Kaise S328 User manual
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
折叠示意图：
英文
封
面
英文
封
面
生产大货时，必须参照
右边示意图折叠好!!!
尺寸：420x285mm
四折页(105x142.5mm)
材质：128g铜版纸，双面印刷
备注：图中 虚线为
折叠线不需要印刷
正 面
【IV 】SECURITY AND MAINTENANCE
Battery information
Statement
Your device has and internal, non-removable, rechargeable baery. Do not aempt to remove
the baery, as you may damage the device.
The baery can be charged and discharged over 500 mes, but it will eventually wear out.
All rights reserved. Reproducon in whole or in part without wrien permission is prohibited.
All other trademarks are trademarks of their respecve owners. Features and specificaons are
subject to change without noce.
Do not short-circuit the unit. To avoid short-circuing, keep the unit away from all metal
objects (e.g. coins, hair-pins, keys, etc.).
Do not heat the unit, or dispose of it in fire, water or other liquids. Keep away from high
temperatures. Do not expose the unit to direct sunlight.
Keep away from high humidity, dusty places.
Do not disassemble or reassemble this unit.
In order to extend the life of product (lithium baery), it is best to charge within 3 Do not
drop, place heavy objects on, or allow strong impact to this unit.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
Do not cover the device with towels, clothing and other item.
The unit may become hot when charging. This is normal. Use cauon when handling.
Do not charge the unit over the required me.
Disconnect the unit when fully charged.
Use the unit properly to avoid electronic shock.
Cold temperatures (below freezing) can affect the unit’s baery capacity due to chemical
characteriscs of the baery. If you’ll be living off-grid in sub-zero condions, we recommend
you keep your unit in an insulated cooler, and connected to a power source (solar panels). The
natural heat generated by the unit contained in an insulated cooler will keep baery capacity at
its highest.
a)
b)
c)
d)
e)
f)
g)
h)
i)
j)
k)
l)
m)
n)
MADE IN CHINA
PORTABLE POWER SUPPLY
Universal Instruction manual
ATTENTION: This product user manual is universal for portable solar generator AC output range
between 100V~240V/50Hz~60Hz. Actual product specificaon, actual AC outlets will be different
according to different countries, areas or customers. Please refer to the actual
product before you use the product.
ABOUT THE UNIT
ATTENTION!
This manual is to help you use the product correctly; it does not represent any descripon on
the hardware and soware configuraon of the product. About the product configuraon,
please refer to the contract related to this product (if there is), or consult to the seller that sells
the product. Pictures in this manual is for reference only, if there are individual pictures do not
match the actual, please prevail in actual products.
Thank you for applying our mul-funcon portable solar generator. In case of power failure or
you need to charge on a travel, you can temporarily charge your electrical or digital devices with
this unit. This unit can provide USB, DC and AC output. You can keep laptops, appliances, lights
and more going for hours longer. Before using this unit, please read the user manual carefully
and properly keep it for reference.
The unit provides Modified Sine Wave output
The unit provides Modified Sine Wave output, and can be compable to AC electric appliance
that works with Sinusoidal waveform(power <100W). However, anything that uses an AC motor
isn't going to work to full capacity on a modified sine wave. such as an electrical fan, It will even
make the electric appliance arouse some noise.Appliances like refrigerators, microwaves, and
compressors that use AC motors and some delicate medical equipment will be beer off with a
pure sine wave inverter. This product is only used for emergency, it cannot replace the normal
alternang current, for long-term use, please adapts the power staon specificaon required by
electrical appliances.
【I 】PRODUCT PARAMETERS
AC Output
AC Connuous Output: 100W/150W Max
1 x LED Light Panel
Modified SineWave Output;
AC Voltage: 100/110/120/220/230/240VAC±10%
Output Frequency:50/60Hz±10%
Aenon:Actual AC voltage/Frequency/Outlet(s) are customized
according to different Countries and areas.
1 x Portable Power Supply 1 x 15V/2A Power Adapter
1 x Car Charger 1 x Cigaree Lighter Adapter
1 x user manual.
Package include
Lifecycle >500 mes
Operaon temperature -10℃-40℃
Power Indicator Led Display
【II 】PRODUCT DESCRIPTION
Capacity
Dimensions(LWH)
Weight
Built-in Baery
222Wh, 20Ah/11.1V(equivalent:60000mAh,3.7V)
167x100.3x213mm
about 2.07Kg
High Quality Lithium ion Baeries
Adapter: DC15V/2A
Solar Panel Charging: DC 13V-24V/2.2A Max
Input Recharging
DC Output
Fully Charged Time
USB Output
DC15V/2A: 10~11 hours
2x USB Output 5V/2.1A(Total 3.1A Max)
1 x USB 5-9V/2.1A Qualcomm QuickCharge3.0
2 x USB C 5-9V/2.1A Qualcomm QuickCharge3.0
3 x 5.5MM DC Output: 9-12.6V/10A（Total 15A Max）
【III】PRODUCT INSTRUCTION
※ There may be some differences on different spare parts.Please adhere to the actual product instead.
USB 5-9V/2.1A
Qualcomm QuickCharge3.0
1) How to provide power for DC12V appliances(such as head lamp, fan) with this product?
Press the power buon,Plug your appliances to the DC output port to gain power. DC output
rated Current:10A , Max output Current<15A.
Noces: Please confirm whether your DC12V appliance support charging with 5.5mm DC
header interface (The diameter of the DC Port of the Product is: 5.5mm),otherwise it is unable
to connect with the DC output, you can consult the electrical manufacturer, buy the
corresponding adapter and connect with it.
※Note:
The12V DC output voltage is range between 9V~12.6V, maximum output current is
15A. DC output voltage drops while baery capacity drops due to chemical characteriscs of
the baery. If your appliance is not built-in input voltage stabilizing funcon, it may
shutdown when input voltage is too low, please unplug your device from the unit in me.
And please charge the unit in me.
Protecon Mode:
Short-circuit/Overpower Protecon: If the DC output is short-circuited or overpowered(Load(s)
power>150W), the unit will shutdown to protect itself. Please clear the problem and recharge
the unit to recover from protecon mode.
2) How to provide power for AC appliances with this product?
Connect the power cable plug of the electrical appliance to the AC outlet of the product,
switch on the power buon and the unit will start providing power to your appliances.
WARNING! The Ac outlets, AC voltage and frequency are different according to different
countries ; please carefully check whether the product specificaons are consistent with the
appliance specificaons before use, otherwise it can lead to dangerous situaons.
a) This product is built in high quality original lithium ion baery, it has no memory effect but
high-capacity, and it is durable. However, we sll recommend you toapply in the range of 10 ℃
~30 ℃, so as to obtain the opmal charging capacity.
b) When charging, in order to avoid interference, please stay away from TV, radio and other
equipment.
c) If the device has not been used for a long me, please disconnect the cable and store.
d) Some portable devices may need to be set in charge mode to charge, see the corresponding
equipment use manual for more informaon.
e) In order to extend the life of product (lithium baery), it is best to charge within 3 months,
and charge at least once within 6 months.
When the AC port is not in use, turn it off to conserve power.
Short-circuit/Overpower Protecon: If the AC output is short-circuited or overpowered(Load(s)
power>100W), the unit will shutdown AC output to protect itself. Please clear the problem and
re-press the AC buon for AC output.
※ Some devices, such as refrigerator, ice maker or a laser printer may require a surge power to
start or work during a very me period, the surge power could exceed 150W or even higher,
this could cause overpower protecon with this unit. Please remove the devices and consult
with the device manufacturers for more informaon. Please clear the problem and re-press the
AC buon for AC output.
Connect the standard USB cable of digital appliance to the USB output of the unit, press the
Baery check buon to switch on to gain power.
Noce: Some smart devices, such as Bluetooth headphones and LED lights..require very small
input current to charge, which could be less than 150mA. The unit may fail to charge these kind
of smart devices due to detecon current limitaon by the USB output ports. On this occasion,
user can press the AC buon “ ” to keep the USB port output running. Please turn off AC
output when the smart devices are fully charged to save power.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to
different countries or areas. Please refer to the actual product before using.
ATTENTION!:
AC Outlets,AC output voltage and frequency will be different according to different countries or
areas. Please refer to the actual product before using.
b.Charge from Solar panel
5) How to charge the unit?
a.Charge through AC Wall Charger
Using the included AC Wall Charger, plug the unit into any wall outlet to charge the unit. You will
know the unit is charging when the blue LED baery indicators are blinking. The unit is fully
charged when all baery indicators stop blinking and remain solid. Aer the unit is fully
charged, please remove the AC wall charger in me.
1. Place your solar panel where it will get as much direct sunlight as possible.
2. Plug the output of the solar panel into the input of the unit to start charging.You will know
the unit is charging when the blue LED Baery Indicator lights up and blinks. The unit is fully
charged when all baery indicators stop blinking and remain solid.
Using the included car charger, plug the unit into a 12V cigaree lighter (car port) of your car.
You will know the unit is charging when the blue LED Baery Indicator lights up and blinks. The
unit is fully charged when all baery indicators stop blinking and remain solid.
Noce: Since the output voltage from 12v car port will float, charging speed and me from a
12v car port will be depending on actual vehicles and vehicle status.
c. Charge from your car with a 12V car port.
Aenon: To avoid car baery power loss. Charging this unit through your car cigaree
lighter is only available when your car engine is started.
【Front】
【Front】
【Rear】
【Rear】
【Rear】
AC Power
Bulb Type
Limited Appliance Waage<100W,Lamp,
Electric Fan, TV, etc. AC will shutdown when it’s short
circuited or power overloaded. Remove the device and
the unit will recover from short-circuit or overpower
protecon in a few seconds. Repress the AC output
buon to switch on AC output again.
Handle
LED DISPLAY
AC ON/OFF
Main power switch
Protecon Mode:
3) How to provide power for USB(C) digital appliances with this product?
This unit is built with LED lightpanel. Press the“ ” buon to switch on lightpanel and single
press the buon to switch brightness, Press the buon again to switch off.
4) How to use the Led light panel
Warning!Do not point directly at the eyes of human in case of any damage due to
the strong light.
Cold Weather Usage
【V 】PRODUCT APPLICATION SKILLS
Always return your used electronic products, baeries, and packaging materials to dedicated
collecon points. This way you help prevent uncontrolled waste disposal and promote the
recycling of materials.
Recycle
Support 5.5mm DC12V car kits with DC-Cigaree
Lighter Adapter, such as Vacuum Cleaner,Inflaon
Pump,Electric wrench,fridge,etc.
▲
Input Charging
DC 13V~24V/2.2A Max
▲
AC Adapter (charger) 15V/2A
AC Socket
▼
or charge car kits via DC to Cigaree Litghter Connector
5.5mm DC12V for Fan or LED
lights
Please deal with scrap products in accordance with the regulaons, do not treat the built-in
baery as a household garbage, so as not to cause the explosion and polluon.
The product is only used for emergency situaons, it cannot replace the standard DC or AC
power of household appliances or digital products.
Quick Charge Output: This product supports Qualcomm QuickCharge 3.0 output, support
5V-9V / 2.1A max output for smartdevices which also support Qualcomm QuickCharge 3.0. The
actual output voltage and current depends on the actual smartdevices, it can be obtained by
consulng the smartdevice manufacturer.
USB C
AC Outlet
5.5mm DC Output
Total (9V~12.6V)/10A/15A Max
5.5MM/2.1mm DC Input
Quick Recharging
LED LIGHTPANEL
LED LIGHTPANEL SWITCH
Cooling vents
DC Output
DC Input Charging
USB Output
AC/DC Status
Baery Capacity
AC Output ON/OFF
【LED DISPLAY】
2 x USB C 5-9V/2.1A
Qualcomm QuickCharge3.0
2x USB 5V/2.1A
(Total 3.1A Max)
Baery Check
【Front】
【Front】
Please turn on the main power switch
before using the product.
Please turn off the main power switch
when you are not planning to use the
product for a long me.
Table of contents
Other Kaise Power Supply manuals
