SERVICE MANUAL
MULTI-FORMAT MONITOR
BASIC CHASSIS
R1
No. 52152
2003/9
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LTD.
DT-V1710CG /U
DT-V1710CG /E
For the specifications, adjustments or part lists of optional board IF-C01PNG (NTSC/PAL
video input card) and IF-C01COMG (Component/RGB input card), refer to service manual
DT-V1700CG/E (No.51899).
(No. 52152) Printed in Japan
WPC
VICTOR COMPANY OF JAPAN, LIMITED
AV & Multimedia Company 12,3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa 221-8528, Japan
TABLE OF CONTENTS
1. PRECAUTIONS .......................................................................................................................................... 1-3
2. SPECIFIC SERVICE INSTRUCTIONS .......................................................................................................... 1-4
3. DISASSEMBLY ........................................................................................................................................... 1-5
4. ADJUSTEMNT .......................................................................................................................................... 1-13
5. TROUBLE SHOOTING .............................................................................................................................. 1-73

Unit : mm
< Side View >< Front View >
<Front View with the wide mask attached>
331
336
288
395
183
334
254
VOLUME
SLOT 1
AB
DEGAUSS
MENU
MUTIN G
SCREEN S
CHEC K
ASPECT AREA
MARKER
UNDE R
SCAN
PULS E
CROS S
COLO R
OF F
SLOT 2
CD
SLOT 3 POWER
EF
INPUT SELECT
VOLUME
SLOT1
AB
DEGAUSS
MENU
MUTING
SCREENS
CHECK
ASPECT AREA
MARKER
UNDER
SCAN
PULSE
CROSS
COLOR
OFF
SLOT 2
CD
SLOT 3 POWER
EF
INPUT SELECT
466.5
454
415
286
68
25
1.5
DIMENSIONS
(No. 52152) 1-75
Type
Picture Tube
Effective Screen Size
Input Signal Frequency
Video Band
Horizontal Resolution
Compliant Video Signal
Input Terminals
Remote Inputs
Audio Output
Environmental Conditions
Power Requirements
Power Consumption
Dimensions (W ×H ×D)
Mass
Accessory
SPECIFICATIONS
Items Contents
1-2 (No. 52152)
Multi-format monitor
17” Flat
33cm(13”) ×25cm(9-7/8”) /41cm(16-1/4”) [measured diagonally]
Horizontal : 15kHz/27kHz – 45kHz
Vertical : 50Hz – 80Hz
Component : 25MHz (-3dB)
Video (Y/C) : 8MHz (-3dB)
1080/60i : 800 TV lines
Video (Y/C) : 600 TV lines
NTSC (3.58 MHz)/PAL (4.43 MHz) (using the IF-C01PNG)
480i/576i/480p/576p/1080i (50 Hz/60 Hz/24psF)/720p (50 Hz/60 Hz) (using the IF-
C01COMG)
D1 serial digital (using the IF-C01SDG)
HD serial digital (using the IF-C12HSDG)
Installing an optional input card in SLOT1, 2, or 3 is required.
INPUT A/INPUT B : Terminals on the input card in SLOT1.
INPUT C/INPUT D : Terminals on the input card in SLOT2.
INPUT E/INPUT F : Terminals on the input card in SLOT3.
Point-of-contact connection, 1 line, D-sub connector (15-pin 3-line)
Serial connection, 1 line, D-sub connector (9-pin), compliant to RS-485
1W (monaural) 3-1/8” (8cm) round speaker ×1
Operating Temperature : 5°C – 35°C (41°F – 95°F)
Operating humidity : 20% – 80% (non-condensing)
120V/230V, 50Hz/60Hz
1.56A/0.9A (including input card)
39.5cm(15-5/8”) ×33.4cm(13-1/4”) ×46.7cm(18-3/8”)
(not including wide mask and input card)
23.7 kg (not including wide mask and input card)
AC power cord (2.5 m) x1
Power cord holder x 1 (case and cover)
Screws x 2 (Power cord holder)
Wide Mask x 1
Screws x 4 (Wide Mask)
NOTE : Design and specifications subject to change without notice.

(No. 52152) 1-3
1.1 SAFETY PRECAUTIONS
(1) The design of this product contains special hardware,
many circuits and components specially for safety
purposes. For continued protection, no changes should
be made to the original design unless authorized in writing
by the manufacturer. Replacement parts must be identical
to those used in the original circuits. Service should be
performed by qualified personnel only.
(2) Alterations of the design or circuitry of the products should
not be made. Any design alterations or additions will void
the manufacturer's warranty and will further relieve the
manufacturer of responsibility for personal injury or
property damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These
characteristics are often not evident from visual inspection
nor can the protection afforded by them necessarily be
obtained by using replacement components rated for
higher voltage, wattage, etc. Replacement parts which
have these special safety characteristics are identified in
the parts list of Service manual. Electrical components
having such features are identified by shading on
the schematics and by ( ) on the parts list in Service
manual. The use of a substitute replacement which does
not have the same safety characteristics as the
recommended replacement part shown in the parts list of
Service manual may cause shock, fire, or other hazards.
(4) Use isolation transformer when hot chassis.
The chassis and any sub-chassis contained in some
products are connected to one side of the AC power line.
An isolation transformer of adequate capacity should be
inserted between the product and the AC power supply
point while performing any service on some products when
the HOT chassis is exposed.
(5)
Don't short between the LIVE side ground and
ISOLATED (NEUTRAL) side ground or EARTH side
ground when repairing.
Some model's power circuit is partly different in the GND.
The difference of the GND is shown by the LIVE : ( ) side
GND, the ISOLATED(NEUTRAL) : ( ) side GND and EARTH
: ( ) side GND. Don't short between the LIVE side GND
and ISOLATED(NEUTRAL) side GND or EARTH side GND
and never measure the LIVE side GND and
ISOLATED(NEUTRAL) side GND or EARTH side GND at the
same time with a measuring apparatus (oscilloscope etc.).
If above note will not be kept, a fuse or any parts will be
broken.
(6) If any repair has been made to the chassis, it is
recommended that the B1 setting should be checked or
adjusted (See ADJUSTMENT OF B1 POWER SUPPLY).
(7) The high voltage applied to the picture tube must conform
with that specified in Service manual. Excessive high
voltage can cause an increase in X-Ray emission, arcing
and possible component damage, therefore operation
under excessive high voltage conditions should be kept
to a minimum, or should be prevented. If severe arcing
occurs, remove the AC power immediately and determine
the cause by visual inspection (incorrect installation,
cracked or melted high voltage harness, poor soldering,
etc.). To maintain the proper minimum level of soft X-Ray
emission, components in the high voltage circuitry
including the picture tube must be the exact replacements
or alternatives approved by the manufacturer of the
complete product.
(8) Do not check high voltage by drawing an arc. Use a high
voltage meter or a high voltage probe with a VTVM.
Discharge the picture tube before attempting meter
connection, by connecting a clip lead to the ground frame
and connecting the other end of the lead through a 10kΩ
2W resistor to the anode button.
(9) When service is required, observe the original lead dress.
Extra precaution should be given to assure correct lead
dress in the high voltage circuit area. Where a short circuit
has occurred, those components that indicate evidence
of overheating should be replaced. Always use the
manufacturer's replacement components.
(10)Isolation Check
(Safety for Electrical Shock Hazard)
After re-assembling the product, always perform an
isolation check on the exposed metal parts of the cabinet
(antenna terminals, video/audio input and output terminals,
Control knobs, metal cabinet, screwheads, earphone jack,
control shafts, etc.) to be sure the product is safe to operate
without danger of electrical shock.
a) Dielectric Strength Test
The isolation between the AC primary circuit and all metal
parts exposed to the user, particularly any exposed metal
part having a return path to the chassis should withstand
a voltage of 1100V AC (r.m.s.) for a period of one second.
(. . . . Withstand a voltage of 1100V AC (r.m.s.) to an
appliance rated up to 120V, and 3000V AC (r.m.s.) to an
appliance rated 200V or more, for a period of one second.)
This method of test requires a test equipment not generally
found in the service trade.
b) Leakage Current Check
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Using
a “Leakage Current Tester”, measure the leakage current
from each exposed metal part of the cabinet, particularly
any exposed metal part having a return path to the chassis,
to a known good earth ground (water pipe, etc.). Any
leakage current must not exceed 0.5mA AC (r.m.s.).
However, in tropical area, this must not exceed 0.2mA AC
(r.m.s.).
•Alternate Check Method
Plug the AC line cord directly into the AC outlet (do not
use a line isolation transformer during this check.). Use
an AC voltmeter having 1000 ohms per volt or more
sensitivity in the following manner. Connect a 1500Ω10W
resistor paralleled by a 0.15µF AC-type capacitor
between an exposed metal part and a known good earth
ground (water pipe, etc.). Measure the AC voltage across
the resistor with the AC voltmeter. Move the resistor
connection to each exposed metal part, particularly any
exposed metal part having a return path to the chassis,
and measure the AC voltage across the resistor. Now,
reverse the plug in the AC outlet and repeat each
measurement. Any voltage measured must not exceed
0.75V AC (r.m.s.). This corresponds to 0.5mAAC (r.m.s.).
However, in tropical area, this must not exceed 0.3V AC
(r.m.s.). This corresponds to 0.2mA AC (r.m.s.).
(11) High voltage hold down circuit check.
After repair of the high voltage hold down circuit, this circuit
shall be checked to operate correctly.
See “X-RAY PROTECTOR ADJUSTMENT/CHECK” on
page 1-44.
GOOD
EARTH
GROUND 0.15 µF AC-TYPE
AC VOLTMETER
(HAVING 1000Ω/V,
OR MORE SENSITIVITY)
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1500Ω10W
A V
This mark shows a fast POWER CORD
REPLACEMENT WARNING
Connecting the white line side of
power cord to “WHT” character side.
operating fuse, the
letters indicated below
show the rating.
PWB
WHT
PW
White line side
SECTION 1
PRECAUTION

1-4 (No. 52152)
2.1 HOW TO IDENTIFT MODEL
Please check the destination and the version of your model by RATING LABEL.
!DT-V1710CG/U [FOR NORTH AMERICA MODEL]
!DT-V1710CG/E [FOR EUROPE AND ASIA MODELS]
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
INDICATED “DT-V1710CGU”
INDICATED “DT-V1710CGE”

(No. 52152) 1-5
3.1 DISASSEMBLY PROCEDURE
CAUTION :
•Some parts are active even after the main power switch is
set to OFF.
•Be sure to unplug the power cord from the power outlet before
proceeding with disassembly or assembly of the unit.
3.1.1 REMOVING THE SLOT PANEL, TOP COVER AND
REAR PANEL
(1) Unplug the power cord, remove the six screws [1] and
remove the SLOT PANEL.
(2) Remove the fourteen screws [2] and then the two screws
[3].
(3)
Open up the lower part of the TOP COVER slightly. Then
pull the TOP COVER toward the rear and lift to remove it.
(4) Also remove the REAR PANEL.
3.1.2 REMOVING THE BOTTOM COVER
•Remove the SLOT PANEL, TOP COVER and REAR PANEL.
(1) Place the unit so that the side with the SLOT CHASSIS
comes at the bottom.
(2) Remove the six screws [4] and pull the BOTTOM COVER
toward the rear to remove it.
3.1.3 REMOVING THE SIGNAL PW BOARD, MOTHER PW
BOARD AND REMOTE PW BOARD
•Remove the SLOT PANEL, TOP COVER and REAR PANEL.
(1) Disconnect the wire clamps and connectors as required.
(2) Remove the four screws [5] and unplug the SIGNAL PWB
from the connector on the MOTHER PWB.
(3) Remove the two screws [6] and then remove the Joint
Bracket.
(4) Remove the two screws [7] and then remove the SLOT
CHASSIS by lifting it while pushing the claw [C] on the
CHASSIS BASE.
(5) Remove the nine screws [8] and remove the MOTHER
PWB.
(6) Remove the screw [9], the four screwnuts [10] and the
two screwnuts [11], then remove the REMOTE PWB.
3.1.4 REMOVING THE CHASSIS BASE, SPEAKER AND
S. CORRECTION PW BOARD
•Remove the SLOT PANEL, TOP COVER, REAR PANEL and
SLOT CHASSIS.
(1) Disconnect the wire clamps and connectors as required.
(2) Remove the two screws [12] and pull the CHASSIS BASE
toward the front to remove it.
(3) While disengaging the claw [D] on the CHASSIS BASE
that is engaged with the rear of the SPEAKER, lift the
SPEAKER to remove it (see Fig. 2).
(4) Remove the three screws [13] and then remove the PB
BRACKET.
(5) Unplug the S. CORRECTION PWB from the connector
on the MAIN PWB.
CAUTION
Before turning the power on, ensure that the spiral wires
(Yellow/Green) and the CRT grounding wires are
connected properly.
CRT grounding wire
View from the rear of the AC inlet
Spiral wires
(Yollow/Green)
Black
White
Black
White
3.1.8 NOTE CONCERNING WIRE CLAMPING
•Be sure to reconnect the wire clamps that have been
disconnected during the above work.
3.1.5 REMOVING THE CRT AND LED PW BOARD
•Remove the SLOT PANEL, TOP COVER, REAR PANEL,
BOTTOM COVER, SLOT CHASSIS and CHASSIS BASE.
(1) Remove the four screws [14] and remove the SIDE
BRACKETS.
(2) Also remove the CRT.
(3) Remove the two screws [15] and remove the LED PWB.
3.1.6 REMOVING THE FRONT CONTROL PW BOARD AND
FRONT VR PW BOARD
(1) Remove the five screws [16] and remove the CONTROL
BASE.
(2) Disconnect the connectors as required.
(3) Remove the three screws [17] and remove the FRONT
CONTROL PWB.
(4) While slightly lifting the two claws [E] on the CONTROL
BASE, remove the FRONT VR PWB.
3.1.7 DIAGNOSING THE MAIN PW BOARD
•Remove the SLOT PANEL, TOP COVER and REAR PANEL.
(1) Place the unit so that the side with the SLOT CHASSIS
comes at the bottom, and remove the BOTTOM COVER.
(2) Now the diagnosis of the MAIN PWB is possible.
CAUTION :
•The unit is unstable when it is placed on its side so please
be careful that it does not topple over during work.
•
Before turning the power on, ensure that the connectors in
cluding the CRT grounding are connected properly.
SECTION 3
DISASSEMBLY

1-6 (No. 52152)
9
B
A
HV CONTROL
MODULE PWB
S. CORRECTION
PWB
MAIN PWB
CHASSIS BASE
SUB DEF MODULE PWB
C
SPEAKER
Fig. 2
Fig. 1
LED PWB
CRT
JOINT BRACKET
SLOT CHASSIS
PB BRACKET
SIDE BRACKET
SIDE
BRACKET
CONTROL
BASE
CRT SOCKET
PWB
MOTHER PWB
TOP COVER
SIGNAL PWB
REMOTE PWB
REAR PANEL
SLOT PANEL
FRONT VR PWB
FRONT CONTROL PWB
Speaker
back side
BOTTOM COVER
REMOVING THE SPEAKER
A
E
D
B
14
14
14
12
12
14
4
17
4
16
4
4
2
2
10
8
8
8
6
13
13
13
7
5
11
2
2
2
15
1
2
3
2
2
1
10
1

(No. 52152) 1-7
3.2 DEMAGNETIZATION PROCEDURE
3.2.1 CAUTION
(1) Use a rod-type demagnetization coil.
NOTE:
Never use a ring-shaped demagnetization coil.
(2) Keep the demagnetization coil at a distance of more than 1.5 cm from the CRT screen and the main unit during use.
(3) When demagnetizing the CRT screen, hold the demagnetization coil perpendicularly to the CRT screen.
(4) When demagnetizing the outer cabinet of the unit, use the demagnetization coil in the orientation as shown below.

1-8 (No. 52152)
3.2.2 DEMAGNETIZING THE CRT SCREEN
(1) While holding the power button of the demagnetization coil, move it to approach the CRT screen area that has color irregularities.
(Keep the demagnetization coil at a distance of more than 1.5 cm from the screen.)
(2) From the area with the colour irregularities, move the demagnetization coil as if drawing a spiral toward the center of the CRT
screen.
(3) Move the demagnetization coil slowly away from the center of the CRT screen.
(4) When the demagnetization coil comes to about 1 meter from the CRT screen, release the demagnetization coil power button.
(5) If the color irregularities are still observed, repeat the above steps once more.
3.2.3 DEMAGNETIZING THE OUTER CABINET OF THE UNIT
(1) While holding the power button of the demagnetization coil, move it to approach the outer cabinet of the unit.
(Keep the demagnetization coil at a distance of more than 1.5 cm from the cabinet.)
(2) Keep the demagnetization coil in the same orientation, and move it around the cabinet as if drawing a circle around the side
and top panels of the unit.
(3) Move the demagnetization coil slowly away from the outer cabinet of the unit.
(4) When the demagnetization coil comes to about 1 meter from the unit, release the power button of the demagnetization coil.
1 m
1 m

(No. 52152) 1-9
3.3 MEMORY IC REPLACEMENT
3.3.1 MEMORY IC
The unit incorporates a nonvolatile Memory IC, which stores data on the video and deflection systems, etc.
When it is replaced with an IC without the data stored in it, the set may malfunction or the video may become abnormal
when the unit is turned on.
When replacing the Memory IC, be sure to use an IC in which the data (initial values) has already been written.
< SETUP MENU >
FUNCTION SETTING
PICTURE SUB ADJ.
COLOR TEMP./BAL.
SIZE/POSI. ADJ.
DISTORTION ADJ.
STATUS DISPLAY
CONTROL LOCK : OFF
all reset
Fig. 1
SIGNAL BLOCK
WHITE BALANCE BLOCK
DEFLECTION BLOCK
CPU BLOCK
DIAGNOSIS
UPC1884 ADJ.
TA1276 ADJ.
HOUR METER
Fig. 3
< MAIN MENU >
APERTURE CONTROL
SLOT CONDITION
sub menu POSITION : LOWER
AREA MARKER
COLOR MATRIX
Fig. 2
EXIT:
MENU
SELECT:
ENTER: +
EXIT:
MENU
SELECT:
ENTER: +
EXIT:
MENU
SELECT:
ENTER: +
3.3.2 MEMORY IC REPLACEMENT PRECDURE
1. Turn the unit off and unplug the power cord from the power
outlet.
2. Replace the Memory IC with a new Memory IC storing
the initial setting value data.
3. Plug the power cord into the power outlet and turn the
unit on.
4. Check the SETUP MENU and set its items as required.
(1) While holding down the key, press the VOL - ( )
key.
(2) The SETUP MENU appears (Fig. 1).
(3) Check the items in the SETUP MENU by comparing
them with the data in the table on page 1-10.
If any item is set differently, set it as required.
5. Check the MAIN MENU and set its items as required.
Press the [MENU] key to display the MAIN MENU (Fig.
2). Check the items in the MAIN MENU by comparing
them with the data in the table on page 1-11. If any item is
set differently, set it as required.
6. Adjust the items that can be adjusted on the front panel.
(Some items cannot be adjusted unless the required signal
is input.)
7. Check that the initial values of the items in the SERVICE
MENU (Fig. 3). If any item is set differently, set it as
required.
For the setting method and the initial values, see the
corresponding pages for “SERVICE ADJUSTMENTS” in
this manual.

1-10 (No. 52152)
3.3.3 FACTORY SETTING VALUE
!INITIAL SETTING VALUE TABLE [SET-UP MENU]
Setting Item Data / Variable range Initial setting value Remarks
FUNCTION SETTING
COLOR SYSTEM AUTO / NTSC / PAL AUTO Apply the NTSC/PAL signal
AUTO INPUT ON/OFF OFF Apply the HD SDI/SDI signal
SYNC SELECT INT. / EXT. INT.
RUSH DELAY TIME STD. / SLOW STD.
TALLY SELECT GREEN / RED GREEN
REMOTE SYSTEM MAKE / TRIGGER MAKE
E.AUDIO GROUP 1G / 2G / 1-2G 1G
HOUR METER X 100h 000 – 655 000
PICTURE SUB ADJ.
CONTRAST -20 – +20 00
BRIGHT -20 – +20 00
CHROMA -20 – +20 00
PHASE -20 – +20 00
NTSC SETUP 00 / 75 00
COMPO. LEVEL SMPTE / B00 / B75 SMPTE Apply the Component signal
COLOR TEMP. / BAL.
COLOR TEMP. LOW / HIGH LOW
BLUE DRIVE MIN – MAX (127 steps) 000
RED DRIVE MIN – MAX (127 steps) 000
GREEN CUTOFF MIN – MAX (205 steps) 000
BLUE CUTOFF MIN – MAX (205 steps) 000
RED CUTOFF MIN – MAX (205 steps) 000
SIZE / POSI. ADJ.
H.SIZE -20 – +20 00 Reduced to 00 – +20 during the under-scan mode.
H.POSITION -20 – +20 00
V.SIZE -20 – +20 00
V.POSITION -20 – +20 00
ZOOM H. SIZE -20 – 00 00
ZOOM V. SIZE -20 – +20 00
DISTORTION ADJ.
PINCUSHION -20 – +20 00
PIN.BALANCE -20 – +20 00
PARALLELOGRAM -20 – +20 00
TRAPEZOID -20 – +20 00
ROTATION -31 – +31 00
STATUS DISPLAY
STATUS DISPLAY ON / OFF ON
LEVEL METER ch OFF/1:2/12:34/31:24/123:456/1-8 OFF
BAR TYPE 3 COLORS / WHITE-1 / WHITE-2 3 COLORS
REFERENCE LEVEL -20dB / -18dB -20dB
OVER LEVEL -8dB / -6dB / -4dB / -2dB -8dB
BAR BRIGHTNESS HIGH / LOW HIGH
CONTROL LOCK ON / OFF OFF

(No. 52152) 1-11
!INITIAL SETTING VALUE TABLE [MAIN MENU]
Setting Item Data / Variable range Initial setting value
!INITIAL SETTING VALUE TABLE [FRONT PANEL CONTROL]
Setting Item Data / Variable range Initial setting value
POWER ON / OFF OFF
INPUT SELECT INPUT A – F INPUT A
COLOR OFF
AREA MARKER
PULSE CROSS
ASPECT ON / OFF OFF
UNDER SCAN
SCREENS CHECK
DEGAUSS
VOLUME 00 – 50 10
CONTRAST
BRIGHT POTENTIOMETER Center click position
CHROMA
PHASE
APERTURE CONTROL
LEVEL 00 – 10 00
CONTROL FREQ. HIGH / LOW / OFF HIGH
SLOT CONDITION Type of boards installed in the rear panel slots.
INPUT A – F SLOT1 : INPUT A, B
SLOT2 : INPUT C, D
SLOT3 : INPUT E, F
sub menu POSITION LOWER / UPPER LOWER
AREA MARKER
MARKER SELECT OFF / LINE /S. HALF / HALF+L / S. BLK / BLK. +L OFF
ZOOM OFF / ON OFF
ASPECT SELECT 4 : 3 / 13 : 9 / 14 : 9 4 : 3
SAFEY AREA OFF / 80% / 88% / 90% OFF
R-MARKER SELECT OFF / LINE / S. HALF / HALF+L / S. BLK / BLK. +L OFF
R-ZOOM OFF / ON OFF
R-ASPECT SELECT 4 : 3 / 13 : 9 / 14 : 9 4 : 3
R-SAFETY AREA OFF / 80% / 88% / 90% 0FF
COLOR MATRIX SELECT : MANUAL / ITU601 or ITU709 NORMAL
[Example when MANUAL is set]
R-Y PHASE : 90/92/94/112 90
R/B GAIN : 0.56/0.68/0.79/0.86 0.86
G-Y PHASE : 236/240/244/253 244
G/B GAIN : 0.30/0.34/0.40/0.45 0.30

1-12 (No. 52152)
3.4 REPLACEMENT OF CHIP COMPONENT
3.4.1 CAUTIONS
(1) Avoid heating for more than 3 seconds.
(2) Do not rub the electrodes and the resist parts of the
pattern.
(3) When removing a chip part, melt the solder adequately.
(4) Do not reuse a chip part after removing it.
3.4.2 SOLDERING IRON
(1) Use a high insulation soldering iron with a thin pointed
end of it.
(2) A 30w soldering iron is recommended for easily removing
parts.
3.4.3 REPLACEMENT STEPS
1. How to remove Chip parts
[Resistors, capacitors, etc.]
(1) As shown in the figure, push the part with tweezers and
alternately melt the solder at each end.
(2) Shift with tweezers and remove the chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply extra solder to each lead.
(2) As shown in the figure, push the part with tweezers and
alternately melt the solder at each lead. Shift and remove
the chip part.
Note :
After removing the part, remove remaining solder from
the pattern.
2. How to install Chip parts
[Resistors, capacitors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder. Then heat and melt the solder at both ends of the
chip part.
[Transistors, diodes, variable resistors, etc.]
(1) Apply solder to the pattern as indicated in the figure.
(2) Grasp the chip part with tweezers and place it on the
solder.
(3) First solder lead A as indicated in the figure.
(4) Then solder leads Band C.
SOLDER SOLDER
A
B
C
A
B
C

(No. 52152) 1-13
4.1 ADJUSTMENT PRECUTION
(1) Make sure that connection is correctly mode AC to AC power souce.
(2) Warm run the unit and measuring tools sufficiently (at least 30 minutes).
(3) Perform all adjustments based on the initial values. There is no problem if the result of an adjustment performed by observing
the screen is different from the initial value.
(4) Never attempt to turn on potentiometers or other controls that are not explicitly mentioned in the adjustment procedures.
NOTE:
When using the IF-C01PNG (NTSC/PAL Video Input Card) in an adjustment, be sure to check the output waveforms
from the video input card in advance.
4.2 SETTINGS REQUIRED FOR ADJUSTMENTS
For the functions other than those that should be set before each adjustment, reset them to the initial values
according to the table on page 1-10 before proceeding to the adjustment.
Correct adjustments will not be possible unless the values of the functions are reset to the initial values.
4.3 SETTING ITEMS
Begin adjustments with the primary items and then proceed to the secondary items, (1) to (3).
!PRIMARY ADJUSTMENT ITEMS
•Screen voltage coarse adjustment
•High-voltage coarse adjustment
•X-ray protector adjustment/check
•High-voltage adjustment
•Focus adjustment
•Image rotation adjustment
•Convergence adjustment
!SECONDARY ADJUSTMENT ITEMS (1)
•Contrast adjustments
•Chroma/Phase adjustments
!SECONDARY ADJUSTMENT ITEMS (2)
•Deflection system adjustments
(Overscan, underscan, aspect mode)
!SECONDARY ADJUSTMENT ITEMS (3)
•White balance adjustments
•Brightness adjustments
(Overscan, underscan, aspect mode)
SECTION 4
ADJUSTMENT

1-14 (No. 52152)
Fromats of Signal Used in Adjustments Types of Signals Used in Adjustments
•DTV format component signals
(480/60i, 480/60p, 576/50i, 576/50p, 720/50p, 720/60p,
1080/24psF, 1080/50i, 1080/60i)
•NTSC signals
(Composite, Y/C)
•PAL signals
(Composite, Y/C)
•Color bar signal
•Size adjustment signal
•All white signal
•All black signal
•Mono-scope signal
•Gray scale signal
•10-step gray scale signal
•Crosshatch signal
•Crosshatch signal with circle pattern
4.4 MEASURING INSTRUMENTS AND FIXTURES
(1) DC voltmeter ( or digital voltmeter)
(2) Oscilloscope
(3) Color analyzer (colour temperature meter)
(4) High-voltage voltmeter
(5) Signal generator (Should be compatible with the following signal specifications.)
(6) Scale (made of non-metallic material)
(7) IF-C01PNG (NTSC/PAL Video Input Card)
(8) IF-C01COMG (Component/RGB Input Card)
4.5 FOCUS AND SCREEN ADJUSTMENT HOLES
The rear panel has the adjustment holes for use in adjusting the focusing and screen.
CAUTION :
•Be sure to use screwdrivers made of non-metallic materials for the following adjustments. If a metallic screwdriver is used,
short-circuiting may damage parts of the unit, including the high-voltage parts.

(No. 52152) 1-15
Signal NTSC(14.3) PAL 480/60i 576/50i 480/60p 576/50p 720/50p 720/60p 1080/24psF 1080/50i 1080/60i
Resolution(Horizontal) 768 624 720 720 720 720 1280 1280 1920 1920 1920
Resolution(Vertical) 243 287 244 287 483 576 720 720 540 540 540
Horizontal frequency(kHz) 15.73 15.625 15.73 15.625 31.469 31.25 37.50 44.955 27 28.125 33.75
Vertical frequency(Hz) 29.97i 25i 30i 25i 60p 50p 50p 60p 24psF(48i) 50i 30i
CS & V RGB RGB RGB RGB RGB RGB RGB RGB RGB RGB
CS -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1
HS -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1
VS -1 -1 -1 -1 -1 -1 -1 -1 -1 -1 -1
Dot clock(MHz) 14.318 12 13.5 13.5 27 12 74.25 74.25 74.25 74.25 74.25
H period 910 768 858 864 858 864 1980 1650 2750 2640 2200
H sync 68 56 63 63 63 63 40 40 44/44 44/44 44/44
H back p. 58 70 59 68 59 69 260 260 144/188 144/188 144/188
H disp 768 624 720 720 720 720 1280 1280 1920 1920 1920
V period 263 312 263 312 525 625 750 750 562 562 562
V sync 33336555555
V back p. 14 19 13 19 30 39 25 20 15 15 15
V disp 243 287 243 287 483 576 750 720 540 540 540
Equivalent pulse(fp/bp) 3H/3H 3H/3H 3H/3H 3H/3H 0H/0H 0H/0H 0H/0H 0H/0H 0H/0H 0H/0H 0H/0H
EQ
fp EQ bp
Sync
Back porch
Front porch
Total period
Display area
4.6 TIMING CHART OF SIGNALS REQUIRED FOR ADJUSTMENTS
Generate the signals required for adjustments with a programmable signal generator by referring to the following figure.

1-16 (No. 52152)
4.7 ADJUSTMENT LOCATIONS
S. CORRECTION PWB (SOLDER SIDE) CRT SOCKET PWB (SOLDER SIDE)
MAIN PWB
FRONT
FRONT
UPPER : FOCUS-1
MIDDLE : FOCUS-2
LOWER : SCREEN
TOP
VR505 COVN_V
VR504 CONV_H
VR501 X-RAY
TP-G TP-XR
VR502 H.VOLTAGE
TP-47B
TP-47R
TP-47G
E1
U
VR
S
D
P
H
T
T
TP-GND
CN011
CN010
CN004
CN001
CN002
CN003
CN005
S. CORRECTION PWB
HV CONTROL MODULE PWB
SUB DEF MODULE PWB
F901
CN010
CN0RD CN00R
CN011
TOP

(No. 52152) 1-17
4.8 BASIC OPERATIONS OF SERVICE MENU
4.8.1 SERVICE MENU ITEMS
The service menu is roughly classified according to setup and adjustments, and is divided into the following items. Do not
alter the values of unnecessary items.
4.8.2 BASIC OPERATIONS IN THE SERVICE MENU
1. Entering the Service Menu
Use the front panel keys to display the Service Menu (Fig. 1).
(1) While holding the key, press the [MENU] key.
The “ ” mark appears at the center of the screen (Fig. 2).
(2)Before the “ ” mark disappears (within 5 seconds after it
appears), hold the key and press the VOL- ( ) key.
Warning message “Please don't touch!” appears on the
screen (Fig. 3).
(3) Before the warning message disappears (within 5 seconds
after it appears), press the VOL+ ( ) key.
The service menu items appears on the display (Fig. 4).
–+
VOLUME
MENU
Please don't touch!
SIGNAL BLOCK
WHITE BALANCE BLOCK
DEFLECTION BLOCK
CPU BLOCK
DIAGNOSIS
UPC1884 ADJ.
TA1276 ADJ.
HOUR METER
EXIT:
MENU SELECT:
ENTER: +
Fig. 1 FRONT PANEL KEYS
Fig. 2 WRNING MARK
Fig. 3 WARNING MESSAGE DISPLAY
Fig. 4 SERVICE MENU
SIGNAL BLOCK Adjustments of the contrast, brightness, chroma and phase.
WHITE BALANCE BLOCK Adjustments of the white balance.
DEFLECTION BLOCK Adjustments of the deflection circuitry.
CPU BLOCK Setting of the entire system by means of the control values of the microcomputer. (This block is
usually not adjusted in servicing. Do not touch it except for adjustment items CC41 and CE05 to
CE24.)
DIAGNOSIS Display of the results of self diagnosis.
UPC1884 ADJ. Display of the status of UPC1884 which is the DEF processor IC. (Do not adjust this item because
it is not required for servicing.)
TA1276 ADJ. Display of the status of TA1276 which is the RGB processor IC. (Do not adjust this item because it
is not required for servicing.)
HOUR METER Display of the hour meter count.
UPDATE CPU PROGRAM Display of the software version.
E2PROM VERSION Display of the E2PROM version. (Do not adjust this item because it is not required for servicing.)
FPGA VERSION Display of the HDSDI FPGA version. (Do not adjust this item because it is not required for servicing.)
INITIALIZE EEPROM Initialization of the user-setting menu. (Do not adjust this item because it is not required for servicing.)

1-18 (No. 52152)
2. Setting the Service Menu items
(1) With the Service Menu displayed, press the key to
select the item to be adjusted, then press the VOL+
( ) key to enter the submenu for the item.
(2) Press the key to select the item to be adjusted, then
press the VOL+ ( ) key to enter the item.
(3) Set the adjustment item by varying it with the VOL- ( )
and VOL+ ( ) keys.
3. Exiting from the Service Menu
(1) After completing the adjustment of an item, press the
[MENU] key to return to the submenu.
(2) Press the [MENU] key again to return to the Service
Menu.
(3) Press the [MENU] key again to return to the normal
screen.
< SIGNAL BLOCK >
SA : VIDEO -NTSC
SB : Y/C -NTSC
SC : VIDEO -PAL
SD : YC -PAL
SE : COMP. -480/60i
SF : COMP. -576/50i
SG : COMP. -480/60p
SH : COMP. -576/50p
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
S (A01)
EXIT:
MENU
SELECT:
ENTER: +
SUBMENU
ADJUSTMENT ITEM DISPLAY
S (A01)
ADJUSTMENT ITEM ADJUSTMENT VALUE

(No. 52152) 1-19
4.8.3 SERVICE MENU FLOW CHART
< DEFLECTION BLOCK >
DA : NTSC
DB : NTSC-UNDER
DC : PAL
DD : PAL-UNDER
DE : 480/60i
DF : 480/60i-UNDER
DG : 576/50i
DH : 576/50i-UNDER
EXIT: MENU SELECT:
ENTER: +
< DEFLECTION BLOCK >
DI : 480/60p
DJ : 480/60p -UNDER
DK : 576/50p
DL : 576/50p -UNDER
DM : 1080/60i
DN : 1080/60i-UNDER
DO : 1035/60i
DP : 1035/60i-UNDER
EXIT: MENU SELECT:
ENTER: +
< DEFLECTION BLOCK >
DQ : 1080/50i
DR : 1080/50i-UNDER
DS : 1080/24p
DT : 1080/24p-UNDER
DU : 720/60p
DV : 720/60p-UNDER
DW : 720/50p
DX : 720/50p-UNDER
EXIT: MENU SELECT:
ENTER: +
< DEFLECTION BLOCK >
DY : ASPECT
DZ : V.LIN/FOCUS
D1 : ROTATION/PURITY
D2 : COMMON
D3 : ZOOM
EXIT: MENU SELECT:
ENTER: +
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
D [A01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
D [I01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
D [Q01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
W [A01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
W [I01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
D [Y01]
(DA : NTSC) (DI : 480/60p) (DQ : 1080/50i)
(WA : NTSC HIGH) (WI : COMP.-1080i HIGH)
(DY : ASPECT)
[DEFLECTION BLOCK 1/4] [DEFLECTION BLOCK 2/4] [DEFLECTION BLOCK 3/4]
< WHITE BALANCE BLOCK >
WA : NTSC HIGH
WB : NTSC LOW
WC : PAL HIGH
WD : PAL LOW
WE : COMP.-480(576)i HIGH
WF : COMP.-480(576)i LOW
WG : COMP.-480(576)p HIGH
WH : COMP.-480(576)p LOW
EXIT: MENU SELECT:
ENTER: +
< WHITE BALANCE BLOCK >
WI : COMP.-1080i HIGH
WJ : COMP.-1080i LOW
WK : COMP.-1035/60i HIGH
WL : COMP.-1035/60i LOW
WM : COMP.-1080/50i HIGH
WN : COMP.-1080/50i LOW
WO : COMP.-1080/24psF HIGH
WP : COMP.-1080/24psF LOW
EXIT: MENU SELECT:
ENTER: +
[WHITE BALANCE BLOCK 1/3] [WHITE BALANCE BLOCK 2/3]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
S [A01]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
S [I01]
(SA : VIDEO -NTSC) (SI : COMP. -1080/60i)
< SIGNAL BLOCK >
SA : VIDEO -NTSC
SB : Y/C -NTSC
SC : VIDEO -PAL
SD : YC -PAL
SE : COMP. -480/60i
SF : COMP. -576/50i
SG : COMP. -480/60p
SH : COMP. -576/50p
EXIT: MENU SELECT:
ENTER: +
< SIGNAL BLOCK >
SI : COMP. -1080/60i
SJ : COMP. -1035/60i
SK : COMP. -1080/50i
SL : COMP. -1080/24psF
SM : COMP. -720/60p
SN : COMP. -720/50p
SO : RGB
SP : SCAN -UNDER
EXIT: MENU SELECT:
ENTER: +
[SIGNAL BLOCK 1/3]
SIGNAL BLOCK
WHITE BALANCE BLOCK
DEFLECTION BLOCK
CPU BLOCK
DIAGNOSIS
UPC1884 ADJ.
TA1276 ADJ.
HOUR METER
EXIT: MENU SELECT:
ENTER: +
EXIT: MENU SELECT:
ENTER: +
[SERVICE MENU] [SIGNAL BLOCK 2/3]
[DEFLECTION BLOCK 4/4]
UPDATE CPU PROGRAM
E2PROM VERSION
INITIALIZE EEPROM
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
W [Q01]
(WI : COMP.-720/60p HIGH)
< WHITE BALANCE BLOCK >
WQ : COMP.-720/60p HIGH
WR : COMP.-720/60p LOW
WS : COMP.-720/50p HIGH
WT : COMP.-720/50p LOW
WU : RGB HIGH
WV : RGB LOW
WW: COMMON HIGH
WX : COMMON LOW
EXIT: MENU SELECT:
ENTER: +
[WHITE BALANCE BLOCK 3/3]
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
S [Q01]
(SQ : ASPECT)
< SIGNAL BLOCK >
SQ : ASPECT
SR : COMMEN
SS : SCAN -ZOOM
ST : SUB DATA (HD/SD)
EXIT: MENU SELECT:
ENTER: +
[SIGNAL BLOCK 3/3]

1-20 (No. 52152)
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
U [P01]
T [A01]
< EEPROM VERSION >
EEPROM :
SET FPGA:
SLOT1 :
SLOT2 :
SLOT3 :
[E2PROM VERSION]
< HOUR METER >
RESET
HOUR METER :
EXIT: MENU ENTER: +
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
[TA1276 ADJ. ]
[HOUR METER]
[UPC1884 ADJ. ]
C [A01]
[DIAGNOSIS]
< CPU BLOCK >
CA : MENU
CB : SIGNAL
CC : SETTING
CD : DEFLECTION
CE : OSD etc
< DIAGNOSIS MENU >
CLEAR
I2C-0 SIGNAL BUS
I2C-1 SIGNAL BUS
I2C ROM BUS
X-RAY
OCP
VOFF
EXIT: MENU SELECT:
ENTER: +
EXIT: MENU ENTER: +
[FPGA VERSION]
< FPGA VERSION >
XXXXX X
XXXXX
XXXX
XXXX
XXXX
XXX
[CPU BLOCK]
SIGNAL BLOCK
WHITE BALANCE BLOCK
DEFLECTION BLOCK
CPU BLOCK
DIAGNOSIS
UPC1884 ADJ.
TA1276 ADJ.
HOUR METER
EXIT: MENU SELECT:
ENTER: +
EXIT: MENU SELECT:
ENTER: +
[SERVICE MENU] [CA : MENU]
UPDATE CPU PROGRAM
E2PROM VERSION
FPGA VERSION
INITIALIZE EEPROM
< UPDATE CPU PROGRAM >
Necessity! : PC, cable
& terminal software
CURRENT Ver.
[ UPDATE CPU PROGRAM ]
< EEPROM INITIALIZE >
Are you sure?
“YES” then + key.
“NO” then MENU key.
[INITIALIZE EEPROM]
EXIT: MENU
Are you sure?
“Yes” then + key.
“No” then MENU key.
ENTER: +
Do not adjust these items because they are not rquired for servicing.
