K9 Kennel Quick N Clean User manual

A.Safety Guide
Thank you for purchasing this products.
You will be using sharp tools. Always use personal protective equipment such as gloves and safety
glasses to avoid the risk of injury.
Make sure the floor you step on is dry, free from any liquids such as oil and water when assembling
this product. Use anti-slip shoes to avoid falling due to slips.
Keep this product out of reach of electric current, as this product is made of metal that conducts
electricity.
Make sure there is adequate lighting when doing the assembly. When assembling keep it away from
children and pets.
Quick N Clean Tall Galvanized Kennel Pod User’s Manual
KENNEL STORE
SAFETY PRECAUTION
WWW.K9-KENNELSTORE.COM1
K9 KENNEL STORE
833 West 27th Street Ogden, Ut 84401
Phone : [phone] Fax :[phone]
E-Mail : [email protected]
B. Equipment needed to assemble.
Not included in the item package.
It is recommended that you have knowledge of assembly are helpfull.
Safety transparent glass (if there any)
Safety Gloves and Safety Shoes
Electrical Hand Drill
WARNING • Before using, read these user's manuals of this product to ensure correct usage through
understanding. After reading, store them in a safe place for future reference. Incorrect handling of
this product could possibly result in personal injury or physical damage. The manufacturer assumes
no responsibility for any damage caused by mishandling that is beyond normal usage defined in these
manuals of this product.

C.Whats inside the package?
A
B
C
D
E
F
G
H
I
J
K
L
Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM2
A
B
CD
E
F
G
H
I
A
B
CD
E
F
G
H
I
GB
E
A
B
CD
E
F
G
H
I
GB
E
GB
E
- Right Front Wall
- Right Side Wall
- Right Back Wall
- Left Back Wall
- Left Side Wall
- Left Front Wall
- Top Panel
- Top Front Panel
- Fence Door
- Floor Pan
- Raising Floor
- Bolts and Screw
TOP VIEW SCHEME
4‘ X 4’ POD
4‘ X 8’ POD 4‘ X 6’ POD

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM3
Tips for maximum waterproof
For maximum waterproof result
we suggest to gets caulk and then
all the seams get caulked.

D. Assembly
Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM4
1. Assemble Casters to Floor Pan
J
J

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM5
2. Attach Side and Rear Wall Panel to Inside of Floor Pan
Put bolts and nuts on every
holes
TOP VIEW
B
C
J
J
B
B
C
B
C

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM6
3. Attach other rear & side wall to Floor Pan
Put bolts and nuts on every
holes
4. Attach Side Wall to Roof Panel & Floor Pan
DCBB
Screw using hand drill
EE
G

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM7
5. Attach other Roof Panel and side wall to Floor Pan
Put bolts and nuts on every
holes
Screw using hand drill
F
G
A
6. Attach the Front Roof Panel
F
H
A

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM8
7. Attach The Door Panel
8. Attach the Pipe Holder

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM9
9. Cross Connect the Drain Grid
10. Insert Raised Flooring

Quick N Clean Tall Galvanized Kennel Pod User’s Manual
WWW.K9-KENNELSTORE.COM10
12. Water draining Instalation
Your Quick N Clean Tall Galvanized Kennel Pod
Is ready to use
~Thank You~
