JVC LT-32C670 User manual

Instruction Manual
32" LED Smart HD TV
LT-32C670(B) / LT32C671(B)
GB
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 1 11/09/2018 10:19

JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 2 11/09/2018 10:19

Contents
1 Safety Warnings ...........................................................................................................................................................................5
2 Preparation...................................................................................................................................................................................8
Unpacking the TV ...............................................................................................................................................................................................................8
Installing / Removing the Base Stand .........................................................................................................................................................................9
− Fitting the Stand Neck and Base Together....................................................................................................................................................9
− Fitting the Stand Neck and Base Together....................................................................................................................................................9
Mounting the TV to a Wall.............................................................................................................................................................................................10
Front / Right Side View and Controls.........................................................................................................................................................................10
Rear View and Sockets....................................................................................................................................................................................................11
Installing Batteries in the Remote Control ..............................................................................................................................................................12
Remote Control Operation Range..............................................................................................................................................................................12
Remote Control .................................................................................................................................................................................................................13
3 Initial Setup ................................................................................................................................................................................17
Turning the TV On for the First Time .........................................................................................................................................................................17
− Choose Region (UK only) .................................................................................................................................................................................. 20
− Connecting an Analogue Device....................................................................................................................................................................21
− Channel Selection ...............................................................................................................................................................................................21
− Display Channel Information ...........................................................................................................................................................................21
− Volume Adjustment.............................................................................................................................................................................................21
4 Customising TV Settings ...........................................................................................................................................................22
Adjusting the Picture Settings.................................................................................................................................................................................... 22
− Aspect Ratio........................................................................................................................................................................................................... 23
Adjusting the Sound Settings..................................................................................................................................................................................... 23
Editing the Channel List ................................................................................................................................................................................................ 24
Viewing your Favourite Channel List........................................................................................................................................................................ 25
5 Using the Features.....................................................................................................................................................................26
Programme Guide........................................................................................................................................................................................................... 26
− Switch On / O Programme Guide ............................................................................................................................................................... 26
− Select a Programme ........................................................................................................................................................................................... 26
Time Shift Recording onto a USB Storage Device ............................................................................................................................................... 28
Recording DTV Programmes onto a USB Storage Device ................................................................................................................................ 29
Timer Programming ....................................................................................................................................................................................................... 30
Recording Settings...........................................................................................................................................................................................................31
Playing Recorded Programmes.................................................................................................................................................................................. 32
Red Button + (Interactive services)........................................................................................................................................................................... 33
− Accessing the Information ............................................................................................................................................................................... 33
Listening to the Radio.................................................................................................................................................................................................... 33
6 Using the Smart Features..........................................................................................................................................................34
Connecting to the Internet (Wired) .......................................................................................................................................................................... 34
Connecting to the Internet using wireless............................................................................................................................................................. 35
− Wake On .................................................................................................................................................................................................................. 35
Connecting to the WPS button .................................................................................................................................................................................. 36
Using Freeview Play ........................................................................................................................................................................................................ 37
− Catch Up Services................................................................................................................................................................................................ 37
− Recommendations.............................................................................................................................................................................................. 37
− Freeview Apps Updating .................................................................................................................................................................................. 38
− Freeview Play 7 day Catch Up through the Programme Guide.......................................................................................................... 38
Selecting Smart TV.......................................................................................................................................................................................................... 39
− Market...................................................................................................................................................................................................................... 39
− Widget ..................................................................................................................................................................................................................... 39
− My Apps................................................................................................................................................................................................................... 40
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 3 11/09/2018 10:19

− Organising your apps in My Apps ................................................................................................................................................................. 40
− Deleting an app from My Apps ...................................................................................................................................................................... 40
− Key Apps ................................................................................................................................................................................................................. 40
− Searching for Apps.............................................................................................................................................................................................. 40
− Editing the Smart Wallpaper ............................................................................................................................................................................41
Using the Internet............................................................................................................................................................................................................ 42
− Adding Bookmarks ............................................................................................................................................................................................. 42
− Adding Tabs........................................................................................................................................................................................................... 42
− Adding a Site to Speed Dial ............................................................................................................................................................................. 43
− Editing Speed Dial............................................................................................................................................................................................... 43
− Opera Menu........................................................................................................................................................................................................... 43
Casting You Tube or Netix to your TV....................................................................................................................................................................44
7 Other Information......................................................................................................................................................................45
CI (Common Interface) (DTV Mode).......................................................................................................................................................................... 45
Privacy Settings................................................................................................................................................................................................................ 46
Time Settings..................................................................................................................................................................................................................... 47
Accessibility Settings...................................................................................................................................................................................................... 47
Other Settings................................................................................................................................................................................................................... 48
− Connecting a Soundbar - HDMI ARC (Audio Return Channel)........................................................................................................... 49
Language Settings .......................................................................................................................................................................................................... 50
Sources................................................................................................................................................................................................................................. 50
Resetting your TV .............................................................................................................................................................................................................51
Parental Settings.............................................................................................................................................................................................................. 52
8 Entertainment ............................................................................................................................................................................53
Connecting a USB Storage Device............................................................................................................................................................................. 53
Viewing Videos................................................................................................................................................................................................................. 54
Viewing Photos................................................................................................................................................................................................................. 55
Listening to Music............................................................................................................................................................................................................ 56
9 Technical Information and Help...............................................................................................................................................57
Maintenance...................................................................................................................................................................................................................... 57
Hints and Tips.................................................................................................................................................................................................................... 58
Product Fiche and Specications ............................................................................................................................................................................. 60
License Information used with JVC Televisions.................................................................................................................................................... 62
Declaration of Conformity............................................................................................................................................................................................ 62
Remote Control Codes................................................................................................................................................................................................... 62
− Sky Codes ............................................................................................................................................................................................................... 62
− Virgin Media Codes (TiVo box) ....................................................................................................................................................................... 62
− BT Vision.................................................................................................................................................................................................................. 62
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 4 11/09/2018 10:19

5
1 Safety Warnings
Chapter
1
10 cm 10 cm
20 cm
10 cm
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
• WARNING: Never let people (including children) with
reduced physical, sensory or mental capabilities or lack
of experience and / or knowledge use electrical devices
unsupervised.
• To avoid danger of suffocation, keep plastic bags out of
reach of babies, children and domestic animals.
• Carefully attach the stand to the TV. If the stand is
provided with screws, tighten the screws firmly to
prevent the TV from tilting. Do not over tighten the
screws and mount the stand rubbers properly.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall off or tip over causing serious
personal injury or death.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
• Use this TV set at an altitude of less than 2000 meters
above sea level, in dry locations and in regions with
moderate or tropical climates.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as;
• Using cabinets or stands recommended by the
manufacturer of the television set.
• Only use furniture that can safely support the
television set.
• Ensuring the television set is not overhanging the edge
of the supporting furniture.
• Not placing the television set on tall furniture (for
example, cupboards or bookcases) without anchoring
both furniture and the television set to a suitable
support.
• Not standing the television set on cloth or other
materials placed between the television and
supporting furniture.
• Educating children about the dangers of climbing
on furniture to reach the television set or its controls.
If your existing television set is being retained and
relocated, the same considerations as above should be
applied.
Wall Mounting
• Read the TV and wall mount instructions before
mounting your TV on the wall.
• For TVs over 40" in size, wall mounting requires 2
people to lift and position the TV on to the wall mount.
• The wall mount bracket is not supplied, they can be
purchased from your dealer.
• Do not install the TV on a ceiling or an inclined wall.
• Only use the screws supplied with the wall mount
bracket when attaching the TV to the bracket. See your
TV instructions for screw type.
• Tighten the wall mount screw firmly to prevent the TV
from falling. Do not over tighten the screws.
• If you are in any doubt how to mount your TV, contact
a professional.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm and long inactivity periods (going on
holiday).
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 5 11/09/2018 10:19

6
1Safety Warnings
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• A damaged power cord/plug can cause fire or give
you an electric shock. Handle the power cord by the
plug, do not unplug the TV by pulling the power cord.
Never touch the power cord/plug with wet hands
as this could cause a short circuit or electric shock.
Never make a knot in the power cord or tie it with
other cords. If the mains cable is damaged it must be
replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long
periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Country Restrictions for Wireless Internet
• This device is intended for home and office use in
all EU countries (and other countries following the
relevant EU directive) without any limitation except for
the countries mentioned below.
Country Restriction
Bulgaria (BG) General authorization required for
outdoor use and public service
France (FR) In-door use only for 2454-2483.5 MHz
Italy (IT) If used outside of own premises, general
authorization is required
Greece (GR) In-door use only for 5470 MHz to 5725
MHz band
Luxembourg
(EL)
General authorization required for
network and service supply(not for
spectrum)
Norway (NO)
Radio transmission is prohibited for the
geographical area within a radius of 20
km from the centre of Ny-Ålesund
Russian
Federation (RU) In-door use only
• The requirements for any country may change at any
time. It’s recommended that user checks with local
authorities for the current status of their national
regulations for both 2.4 GHz and 5 GHz wireless LAN’s.
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• Do not dispose of batteries in fire or with hazardous or
flammable materials.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 6 11/09/2018 10:19

7
1
Safety Warnings
Earthing
• Apparatus connected to the protective earthing of the
building installation through the MAINS connection
or through other apparatus with a connection to
protective earthing - and to a television distribution
system using coaxial cable, may in some circumstances
create a fire hazard. Connection to a television
distribution system has therefore to be provided
through a device providing electrical isolation below a
certain frequency range (galvanic isolator,
see EN 60728-11)
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of fire,
keep candles or other open
flames away from this product
at all times.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 7 11/09/2018 10:19

8
2 Preparation
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new JVC TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
Chapter
2
Remote Control /
AAA Batteries x 2
Stand screws x6
Instruction Manual Quick Start Guide
Instruction Manual
32" LED Smart HD TV
LT-32C670(B) / LT32C671(B)
GB
Slide under
the lip
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(ARC)
HDMI2
LAN
Quick Start Guide
32" LED Smart TV
LT-32C670(B) / LT32C671(B)
Thank you for purchasingyour new JVC TV.
Yournew TV incorporates the latest technology to enhance your viewing
experience.We would suggest that you allow about 15 mins for initial setup.
Pleasefollow this guide for a successful rst time installation.
Thelatest eco-friendly power-saving technology will switch o the TV if
itis left on and idle for 4 hours. Please refer to “AutoStandby” under the
“TimeSettings” section of the instruction manual for more detail.
What’sin the Box?
1
Removeall packaging from the unit. Retain the packaging. If you dispose of it please do so according to any local regulations.
TV
TVStand Base
TVStand Neck
RemoteControl/
AAABatteries x2
StandScrews x 6
InstructionManual
QuickStart Guide Please inspect your TV for damage after unpacking. If
youdo notice any damage please consult your dealer.
Operating YourRemote Control
2
1. Slideopen the batter y compartment on the back of the remotecontrol.
2. Insert two AAA size batteries.M ake sureto match the (+) and ( - ) ends of
thebatteries with the (+) and ( - ) ends indicated in the batterycompartment.
3. Slidethe batter y compartment coverback into place. Make sure itclicks into place.
Fitting the Stand Neck and BaseTogether
1. Fitthe neck onto the base.
2. Using2 of the supplied screws, screw the neck to the base.
Fitting the Stand Neck and BaseTogether
1. Ensurethe TV is switched off and not connected to the mains power supply.
2. Lay the TV down on a flat surface ideally on the edge of a table so the base of the TV slightly
overhangsthe edge of the table, with the back side facing up. Please make sure a soft cushioned
material(such as a dr y bath towelor thick piece of foam) is placed beneath the screen.
3. Slide the stand under the lip, the neck will fit snugly over the screwholes. Then screw the stand
tothe TV using the 4 screws supplied.
Installing the Base Stand
3
TheLCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or
anythingthat could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of theT V at any time because the
screencould crack.
• Donot connect the TV to the mains supply until you have completed all the connections.
• Alwaysdisconnect the TV from the mains socket when not in use for a long period of time.
• The buttonon the remote control is only used for switching the TV into standby, it does not disconnect the TV from the mains power.
Tocompletely disconnect the mains power, please remove the mains plug from the mains socket.
1. Connectone end of the RF coaxial cable to the aerial socket on the wall and the other end of thecable to the ANT socket on the back of your TV.
2. Plugthe TV into a mains socket and switch on at the mains.
3. Instandby mode, press the button on the remote controlto turn the TV on. The LED indicator will flash for a few seconds then the TV will switch on.
Connecting the Aerial and Turningon the TV
4
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(ARC)
HDMI2
LAN
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(ARC)
HDMI2
LAN
Router
(notincluded)
RFcoaxial cable
(notincluded)
Optional
Ifyou want to connect to the internet via a wired connection
thenconnect your ethernet cable to the LAN socket.
Setup in
15mins
Protective
Bag
Cushioned
material
Table
JVC32' LED Smart HD TV LT-32C670/671(B) Quick Start Guide.indd 1-3 04/09/2018 17:08
SUBT.LANG.
TXT
MENU
Q.MENU
EXIT
BACK
OK
6
MNO
9
WXYZ
0
TV
7
PQRS
8
TUV
4
GHI
5
JKL
.,/@
2
ABC
3
DEF
VP
EPG
TV
TV Stand (base) TV Stand (neck)
4
789
0
1
.,/@
23
56
OK
Q.MENU
EXIT
BACK
LANG.
2
1
SOURCE
/
/
P+
P-
V+
V-
OR
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 8 11/09/2018 10:19

2
Preparation
9
Installing / Removing the Base Stand
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that
no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert
pressure on the front of the TV at any time because the screen could crack.
1. Fit the neck onto the base.
2. Using 2 of the supplied screws, screw the neck to the base.
Fitting the Stand Neck and Base Together
TV Stand (supplied)
Slide under
the lip
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(ARC )
HDMI2
LAN
Fitting the Stand Neck and Base Together
1. Ensure the TV is switched off and not connected to the mains power supply.
2. Lay the TV down on a flat surface ideally on the edge of a table so the base of the TV slightly overhangs the edge of the table,
with the back side facing up. Please make sure a soft cushioned material (such as a dry bath towel or thick piece of foam) is
placed beneath the screen.
3. Slide the stand under the lip, the neck will fit snugly over the screw holes. Then screw the stand to the TV using the 4 screws
supplied.
Table
Cushioned
material Protective bag
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 9 11/09/2018 10:19

2
10
Preparation
• If you are wall mounting your TV you may wish to buy a 90° HDMI adapter. This will help with your cable management.
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance please call our Call Centre on (UK) 0344 561 1234 or (Ireland) 1 890 818 575.
Our Customer Contact Centre is open Monday-Saturday 8am-8pm or Sunday 8am-6pm.
Remove the stand assembly before mounting the TV onto the wall.
1. Remove the 4 screws from the neck of the stand and detach the
stand.
Mounting the TV to a Wall
2. This TV is designed to be wall-mounted
with a standard 200 mm x 100 mm
mounting kit (sold separately) designed
for flat-panel TVs. Mount this TV
according to the instructions included
in the mounting kit. Due to space
restrictions, we recommend that you
make all connections before mounting
on to the wall.
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(AR C)
HDMI2
LAN
x4
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(AR C)
HDMI2
LAN
200mm
Four mounting holes
(size M4 screw)
100mm
5-8mm
M4
Front / Right Side View and Controls
Item Description
1 MULTI FUNCTION SWITCH Switches the TV into standby and on. Selects modes (channel,volume, and source).
2POWER LED Illuminates when the TV is in standby mode. The LED will blink confirming that a timer
recording programme has started in the standby mode.
3 IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2
1
3
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 10 11/09/2018 10:19

2
Preparation
11
Rear View and Sockets
COMMON INTERFACE
USB
5Vdc
Max. 500mA
USB
5Vdc
Max. 500mA
SIDE AVYPbPr
MODE - / I
- +
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI 1(ARC)
HDMI 2
LAN
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI 1(ARC)
HDMI 2
LAN
3
4
5
2
1
6
Item Description
1 HDMI 1 & 2 Connects to a High-Definition (HD) signal output device, such as a set-top box, blu-ray
disc player or AV receiver.
2 LAN Connects to the internet for using the Smart hub.
3 SPDIF (Optic. OUT) Optical audio out (Digital) - Connects to an audio device via an optical cable.
4 VGA/YPbPr
Connects to a computer or other devices with a VGA interface.
The VGA input is also used for component input via a VGA to component cable (not
supplied).
5 SCART Connects to a VCR, DVD Player, or other AV device with a SCART output socket.
Select SCART 1.
6 ANT Connects to the aerial socket on the wall with the RF coaxial cable.
7 COMMON INTERFACE Allows the insertion of a Common Access Module.
8 USB Allows the insertion of a USB storage device to play video, audio, photo and text files
(USB mode) and record DTV programmes on to a USB storage device.
9 CVBS/AUDIO IN (L/R)
(audio L/R also used for YPbPr and VGA)
Connects to the Composite VIDEO and AUDIO (L/R) output sockets on external video
devices.
10 Connects to the headphones.
11 MULTI FUNCTION SWITCH Switches the TV into standby and on. Selects modes (channel,volume, and source).
7
8
9
10
11
SCART
SPDIF
COMMON INTERFACE
USB
5Vdc
Max. 500mA
VGA
ANT.
HDMI 1
HDMI 2
LR
MODE - / I
- +
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 11 11/09/2018 10:19

2
12
Preparation
Remote Control Operation Range
Point the remote control at the TV no more than 5 metres from the
remote control sensor on the TV and within 60° in front of the TV.
The operating distance may vary depending on the brightness of
the room.
Installing Batteries in the Remote Control
1. Slide open the battery
compartment on the back
of the remote control.
2. Insert two AAA size
batteries. Make sure to
match the (+) and ( - ) ends
of the batteries with the (+)
and ( - ) ends indicated in
the battery compartment.
3. Replace the battery
compartment cover. Make
sure it clicks into place.
SUBT.LANG.
TXT
MENU
Q.MENU
EXIT
BACK
OK
6MNO
9WXYZ
0
TV
7PQRS 8TUV
4GHI 5JKL
.,/@ 2ABC3DEF
VP
EPG
30° 30°
5M
Handling the Batteries
• Improper or incorrect use of batteries may cause
corrosion or battery leakage, which could cause
fire, personal injury or damage to property.
• Only use the battery type indicated in this manual.
• When the batteries are exhausted, the remote will
not function. Replace both batteries at the same
time with new ones.
• Do not install new batteries with used ones and do
not mix different types of batteries.
• Do not dispose of used batteries as domestic
waste. Dispose of them in accordance with local
regulations.
Handling the Remote Control
• Take care of your fingernails when you press and
hold the battery release tab.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquid on the remote
control.
• Do not place the remote control on a wet object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote control
when not in use for a long period of time, as it
could cause corrosion or battery leakage and may
result in physical injury and/or property damage
including fire.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 12 11/09/2018 10:19

2
Preparation
13
Remote Control
SUBT.LANG.
TXT
MENU
Q.MENU
EXIT
BACK
OK
6MNO
9WXYZ
0
TV
7PQRS 8TUV
4GHI 5JKL
.,/@ 2ABC3DEF
VP
EPG
1.
Switch the TV between on and standby mode.
2. NETFLIX Button
Connects to Netix for viewing online TV shows and lms
(internet connection required).
3. SOURCE
Press to change the source you are viewing.
TV - EXT1 - SIDE AV - HDMI 1 - HDMI 2 - YPbPr - VGA/PC.
4. 0-9 Number Button
• Press to select a programme. (TV / RADIO mode)
5. TV
• Press to enter TV mode when viewing other sources.
6. (Previous programme/source)
• Press to switch between the previous programme or source
that was selected.
7. MUTE
Mute and restore the sound.
8. V + / –
Adjust the volume.
9. P+ / P-
Press to select the next channel up or down the channel list.
10. SMART HUB
Connects to the Smart Hub (internet connection required).
11. MENU
Display the main menu.
12. Q. MENU
Press the select the Settings menu.
13. OK /
• Press OK to select or save a setting in menus.
• Press OK to select the Channel list while watching TV.
• Allows you to navigate the OSD menus and adjust
the system settings to your preference.
14. BACK
Press to move backwards through menus.
15. EXIT
Press to exit a menu.
16. (Media Browser)
Press to enter the media browser menu, a hard drive will need
to be attached to the USB port.
17. EPG (Programme Guide)
Press to view the Programme Guide.
18. i (info)
Press to see programme information in TV mode.
5
4
1
7
10
16
3
2
9
12
15
17
11
14
18
8
13
6
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 13 11/09/2018 10:19

2
14
Preparation
SUBT.LANG.
TXT
MENU
Q.MENU
EXIT
BACK
OK
6MNO
9WXYZ
0
TV
7PQRS 8TUV
4GHI 5JKL
.,/@ 2ABC3DEF
VP
EPG
21
23
20
22
25
26
19
24
19.
Press to enter YouTube (internet connection required).
20.
Press to enter Freeview Play (internet connection required).
21. TXT
Press to enter teletext if available.
22. SUBT
Press to switch subtitles on and o.
23. (Aspect ratio)
Press to adjust the aspect ratio of the picture.
AUTO - 16:9 - Subtitle - 14:9 - 14:9 Zoom - 4:3 - Cinema.
24. LANG.
Selects the Current Language menu.
25. PLAYBACK and RECORD buttons
• starts a recording, continue to press will add more
recordings.
• plays a recording.
pauses a recording and starts timeshifting in TV mode
if you have a hard drive attached to the USB port.
• stops a recording.
• searches forwards and backwards when
viewing a recording.
26. COLOURED BUTTONS
Access the TELETEXT items (TV mode) or menu options.
TELETEXT (RED)
Accesses TELETEXT.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 14 11/09/2018 10:19

2
Preparation
15
1. SOURCE
Press to change the source you are viewing.
TV - SCART - AV - HDMI 1 - HDMI 2 - YPbPr - VGA/PC.
2.
Switch the TV between on and standby mode.
3. NETFLIX Button
Connects to Netix for viewing online TV shows and lms
(internet connection required).
4. YouTube Button
Connects to YouTube (internet connection required).
5.
Press to enter Freeview Play (internet connection required).
6. PLAYBACK and RECORD buttons
• starts a recording, continue to press will add more
recordings.
• plays a recording.
pauses a recording and starts timeshifting in TV mode
if you have a hard drive attached to the USB port.
• stops a recording.
• searches forwards and backwards when viewing
a recording.
7. LANG.
Selects the Current Language menu.
8. (Subtitles)
Press to switch subtitles on and o.
9. COLOURED BUTTONS
Access the TELETEXT items ( TV mode) or menu options.
TELETEXT (RED)
Accesses TELETEXT.
10. 0-9 Number Button
• Press to select a programme. (TV / RADIO mode)
• Select numbered items in a menu.
11. TV
• Press to enter TV mode when viewing other sources.
12. (Previous programme/source)
• Press to switch between the previous programme or source
that was selected.
13. MENU
Display the main menu.
14.
Connects to the internet (internet connection required).
15. Q. MENU
Press the select the Settings menu.
4
3
1
5
2
8
12
15
7
11
13
14
6
9
10
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 15 11/09/2018 10:19

2
16
Preparation
22
28
23
29
21
25
27
20
24
26
18 19
16 17
16. V + / –
Adjust the volume.
17. P+ / P-
Press to select the next channel up or down the channel list.
18. OK
• Press OK to select or save a setting.
19.
• Allow you to navigate the OSD menus and adjust the
system settings to your preference.
20. BACK
Press to move backwards through menus.
21. EXIT
Press to exit a menu.
22. FAVOURITES
Press to access favourite channels list.
23. i (info)
Press to see programme information in TV mode.
24. (Aspect ratio)
Press to adjust the aspect ratio of the picture.
AUTO - 16:9 - Subtitle - 14:9 - 14:9 Zoom - 4:3 - Cinema.
25. MUTE
Mute and restore the sound.
26.
• Press to return to the rst channel in your selected
channel list in TV mode.
27. (Programme Guide)
Press to view the Programme Guide.
28. (Media Browser)
Press to enter the media browser menu, a hard drive will
need to be attached to the USB port.
29.
Press to enter teletext if available.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 16 11/09/2018 10:19

17
3 Initial Setup
Turning the TV On for the First Time
1. Connect one end of the RF coaxial cable
to the aerial socket on the wall and
the other end of the cable to the ANT
socket on the back of your TV.
2. Plug the TV into a mains socket and switch on at the mains.
3. In standby mode, press the button on the remote control to turn the TV on. The LED indicator will flash for a few seconds
then the TV will switch on.
SCART
SPDIF
Optic.OUT
VGA
ANT.
HDMI1(ARC)
HDMI2
LAN
RF coaxial cable
(not included)
Do not connect the TV to the mains
supply until you have completed all
the connections.
• Always disconnect the TV from the mains socket when not in use for a long period of time.
• The button on the remote control is only used for switching the TV into standby, it does not disconnect the TV from the
mains power. To completely disconnect the mains power, please remove the mains plug from the mains socket.
Chapter
3
4. The first time you turn the TV on, it will go straight
into the First Time Installation menu. Please ensure
the aerial is plugged in.
Press the buttons to highlight your language
then press OK.
5. Press the buttons to select your country.
6. Press the button to highlight Scan Encrypted (pay-
per-view) Channel, then press the buttons to
select On or Off.
Select Favorite Network Type
In this section you can tell your TV what to tune in.
Digital Aerial is TV through your aerial this is automatically selected.
Cable is if you have cable wired directly into your TV NOT through a set top box.
Analogue is for analogue devices that you may have connected to your TV e.g. a video recorder.
None select this if you don't want to tune in any channels, this could be because you receive your TV via a set top box that you
have connected via HDMI.
7. Press the button to highlight Select favourite
network type, then press the buttons to select
Digital Aerial, Digital Cable, Analogue or None.
Confirm these settings by pressing OK.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 17 11/09/2018 10:19

18
3Initial Setup
8. Press the buttons to highlight Home Mode then
press OK.
Privacy Settings
Before you are able to connect to the internet and use the smart features of your TV, you MUST make sure that some Privacy
Settings are activated.
To use Smart functions the minimum settings that you will need to activate are Portal and Applications and Internet
connection . For Red Button services you must activate HbbTV.
By activating these settings you are allowing the TV Manufacturer to store data to help improve the performance and user
experience of your TV.
Each setting has a description, if you press the P/ button when the setting is highlighted you will be able to scroll up and
down the text to read the description.
To Accept ALL (recommended)
9. To accept all the setting press
the OK button. All of the sliders
will slide across to the right and
change to Green.
10. Press OK again to continue with
your installation.
Press OK to Accept All
14. To access all the features of your Smart TV you must
be connected to the internet. If you do not wish to set
up your network connection you can skip this section
by selecting NO, however we recommend you set up
your network connection now.
15. Select Yes and Press OK.
Select Individual Settings
If you don’t want to accept all the setting you can choose to activate settings individually.
11. First make sure Accept All is
deactivated, the slider should
be on the left and red.
12. Press the button to highlight
your desired setting then press
the to activate it.
13. Press the OK button to confirm
your settings, a list will appear
highlighting the settings that
you haven't accepted. Select
YES to continue.
Reminder of setting not selected
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 18 11/09/2018 10:19

19
3
Initial Setup
18. You now need to enter your password, a keyboard will appear. Press the
buttons to select a letter/number/symbol and press OK to enter each
one. Once you have typed your password highlight OK and press OK. The
network will now show Connected.
19. Press the OK button to continue.
• To enjoy Freeview Play your TV must be connected to the internet.
WIRED Connection
• If you have connected your ethernet cable to the LAN socket on the back of
your TV press the buttons to select WIRED DEVICE. When Network says
ENABLED press the OK button.
WIRELESS Connection
You can connect using a wireless connection via your router.
16. Press the buttons to select WIRELESS DEVICE. Wait a few seconds and a
list of all wireless networks will be displayed.
17. Press the buttons to select your wireless network then press OK.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 19 11/09/2018 10:19

20
3Initial Setup
20. Your TV will now start the automatic channel scan.
Choose Region (UK only)
During tuning, your TV may have received signals from more than one
transmitter. If this has occurred the Choose Region screen will be displayed.
This will enable you to select the correct regional transmission for the local
news service that you require.
• Press the button to highlight Primary region, then press the
buttons to select your Primary Region e.g. England.
• Press the button to highlight Secondary region, then press the
buttons to select your Secondary Region e.g. London.
• Press the button to highlight Tertiary region, then press the
buttons to select your Tertiary Region e.g. Greater London.
• Press the button to highlight Save then press OK.
Your TV is now fully tuned in.
Country Code This will be shown as UK.
Primary Region This will show the regional country (England, Wales,
Scotland, NI).
Secondary Region
This will allow you to set the region for your local
news service on BBC and ITV (London, Beds and
Cambs etc).
Tertiary Region
You may receive signals from more than one
transmitter within the Secondary Region, (e.g Beds
and Cambs may have Luton or Sandy Heath).
21. The Scan statistics screen will now be displayed. This shows the amount of TV
and Radio channels that have been tuned in. Press OK to exit.
22. The Edit Channel list will appear, press the EXIT button to remove this. Your TV
is now fully tuned in and ready to use.
JVC 32' LED Smart HD TV LT-32C670/671(B) Manual.indd 20 11/09/2018 10:19
