JVC SP-AD85-A User manual

Instruction Manual
360 degree Portable
Bluetooth speaker
SP-AD85-A / SP-AD85-B
SP-AD85-x_IB_Final191104V3.indd 1 04/11/2019 15:18

SP-AD85-x_IB_Final191104V3.indd 2 04/11/2019 15:18

Contents
Safety Warnings..........................................................5
Unpacking .................................................................13
Product Overview..................................................... 14
Front View............................................................................. 14
Rear View............................................................................... 15
Top View ................................................................................ 16
Important Information about Water Resistant
Operation ..................................................................18
Charging the Speaker ..............................................20
Battery Life ........................................................................... 21
When the Battery is Almost Empty.............................22
Connection................................................................24
Using the AUX Connection ............................................ 24
Charging from the USB socket................................25
General Operation....................................................26
SP-AD85-x_IB_Final191104V3.indd 3 04/11/2019 15:18

Powering ON/OFF..............................................................26
Automatic Power O Function.....................................26
Adjusting the Volume......................................................27
Bluetooth® Operation...............................................28
NFC (Near Field Communication) Operation ........30
Listening to Music ....................................................31
Bluetooth® Mode................................................................. 31
AUX IN Mode........................................................................32
Hands-free Calling....................................................33
Making a Call........................................................................34
Redial ......................................................................................34
End Call...................................................................................34
Receiving a Call................................................................... 35
Reject an Incoming Call...................................................35
Maintenance .............................................................36
Hints and Tips............................................................37
Product Fiche and Specifications...........................42
Others Information and Licences...........................44
SP-AD85-x_IB_Final191104V3.indd 4 04/11/2019 15:18

5
Safety Warnings
• Read all the instructions carefully before using the
unit and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch o and consult your dealer.
Location of Unit
• The unit must be placed on a at stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces
as the unit may fall o or tip over.
• Do not place the unit close to table edge. It may fall
o due to vibration during high volume listening.
SP-AD85-x_IB_Final191104V3.indd 5 04/11/2019 15:18

6
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other sources
of heat.
Naked Flames
• Never place any type of candle or naked ame on the
top of or near the unit.
Moisture
• Do not submerge this unit in water. It can cause
serious damage.
Water Resistance
• In compliance with IPX7.
• To ensure the water resistance of the unit, all covers
for the USB port must be rmly closed.
SP-AD85-x_IB_Final191104V3.indd 6 04/11/2019 15:18

7
• Even if your device is resistant to dust and water,
you should avoid using it unnecessarily to
environments with excessive dust, sand and mud
or to moist environments with extreme high or low
temperatures. The water resist ability cannot be
guaranteed in all environments or conditions.
Ventilation
• To prevent the risk of electric shock or re hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another conned space. Ensure the unit
is well ventilated.
Interference
• Do not place the unit on or near appliances which
may cause electromagnetic interference. If you do, it
may adversely aect the operating performance of
the unit, and cause a distorted sound.
SP-AD85-x_IB_Final191104V3.indd 7 04/11/2019 15:18

8
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-
serviceable parts. Please leave all maintenance work
to qualied personnel.
• Do not open any xed covers as this may expose
dangerous voltages.
Built-in Battery Care
• Your product is powered by a rechargeable battery.
• The battery can be charged and discharged
hundreds of times, but will eventually wear out.
• Unplug the charger from the electrical plug and the
product when not in use.
• Do not leave a fully charged battery connected to a
charger, since overcharging may shorten its lifetime.
• If left unused, a fully charged battery will lose its
charge over time.
SP-AD85-x_IB_Final191104V3.indd 8 04/11/2019 15:18

9
• Leaving the product in hot or cold places, such as in a
closed car in the summer and winter conditions, will
reduce the capacity and lifetime of the battery.
• Always try to keep your device in a cool, moisture-
free environment that’s less than 32°C. A product
with a hot or cold battery may not work temporarily,
even when the battery is fully charged. Battery
performance is particularly limited in temperatures
well below freezing.
• The unit should be fully recharged after using the
device each time. This will keep the health of the
battery.
• If you plan to store your device for longer than six
months, charge the battery for an hour every six
months to keep it fresh.
SP-AD85-x_IB_Final191104V3.indd 9 04/11/2019 15:18

10
Battery warning!
• The battery used in this product may present a risk of
re or chemical burn if mistreated.
• Do not attempt to open the product or replace the
battery. It is built-in and not changeable. Use of other
batteries may present a risk of re or explosion and
the warranty will be terminated.
• Only recharge your battery with the provided
approved charger or USB cable designated for this
product.
• Dispose of batteries according to local regulations.
Please recycle when possible. Do not dispose as
household waste or in a re as they may explode.
• Batteries may explode if damaged.
SP-AD85-x_IB_Final191104V3.indd 10 04/11/2019 15:18

11
Maintenance
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
~ AC voltage: This symbol indicates that the rated
voltage marked with the symbol is AC voltage.
DC voltage: This symbol indicates that the rated
voltage marked with the symbol is DC voltage.
SP-AD85-x_IB_Final191104V3.indd 11 04/11/2019 15:18

12
Thank you for purchasing your new
product.
We recommend that you spend some time
reading this instruction manual in order that you
fully understand all the operational features it
oers. You will also nd some hints and tips to
help you resolve any issues.
Read all the safety instructions carefully before
use and keep this instruction manual for future
reference.
SP-AD85-x_IB_Final191104V3.indd 12 04/11/2019 15:18

13
Unpacking
Remove all items from the packaging. Retain
the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
• Main Unit
• USB to Micro USB Cable
• 3.5mm to 3.5mm Stereo Audio Cable
• Instruction Manual
If items are missing, or damaged please contact
Partmaster (UK only). Tel: [phone] for assistance.
SP-AD85-x_IB_Final191104V3.indd 13 04/11/2019 15:18

14
Product Overview
Front View
1. Speakers
2. Built-in microphone
Manually open the jack cover at the
rear of the unit for the connector panel.
Do not use any metal or sharp objects
to open the jack cover, because they
will damage the rubber and impact the
waterproong function.
11
2
SP-AD85-x_IB_Final191104V3.indd 14 04/11/2019 15:18

15
Rear View 1. Strap Hole
Attach the carry strap with the
unit for easy carrying.
2. ON/OFF Button
• Press to switch the unit On / O.
• Flash slowly when charging.
• Light up when the unit is fully
charged.
3. Aux in Socket
Connect a music player, etc. to this
socket by using a supplied Stereo
Audio Cable.
4. I/P: 5V 1A Socket
Connect a computer, etc. to this
socket with the supplied micro-
USB cable to charge the unit.
5. O/P: 5V 2.1A Socket
Supply 5V 2.1A max. for charging
an external unit.
O/P: 5V 2.1A
I/P: 5V 1A
3
2
1
4
5
SP-AD85-x_IB_Final191104V3.indd 15 04/11/2019 15:18

16
Top View
1 2
3 4
1. Button
• Press to answer/end an
incoming call in Bluetooth®
mode.
• Press twice to dial the last
called number.
• Press and hold to reject an
incoming call.
2. Volume +/– Button
• Press / Press and hold +
button to increase the
volume.
• Press / Press and hold –
button to decrease the
volume.
3. NFC sensor
SP-AD85-x_IB_Final191104V3.indd 16 04/11/2019 15:18

17
4. Button
• Press to activate the pairing
function in Bluetooth®
mode.
• Press and hold to
disconnect the existing
paired Bluetooth® device.
SP-AD85-x_IB_Final191104V3.indd 17 04/11/2019 15:18

18
Important Information about
Water Resistant Operation
For proper water resistant operation, make sure
the plastic jack cover of the unit is completely ush
with the unit by pressing along the entire edge
of the cover until it is completely and securely in
place.
The unit is IPX7 splash proof rated. However, DO NOT
immerse the unit in water. It may cause product failure.
• Make sure the jack cover and surrounding
surfaces are completely dry before opening the
jack cover to prevent moisture from damaging
the internal electronics.
SP-AD85-x_IB_Final191104V3.indd 18 04/11/2019 15:18

19
• Keep the jack cover free of dirt, sand, or other
objects that can interfere with proper sealing.
If for any reason the jack cover is not making a
tight waterproof seal water may enter the unit.
• DO NOT clean unit with oily soaps or use
chemicals or solvents. Clean with damp cloth.
SP-AD85-x_IB_Final191104V3.indd 19 04/11/2019 15:18

20
Charging the Speaker
The unit has a built-in rechargeable battery, which
should be charged before using the speaker for the
rst time.
Charge the internal battery for 5 hours before rst
time use.
The battery is charged automatically whenever the unit
is connected to a computer or a USB charging device.
O/P:5V 2.1A
I/P:5V 1A
USB to Micro USB
Cable (included)
Computer USB charging
device
SP-AD85-x_IB_Final191104V3.indd 20 04/11/2019 15:18
