JVC SP-AD80-B Manual

Instruction Manual
360º Portable wireless
speaker
SP-AD80-B / SP-AD80-G
SP-AD80-x_IB_170626_will.indd 1 26/6/2017 12:18 PM

SP-AD80-x_IB_170626_will.indd 2 26/6/2017 12:18 PM

Contents
Safety Warnings.............................................................. 5
Unpacking ..................................................................... 12
Product Overview......................................................... 13
Front View...................................................................................13
Rear View ....................................................................................14
Top View......................................................................................16
Bottom View..............................................................................18
Important Information about Water Resistant
Operation ...................................................................... 19
Charging the Speaker .................................................. 21
Battery Life................................................................................ 22
When the Battery is Almost Empty ................................. 23
Charging an External Device....................................... 25
Connection.................................................................... 26
Using the AUX Connection................................................. 26
Stereo Pairing Function............................................... 27
General Operation........................................................ 29
Powering ON/OFF................................................................... 29
SP-AD80-x_IB_170626_will.indd 3 26/6/2017 12:18 PM

Automatic Power O Function ......................................... 29
Adjusting the Volume........................................................... 30
Torch Function .............................................................. 30
Bluetooth® Operation................................................... 31
NFC (Near Field Communication) Operation ............ 33
Listening to Music ........................................................ 34
Bluetooth® Mode ..................................................................... 34
AUX Mode.................................................................................. 35
Hands-free Calling........................................................ 36
Making a Call .............................................................................37
Redial............................................................................................37
End Call........................................................................................37
Receiving a Call ....................................................................... 38
Reject an Incoming Call ....................................................... 38
Maintenance ................................................................. 39
Hints and Tips................................................................40
Product Fiche and Specifications...............................44
Others Information and Licences............................... 47
SP-AD80-x_IB_170626_will.indd 4 26/6/2017 12:18 PM

5
Safety Warnings
• Read all the instructions carefully before using the
unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch o and consult your dealer.
Location of Unit
• The unit must be placed on a at stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall o or tip over.
• Do not place the unit close to table edge. It may fall
o due to vibration during high volume listening.
SP-AD80-x_IB_170626_will.indd 5 26/6/2017 12:18 PM

6
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other sources
of heat.
Naked Flames
• Never place any type of candle or naked ame on the
top of or near the unit.
Moisture
• Do not submerge this unit in water. It can cause
serious damage.
Water Resistance
• In compliance with IPX7.
• To ensure the water resistance of the unit, all covers
for the USB port must be rmly closed.
SP-AD80-x_IB_170626_will.indd 6 26/6/2017 12:18 PM

7
• Even if your device is resistant to dust and water,
you should avoid using it unnecessarily to
environments with excessive dust, sand and mud
or to moist environments with extreme high or low
temperatures. The water resist ability cannot be
guaranteed in all environments or conditions.
Interference
• Do not place the unit on or near appliances which
may cause electromagnetic interference. If you do, it
may adversely aect the operating performance of
the unit, and cause a distorted sound.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-
serviceable parts. Please leave all maintenance work
to qualied personnel.
• Do not open any xed covers as this may expose
dangerous voltages.
SP-AD80-x_IB_170626_will.indd 7 26/6/2017 12:18 PM

8
Built-in Battery Care
• Your product is powered by a rechargeable battery.
• The battery can be charged and discharged
hundreds of times, but will eventually wear out.
• Unplug the charger from the electrical plug and the
product when not in use.
• Do not leave a fully charged battery connected to a
charger, since overcharging may shorten its lifetime.
• If left unused, a fully charged battery will lose its
charge over time.
• Leaving the product in hot or cold places, such as in a
closed car in the summer and winter conditions, will
reduce the capacity and lifetime of the battery.
• Always try to keep your device in a cool, moisture-
free environment that’s less than 32°C. A product
with a hot or cold battery may not work temporarily,
even when the battery is fully charged. Battery
performance is particularly limited in temperatures
well below freezing.
SP-AD80-x_IB_170626_will.indd 8 26/6/2017 12:18 PM

9
• The unit should be fully recharged after using the
device each time. This will keep the health of the
battery.
• If you plan to store your device for longer than six
months, charge the battery for an hour every six
months to keep it fresh.
Battery warning!
• The battery used in this product may present a risk of
re or chemical burn if mistreated.
• Do not attempt to open the product or replace the
battery. It is built-in and not changeable. Use of other
batteries may present a risk of re or explosion and
the warranty will be terminated.
• Only recharge your battery with the provided USB
cable designated for this product.
• Dispose of batteries according to local regulations.
Please recycle when possible. Do not dispose as
household waste or in a re as they may explode.
• Batteries may explode if damaged.
SP-AD80-x_IB_170626_will.indd 9 26/6/2017 12:18 PM

10
Maintenance
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
SP-AD80-x_IB_170626_will.indd 10 26/6/2017 12:18 PM

11
Thank you for purchasing your new
product.
We recommend that you spend some time
reading this instruction manual in order that you
fully understand all the operational features it
oers. You will also nd some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
SP-AD80-x_IB_170626_will.indd 11 26/6/2017 12:18 PM

12
Unpacking
Remove all items from the packaging. Retain
the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
• Main Unit
• USB to Micro USB Cable
• 3.5mm to 3.5mm Stereo Audio Cable
• Instruction Manual
If items are missing, or damaged please contact
Partmaster (UK only). Tel: [phone] for assistance.
SP-AD80-x_IB_170626_will.indd 12 26/6/2017 12:18 PM

13
Product Overview
11
Front View
1. Speakers
2. Built-in microphone
Manually open the jack cover at the rear of
the unit for the connector panel. Do not use
any metal or sharp objects to open the jack
cover, because they will damage the rubber
and impact the waterproong function.
2
SP-AD80-x_IB_170626_will.indd 13 26/6/2017 12:18 PM

14
Rear View 1. Carrying Strap
2. ON/OFF Button
• Press and hold to switch
on the unit.
• Press and hold to switch
o the unit.
3. Battery Indicator
• Flash blue when the unit
is in ON mode, and is
searching for Bluetooth
device.
• Light up red when
charging.
• Switch o when the unit is
fully charged.
3
2
1
SP-AD80-x_IB_170626_will.indd 14 26/6/2017 12:18 PM

15
4. Torch Button
• Press and hold to switch
the torch light ON.
• When the torch light is
on, press repeatedly to
switch it in Dim/Flashing/
O mode.
5. Aux in Socket
Connect a music player, etc.
to this socket by using the
supplied Stereo Audio Cable.
6. DC in 5V Socket
Connect a computer, etc. to
this socket with the supplied
micro-USB cable to charge
the unit.
7. 5V 1A Charge out Socket
Supply 5V 1.0 A max for
charging an external unit.
4
5
6
7
SP-AD80-x_IB_170626_will.indd 15 26/6/2017 12:18 PM

16
Top View
1 2
3 4
1. Button
The stereo pairing function is
only available when you have
two speakers:
• After you have switched
on both speakers, press
and hold for about 5
seconds on one speaker.
The two speakers will be
automatically connected.
• Press and hold this button
on one of the speakers
to disconnect the two
connected speakers
Button
• Press to answer/end
an incoming call in
Bluetooth® mode.
• Press twice to dial the
last called number.
SP-AD80-x_IB_170626_will.indd 16 26/6/2017 12:18 PM

17
• Press and hold to reject an
incoming call.
2. Volume +/– Button
• Press and hold +/– button to
increase/decrease the volume.
• Press +/– button to skip to the
next/previous track in Bluetooth
mode.
3. NFC sensor
4. Button
• Press to activate the pairing
function in Bluetooth® mode.
• Press and hold to disconnect
the existing paired Bluetooth®
device.
SP-AD80-x_IB_170626_will.indd 17 26/6/2017 12:18 PM

18
Bottom View
1
1. Torch light
SP-AD80-x_IB_170626_will.indd 18 26/6/2017 12:18 PM

19
Important Information about
Water Resistant Operation
For proper water resistant operation, make sure
the plastic jack cover of the unit is completely ush
with the unit by pressing along the entire edge
of the cover until it is completely and securely in
place.
The unit is IPX7 splash proof rated. However, DO NOT
immerse the unit in water. It may cause product failure.
• Make sure the jack cover and surrounding
surfaces are completely dry before opening the
jack cover to prevent moisture from damaging
the internal electronics.
SP-AD80-x_IB_170626_will.indd 19 26/6/2017 12:18 PM

20
• Keep the jack cover free of dirt, sand, or other
objects that can interfere with proper sealing.
If for any reason the jack cover is not making a
tight waterproof seal water may enter the unit.
• DO NOT clean unit with oily soaps or use
chemicals or solvents. Clean with damp cloth.
SP-AD80-x_IB_170626_will.indd 20 26/6/2017 12:18 PM
