SERVICE MANUAL
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
No.A0008B
2002/11
XV-M50BK
DVD VIDEO PLAYER
A0008B200211
XV-M50BK
TABLE OF CONTENTS
1 Description of major ICs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Block diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Area Suffix
J ------------- U.S.A.
C ---------- Canada
Because service manual XV-M50BK (Issue No.A0008)
which has already been issued contains some mistakes,
the following pages are modified in this service manual.
< Modified pages >
*Description of major ICs
*Block diagrams
Refer to the service manual XV-M50BK (Issue No. A0008)
which has already been issued for other pages.
Supplement

XV-M50BK
2
SECTION 1
Description of major ICs
1.1 AK93C65AF-X (IC403) : EEPROM
• Pin layout
• Block diagram
• Pin function
NOTE :
The pull-up resistor of the PE pin is about 2.5Mohm (VCC=5V)
Pin no. Symbol Function
1 PE Program enable (With built-in pull-up resistor)
2 VCC Power supply
3 CS Chip selection
4 SK Cereal clock input
5 DI Cereal data input
6 DO Cereal data output
7 GND Ground
8 NC No connection

XV-M50BK
3
1.2 AN8702FH(IC101):Frontend processor
• Pin layout
• Pin function
Pin No. Symbol I/O Description
1 PC1 I Input for Laser current monitor
2 PC01 O Laser power control output for DVD
3 PC2 I Photo detector fo CD
4 PC02 O Laser power control output for CD
5 TGBAL I Tangential phase balance control terminal
6 TBAL I Tracking balance control terminal
7 FBAL I Focus balance control ter
8 POFLT O Track detection threshold level terminal
9 DTRD I Data slice part data read signal input terminal (For RAM)
10 IDGT I Data slice part address part gate signal input terminal (For RAM)
11 STANDBY I Standby mode control terminal
12 SEN I SEN(Serial data input terminal)
13 SCK I SCK(Serial data input terminal)
14 STDI I STDI(Serial data input terminal)
15 RSEL I DVD and CD selection
16 JLINE I J-line setting output (FEP)
17 TEN I Tracking error output amplifier reversing input terminal
18 TEOUT O Tracking error signal output terminal
19 ASN I Off set adjustment terminal for DRC
20 ASOUT O All added signal output terminal
21 FEN I Focus error output amplifier reversing input terminal
22 FEOUT O Focus error signal output terminal
23 VSS - Connect to GND
24 TG O Tangential phase error signal output terminal
25 VDD - Power supply terminal 3V
26 GND2 - Connect to GND
27 VREF2 O VREF2 voltage output terminal
28 VCC2 - Power supply terminal 5V
29 VHALF O VHALF voltage output terminal
30 DFLTON O Filter amplifier reversing output terminal
31 DFLTOP O Filter amplifier output terminal
32 DSFLT O Connected capacitor terminal for filter output
33 GND3 - Connect to GND
34 RFDIFO O RF operation output terminal
35 RFOUT O RF output terminal
36 VCC3 - Power supply terminal 5V
37 RFC I Filter for RF amplifier

XV-M50BK
4
38 DCRF O All addition amplifier capacitor terminal
39 OFTR O OFTR output teminalr
40 BDO O BDO output terminal
41 RFENV O RF envelope output terminal
42 BTTOM O Bottom envelope detection filter terminal
43 PEAK O Peak envelope detection filter terminal
44 AGCG O AGC amplifier gain control teminalr
45 AGCO O AGC amplifier level control terminal
46 TESTSG I TEST signal input terminal
47 RFINP I RF signal positive input terminal
48 RFINN I RF signal negative input terminal
49 VIN5 I RF input of external division into 4 terminal for CD
50 VIN6 I RF input of external division into 4 terminal for CD
51 VIN7 I RF input of external division into 4 terminal for CD
52 VIN8 I RF input of external division into 4 terminal for CD
53 VIN9 I RF input of external division into 2 terminal for DVD
54 VIN10 I RF input of external division into 2 terminal for DVD
55 VCC1 - Power supply terminal 5V
56 VREF1 O VREF1 voltage output terminal
57 VIN1 I External division into four (DVD/CD) RF input terminal1
58 VIN2 I External division into four (DVD/CD) RF input terminal2
59 VIN3 I External division into four (DVD/CD) RF input terminal3
60 VIN4 I External division into four (DVD/CD) RF input terminal4
61 GND1 - Connect to GND
62 VIN11 I 3 beem sub input terminal for CD
63 VIN12 I 3 beem sub input terminal for CD
64 HDTYPE I HD type switching
Pin No. Symbol I/O Description

XV-M50BK
5
1.3 HY57V161610DTC8(IC504,IC505) : 16MB SDRAM
• Block diagram
• Pin function
Pin No. Symbol Description
1 VCC Power supply
2,3 DQ0,1 Data input/output
4 VSS Connect to GND
5,6 DQ2,3 Data input/output
7 VDD Power supply
8,9 DQ4,5 Data input/output
10 VSS Connect to GND
11,12 DQ6,7 Data input/output
13 VCC Power supply
14 LDQM Lower DQ mask enable
15 WE Write enable
16 CAS Column address strobe
17 RAS Row address strobe
18 CS Chip enable
19,20 A11,10 Address inputs
21~24 A0~3 Address inputs
25 VCC Power supply
26 VSS Connect to GND
27~32 A4~9 Address inputs
33 NC Non connect
34 CKE Clock enable
35 CLK System clock input
36 UDQM Upper DQ mask enable
37 NC Non connect
38 VCC Power supply
39,40 DQ8,9 Data input/output
41 VSS Connect to GND
42,43 DQ10,11 Data input/output
44 VDD Power supply
45,46 DQ12,13 Data input/output
47 VSS Connect to GND
48,49 DQ14,15 Data input/output
50 VSS Connect to GND

XV-M50BK
6
1.4 M35500AFP(IC802) : FL Driver
• Pin layout
• Pin function
Pin No. Symbol I/O Description
1 VDD - Power supply terminal
2 XOUT O The short-circuit is made and the capacitor is connected with XIN on the outside
3 VSS - Connect to ground
4 XIN I The short-circuit is made and the capacitor is connected with XOUT on the outside
5 RESET I Reset input L:Reset
6~11 AIN5~0 I Key control signal input
12 CS I Chip select input L:The serial transfer is possible
13 SIN I Serial data input
14 SOUT O Serial data output
15 SCLK I Clock input of serial transfer
16,17 VEE - The voltage supplied to the pull down resistance is impressed
18~20 DISC3~1 IND O Indicator control signal output of disc indicator 1~3
21,22 NC - Not use
23~29 7G~1G O FL Grid control signal output
30~43 S14~S1 O FL Segment control signal output
44 VDD - Power supply terminal

XV-M50BK
7
1.5 M56788FP-W (IC271) : Traverse mechanism driver
• Terminal Layout
• Block diagram

XV-M50BK
8
1.6 MN101C49GGJ1(IC701): System controller
• Terminal layout
• Pinfunction
Pin No. Symbol I/O Function
1 GND - Connect to ground
2 NC - No connect
3 NC - No connect
4 NC - No connect
5 NTSEL I NTSC/PAL selection
6 POWER SW I Power switch detect terminal
7 SHUT1 - Connect to VDD
8 KEY1-5 - Connect to VDD
9 KEY6-10 - Connect to VDD
10 VREF+ I Reference voltage
11 VDD I Power supply
12 OSC2 O External terminal for connected oscirator
13 OSC1 I External terminal for connected oscirator
14 VSS - Connect to ground
15 XI - Connect to ground
16 XO - No connect
17 MMOD - Connect to ground
18 DADATA I/O Data bus for DAC
19 DACSO O Serial bus output for DAC
20 DACK I/O Clock for DAC
21 S2UDT O Communication between unit microcomputers DATA output
22 U2SDT I Communication between unit microcomputers DATA output
23 SCLK I/O Serial clock bus
24 BUSY I/O Busy bus
25 CPURST O Unit microcomputer reset
26 REQ I Commnication between unit microcomputers REQ
27 REMO I Remote control interrruption
28 - Non connect
29 - Non connect
30 - Connect to ground
31 - Connect to ground
32 - Connect to ground
33 RESET I DVD reset
34 - No connect
35 - No connect
36 VCD - No connect
37 OSDCK - No connect
38 NT - No connect
39 FS2 - No connect

XV-M50BK
9
40 CHREQ I Changer commnication REQUEST
41 CHST O Changer commnication STROBE
42 CHDATA O Changer commnication DATA I/O
43 - No connect
44 CHCK I Channel clock
45 FLDATAO O Serial data output
46 FLDATAI I Serial data input
47 FLCK O Clock output of serial transfer
48 FLCS O Chip select output
49 FLRST O Reset output
50 EEDO O Data output to EEPROM
51 EEDI I Data input from EEPROM
52 EECK O Clock signal output to EEPROM
53 EECS O Chip select output to EEPROM
54 VS1 O Fanction SW control
55 VS3 O Fanction SW control
56 DMUT1 - No connect
57 DMUT2 - No connect
58 PDB2 - No connect
59 PDB1 - No connect
60 DEMP2 - No connect
61 DEMP1 - No connect
62 DENA - No connect
63 KARAOKE O KARAOKE Mode switching terminal
64 POWER ON O Power on control output
65 VS2 - No connect
66 - No connect
67 - No connect
68 - No connect
69 - No connect
70 - No connect
71 - No connect
72 - No connect
73 - No connect
74 - No connect
75 - No connect
76 - No connect
77 AVCI I AV compulink signal input
78 AVCO O AV compulink signal output
79 RGB O RGB select control signal output
80 STDIND O Standby LED control signal output
81 - No connect
82 - No connect
83 - No connect
84 - No connect
85 - No connect
86 CS4 - No connect
87 MA - No connect
Pin No. Symbol I/O Function

XV-M50BK
10
88 MB - No connect
89 M1M3 - No connect
90 MD - No connect
91 MC - No connect
92 GAIN2 - No connect
93 GAIN1 - No connect
94 HPMUT - No connect
95 DAVSS - No connect
96 LMUTE - No connect
97 CMUTE - No connect
98 SMUTE - No connect
99 MUTE O Muting control signal output
100 DAVDD - Power supply terminal
Pin No. Symbol I/O Function

XV-M50BK
11
1.7 MN102L62GGP (IC401) : Unit CPU
PinNo. Symbol I/O Function
1 WAIT I Micon wait signal input
2 RE O Read enable
3 SPMUTE O Spindle muting output to IC251
4 WEN O Write enable
5CS0-Notuse
6 CS1 O Chip select for ODC
7 CS2 O Chip select for ZIVA
8 CS3 O Chip select for outer ROM
9 DRVMUTE O Driver mute
10 SPKICK - Non connect
11 LSIRST O LSI reset
12 WORD I Bus selection input
13 A0 O Address bus 0 for CPU
14 A1 O Address bus 1 for CPU
15 A2 O Address bus 2 for CPU
16 A3 O Address bus 3 for CPU
17 VDD - Power supply
18 SYSCLK - Non connect
19 VSS - Ground
20 XI - Not use (Connect to vss)
21 XO - Non connect
22 VDD - Power supply
23 OSCI I Clock signal input(13.5MHz)
24 OSCO O Clock signal output(13.5MHz)
25 MODE I CPU Mode selection input
26 A4 O Address bus 4 for CPU
27 A5 O Address bus 5 for CPU
28 A6 O Address bus 6 for CPU
29 A7 O Address bus 7 for CPU
30 A8 O Address bus 8 for CPU
31 A9 O Address bus 9 for CPU
32 A10 O Address bus 10 for CPU
33 A11 O Address bus 11 for CPU
34 VDD - Power supply
35 A12 O Address bus 12 for CPU
36 A13 O Address bus 13 for CPU
37 A14 O Address bus 14 for CPU
38 A15 O Address bus 15 for CPU
39 A16 O Address bus 16 for CPU
40 A17 O Address bus 17 for CPU
41 A18 O Address bus 18 for CPU
42 A19 O Address bus 19 for CPU
43 VSS - Ground
44 A20 O Address bus 20 for CPU
45 TXSEL O TX Select
46 HAGUP O Connect to pick-up
47 CD/DVD I CD/DVD Detect signal
48 ADPD O Power down control signal to IC511
49 HMFON O HFM Control output to IC102
50 TRVSW I Detection switch of traverse inside
51 FGIN I Focus gain input
52 TRS
53 ADSCEN O Servo DSC serial I/F chip select
54 VDD - Power supply
55 FEPEN O Serial enable signal for FEP
56 SLEEP O Standby signal for FEP
57 BUSY I Communication busy
58 REQ O Communication request
59 CIRCEN O CIRC serial I/F chip select
60 HSSEEK
61 VSS - Ground
62 EPCS O EEPROM chip select
63 EPSK O EEPROM clock
64 EPDI I EEPROM data input
65 EPDO O EEPROM data output
66 VDD - Power supply
67 SCLKO O Communication clock
68 S2UDT I Communication input data
69 U2SDT O Communication output data
70 CPSCK O Clock for ADSC serial
71 SDIN I ADSC serial data input
72 SDOUT O ADSC serial data output
73 - I Not use (Pull up)
74 - I Not use (Pull up)
75 NMI I NMI Terminal
76 ADSCIRQ I Interrupt input of ADSC
77 ODCIRQ I Interrupt input of ODC
78 DECIRQ I Interrupt input of ZIVA
79 WAKEUP - Connect to ground
80 ODCIRQ2 I Interruption of system control
81 ADSEP I Address data selection input
82 RST I Reset input
83 VDD - Power supply
84 TEST1 I Test signal 1 input
85 TEST2 I Test signal 2 input
86 TEST3 I Test signal 3 input
87 TEST4 I Test signal 4 input
88 TEST5 I Test signal 5 input
89 TEST6 I Test signal 6 input
90 TEST7 I Test signal 7 input
91 TEST8 I Test signal 8 input
92 VSS - Ground
93 D0 I/O Data bus 0 of CPU
94 D1 I/O Data bus 1 of CPU
95 D2 I/O Data bus 2 of CPU
96 D3 I/O Data bus 3 of CPU
97 D4 I/O Data bus 4 of CPU
98 D5 I/O Data bus 5 of CPU
99 D6 I/O Data bus 6 of CPU
100 D7 I/O Data bus 7 of CPU
PinNo. Symbol I/O Function

XV-M50BK
12
1.8 MN103S13BDA(IC301):Optical disc controller
• Pin layout
• Block diagram

XV-M50BK
13
• Pin function
PinNo. Symbol I/O Description
1 HDD15 I/O ATAPI Data
2 HDD0 I/O ATAPI Data
3 HDD14 I/O ATAPI Data
4 VDD - Power supply 3V
5 HDD1 I/O ATAPI Data
6 HDD13 I/O ATAPI Data
7 HDD2 I/O ATAPI Data
8 VSS - Connect to GND
9 HDD12 I/O ATAPI Data
10 VDD - Power supply 2.7V
11 HDD3 I/O ATAPI Data
12 HDD11 I/O ATAPI Data
13 HDD4 I/O ATAPI Data
14 HDD10 I/O ATAPI Data
15 VDD - Power supply 3V
16 HDD5 I/O ATAPI Data
17 HDD9 I/O ATAPI Data
18 VSS - Connect to GND
19 HDD6 I/O ATAPI Data
20 HDD8 I/O ATAPI Data
21 HDD7 I/O ATAPI Data
22 VDDH
23 NRESET I ATAPI Reset input
24 MASTER I/O ATAPI Master/slave select
25 NINT0 O Interruption of system control 0
26 NINT1 O Interruption of system control 1
27 WAITDOC O Wait control of system control
28 NMRST O Reset of system control (Connect to TP302)
29 DASPST I Setting of initial value of DASP signal
30 VDD - Power supply 3V
31 OSCO2 O Non connect
32 OSCI2 I Non connect
33 UATASEL I Connect to VSS
34 VSS - Connect to GND
35 PVSSDRAM Connect to VSS
36 PVDDDRAM Connect to VDD(2.7V)
37 CPUADR17 I System control address
38 CPUADR16 I System control address
39 VSS - Connect to GND
40 CPUADR15 I System control address
41 CPUADR14 I System control address
42 CPUADR13 I System control address
43 CPUADR12 I System control address
44 VDD - Power supply 2.7V
45 CPUADR11 I System control address
46 CPUADR10 I System control address
47 CPUADR9 I System control address
48 CPUADR8 I System control address

XV-M50BK
14
49 CPUADR7 I System control address
50 CPUADR6 I System control address
51 CPUADR5 I System control address
52 CPUADR4 I System control address
53 CPUADR3 I System control address
54 CPUADR2 I System control address
55 CPUADR1 I System control address
56 VSS - Connect to GND
57 CPUADR0 I System control address
58 NCS I System control chip select
59 NWR I Writing system control
60 NRD I Reading system control
61 VDD - Power supply 3V
62 CPUDT7 I/O System control data
63 CPUDT6 I/O System control data
64 PVPPDRAM O Connect to VSS
65 PTESTDRAM I Connect to VSS
66 PVDDDRAM Connect to VDD(2.7V)
67 PVSSDRAM Connect to VSS
68 CPUDT5 I/O System control data
69 CPUDT4 I/O System control data
70 CPUDT3 I/O System control data
71 VSS - Connect to GND
72 CPUDT2 I/O System control data
73 CPUDT1 I/O System control data
74 CPUDT0 I/O System control data
75 CLKOUT1 O Clock signal output (16.9/11.2/8.45MHz)
76 VDD - Power supply 3V
77 TEHLD O Mirror gate (Connect to TP141)
78 DTRD O Data frequency control switch (Connect to TP304)
79 IDGT O CAPA switch
80 BDO I RF Dropout/BCA data
81 CPDET2 I Outer capacity detection
82 CPDET1 I Inner capacity detection
83 VSS - Connect to GND
84 MMOD I Connect to VSS
85 NRST I System reset
86 VDD - Power supply 3V
87 CLKOUT2 O Clock 16.9MHz
88 SBCK/PLLOK O Flame mark detection
89 IDOHOLD O ID gate for tracking holding
90 JMPINH O Jump prohibition
91 LG O Land/group switch
92 NTRON I Tracking ON
93 DACDATA O Serial data output (Connect to TP148)
94 DACLRCK O Identification signal of L and R (Connect to TP149)
95 DACCLK I Clock for serial data output
96 IPFLAG I Input of IP flag
PinNo. Symbol I/O Description

XV-M50BK
15
97 BLKCK I Sub code/block/input clock
98 LRCK I Identification signal of L and R (Connect to VSS)
99 VSS - Connect to GND
100 OSCI1 I Oscillation input terminal 16.9MHz
101 OSCO1 O Oscillation output terminal 16.9MHz
102 VDD - Power supply 3V
103 PVSS - Connect to GND
104 PVDD - Power supply 3V
105 P1 I/O Terminal master polarity switch input
106 P0 I/O CIRC-RAM,OVER/UNDER Interruption
107 VSS - Connect to GND
108 SBCK O Clock output for sub code,serial input
109 SUBC I Sub code,serial input
110 NCLDCK I Sub code,flame clock input
111 CHCK40 I Clock is read to D
112 DAT3 I AT3~0 (Output of division frequency from ADSC)
113 DAT2 I Data is read from disc (Going side by side output from ADSC)
114 DAT1 I Data is read from disc (Going side by side output from ADSC)
115 DAT0 I Data is read from disc (Going side by side output from ADSC)
116 VDD - Data is read from disc (Going side by side output from ADSC)
117 SCLOCK I/O Power supply 3V
118 SDATA I/O Debug serial clock (270 ohm pull up)
119 MONI3 O Debug serial data (270 ohm pull up)
120 MONI2 O Internal good title monitor (Connect to TP150)
121 MONI1 O Internal good title monitor (Connect to TP151)
122 MONI0 O Internal good title monitor (Connect to TP152)
123 VSS - Internal good title monitor (Connect to TP153)
124 NEJECT I Connect to GNDEject detection
125 VDD - Power supply 2.7V
126 NTRYCL I Non connect (Tray close detection)
127 NDASP I/O ATAPI drive active / slave connect I/O
128 NCS3FX I Non connect (ATAPI host chip select)
129 NCS1FX I Non connect (ATAPI host chip select)
130 VDD - Power supply 3V
131 DA2 I/O ATAPI host address
132 DA0 I/O Non connect (ATAPI host address)
133 NPDIAG I/O ATAPI Slave master diagnosis input
134 VSS - Connect to GND
135 DA1 I/O Non connect (ATAPI host address)
136 NIOCS16 O Output of selection of width of ATAPI host data bus
137 INTRQ O ATAPI Host interruption output
138 VDD - Power supply 3V
139 NDMACK I Non connect (ATAPI Host DMA characteristic)
140 IORDY O ATAPI Host ready output (Connect to TP157)
141 NIORD I Non connect (ATAPI host read)
142 VSS - Connect to GND
143 NIOWR I/O ATAPI Host writeAT
144 DMARQ O API Host DMA request (Connect to TP159)
PinNo. Symbol I/O Description

XV-M50BK
16
1.9 MN35505-X (IC703) : DAC
• Terminal layout
• Pin function
Pin No. Symbol I/O Description
1 M5 I Control signal for DAC
2 DIN I Digital data input
3 LRCK I L and R clock for DAC
4 BCK I Bit clock for DAC
5 M3 I Control signal for DAC
6 DVDD2 - Power supply terminal
7 CKO - Non connect
8 DVSS2 - Connect to ground
9 M2 I Control signal for DAC
10 M1 I Control signal for DAC
11 OUT1C O Analog output 1
12 AVDD1 - Power supply terminal
13 OUT1D O Analog output 1
14 AVSS1 - Connect to ground
15 AVSS2 - Connect to ground
16 OUT2D O Analog output 2
17 AVDD2 - Power supply terminal
18 OUT2C O Analog output 2
19 M9 I Control signal for DAC
20 DVSS1 - Connect to ground
21 XOUT - Non connect
22 XIN - Non connect
23 VCOF I VCO Frequency
24 DVDD1 - Power supply D+5V
25 M7 - Connect to ground
26 M8 - Connect to ground
27 M4 I Control signal for DAC
28 M6 I Clock for control signal

XV-M50BK
17
1.10 MN67706ZY (IC201) : Auto digital servo controller
• Terminal layout
• Pin functions
Pin No Symbol I/O Function
1 AS(AD2) I AS :Full adder signal(FEP)
2 TE(AD1) I Phase difference/3 beam tracking error(FEP)
3 FE(AD0) I Focus error(FEP)
4 AVDD - Apply 3.3V(For analog circuit)
5 FODRV(DA1) O Focus drive(DRVIC)
6 TRDRV(DA0) O Tracking drive(DRVIC)
7 AVSS - Ground(For analog circuit)
8 ARF I Equivalence RF+(FEP)
9 NARF I Equivalence RF-(FEP)
10 IREF1 I Reference current1(For DBAL)
11 IREF2 I Reference current2(For DBAL)
12 DSLF1 I/O Connect to capacitor1 for DSL
13 DSLF2 I/O Connect to capacitor2 for DSL
14 AVDD - Apply 3.3V(For analog circuit)
15 VHALF I Reference voltage 1.65+-0.1V(FEP)
16 PLPG - Not use(PLL phase gain setting resistor terminal)
17 PLFG - Not use(PLL frequency gain setting resistor terminal)
18 VREFH I Reference voltage 2.2V+-0.1V(FEP)
19 RVI I/O Connect to resistor for VREFH reference current source
20 AVSS - Ground(For analog circuit)
21 PLFLT1 O Connect to capacitor1 for PLL
22 PLFLT2 O Connect to capacitor2 for PLL
23 JITOUT I/O Output for jitter signal monitor

XV-M50BK
18
24 RFDIF I Not use
25 CSLFL1 I/O Pull-up to VHALF
26 VFOSHORT O VFO short output
27 AVDD - Apply 3.3V(For analog circuit)
28 HPFIN I Pull-up to VHALF
29 HPFOUT O Connect to TP208
30 AVSS - Ground(For analog circuit)
31 LPFIN I Pull-up to VHALF
32 LPFOUT O Not use
33 CMPIN I Connect to TP210
34 TRCRS I Input signal for track cross formation
35 VCOF I/O JFVCO control voltage
36 DBALO O DSL balance adjust output
37 JLINE O J-line setting output(FEP)
38 AVDD - Apply 3.3V(For analog circuit)
39 LOUT O Connect to TP203 (Analog audio left output)
40 ROUT O Connect to TP204 (Analog audio right output)
41 AVSS - Ground(For analog circuit)
42 TGBAL O Tangential balance adjust(FEP)
43 TBAL O Tracking balance adjust(FEP)
44 FBAL O Focus balance adjust(FEP)
45 33VSS - Ground(For I/O)
46 33VDD - Apply 3.3V(For I/O)
47 OFTR I Off track signal
48 SYSCLK I 16.9344MHz system clock input(ODC)
49 BDO I Drop out(FEP)
50 TSTSG O Calibration signal(FEP)
51 TRSDRV O Traverse drive(DRVIC)
52 SPDRV O Spindle drive output(DRVIC)
53 FG I FG signal input (Spindle motor driver)
54 TILTP O Connect to TP205
55 TILT O Connect to TP206
56 TILTN O Connect to TP207
57 25VSS - Ground(For internal core)
58 25VDD - Apply 2.5V(For internal core)
59 DTRD I Data read control signal(ODC)
60 IDGT/TEMUTE I Pull-down to Ground
61 LRCK/CPDET2 O LR channel data strobe(ODC)/
62 BLKCK/CPDET1 O CD sub code synchronous signal(ODC)/
63 SBCK/PLLOK I CD sub code data shift clock(ODC)/PLL pull-in OK signal input
64 IDHOLD I Pull-down to Ground
65 DACLRCK/JMPINH I 1bit DAC-LR channel data strobe(ODC)/
66 DACDATA/LG I CD 1bit DAC channel data(ODC)
67 NTRON O L :Tracking ON(ODC)
68 DACCLK O 1bit DAC channel data shift clock(ODC)
69 IPFLAG O CIRC error flag(ODC)
70 SUBC O CD sub code(ODC)
71 NCLDCK/JUMP O CD sub code data frame clock(ODC)/DVD JUMP signal(ODC)
Pin No Symbol I/O Function

XV-M50BK
19
72 MINTEST I Pull-down to Ground(For MINTEST)
73 TEST I Pull-down to Ground(For TEST)
74 33VSS - Ground(For I/O)
75 33VDD - Apply 3.3V(For I/O)
76 CHCK40 O Clock for SRDATA(ODC)
77 DAT3 O SRDATA3(ODC)
78 DAT2 O SRDATA2(ODC)
79 DAT1 O SRDATA1(ODC)
80 DAT0 O SRDATA0(ODC)
81 33VSS - Ground(For I/O)
82 33VDD - Apply 3.3V(For I/O)
83 TX O Digital audio interface
84 XRESET I Reset input (System control)
85 ENS I Servo DSC serial I/F chip select (System control)
86 ENC I CIRC serial I/F chip select (System control)
87 CPUIRQ O Interrupt request (System control)
88 CPUCLK I Syscon serial I/F clock (System control)
89 CPUDTIN I Syscon serial I/F data input (System control)
90 CPUDTOUT O Syscon serial I/F data output (System control)
91 MONA O Connect to TP226 (Monitor terminal A)
92 MONB O Connect to TP225 (Monitor terminal A)
93 MONC O Connect to TP224 (Monitor terminal A)
94 NC O Connect to TP211
95 25VSS - Ground(For internal core)
96 25VDD - Apply 2.5V(For internal core)
97 LDCUR(AD6) I Laser current control terminal
98 TDOFS(AD5) I Connect to TP215
99 TG(AD4) I Tangential phase difference(FEP)
100 RFENV(AD3) I RF envelope input(FEP)
Pin No Symbol I/O Function

XV-M50BK
20
1.11 MR27V1602EN8MAX (IC402) :P2 ROM of 1,048,576word x 16 bit / 2,097,152 word x 8 bit
• Pin layout
• Block diagram
• Pin functions
Symbol Function
A0 - A20 Address Input
D0 - D14 Data Output
CE Chip Enable
OE Output Enable
BYTE Mode Switch
Vcc Power Supply
Vss GND
WE Write enable
WP Connect to ground
