With growing number of Power-over-Ethernet
(PoE) powered edge devices, and the explosion
of multi-media trac and cloud-based apps on
the Local Area Network (LAN), having a resilient
network infrastructure is essential to your
business. And a key to having a resilient network
is to ensure uninterrupted power.
ADTRAN addresses this need with the
NetVanta 1131 RPS/EPS unit, which provides
redundant power and supplemental power to
the NetVanta 1600 Series, and redundant power
to the NetVanta 1500 Series Gigabit switches.
Hardware
e NetVanta 1131 has three Redundant Power
Supply (RPS) outputs and one External Power
Supply (EPS) output. e RPS outputs provide
backup power for a NetVanta 1500 or 1600 switch’s
internal power supply. e EPS output provides
370 watts of backup PoE for a NetVanta 1500 or
1600 PoE switch for PoE redundancy. In addition,
the EPS output provides 370 watts of additional
PoE for the NetVanta 1638P for a total of 740 watts
of available PoE budget power.
Alternate Power Supply
e NetVanta 1131 RPS/EPS unit provides
redundant power feeds via an alternate AC power
circuit. In this instance, the NetVanta switch
is connected to the primary AC circuit, and
connected to NetVanta 1131 RPS/EPS, which
is powered via an alternate AC power source.
Should the primary AC circuit fail, the
NetVanta 1131 RPS automatically provides
power feed to the connected NetVanta switch
eliminating any downtime.
Internal Power Supply Backup
e NetVanta 1131 RPS output provides
redundancy for NetVanta PoE and non-PoE
switches in the event of an internal power supply
failure. In the event the switch’s internal power
supply fails, the NetVanta 1131 would power the
NetVanta switch until the power unit is replaced or
swapped out.
Redundant PoE Budget
e NetVanta 1131 EPS output provides external
backup power supply to the NetVanta 1500 and
1600 Series PoE switches, in case the internal PoE
power supply fails. e NetVanta 1131 can provide
up to 370 watts of redundant PoE budget to ensure
PoE-powered edge devices such as VoIP phones,
wireless Access Points (APs) or IP security cameras
operate without interruption.
Supplemental PoE Power
e NetVanta 1131 EPS output can also provide
supplemental power up to 370 additional watts,
for the NetVanta 1638P Gigabit PoE switch. is
provides increased power wattage, eectively
doubling the available PoE budget, enabling the
NetVanta 1638P to support greater number of PoE
or PoE+-powered edge devices. e NetVanta 1131
EPS’ internal power management enables ecient
budgeting of available PoE power.
Key Features
nRedundant and Extended
Power Supply for
NetVanta switches
nRedundant Power for up
to three NetVanta switches
nEnables NetVanta switches
to be powered from
Dual AC circuits
nBackup 370 watts PoE
budget power for
NetVanta PoE switches
nAdditional 370 watts
PoE budget power
for NetVanta 1638P
nHalf-rack form factor,
allowing two NetVanta 1131s
to be mounted using the
optional dual mounting tray
nPlug-and-play operation—
requires no manual
conguration
Supported
Switches
nNetVanta 1534/1534P
nNetVanta 1535P
with ActivReach
nNetVanta 1544/1544P
nNetVanta 1638/1638P with
and without ActivChassis
NetVanta 1131
Redundant /External Power Supply Unit
NetVanta 1638P
NetVanta 1544
NetVanta 1534
NetVanta 1131
RPS/EPS
23
STAT
25
26
27
28
RPS
VCID
ILL428A
Redundant Power
Redundant Power
Redundant Power
External Power

ADTRAN, Inc.
International Department
U.S. Headquarters
901 Explorer Boulevard
Huntsville, Alabama 35806
www.adtran.com/global
[phone]
[phone] fax
[email protected]
International Customer Service
[phone]
Asia—Beijing, China
[phone]
[email protected]
Asia—Hong Kong
[phone]
[email protected]
Asia—Singapore
[phone]
[email protected]
Australia/New Zealand—
Melbourne, Australia
[phone]
[email protected]
Australia/New Zealand—
Sydney, Australia
[phone]
[phone]
[email protected]
Canada Headquarters—
Toronto, Ontario
[phone]
[phone]
[email protected]
Canada—Montreal, Quebec
[phone]
[phone]
[email protected]
Europe, Middle East and Africa
Headquarters—Munich Germany
[phone]
[email protected]
Germany
[phone]
[email protected]
Central/East Europe
[phone]
[email protected]
South Europe
[phone]
[email protected]
West/North Europe
[phone]
[email protected]
Middle East and Africa
[phone]
[email protected]
Mexico and Central America
[phone]
[phone] Mexico
[email protected]
South America
[phone]
[email protected]
[email protected]
ADTRAN believes the information in this publication to be accurate as of publication date, and is not responsible for error. Specifications subject to
change without notice. ADTRAN and NetVanta are registered trademarks of ADTRAN, Inc. and its affiliates in various countries. All other trademarks
mentioned in this document are the property of their respective owners.
ADTRAN warranty duration and entitlements vary by product and geography. For specific warranty information, visit www.adtran.com/warranty
ADTRAN products may be subject to U.S. export controls and other trade restrictions. Any export, re-export, or transfer of the products contrary to
law is prohibited. For more information regarding ADTRAN’s export license, please visit www.adtran.com/exportlicense
ADTRAN is an ISO 9001, ISO 14001,
and a TL 9000 certified supplier.
I64700530F1-8A September
Copyright © 2013 ADTRAN, Inc.
All rights reserved.
Physical Interface
nThree RPS connectors
nOne EPS connector
Redundant Power Supply (RPS)
nThree RPS ports
n12V at 10A
nCapable of powering a single switch
External Power Supply (EPS)
nOne EPS port
n50V at 7.5A
n370 watts of backup PoE budget
n370 watts of supplemental PoE power
Supported Switches
n2nd Gen NetVanta 1534/1534P
n2nd Gen NetVanta 1544/1544P
nNetVanta 1535P with ActivReach
nNetVanta 1638/1638P with or
without ActivChassis
NetVanta 1131 LED Diagnostics
RPS Status
nOff – RPS not connected
nGreen (solid) – RPS connected,
internal supply OK
nRed (solid) – RPS connected,
internal supply failed
EPS Status (PoE product only)
nOff – EPS not connected
nGreen (solid) – EPS connected,
internal supply OK
nRed (solid) – EPS connected,
internal supply failed
Environment
nOperating Temperature: 0° to 50 °C
(32° to 122 °F)
nStorage Temperature: -20° to 70 °C
(-4° to 158 °F)
nRelative Humidity: Up to 95%,
non-condensing
Physical
nChassis: 0.5U, 19 in. dual mounting tray
supports two NetVanta 1131 units
nDimensions: 4.3 cm x 21.6 cm x 34.5 cm
(H x W x D) (1.7 in. x 8.5 in. x 13.6 in.)
nWeight: 2.8 kg (6.0 lbs)
nAC Power: 110–240 VAC, 5.7A, 50/60 Hz
Minimum Requirement
nAOS 10.9 and above
Warranty
nLimited lifetime warranty
Agency Approvals
nFCC Part 15 Class A and UL 1950/CSA
nNorth America EMI/EMC Class A
nUL/CUL
nInternational EMI/EMC Class A
nCE Mark
nC-Tick for Australia
nRoHS 6/6
Approved Countries
nUSA n Puerto Rico
nGuam n Canada
nUnited Kingdom n Italy
nFinland n Sweden
nDenmark n Belgium
nNetherlands n Estonia
nLatvia n Lithuania
nPoland n Czech Republic
nSlovakia n Romania
nBulgaria n Greece
nMalta n Portugal
nSlovenia n Hungary
nLuxembourg n Austria
nCyprus n Spain
nGermany n France
nIreland n Norway
nIceland
nMexico (formal testing not required,
designed to meet the requirements)
nAustralia except Telstra
Product Specications
NetVanta 1131
Redundant /External Power Supply Unit
Ordering Information
Equipment Part No.
NetVanta 1131 (RPS/EPS) 4700530F1#IN
NetVanta 1131 RPS Cable 1700532F1
NetVanta 1131 EPS Cable 1700533F1
NetVanta 1131 Tray 1700534F1
Bundles
NetVanta 1131
with RPS Cable
4700531F1
NetVanta 1131
with EPS Cable
4700532F1
