RM-RK50) ...... 7
Listening to the radio ................................... 8
Disc operations ............................................. 10
Listening to the USB de ice .......................... 12
Using the Bluetooth
® de ices ....................... 13
• Using the Bluetooth cellular phone ............ 15
• Using the Bluetooth audio player ............... 18
EXTERNAL DEVICES
Listening to the HD Radio ™ Broadcast ......... 19
Listening to the CD changer ......................... 20
Listening to the satellite radio ..................... 21
Listening to the iPod .................................... 24
Listening to the other external
components .............................................. 27
SETTINGS
Selecting a preset sound mode .................... 28
General settings — PSM .............................. 31
Bluetooth settings ....................................... 36
Title assignment .......................................... 37
REFERENCES
More about this unit .................................... 38
Troubleshooting ........................................... 43
Maintenance ................................................ 49
Specifications ............................................... 50
EN02-07_KD-ABT22[J]3.indd 3EN02-07_KD-ABT22[J]3.indd 3 12/11/07 1:44:01 PM12/11/07 1:44:01 PM

ENGLISH
4
Detaching the control panel
Attaching the control panel
Caution:
If the temperature inside the car is below 32°F (0°C),
the movement of animation and text scroll will be
halted on the displa to prevent the displa from being
blurred. appears on the displa .
When the temperature increases, and the operating
temperature is resumed, these functions will start
working again.
Warning:
If ou need to operate the unit while driving, be sure to
look around carefull or ou ma be involved in a traffic
accident.
Caution on volume setting:
Digital devices (CD/USB) produce ver little noise
compared with other sources. Lower the volume before
pla ing these digital sources to avoid damaging the
speakers b sudden increase of the output level.
How to use the M MODE and SEL
buttons
If ou use M MODE or SEL (select), the displa and some
controls (such as the number buttons,
4 /¢ buttons, 5/∞ buttons, and the
control dial) enter the corresponding control mode.
Ex.: When ou press number button 1 after pressing
M MODE, to operate the FM tuner.
To use these controls for original functions, press
M MODE again.
• However, pressing SEL makes the unit enters a
different mode.
• Waiting for about 15 seconds without pressing an of
these buttons will automaticall cancels the control.
Avoid touching the connectors.
EN02-07_KD-ABT22[J]f.indd 4EN02-07_KD-ABT22[J]f.indd 4 1/2/08 9:47:47 AM1/2/08 9:47:47 AM

ENGLISH
5INTRODUCTIONS
Preparation
Cancel the displa demonstration and set the clock
• See also pages 31 and 32.
1Turn on the power.
2Enter the PSM settings.
3Cancel the displa demonstrations
Select “Demo,” then “Off.”
Set the clock
Select “Clock Hr” (hour), then adjust the hour.
Select “Clock Min” (minute), then adjust the minute.
Select “24H/12H,” then “24Hours” or “12Hours.”
4Finish the procedure.
Changing the displa information and pattern
When the power is turned off: Check the current clock time
Ex.: When tuner is selected as the source
Source operation display
• If a station has been assigned a title, station
title appears after about 5 seconds.
• To assign a title to a station, see page 37.
Audio le el meter display
(see “Le elMeter” on page 31)
EN02-07_KD-ABT22[J]3.indd 5EN02-07_KD-ABT22[J]3.indd 5 12/11/07 1:44:03 PM12/11/07 1:44:03 PM

ENGLISH
6
Basic operations
Using the control panel
• Select the source [Press] .
TUNER *1/HD RADIO *2 = SIRIUS *2/XM *2 =
CD *2 = USB *2 (or USB-i od) *2 = CD-CH *2/
i od *2 (or EXT IN) = BT-AUDIO = AUX IN
= (back to the beginning)
9 • Select/adjust the sound mode.
• Enter the PSM settings [Hold].
p • TUNER/SIRIUS/XM: Select reset station/
channel.
• CD/USB/CD-CH: Select folder/track/disc (for CD
changer).
• USB-i od: Select reset to menu items.
• Bluetooth: Dial reset hone number *3.
q • Enter functions mode.
• Bluetooth: Activate Voice Dialing [Hold].
w Change the dis lay information and attern.
e • TUNER: Select the bands.
• USB-i od: Start/ ause layback.
• BT-AUDIO: Start/ ause layback.
*1 When the HD Radio tuner box is connected, the
built-in tuner of this unit will be disable. To listen
to the HD Radio broadcast, refer to “Listening to the
radio” on age 8. For more features, see ages 19 and
20.
*2 You cannot select these sources if they are not ready
or not connected.
*3 For storing reset hone number, see age 17.
1 • TUNER: Select reset station.
• HD RADIO: Select channel.
• SIRIUS/XM: Select category.
• CD/USB/CD-CH: Select folder.
• USB-i od: Enter the main menu [Hold].
• i od: Enter the main menu/Pause layback/
Confirm selection.
2 • Turn on the ower.
• Turn off the ower [Hold].
• Attenuate the sound (if the ower is on).
• Bluetooth: Switch the conversation media
during a hone call conversation.
3 Dis lay window
4 • Enter/exit Bluetooth menu.
• Dis lay the dialed list [Hold].
5 Fli down the control anel.
• To eject the disc, fli down the control anel
then ress 0 on the unit.
6 AUX (auxiliary) in ut jack
7 • TUNER/HD RADIO/SIRIUS/XM: Search for
station/channel.
• CD/USB/CD-CH/USB-i od/i od: Select track.
• BT-AUDIO: Reverse ski /forward ski .
8 • Volume control [Turn].
EN02-07_KD-ABT22[J]f.indd 6EN02-07_KD-ABT22[J]f.indd 6 1/2/08 9:48:45 AM1/2/08 9:48:45 AM

ENGLISH
7OPERATIONS
Installing the lithium coin battery (CR2025)
Caution:
Battery shall not be exposed to excessive heat such as
sunshine, fire, or the like.
If the effectiveness of the remote controller
decreases, replace the battery
Before using the remote controller:
• Aim the remote controller directly at the remote
sensor on the unit.
• DO NOT expose the remote sensor to bri ht li ht
(direct sunli ht or artificial li htin ).
Warning (to prevent accidents and damage):
• Do not install any battery other than CR2025 or its
equivalent.
• Do not leave the remote controller in a place (such as
dashboards) exposed to direct sunli ht for a lon time.
• Store the battery in a place where children cannot
reach.
• Do not rechar e, short, disassemble, heat the battery,
or dispose of it in a fire.
• Do not leave the battery with other metallic
materials.
• Do not poke the battery with tweezers or similar tools.
• Wrap the battery with tape and insulate when
throwin away or savin it.
Using the remote controller (RM-RK50)
Remote sensor
For USA-California Only:
This product contains a CR Coin Cell Lithium Battery
which contains Perchlorate Material—special
handlin may apply.
See www.dtsc.ca. ov/hazardouswaste/perchlorate
1 • Turns the power on if pressed briefly or
attenuates the sound when the power is on.
• Turns the power off if pressed and held.
• Switches the conversation media durin a phone
call conversation.
2 • Chan es the FM/AM bands with 5 U.
• Chan es the preset stations with D ∞.
• Chan es the folder of the MP3/WMA/AAC/WAV.
• While playin an MP3 disc on an
MP3-compatible CD chan er:
– Chan es the disc if pressed briefly.
– Chan es the folder if pressed and held.
• While listenin to the satellite (SIRIUS or XM)
radio:
– Chan es the cate ories.
• While listenin to an Apple iPod:
Connected to KS-PD100:
– Pauses or resumes playback with D ∞.
– Enters the main menu with 5 U.
(Now 5 U/D ∞/2 R/F 3 work as the menu
selectin buttons.)*
* 5 U : Returns to the previous menu.
D ∞ : Confirms the selection.
Connected to the USB cable:
– Enter the main menu if pressed and held.
– Select the desired menu if pressed briefly.
– Fast skip in every layer of the main menu if
pressed and held. Continued on the next page
EN02-07_KD-ABT22[J]f.indd 7EN02-07_KD-ABT22[J]f.indd 7 1/2/08 3:12:47 PM1/2/08 3:12:47 PM

ENGLISH
8
Listening to the radio
1Select “TUNER.”
2Select the bands.
3Search for a station to listen—Auto Search.
Manual Search: Hold either one of the buttons until “M” lights up on the display, then
press it repeatedly.
• When receiving an FM stereo broadcast ith sufficient signal strength, lights up
on the display.
3 Adjusts the volume level.
4 Selects the sound mode (iEQ: intelligent equalizer).
5 Selects the source.
6 For Bluetooth cellular phone:
– Ans ers calls if pressed briefly.
– Rejects calls if pressed and held.
– Holds calls if pressed briefly during phone call
conversation.
7 • Searches for stations if pressed briefly.
• Fast-for ards or reverses the track if pressed and
held.
• Changes the tracks if pressed briefly.
3 Exit from the setting.
• While listening to the satellite (SIRIUS or XM)
radio:
– Changes the channels if pressed briefly.
– Changes the channels rapidly if pressed and
held.
• While listening to an iPod (in menu selecting
mode):
Connected to S-PD100:
– Selects an item if pressed briefly. (Then, press
D ∞ to confirm the selection.)
– Skips 10 items at a time if pressed and held.
Connected to the USB cable:
– Start play back the selected folder directly if
pressed and held.
• Reverse skip/for ard skip for Bluetooth audio.
When an FM stereo broadcast is
hard to receive
1
2
Reception improves, but stereo effect ill be lost.
• lights up on the display.
EN08-17_KD-ABT22[J]5.indd 8EN08-17_KD-ABT22[J]5.indd 8 12/18/07 9:25:27 AM12/18/07 9:25:27 AM

ENGLISH
9OPERATIONS
FM station automatic presetting
— SSM (Strong-station Sequential
Memory)
You can preset up to six stations for each band.
1 While listening to a station...
2
3
Local FM stations ith the strongest signals are
searched and stored automatically in the selected
FM band.
• If an HD Radio tuner box is connected, you
can also search and store the AM station
automatically.
Manual presetting
Ex.: Storing FM station of 92.5 MHz into preset number
4 of the FM1 band.
Using the number buttons
1
2
3
Using the Preset Station list
• When is sho n on the display, you can
move back to the previous screen by pressing number
button 3.
1 Follow steps 1 and 2 of “Using the number
buttons” on the left column.
• By holding 5 / ∞, the Preset Station List ill
also appear (go to step 4).
2
3 Display the Preset Station List.
4 Select the preset number you want to store
into.
• You can move to the lists of the other FM bands
by pressing number button 5 ( ) or
6 ( ) repeatedly.
5 Store the station.
Preset number flashes for a hile.
Continued on the next page
EN08-17_KD-ABT22[J]3.indd 9EN08-17_KD-ABT22[J]3.indd 9 12/11/07 1:43:38 PM12/11/07 1:43:38 PM

ENGLISH
10
Prohibiting disc ejection
To cancel the prohibition, repeat the same
procedure.
Listening to the preset station on the Preset Station List
1 Display the Preset Station List, then select the preset station you want to listen to.
2 Change to the selected station.
*1
Disc operations
All tracks ill be played repeatedly until you change the
source or eject the disc.
To stop play and eject the disc
• Press SOURCE to listen to another playback source.
Pressing (or holding) the follo ing buttons allo s you
to...
[Press] Select track
[Hold] Reverse/fast-for ard
track
MP3/WMA/AAC: Select folder
(Number buttons) *2
Locate particular folder *3
(for MP3/WMA/AAC) or track
directly
*1 By holding either one of the buttons, you can display
the Folder List (see page 11).
*2 Press to select number 1 to ; hold to select number
7 to 12.
*3 It is required that folders be assigned with 2-digit
numbers at the beginning of their folder names—01,
02, 03, and so on.
EN08-17_KD-ABT22[J]3.indd 10EN08-17_KD-ABT22[J]3.indd 10 12/11/07 1:43:39 PM12/11/07 1:43:39 PM
