JVC DLA-RS55 Installation guide

DLA-RS55
D-ILA Projector
4K Resolution and 80,000:1
Native Contrast Ratio Ensure Film-like
Image Reproduction
• 4K (3,840 x 2,160 pixels) D-ILA projector
• High native contrast ratio of 80,000:1
• Minimized crosstalk for brighter, more
realistic 3D picture
• 2D-3D conversion creates dynamic 3D video
content from 2D video sources
• JVC original Real Color Imaging Technology
• Various picture adjustment functions ensure
a high-quality picture
• Screen Adjustment modes (101 modes*)
• Convenient lens memory function
• Pixel Adjust function corrects color
distortion in 1/16-pixel increments
• Motorized lens cover automatically opens or
closes the lens
*Capable of increasing up to 255 modes with firmware upgrade.
Notet: Optional 3D Glasses (PK-AG2 or PK-AG1) and 3D Synchro Emitter (PK-EM1) are required for viewing images in 3D.

Printed in Japan
CCN-3715-27
"JVC" is the trademark or registered trademark of JVC KENWOOD Corporation.
pro.jvc.com
www.ReferenceSeries.com
DISTRIBUTED BY
• The projector is equipped with an ultra-high pressure mercury lamp, which may break, emitting a loud noise, when it is subjected to shock or after it has been used for some length of time. • Please note that,
depending on how the projector is used, there can be considerable difference between individual lamps regarding how many hours they will operate before requiring replacement. • An additional payment is
required for installation of a new lamp, if necessary. • The projector lamp requires periodic replacement and is not covered by warranty. • Please be aware that, because the D-ILA device is manufactured using
highly advanced technologies, 0.01% or fewer of the pixels may be non-performing (always on or off).
Design and specifications are subject to change without notice. All pictures on this brochure are simulated. Adobe is a trademark or registered trademark of Adobe Systems Incorporated in the U.S. and/or
other countries. ISF is a registered trademark of Imaging Science Foundation, Inc. THX and THX logo are trademarks of THX Ltd., which may be registered in some jurisdictions. HDMI, the HDMI logo and High-
Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC. All other brand or product names may be trademarks and/or registered trademarks of their respective owners. Any rights not
expressly granted herein are reserved.
Copyright Q 2011, JVC KENWOOD Corporation. All Rights Reserved.
Super High-definition 4K Projection
A newly developed optical engine
incorporating three D-ILA devices and
the new e-shift technology, which shifts
one pixel for every 0.5 pixels, are used
together to realize super high-definition
4K-resolution (3,840 x 2,160 pixel)
projection. Unlike ordinary resolution-
upscaling technology employed on full
HD projectors, 4K projection with e-shift technology dramatically improves picture
quality by ensuring exceptionally precise images with ample presence.
D-ILA 3D Projection*
JVC's original D-ILA driving method reproduces superlative 3D content with vivid
colours and helps to reduce crosstalk. But best of all, DLA-RS55 is also equipped
with other innovative 3D functions.
4725
455
4545
80
11 128
472
179
24
ø60
45 45
11 128
45 45
11 128
337
29091
11755
58
41 37
79 48
11755
48
4725
455
4545
80
11 128
472
179
24
ø60
45 45
11 128
45 45
11 128
337
29091
11755
58
41 37
79 48
11755
48
Front Side
• 2D-3D Conversion: The real-time 2D-3D converter featured on JVC’s IF-2D3D1 Professional 3D
Image Processor has been modified for home projector use and is now featured on the DLA-RS55.
This means that 2D video recorded on camcorders and from TV broadcasts can be converted into
3D video instantaneously for home stereoscopic viewing enjoyment. Other adjustment functions
are available such as Depth Adjustment for matching 3D effects to the original source or viewer
preferences, and adjustment of subtitle distortion that can be generated during 2D-3D conversion.
*The optional 3D Synchro Emitter and 3D glasses are required to view 3D images.
• Crosstalk Cancelling: The innovative Crosstalk Cancelling function significantly reduces
crosstalk from intensity levels that are likely to generate this phenomenon by first analyzing the
video signal for the left and right eyes and
then correcting the levels via an original
algorithm. This ensures the reproduction
of more natural and clearer images that are
easier on the eyes to heighten the viewing
enjoyment of realistic 3D video content. Crosstalk Cancelling OFF Crosstalk Cancelling ON
■ Connectors ■ Optional Equipment
Native Contrast Ratio of 80,000:1
A high native contrast of 80,000:1 has
been achieved on the DLA-RS55 through
an improved optical engine employing
original D-ILA devices and a wire grid. A
wide dynamic picture range from peak
whites to deep blacks also helps to ensure
superb picture quality with a heightened
sense of immersion and depth.
Real Color Imaging Technology
Real Color Imaging Technology incorporates an exclusive Color Profile created by
precisely analyzing color information from original film prints, a Wide Color Space
broader than Adobe RGB, and a Xenon-lamp Color Temperature Setting equivalent
to a Xenon lamp to optimize color
replication and heighten picture quality
to recreate 3D content that is as faithful
to the original source as possible.
Conventional color
temperature setting
Xenon-mode color
temperature setting
DLA-RS55
Device 0.7 inch Full HD D-ILA (1920 x 1080) x3
e-shift Technology Yes
Resolution 3840 x 2160*1
Lens x2 Zoom & Focus: Motorised f=21.4-42.8mm / F3.2-4
Lens Shift ±80% Vertical and ±34% Horizontal (motorised)
Light Source Lamp 220W Ultra-High Pressure Mercury Lamp
(lamp life: approx. 3000 hours when the lamp is in Normal mode)
Brightness*2 1,200lm
Contrast Ratio Native: 80,000:1
Connectors
Component 1 (RCA; Y, PB/CB, PR/CR)
HDMI 2 (3D/Deep Colour/CEC compatible)
Analog RGB (PC) 1 (D-sub15pin)
RS-232C 1 (D-sub 9pin)
LAN (RJ-45) 1
Trigger 1 (Mini jack , DC12V/100mA)
Remote 1 (Mini jack)
3D Sync 1 (Mini Din 3pin)
Video Input Signal
Format
Digital 480i/p, 576i/p, 720p 60/50, 1080i 60/50,1080p 60/50/24
Analog 480i/p, 576i/p, 720p 60/50, 1080i 60/50
PC Input Signal Format
HDMI VGA/SVGA/XGA/WXGA/WXGA+/SXGA/WSXGA+/WUXGA
Analog RGB (D-sub 15 pin) VGA/SVGA/XGA/WXGA/WXGA+/SXGA/SXGA+
/WSXGA+/1920x1080/Mac 13”,16”19”
3D Format
Frame Packing 720p 60/50,1080p 24,1080i 60/50
Side-by-Side (half) 720p 60/50, 1080p 60/50, 1080i 60/50
Top & Bottom 720p 60/50, 1080p/24
Noise 20dB (Lamp normal mode)
Power Requirement AC 110-240V,50/60Hz
Power Consumption 360W (Stand-by: 0.8W)
Dimensions 455x179x472 mm
Weight 15.4kg
■ Specifications
*1 Resolution is 1920x1080 at 3D mode. *2 Measurement, measuring conditions, and method of notation all comply with ISO 21118.
Full HD
1920 X 1080
4K
3840 X 2160
Conventional projector DLA-RS55
■ External Dimensions (unit: mm)
■ Projection Distance Chart
Display size (16:9) Projection distance
Screen diagonal (inch) W (mm) H (mm) Wide (m) Tele (m)
60 1,328 747 1.78 3.66
70 1,549 872 2.09 4.28
80 1,771 996 2.40 4.89
90 1,992 1,121 2.70 5.51
100 2,214 1,245 3.01 6.13
110 2,435 1,370 3.31 6.75
120 2,656 1,494 3.62 7.36
130 2,878 1,619 3.92 7.98
140 3,099 1,743 4.23 8.60
150 3,320 1,868 4.53 9.22
160 3,542 1,992 4.84 9.84
170 3,763 2,117 5.14 10.45
180 3,984 2,241 5.45 11.07
190 4,206 2,366 5.75 11.68
200 4,427 2,490 6.06 12.30
*Projection distances are design specifications, so there is ±5% variation.
Notes about viewing 3D video content
• The optional 3D Synchro Emitter and 3D glasses are required to view 3D images. 3D video software (3D media or out put of
3D broadcasts) and a 3D-compatible video player are also required. • Perception of 3D images will vary with individual viewers.
• Stop viewing 3D images immediately if any discomfort such headaches, dizziness, eye fatigue, etc. occur. • Viewing of 3D images by
children under the age of five is not recommended. • Read the Safety Precautions in the User Manual carefully before viewing any 3D source.
4725
455
4545
80
11 128
472
179
24
ø60
45 45
11 128
45 45
11 128
337
29091
11755
58
41 37
79 48
11755
48
Top Bottom User-replaceable
Lamp
PK-L2210U
3D Glasses
PK-AG2
Rechargeable Type
3D Glasses
PK-AG1
Battery-operated Type
3D Synchro
Emitter
PK-EM1
