Kahuna LM7000 User manual

16 1
CONTENTS
Safety Instructions --------------2
Product Specifications ---------------4
Product Components ---------------5
Chair Installation ---------------7
Remote Controller ---------------9
Operation Guide --------------10
Troubleshooting --------------15
Maintenance --------------16
Please read and follow all safety and operating instructions
listed in this user manual prior to use. Basic precautions
should always be used when operating an electrical appliance.
MAINTENANCE
- Use dry cloth to wipe sweat and
besmirch.
other
- Please airing.
- Turn off and pull out the plug before
clean the massage chair, do not touch
the plug with wet hands.
-
chair.
Prohibit to use water to clean the
- Do not dry the chair with roaster.
-
etc.
Prohit to use alcohol, benzene wash

215
SAFETY INSTRUCTION
The plug must be fully inserted into an appropriate outlet. Improper connection of the
equipment-grounding conductor can result in the risk of electric shock.
Check with a qualified electricain or service technician, if you are in doubt as to whether
the product is properly grounded. Do not modify the plug provided with the product. If
the outlet is not suitable. Please ensure that a proper outlet is installed by a qualified
electrician.
When using the massage chair, basis precautions should always be followed to reduce
the risk of electric shock, burns, fire, or injury to person.
Warning
1. Please ensure that you plug the massage chair into a proper electrical outlet.
2. Make sure the power plug is securely inserted into the proper electrical outlet to reduce
the risk of short-circuit and fire.
3. Always unplug the massage chair from the electrical outlet immediately after use and
before cleaing,
4. Do not use the massage chair in places where the humidity is high.
5. Do not use the massage chair outdoors and avoid place with direct sunlight。
6. If the power goes off during use, be sure to turn the power switch to the OFF position
and pull the power plug out from the socket to prevent damage from occurring when the
power is restored.
7. Never operate the massage chair if the power cord is wet or damaged.
8. Never plug/unplug the power cord from the socket with wet hands.
9. Close and continuous supervison is necessary when this appliance is being used by.
on or near children,invalid or disabled persons.
10. Use this appliance only for its intended use as described in this user manual.
11. Do not use any parts not from factory.
12. Do not stand, sit or jump in the calves rest when masage chair is in use to prevent any
injury to person.
13. Do not attempt to stand on the backrest and armrest to prevent any injury to person.
14. Be careful not to fall asleep during the massage session.
15. Always keep the massage chair clean and never insert any object into the gaps on and
around the massage chair.
16. Do not move the massage chair by pulling the power supply cord.
17. Ensure that there are no person(childred in particular), pet or obstacles undereneath
the massage chair prior to lowering the leg rest/backrest.
Problem
TROUBLE SHOOTING

SAFETY INSTRUCTION
NOTE:
This appliance is not intended for use by persons(including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safely.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged,it must be replaced by a special cord or assembly available
from the manufacturer or its service agent.
The appliance heats up during operation. persons sensitive to heat must take extra
caution when using the appliance.
18. Always check whether the surface of the massage chair is torn or ripped before usage,
if you find any unfamiliar rips in any area of the cloth in the backrest, do not use the
massage chair, Kindly contact the service centre immediately for reqairs.
19. This appliance is designed for household use only.
20. For those suffering from illnesses, please consult your doctor for advice prior to use.
21. The following persons are requested to consult a doctor prior to use in order to reduce
the risk of user feeling sick or suffering from injury
Those who have malignant tumor
Those who suffer from heart disease
Those who are experiencing pregnancy, menstruation and puerperal fever
Those who require complete rest
Those who are under medical treatment
Those who suffer from back problem or whose backbone is abnormal or bent
22. If you experience pain during usage, stop using the massage chair immediately, if any
injuries occur, seek medical treatment immediately.
23. Never massage the swollen or inflamed parts of the body.
24. This product is non-professional appliance designed to provide a comfortable massage.
Do not use this product as substitute for medical treatment.
25. Each massage session should not exceed 30 minutes. Massage the targeted area only
for 15minutes, Over-massaging can lead to overheating , thus giving the appliance a
shorter lifespan.
26 Do not operate where aerosol(spray) products are used or where oxygen is being
administered
27. The massage chair is not suitable for children aged 12 and below.
14 3
3 After use
OFF
ON
ON/OFF
OPERATION GUIDE

413
PRODUCT SPECIFICATIONS
Product Name
Model No.
Rated Voltage
Rated Frequency
Rated Power Consumption
Dimension (LxWxH)
Weight
Massage Chair
LM-7000
220V~
50Hz
230W Max.
Main Body: 1790x750x870mm
Net Weight: 94Kg Gross Weight: 108Kg
2 Display Diagram
1 2 3 4
5
7
8
9
10 1112
13
14
15
6
1. Massage chair is powered on.
2. Massage chair is scanning the back contour and preparing for initiation.
3. Scanning is complete and ready for massage programs.
4. Pause button has been pressed and chair is temporarily stopped.
5. Reclining position adjustment buttons are pressed and the backrest and
/or legrest are moving.
6. Displays which automatic program is activated.
7. Displays which massage technique is activated at the time. In order
from left to right: Kneading, Tapping, Dual, Shiatsu, Rolling.
8. Depicts the direction of the massage rollers, moving upwards or
downwards.
9. Cheerful greeting from your massage chair.
10. Shows the massage speed level, from one bar to three bars
illuminated.
11. Shows the air intensity level, from one to three.
12. Shows massage roller width, from narrow to medium to wide.
13. Heating function is on.
14. Displays the location of massage rollers and active air bags.
15. Depicts time remaining in current massage program.
OPERATION GUIDE

12 5
PRODUCT COMPONENTS
Main Body Diagram (Front)
Pillow Cushion
Shoulder Airbags
Remote Controller
Arm Airbags
Hip Airbags
Seat Cushion
Legrest FootrestWheels
Backrest Cushion
Side Panel
Head pillow Speaker
Annular functional area
OPERATION GUIDE
This button allows for you to control the intensity of the air bag on 3
different intensity levels.
Back -> Waist -> Seat -> Back & Waist -> Waist & Seat -> The whole body
“Area Adjustment Button” In manual mode, press to select between
specific areas in the following order:
Press the button to turn on/off the kneading function
Press the button to turn on/off the tapping function
Press the button to turn on/off the rolling function

611
Remote Controller Port
Main Power Switch
Safety Fuse
Power Cord Socket
Main Body Diagram (Rear)
PRODUCT COMPONENTS
Auto mode:
Manual mode
: This chair design with 4 sets of auto massage program for
time and people to use.different
OPERATION GUIDE
PS:The position adjustment button have no function when the chair in the
stretch programe
Press the button to turn on/off the heating function
This is the pressure position button. Each time you pres the button, it
will change the area the air massage is concentrating on.
5-30 adjustment,to select your desired massage duration.
5 minutes additional for each press.
minutes
:Press the button and hold on to adjust the footrest
independently
:Press the button and hold on to adjust the massaging
position of backrest.

10 7
7
CHAIR INSTALLATION
1 ) Remove the carton.
2 ) Take out the packing material.
3 ) Install the Pillow, backrest cushion, cushion, spare parts.
4 ) The spare parts include: remote control, holder, user manual, wheel,
power cord.
1.Remove the package and get out the spare parts
2 ) Connecting the side plate trachea with the saddle lateral tracheal. the both
sides trachea must to insert the end, in order to prevent air leakage.
3 ) Aligning the side plate hole and the massage chair hole, then inserted the
plate into the corresponding side mount, To use screw driver lock-in screw,
fixed. The other side also completed according to the above mentioned.
4 ) After install the side board, please smooth the chair.
1 ) Remove the board from the carton,and take out the sideboard.
2.Install the side board
Iron plates inserted into the seat
frame at the relevant side seat
Air bag air tube
Lock screws
place
Lift upwards
Remove protective packing material
OPERATION GUIDE
: Press the button first, massage back and leg position to zero G1,
press second, the position to zero G2, press third, the position to
zero G3, press fourth, massage chair return to original position.
Zero G1 -> Zero G2 -> Zero G3 -> Original Position
: Press to temporarily pause the massage, chair will enter idle
mode. Press again to resume massage.
：Start or Stop massage chair
Press this button, massage chair will be ON, screen will be ON,
User can choose auto or manual function to massage.
Press this button again, massage chair will be off, massage stopped,
massage chair will come back to the original position, all buttons are
inactive. When the chair returns to the original position the chair will
completely shut off.
1 Function description of Controller buttons.
PS:The position adjustment button have no function when the chair in the
stretch programe
Lock screws
place

89
5-10cm
CHAIR INSTALLATION
cross screwdriver
Philip’s head screw
shoulder airbag air tube OK
the hole of locating pin
locating pin
3. Install the shoulder airbag
1) find the 2 locating pin and screw holes.
2) Using the locating pin insert into the chair backrest, then a cross
screw driver to fix the philip's head screw.
3) Connect the tube with tube connector on the chair.
4) Zip up the opening after check each parts are secured.
5)Another side will follow the same steps.
1. As illustrated, push the backrest downwards
and tilt chair on to its wheels at a 45° angle.
Slowly push and maneuver the massage
chair to desired location. Lower massage
chair slowly and smoothly until it is fully flat
on the ground.
5. Place the massage chair in an open area
6. Moving the massage chair.
*Do not move massage chair when occupied or in use.
*Moving the massage chair may cause damage to floors.
Floor protection is recommended (e.g. rugs, carpet).
*Do not drop or suddenly let go of the chair when moving
as it may damage the chair.
*Two person participation is recommended. Please use
extra care when handling the massage chair.
- Allow sufficient space around the chair
for recline purposes.
5-10cm distance for the back side and
50cm in front of the footrest.
1.Remote Controller
REMOTE CONTROLLER
1.Remote Controller
1
2
3
9
6
11
10
5
16
4
14
15
17
7
8
10
12
13
1. On/off Massage Chair
2. Pause Button
3. Zero Gravity Button
4. Auto button
5. Recline Adjustment
6. Heating Button
7. Position Adjust Button
8. Timer Button
9. Air Pressure Button
10. Air Massage Intensity
11. Area Adjustment Button
12. Fix Spot Massage
13. Manual Mode
14. Roller Width
15. Foot Roller Button
16. Speed Adjustment
17. Display
