JVC TH-N239BA User manual

QUICK START GUIDE
USING THE SOUNDBAR
1. Insert 2 x ‘AAA’ batteries into the remote control.
2. Press Power/Mode button on the Soundbar or the Power button on the remote
control to turn on the unit. Set the Power Switch on the rear of the Subwoofer to the
On position.
3. Press Power/Mode button on the unit or the Mode button on the remote control
repeatedly to select sound source. The display indicates the correct sound source
by displaying BT, OPT, COX, AUX, ARC or USB. You can also press the respective
button on the remote control to directly switch to a particular sound source.
For more information, refer to the user manual or call Customer Support at 1300 366 155.
4

Before using this Soundbar, please read all safety information from
the user manual.
RECOMMENDED PLACEMENT
Soundbar: Under a wall-mounted TV, or in front of the TV stand
Subwoofer: On the oor, alongside the TV (or in the front corner of the room)
CONNECTING THE SOUNDBAR TO THE TV
1. Soundbar power connection: First connect the DC output of the power adaptor to
the ‘DC 18V’ port on the Soundbar, then plug the other end of the power adaptor
into a mains power outlet.
2. Subwoofer power connection: Connect the Subwoofer’s power cord to a mains
power outlet. When switched on (On/O Switch on rear of Subwoofer), the Sub
woofer automatically connects to the Soundbar, wirelessly. If the Subwoofer does
not connect automatically, follow the pairing procedure mentioned in the manual.
3. Connection to TV (select one of these options):
3 (a) HDMI (ARC) on the Soundbar to HDMI Input (ARC) on the TV (If your TV has an
HDMI Input with ARC capability)
OR
3(b) or 3(c) OPT or COAX input on the Soundbar to the Optical or Coaxial output on
the TV
OR
3 (d) AUX IN on the Soundbar to Headphone out on the TV
CONNECTING THE SOUNDBAR TO OTHER DEVICES
4. Connection to Blu-ray/ DVD player/ Gaming consoles: Enjoy sound from these
devices on the soundbar using one of the connections below.
4 (a) OPTICAL Input on the Soundbar to OPTICAL Output on the source device
OR
4 (b) COAXIAL Input on the Soundbar to COAXIAL Output on the source device
5. Other audio sources: Bluetooth/ USB/ Aux
SOUNDBAR
POWER SUPPLY
SUBWOOFER
POWER SUPPLY
CONNECTION TO TV
(choose ONE of these
audio connections)
2 3
