JVC DLA-20LTD User manual

.
D-ILA
PROJECTOR
DLA-20LTD
.
SETTING MEMORY
MODE 1 MODE 2 MODE 3
ANAMO.
HDR
C.M.D.
COLOR
PROFILE
GAMMA
SETTINGS
MODE
.
http://manual3.jvckenwood.com/projector/mobile/global/
The Mobile User Guide can be viewed on mobile internet devices including
smartphones and tablets.
Mobile User Guide
.
Pour utilisation par le client :
Entrerci-dessous le N°de série qui
est situé sous le boîtier. Garder
cetteinformation comme référence
pour le futur.
Instrucción para el cliente :
Introduzca a continuación el nº de
serie que aparece en la parte
inferior lateral de la caja. Conserve
esta información como referencia
para uso ulterior.
For Customer use :
Enter below the serial No. which is
located on the side of the cabinet.
Retain this information for future
reference.
DLA-20LTDModel No.
Serial No.
DLA-20LTDN° de modèle
N° de série
DLA-20LTDModelo Nº
Nº de serie
Not suitable for household room illumination.
INSTRUCTIONS
B5A-2360-0M
Getting Started Set up Operate Adjust/Set Maintenance
Troubleshooting
Others

Safety Precautions
.
This product has a High Intensity
Dis-charge (HID) lamp that contains
mercury. Manage in accord with
disposal laws.
Disposal of these materials may be
regulated in your community due to
environmental considerations. For
disposal or recycling information,
please contact your local authorities or
for USA, the Electronic Industries
Alliance: http://www.eiae.org. or call
1-800-252-5722(For USA)
or 1-800-964-2650(For Canada).
IMPORTANT INFORMATION
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
FCC INFORMATION (U.S.A. only)
CAUTION:
Changes or modification not approved by JVC could
void the user’s authority to operate the equipment.
About the installation place
Do not install the projector in a place that cannot
support its weight securely.
If the installation place is not sturdy enough, the
projector could fall or overturn, possibly causing
personal injury.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Consult the dealer or an experienced radio/TV
technician for help.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
NOTE:
This equipment has been tested and found to comply
with the limits for Class B digital devices, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encourage to try to
correct the interference by one or more of the
following measures:
WARNING:
THIS APPARATUS MUST BE EARTHED.
CAUTION:
To reduce the risk of electric shock, do not remove
cover. Refer servicing to qualified service personnel.
This projector is equipped with a 3-blade grounding
type plug to satisfy FCC rule. If you are unable to
insert the plug into the outlet, contact your electrician.
⹣晼㯡婌♟㒷
For the customers in Taiwan only
NOISE EMISSION DECLARATION
The sound pressure level at the operator position is
equal or less than 50dB(A) according to ISO7779.
Model Number: DLA-20LTDK
Trade Name: JVC
Responsible party: JVCKENWOOD USA Corporation
Address: 1700 Valley Road Wayne, N. J. 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Declaration of Conformity
2
Getting Started

.
Front
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
-
-
-
-
-
-
-
-
-
-
-
-
-
IMPORTANT SAFEGUARDS
Electrical energy can perform many useful functions.
This unit has been engineered and manufactured to
assure your personal safety. But IMPROPER USE
CAN RESULT IN POTENTIAL ELECTRICAL
SHOCK OR FIRE HAZARD. In order not to defeat
the safeguards incorporated into this product,
observe the following basic rules for its installation,
use and service. Please read these Important
Safeguards carefully before use.
All the safety and operating instructions should be read
before the product is operated.
The safety and operating instructions should be retained for
future reference.
All warnings on the product and in the operating
instructions should be adhered to.
All operating instructions should be followed.
Place the projector near a wall outlet where the plug can be
easily unplugged.
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
Do not use attachments not recommended by the product
manufacturer as they may be hazardous.
Do not use this product near water. Do not use immediately
after moving from a low temperature to high temperature,
as this causes condensation, which may result in fire,
electric shock, or other hazards.
Do not place this product on an unstable cart, stand, or
table. The product may fall, causing serious injury to a child
or adult, and serious damage to the product. The product
should be mounted according to the manufacturer’s
instructions, and should use a mount recommended by the
manufacturer.
When the product is used on a cart,
care should be taken to avoid quick
stops, excessive force, and uneven
surfaces which may cause the product
and cart to overturn, damaging
equipment or causing possible injury to
the operator.
Slots and openings in the cabinet are
provided for ventilation. These ensure reliable operation of
the product and protect it from overheating. These
openings must not be blocked or covered. (The openings
should never be blocked by placing the product on bed,
sofa, rug, or similar surface. It should not be placed in a
built-in installation such as a bookcase or rack unless
proper ventilation is provided and the manufacturer’s
instructions have been adhered to.)
To allow better heat dissipation, keep a clearance between
this unit and its surrounding as shown below. When this unit
is enclosed in a space of dimensions as shown below, use
an air-conditioner so that the internal and external
temperatures are the same. Overheating can cause
damage.
-
-
-
-
-
-
-
-
a)
b)
c)
d)
e)
f)
When the power supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen on the
product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the
operating instructions. Adjust only those controls that
are covered by the Operation Manual, as an improper
adjustment of controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to normal operation.
If the product has been dropped or damaged in any
way.
When the product exhibits a distinct change in
performance, this indicates a need for service.
Power source indicated on the label. If you are not sure of
the type of power supply to your home, consult your
product dealer or local power company.
This product is equipped with a three-wire plug. This plug
will fit only into a grounded power outlet. If you are unable
to insert the plug into the outlet, contact your electrician to
install the proper outlet. Do not defeat the safety purpose of
the grounded plug.
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them. Pay particular attention to cords at doors,
plugs, receptacles, and the point where they exit from the
product.
For added protection of this product during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the cable system. This will prevent damage to
the product due to lightning and power line surges.
Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as this can
result in a risk of fire or electric shock.
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltages
and other hazards. Refer all service to qualified service
personnel.
Unplug this product from the wall outlet and refer service to
qualified service personnel under the following conditions:
-
-
-
-
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or with same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
The product should be placed more than one foot away
from heat sources such as radiators, heat registers, stoves,
and other products (including amplifiers) that produce heat.
When connecting other products such as VCR’s, and DVD
players, you should turn off the power of this product for
protection against electric shock.
200 mm
(8 in) and
above
300 mm
(12 in) and
above
300 mm
(12 in) and
above
150 mm (6 in) and above
150 mm
(6 in) and
above
3
Getting Started

.
-
-
-
-
-
-
-
-
-
-
-
Do not place combustibles behind the cooling fan. For
example, cloth, paper, matches, aerosol cans or gas
lighters that present special hazards when over heated.
Do not look into the projection lens while the illumination
lamp is turned on. Exposure of your eyes to the strong light
can result in impaired eyesight.
Do not look into the inside of this unit through vents
(ventilation holes), etc. Do not look at the illumination lamp
directly by opening the cabinet while the illumination lamp is
turned on. The illumination lamp also contains ultraviolet
rays and the light is so powerful that your eyesight can be
impaired.
Do not drop, hit, or damage the light-source lamp (lamp
unit) in any way. It may cause the light-source lamp to
break and lead to injuries. Do not use a damaged light
source lamp. If the light-source lamp is broken, ask your
dealer to repair it. Fragments from a broken light-source
lamp may cause injuries.
The light-source lamp used in this projector is a high
pressure mercury lamp. Be careful when disposing of the
light-source lamp. If anything is unclear, please consult
your dealer.
Do not ceiling-mount the projector to a place which tends to
vibrate; otherwise, the attaching fixture of the projector
could be broken by the vibration, possibly causing it to fall
or overturn, which could lead to personal injury.
Use only the accessory cord designed for this product to
prevent shock.
For health reasons, please take a break of about 5-15
minutes every 30-60 minutes and let your eyes rest. Please
refrain from watching any 3D-images when you feel tired,
unwell or if you feel any other discomfort. Moreover, in case
you see a double image, please adjust the equipment and
software for proper display. Please stop using the unit if the
double image is still visible after adjustment.
Once every three years, please perform an internal test.
This unit is provided with replacement parts needed to
maintain its function (such as cooling fans). Estimated
replacement time of parts can vary greatly depending on
frequency of use and the respective environment. For
replacement, please consult your dealer, or the nearest
authorized JVC service center.
When fixing the unit to the ceiling, Please note that we do
not take any responsibility, even during the warranty period,
if the product is damaged due to use of metal fixtures used
for fixation to the ceiling other than our own or if the
installation environment of said metal fixtures is not
appropriate. If the unit is suspended from the ceiling during
use, please be careful in regard to the ambient temperature
of the unit. If you use a central heating, the temperature
close to the ceiling will be higher than normally expected.
Video images can burn into the electronic component parts.
Please do not display screens with still images of high
brightness or high contrast, such as found in video games
and computer programs. Over a long period of time it might
stick to the picture element. There is no problem with the
playback of moving images, e.g. normal video footage.
-
-
-
-
-
-
Not using the unit for a long time can lead to malfunction.
Please power it on and let it run occasionally. Please avoid
using the unit in a room where cigarettes are smoked. It is
impossible to clean optical component parts if they are
contaminated by nicotine or tar. This might lead to
performance degradation.
Please watch from a distance three times the height of the
projected image size. Persons with photosensitivity, any
kind of heart disease, or weak health should not use 3D
glasses.
Watching 3D-images might be cause of illness. If you feel
any change in your physical condition, please stop
watching immediately and consult a physician if necessary.
When watching 3D images, it is recommended to take
regular breaks. As the length and frequency of the required
breaks differ for every person, please judge according to
your own condition.
If your child watches while wearing 3D glasses, it should be
accompanied by its parents or an adult guardian. The adult
guardian should be careful to avoid situations where the
child’s eyes might become tired, as responses to tiredness
and discomfort, etc., are hard to detect, and it is possible
for the physical condition to deteriorate very quickly. As the
visual sense is not yet fully developed in children under the
age of 6, please consult a physician in regard to any
problem concerning 3D-images if necessary.
Note that when using the 3D feature, the video output may
appear different from the original video image due to image
conversion on the device.
* DO NOT allow any unqualified person to
install the unit.
Be sure to ask your dealer to install the unit
(e.g.attaching it to the ceiling) since special
technical knowledge and skills are required for
installation. If installation is performed by an
unqualified person, it may cause personal injury or
electrical shock.
-
-
-
-
-
-
-
Do not use optical instruments (such as magnifying glass or
reflector) viewing the laser output. It may pose an eye
hazard.
When turning on the projector, ensure that no one is looking
into the projection lens.
Do not look into the lens and openings when the light is on.
Doing so would have serious effects on the human body.
Do not detach or attach the projection lens with the power
connected.
Attempting to disassemble, repair or modify the projector
yourself may lead to serious safety issues.
Using a faulty product not only results in electrical shock or
fire hazard, it can cause visual impairment.
When abnormality occur, stop using the projector
immediately and send it to your authorized dealer for repair.
4
Getting Started

.
Power cord
Power cord
For European continent
countries
For United Kingdom
Green-and-yellow
Blue
Brown
Fuse
: Earth
: Neutral
: Live
POWER CONNECTION
WARNING:
WARNING:
Do not cut off the main plug from this
equipment.
The power supply voltage rating of this product is
AC100V – AC240V. Use only the power cord
designated by our dealer to ensure Safety and EMC.
Ensure that the power cable used for the projector is
the correct type for the AC outlet in your country.
Consult your product dealer.
If the plug fitted is not suitable for the power points
in your home or the cable is too short to reach a
power point, then obtain an appropriate safety
approved extension lead or adapter or consult your
dealer. If nonetheless the mains plug is cut off,
dispose of the plug immediately, to avoid a possible
shock hazard by inadvertent connection to the main
supply.
Dear Customer,
This apparatus is in conformance with the valid
European directives and standards regarding
electromagnetic compatibility and electrical safety.
European representative of
JVC KENWOOD Corporation is:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11,
61118 Bad Vilbel,
GERMANY
THIS APPARATUS MUST BE EARTHED.
IMPORTANT (Europe only):
The wires in the mains lead on this product are
colored in accordance with the following code:
IMPORTANT (Europe only):
POWER CONNECTION
(United Kingdom only)
When replacing the fuse, be sure to use only a
correctly rated approved type, re-fit the fuse cover.
IF IN DOUBT —— CONSULT A COMPETENT
ELECTRICIAN.
Open the fuse compartment with the blade
screwdriver, and replace the fuse.
(* An example is shown in the illustration below.)
As these colors may not correspond with the
colored making identifying the terminals in your
plug, proceed as follows:
The wire which is colored green-and-yellow must be
connected to the terminal which is marked M with
the letter E or the safety earth or colored green or
green-and-yellow. The wire which is colored blue
must be connected to the terminal which is marked
with the letter N or colored black.
The wire which is colored brown must be connected
to the terminal which is marked with the letter L or
colored red.
For USA and Canada only
Use only the following power cord.
5
Getting Started

.
ENGLISH
Information for Users on Disposal of Old Equipment and Batteries
[European Union only]
These symbols indicate that equipment with these symbols should not be disposed
of as general household waste. If you want to dispose of the product or battery,
please consider the collection systems or facilities for appropriate recycling.
Notice:
The sign Pb below the symbol for batteries indicates that this battery contains lead.
Benutzerinformationen zur Entsorgung alter Geräte und Batterien
[Nur Europäische Union]
Diese Symbole zeigen an, dass derartig gekennzeichnete Geräte nicht als normaler
Haushaltsabfall entsorgt werden dürfen. Wenden Sie sich zur Entsorgung des
Produkts oder der Batterie an die hierfür vorgesehenen Sammelstellen oder
Einrichtungen, damit eine fachgerechte Wiederverwertung möglich ist.
Hinweis:
Notification:
Das Zeichen Pb unterhalb des Batteriesymbols gibt an, dass diese
Batterie Blei enthält.
Informations relatives à l’élimination des appareils et des piles usagés, à l’intention des utilisateurs
[Union européenne seulement]
Si ces symboles figurent sur les produits, cela signifie qu’ils ne doivent pas être jetés
comme déchets ménagers. Si vous voulez jeter ce produit ou cette pile, veuillez
considérer le système de collecte des déchets ou les centres de recyclage appropriés.
La symbole Pb en dessous du symbole des piles indique que cette
pile contient du plomb.
Informatie voor gebruikers over het verwijderen van oude apparatuur en batterijen
[Alleen Europese Unie]
Deze symbolen geven aan dat apparatuur met dit symbool niet mag worden
weggegooid als algemeen huishoudelijk afval. Als u het product of de batterij wilt
weggooien, kunt u inzamelsystemen of faciliteiten voor een geschikte recycling
gebruiken.
Opmerking:
Het teken Pb onder het batterijsymbool geeft aan dat deze batterij lood bevat.
Battery
Products
Batterie
Produkte
Pile
Produits
Batterij
Producten
DEUTSCH
FRANÇAIS
NEDERLANDS
Información para los usuarios sobre la eliminación de baterías/pilas usadas
[Sólo Unión Europea]
Estos símbolos indican que el equipo con estos símbolos no debe desecharse
con la basura doméstica. Si desea desechar el producto o batería/pila, acuda
a los sistemas o centros de recogida para que los reciclen debidamente.
Atención: La indicación Pb debajo del símbolo de batería/pila indica que ésta
contiene plomo.
Baterías/pilas
Productos
ESPAÑOL / CASTELLANO
ITALIANO
Informazioni per gli utenti sullo smaltimento delle apparecchiature e batterie obsolete
[Solo per l’Unione Europea]
Questi simboli indicano che le apparecchiature a cui sono relativi non devono
essere smaltite tra i rifiuti domestici generici. Se si desidera smaltire questo
prodotto o questa batteria, prendere in considerazione i sistem i o le strutture di
raccolta appropriati per il riciclaggio corretto.
Nota:
Il simbolo Pb sotto il simbolo delle batter ie indica che questa batteria contiene piombo.
Batteria
Prodotti
6
Getting Started

.
As with any bright light source, do not stare into the
beam, RG2 IEC 62471-5:2015
Location information of the labels
7
Getting Started

Contents
Getting Started
Safety Precautions .................................................. 2
Accessories/Optional Accessories .......................... 9
Check the Accessories ........................................ 9
Optional Accessories ........................................... 9
Controls and Features ........................................... 10
Main Unit - Front ................................................ 10
Main Unit - Bottom ............................................. 10
Main Unit - Rear ................................................. 11
Main Unit - Input Terminals ................................ 12
Remote Control ................................................. 13
Loading Batteries into the Remote Control ........ 14
Effective Range of Remote Control Unit ............ 14
Set up
Installing the Projector ........................................... 15
Precautions during Installation ........................... 15
Precautions during Mounting ............................. 16
Adjusting the Position ........................................ 17
Connecting the Projector ....................................... 18
Connecting to the HDMI Input Terminal (Digital
Input) ................................................................. 18
Connecting to the LAN Terminal ........................ 19
Connecting to the RS-232C Terminal ................ 19
Connecting to the TRIGGER Terminal ............... 20
Connecting the Power Cord (Supplied Accessory) ...... 20
Operate
Viewing Videos ...................................................... 21
Adjusting the Projector Screen .............................. 23
Adjusting the Lens According to the Projection
Position .............................................................. 23
Saving and Retrieving Adjustment Settings ....... 24
Setting Screen Correction .................................. 26
Adjusting the Screen Size (Aspect) ................... 27
Viewing 3D Movies ................................................ 28
Installing the 3D Synchro Emitter ....................... 28
Viewing 3D Movies ............................................ 29
Adjusting 3D Movies .......................................... 29
Adjust/Set
Selecting an Image Quality According to the Video
Type ...................................................................... 30
Setting the Picture Mode ................................... 30
Setting the Color Profile ..................................... 31
Adjusting to the Preferred Color (Color
Management) .................................................... 32
Adjusting Movies for Increased Expressiveness
(Multiple Pixel Control) .......................................... 34
Fine-tuning the Image Quality ............................... 35
Adjusting the Output Value of the Projected Image
(Gamma) ........................................................... 35
Fine-tuning to the Preferred Gamma Setting ..... 36
Reducing the After-image of Fast-moving Images
(Blur Reduction) ................................................. 40
Viewing High Contrast Images (Lens Aperture) . 42
Adjustments and Settings in the Menu .................. 43
List of Menu Items ............................................. 43
Picture Adjust .................................................... 45
Input Signal ........................................................ 48
Installation ......................................................... 50
Display Setup .................................................... 56
Function ............................................................. 56
Information ......................................................... 58
Maintenance
Replacing the Lamp .............................................. 59
Lamp Replacement Procedure .......................... 59
Resetting the Lamp Time ................................... 61
Maintaining the Cabinet and Remote Control ........ 61
Cleaning and Replacing the Filter ......................... 62
Troubleshooting
Troubleshooting .................................................... 63
When the Following Messages Appear... .............. 67
Others
External Control .................................................... 68
RS-232C Specifications ..................................... 68
TCP/IP Connection ............................................ 68
Command Format .............................................. 69
Remote Control Code ........................................ 70
Communications Example ................................. 71
Specifications ........................................................ 72
Index ..................................................................... 81
8

Accessories/Optional Accessories
Check the Accessories
Remote control ....................................................................... 1 piece
.
AAA-size batteries (for operational check) ............................ 2 pieces
.
Power cord (for USA) (about. 2 m) (about. 78.7 in) ................. 1 piece
.
Power cord (for UK) (about. 2 m) ............................................ 1 piece
.
Power cord (for EU) (about. 2 m) ............................................ 1 piece
.
0Quick User Guide, safety precautions, warranty card, and other printed material are also included.
0Be sure to read the “Safety Precautions” before using this projector.
Optional Accessories
0Replacement lamp: Product no. PK-L2615U
03D Glasses: model PK-AG3
03D Synchro Emitter: model PK-EM2
Compatibility Chart for 3D Synchro Emitter and 3D Glasses
3D Glasses
PK-AG1 *
(Communication
Method: IR (Infrared))
PK-AG2 *
(Communication
Method: IR (Infrared))
PK-AG3
(Communication
Method: RF (Radio
frequency))
3D Synchro Emitter PK-EM1 *
(Communication
Method: IR (Infrared))
X X —
PK-EM2
(Communication
Method: RF (Radio
frequency))
— — X
* Discontinued product
Please check with your authorized dealer for details.
9
Getting Started

Controls and Features
Main Unit - Front
.
ABC
D
EE
ALens
This is a projection lens. Do not look through the lens
while an image is projected.
BLens cover
The lens cover opens/closes when the power supply
is turned on/off. (P. 50)
CRemote Sensor (front)
Please aim the remote control at this area when using
it.
* There is also a remote sensor at the rear.
DIndicator
Refer to “Indicator Display on the Main Unit”P. 78.
EExhaust vent
Warm air is discharged to cool down the internal
temperature.
Do not block the vents.
Main Unit - Bottom
FInlets (at 3 points on the rear/bottom)
The inlets take in air to cool down the internal temperature.
Do not block or prevent the outflow of hot air. Doing so may cause
the unit to malfunction.
* There are two inlets on the right and left sides at the rear of the unit.
GManual button for lens cover
The lens cover can be opened when pressed down.
It is used for maintenance purposes. You can also make use of it
when you need to open the lens cover urgently.
HFeet
The height and angle of the projector can be adjusted by turning the
foot. (0 to 5 mm) (0 to 0.2 in) (P. 17)
When the foot is removed, it can be used as the mounting holes for
the ceiling mount bracket.
FG
H
10
Getting Started

Main Unit - Rear
.
F
IKLM
F
J
IInput terminals
In addition to the video input terminal, there are also
other connection terminals for devices such as
controllers and optional equipment.
Please see “Main Unit - Input Terminals”P. 12 for
more details about the terminals.
JLamp cover
When replacing the light source lamp, remove this
cover.
KOperation panel
For more details, please refer to the “Operation
panel” in the diagram below.
LRemote sensor (rear)
Please aim the remote control at this area when using
it.
* There is also a remote sensor at the front.
MPower input terminal
Connect the supplied power cord to this terminal.
Operation panel
.
[MENU]: Displays the menu [BACK]: Returns to the previous menu
[JKH I] keys: Selects an item
[OK]: Confirms a selection
[INPUT]: Switches the input
A[STANDBY/ON]: Turns “on”/“off” the
power
11
Getting Started

Main Unit - Input Terminals
.
A B C
D
E
F
Enlarged View of Rear Face
A[HDMI 1] input terminal
B[HDMI 2] input terminal
For connecting to devices that support HDMI output.
(P. 18)
It is fitted to the M3 lock hole. The depth of the screw
hole is 3 mm (0.1 in).
C[LAN] terminal (RJ-45)
The projector can be controlled by connecting it to a
PC through the computer network for control
commands to be sent to the projector.
D[RS-232C] terminal (D-sub 9-pin
male)
The projector can be controlled by connecting a PC to
this terminal.
E[3D SYNCHRO] terminal
By connecting a 3D Synchro Emitter (sold separately)
to this terminal, you can view 3D movies.
F[TRIGGER] terminal (E)
Output terminal for DC 12 V, 100 mA power supply. It
is used for sending output signals to control devices
such as an elevating screen that is equipped with a
trigger function.
Note that improper connection may damage the
projector. (Tip=DC +12 V, Sleeve=GND)
12
Getting Started

Remote Control
AB [STAND BY]
Turns off the power. (P. 22)
BC [ON]
Turns on the power. (P. 21)
C[INPUT]
Switches the input to [HDMI 1] or
[HDMI 2]. (P. 21)
D[INFO.]
Displays the information menu.
(P. 58)
E[SETTING MEMORY]
Retrieves the [MODE 1] (LENS
MEMORY 1), [MODE 2] (LENS
MEMORY 2) or [MODE 3] (LENS
MEMORY 3) lens memory.
F[LENS CONTROL]
For adjusting focus, zoom, and
shift. (P. 23)
0Pressing the button each time
switches the function in the
following sequence: “Focus” "
“Zoom” " “Shift”...
G[LENS AP.]
For setting the lens aperture.
(P. 42)
H[ANAMO.]
Switches the anamorphic mode.
0Pressing the button each time
switches the anamorphic mode in
sequence.
I[HIDE]
Hides the image temporarily.
(P. 21)
J[LIGHT]
Illuminates the buttons on the
remote control.
K[JKH I] keys
For selecting an item.
L[OK]
Confirms a selected item.
M[MENU]
Displays the menu, or hides the
menu if it is displayed.
N[BACK]
Returns to the previous menu.
O[PICTURE MODE]
Switches the picture mode.
(P. 30)
0Press [NATURAL], [CINEMA] or
[HDR] to switch to the respective
picture mode.
0Pressing [PICTURE MODE]
displays the Picture mode
selection menu.
P[COLOR PROFILE]
Displays the color profile selection
menu. (P. 31)
Q[GAMMA SETTINGS]
Displays the gamma setting
menu.
R[ADVANCED MENU]
Pressing the button each time
switches the menu in the following
sequence: “Picture Mode” "
“Color Profile” " “Color Temp.” "
“Gamma” " “Blur Reduction”...
S[MPC]
Displays the MPC setting menu.
(P. 34)
T[C.M.D.]
For setting frame interpolation.
(P. 41)
0Pressing the button each time
switches the frame interpolation in
sequence.
U[GAMMA]
Switches the gamut. (P. 35)
0Pressing the button each time
switches the configurable gamma
in sequence.
V[COLOR TEMP.]
Switches the color temperature.
(P. 46)
0Pressing the button each time
switches the configurable color
temperature in sequence.
W[3D FORMAT]
For setting the 3D format.
(P. 29)
0Pressing the button each time
switches the 3D format in
sequence.
X[PIC. ADJ.]
Displays the picture quality
adjustment gauge. (P. 47)
0Pressing the button each time
displays the picture quality
adjustment gauge in sequence.
HDMI 1
INPUT
SETTING MEMORY
PICTURE MODE
HDMI 2 INFO.
NATURAL CINEMA HDR
MODE2MODE1 MODE3
ADVANCED
MENU
3D
FORMAT
PIC.
ADJ.
COLOR
TEMP.
GAMMA
C.M.D.MPC
LENS
CONTROL
LENS AP. ANAMO.
COLOR
PROFILE
GAMMA
SETTINGS
MODE
A
O
V
T
W
X
C
D
G
J
B
E
F
S
H
I
K
L
M
N
U
Q
P
R
13
Getting Started

Loading Batteries into the Remote Control
Loading the batteries
.
Removing the batteries
.
0If the remote control has to be brought closer to the unit
to operate, it means that the batteries are wearing out.
Replace the batteries with new ones (AAA).
0Insert the batteries according to the t s marks.
Be sure to insert the s end first.
When removing the battery, do so from the t end.
0If an error occurs while using the remote control,
remove the batteries and wait for five minutes. Load
the batteries again and operate the remote control.
CAUTION
0Do not put the remote control in a place with an
exposure to direct sun light or high temperature.
It may deformed due to heat, or the internal
components may be adversely affected resulting in
fire hazard.
0Remove the batteries from the remote control when
storing the remote control.
Storing the remote control for a prolonged period
without removing the batteries can cause battery
leakage.
Effective Range of Remote Control Unit
When aiming the remote control toward the sensor on this
unit (front or rear), ensure that the distance to the sensor
is within 7 m.
If the remote control fails to work properly, move closer
to this unit.
.
30°
30°
20°
20°
Remote Control
This unit
Control through reflection off a screen, etc.
Ensure that the total of distance A (between this unit and
the screen) and distance B (between the remote control
and the screen) is within 7 m.
*As the efficiency of signals reflected from the remote
control unit varies with the type of screen used, the
operable distance may decrease.
.
A
B
30°
30°
20°
20°
20°
20°
20°
20°
Screen
Remote Control
This unit
CAUTION
0Do not put the remote control in a place with an exposure to direct sun light or high temperature.
It may deformed due to heat, or the internal components may be adversely affected resulting in fire hazard.
0Remove the batteries from the remote control when storing the remote control.
Storing the remote control for a prolonged period without removing the batteries can cause battery leakage.
14
Getting Started

Installing the Projector
Precautions during Installation
Please read the following carefully before installing this
unit.
Do not install at the following
This unit is a precision device. Please refrain from
installing or using it at the following locations. Otherwise,
it may cause fire or malfunction.
0Dusty, wet and humid places
0Places subject to oily smoke or cigarette smoke
0On top of a carpet or bedding, or other soft surfaces
0Places exposed to direct sunlight
0Places with a high or low temperature
0Do not install this unit in a room that is oily or subject
to cigarette smoke. Even a small quantity of smoke or
oiliness can have a long-term impact on this unit.
* This unit produces a great amount of heat, and is
designed to take in cool air to cool its optical
components. Using the unit at the above locations
may cause dirt to attach to the light path, thereby
resulting in dark images or dull colors.
*Dirt that sticks to the optical components cannot be
removed.
Maintain clearance from the wall, etc.
As the unit discharges a large amount of heat, install it
with adequate clearance from the surroundings as shown
below.
.
Front
200 mm
(8 in) and
above
300 mm
(12 in) and
above
300 mm
(12 in) and
above
150 mm (6 in) and above
150 mm
(6 in) and
above
Leave the front area of the unit unblocked.
If there is any obstructing object in front of the exhaust
vent, hot air will flow back to the unit and cause it to heat
up. Hot air flowing out of the unit may cast shadows on
the screen (heat haze phenomenon).
Using the projector
This unit uses a projection lamp, which will heat up when
in use.
Please refrain from projecting in the following
circumstances. Otherwise, it may cause fire or
malfunction.
0Projection with the unit stood vertically
.
0Projection with the unit inclined at an angle
Horizontal inclination: within ± 5 °
.
5° 5°
Vertical inclination: within ± 15 °
.
15°
15°
15°
15°
0Malfunction may occur if the angle is not set within the
abovementioned range.
Installing the screen
Install the unit and the screen such that they are
perpendicular to each other.
.
Screen
Front
0Please choose a screen material with non-uniform
patterns. Uniform patterns such as checks may cause
interference patterns to occur.
0In this case, you can change the size of the screen to
make the interference patterns less noticeable.
Using the projector at a high altitude
When using this unit at a location that is higher than 900
m (3,000 ft) above sea level (low air pressure), set “High
Altitude Mode” to “On”. (P. 52)
15
Set up

Precautions during Mounting
Securing (mounting) the projector
.
0When this unit is to be mounted to a fixed position for
use, install it horizontally.
0Make sure to secure the main unit to prevent accidents
such as during an earthquake.
Securing with screws
.
Air Inlets
4 Locations
Remove the four feet at the bottom, and fasten using the
screws (M5 screws, 13 to 23 mm).
* Using screws other than those designated may cause
the unit to break down.
* Leave a clearance of at least 10 mm (0.4 in) from the
bottom surface of the unit to allow it to take in cool air.
Securing the projector (ceiling mount)
.
0Be sure to ask your dealer to install the unit for you.
Installing the unit on your own may cause the unit to
fall resulting in injury.
0Take the necessary actions to prevent the main unit
from falling off such as during an earthquake.
0Regardless of the warranty period, JVC is not liable for
any product damage caused by mounting the unit with
non-JVC ceiling fittings or to an environment that is not
suited for ceiling mount.
0When using the unit with it suspended from a ceiling,
pay attention to the surrounding temperature. When a
heater is in use, the temperature around the ceiling
may be higher than expected.
0To attach the unit to the ceiling mount bracket, set the
torque between the range of 1.5N m to 2.0N m.
Tightening with torque exceeding the above range
may cause damage to the unit, which may result the
unit to fall.
0Install the outlet at an accessible height to unplug from
the wall. Or install the circuit breaker at an accessible
height to shut down the projector. If you need
information, please consult your authorized dealer or
specialist.
16
Set up

Adjusting the Position
Adjusting the elevation angle of the projector
The height and inclination of the unit (0 to 5 mm (0 to 0.2
in)) can be adjusted by turning the feet.
Lift the unit and adjust the four feet.
.
ContractExtend
Feet
Adjusting the position of the image
By using the lens shift feature of this unit, you can shift
the image upward/downward or to the left/right. Set it to
your preferred position.
Æ “Adjusting the Lens According to the Projection
Position” (P. 23)
.
90
80
70
60
50
40
30
20
10
0 10 3020 40
Lens movement range
Horizontal lens shift (%)
Vertical lens shift (%)
Lens shift Range
Up to about 80% of the
projected image
Horizontal Position: 0 % (Center)
Vertical Position
Up to about 34% of the
projected image
Vertical Position: 0% (Center)
Horizontal Position
■
■
■
0The maximum vertical shift varies with the amount of
horizontal shift. Similarly, the maximum horizontal shift
also changes with the amount of vertical shift.
0The values on the graph are intended as a guide. Use
them for reference during installation.
17
Set up

Connecting the Projector
0Do not turn on the power until connection is complete.
0The connection procedures differ according to the device used. For details, please refer to the instruction manual of
the device to be connected.
0This projector is used for projecting images. To output the audio of connected devices, please connect a separate
audio output device, such as an amplifier or speaker.
0The images may not be displayed depending on the devices and cables to be connected.
A high speed HDMI cable (sold separately) that is HDMI-certified is recommended.
When using a standard cable, you are recommended to set the resolution of the equipment transmitting the video to
1080i or lower.
0Also, please refer to “HDMI2 EDID”P. 49.
0Some cables cannot be connected to this unit due to the size of their connector cover.
Connecting to the HDMI Input Terminal (Digital Input)
Connecting via HDMI cable
.
HDMI Output Terminal
BD/DVD Recorder, etc.
Laptop, etc.
HDMI Cable (Sold Separately)
This Unit
To [HDMI 1] or [HDMI 2] input
terminal
0If noise occurs, move the laptop away from this unit.
Connecting through an AV amplifier
.
HDMI Cable
(Sold Separately)
BD/DVD Recorder, etc.
HDMI Cable (Sold Separately)
This Unit
To [HDMI 1] or [HDMI 2] input
terminal
Speaker Cable
(Sold Separately)
Speakers
AV Amplifier
0If the source device is connected to the projector through an intermediate device such as an AV amplifier or divider,
the video image may not appear depending on the specifications of the intermediate device.
In this case, connect the source device directly to the projector, and check whether the video image is displayed.
18
Set up

Connecting via HDMI-DVI conversion cable
.

HDMI-DVI Conversion Cable (Sold Separately)
To [HDMI 1] or [HDMI 2] input
terminal
This Unit
DVI Output Terminal
Desktop PC, etc.
0If noise occurs, move the desktop PC away from this unit.
0If the video is not displayed, try to reduce the length of the cable or lower the resolution of the video transmitting
equipment.
Connecting to the LAN Terminal
.
Desktop PC, etc. Server
Hub
Network
Connection Cable
(Sold Separately)
This Unit
To [LAN] Terminal
0The network is used to control this unit. It is not used for sending or receiving video signals.
0Please contact your network administrator for information concerning the network connection.
0Set “ECO Mode” to “Off” if LAN communication is performed in the Standby mode. (P. 57)
0For more information on control, please refer to “External Control”P. 68.
Connecting to the RS-232C Terminal
.
RS-232C Terminal
Laptop, etc.
RS-232C Connection Cable (Sold Separately)
To [RS-232C] Terminal
This Unit
0Set “ECO Mode” to “Off” if RS-232C communication is performed in the Standby mode. (P. 57)
0For more information on control, please refer to “External Control”P. 68.
19
Set up

Connecting to the TRIGGER Terminal
.
Trigger Input Terminal (Ø3.5)
Screen
Trigger Cable (Sold Separately)
To [TRIGGER] Terminal
This Unit
0Do not use it to supply power to other devices.
0Connecting to the audio terminal of another device may cause the device to malfunction or break down.
0Using beyond the rated value will cause the unit to malfunction.
0The trigger terminal outputs a voltage of 12 V. Exercise adequate caution to prevent short circuit.
0The factory setting is “Off”. To change the setting, configure the “Trigger” item in the menu (P. 56).
Connecting the Power Cord (Supplied Accessory)
AConnect the power cord supplied to the power input terminal on
the main unit
BInsert the supplied power plug into the wall outlet.
Precautions to prevent fire and electric shock
0The power consumption of this unit is large. Please connect it directly to the wall outlet.
0When you are not using the projector, please unplug the power cord from the outlet.
0Connect it using only the power cord supplied.
0Do not use a voltage other than the indicated power voltage.
0Do not damage, break or modify the power cord. Do not place a heavy object on the power cord, or heat or pull it.
Doing so may damage the power cord.
0Do not unplug the power cord with wet hands.
A
B
Power Cord
(Supplied)
20
Set up
