KAKA Industrial HSG-8 User manual

Operation Manual HSG-8
KAKA Industrial®
— 1 —
Unpacking
The Hand Shear is shipped from the
manufacturer in a carefully packed Carton
box. Thoroughly inspect the product upon
opening the package.
After unpacking the unit, carefully inspect for
any damage that may have occurred during
transit. Check for loose, missing, or damaged
parts. Shipping damage claims must be led
with the carrier and are the responsibility of
the user.
Specications
Stock No. .............................................172303
Model.....................................................HSG-8
Blade length..................................8" (203 mm)
Plate steel....................................0.24" (6 mm)
Flat steel......................2.76"x0.24" (70x6 mm)
Round steel...............................0.51" (13 mm)
Packing size...........20"x6"x18" (50x15x45 cm)
N.W/G.W. .........................42/44 lbs (19/20 kg)
Important:
Blades are coasted with a protectant. To
ensure proper fit and operation, remove
coating. Coating is easily removed with mild
solvents, such as mineral spirits, and a soft
cloth. Avoid getting cleaning solution on paint
or any of the rubber or plastic parts. Solvents
may deteriorate these nishes. Use soap and
water on paint, plastic or rubber components.
After cleaning, cover all exposed surfaces with
a light coating of oil.
WARNING
Never use highly volatile solvents.
Non-ammable solvents are recommended
to avoid possible re hazard.
SAVE THESE INSTRUCTIONS
Thank you for purchasing our HSG-8 Hand
Shear. Before attempting to operate your
new tool please read these instructions
thoroughly. You will need these instructions for
the safety warnings, precautions, assembly,
operation, maintenance procedures, parts
list and diagrams. Keep your invoice number
with these instructions. Write the invoice
number on the inside of front cover. Keep the
instructions and invoice in a safe, dry place for
future reference.
General Safety Information
CAUTION
Always follow proper operating procedures
as defined in this manual even if you are
familiar with use of this or similar tools.
Remember that being careless for even a
fraction of a second can result in severe
personal injury.
SAFETY RULES
1. Wear proper apparel. Do not wear loose
clothing, gloves, neckties, rings, bracelets or
other jewelry which may get caught in moving
parts of machine.
2. Wear protective hair covering to contain
long hair.
3. Wear safety shoes with non-slip soles.
4. Wear safety glasses complying with United
States ANSI Z87.1.

Operation Manual HSG-8
Model HSG-8
— 2 —
capacity may be dangerous to operator and
damage may occur to the machine.
4.Bolt machine to oor or sturdy stand that is
bolted to oor to prevent sliding or tipping of
machine.
IMPORTANT
DO NOT attempt to shear hardened or
stainless steel blocks or rod. You will
damage or break your shear blades !
Assembly
MOUNT HANDLE
Remove two hex head bolts #7 from gear arm
#3. Mount handle #4 into groove on pivot arm.
Secure handle with hex head bolts. Tighten
bolts securely.
INSTALLATION
Machine should be installed on a level surface,
with proper lighting. Machine can be floor-
mounted, stand-mounted or bench-mounted.
Be sure to provide clearance for handle bar
rotation. Use four mounting holes on the base
to bolt machine securely to floor, bench or
stand (fasteners not included).
Area around machine should be clear of
scraps, oil or dirt. Apply a suitable non-skid
material to oor.
Operation
Rotating handle #4 operates the shear. Be
sure to keep hands clear of shear when
rotating handle. The maximum capacity of the
machines is ¼” mild steel.
SHEARING PLATE AND FLAT BARS
1.Adjust hold-down plate #11 so that
Everyday glasses have only impact resistant
lenses. They are NOT safety glasses.
5. Be alert and think clearly. Never operate
tools when tired, intoxicated or when taking
medications that cause drowsiness.
6. Keep work area clean. Cluttered work areas
invite accidents.
7. Work area should be properly lit.
8. Keep visitors at a safe distance from work
area.
9. Keep children out of workplace. Make
workshop childproof. Use padlocks to prevent
any unintentional use of tools.
10. Assemble only according to these
instructions. Improper assembly can create
hazards.
11.When tools are not in use, store them in a
dry, secure place out of the reach of children.
Inspect the tools prior to storage and before
reuse.
12. Maintain product labels and nameplates.
These carry important safety information.
WARNING
The warnings, cautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions or situations
that could occur. It must be understood
by the operator that common sense and
caution are factors which cannot be built
into this product, but must be used by the
operator.
KNOW HOW TO USE TOOL
1.Use right tool for job. Do not force tool or
attachment to do a job for which it was not
designed.
2.Keep hands out of path of shear blades.
3.The maximum capacity of this machine
is 1/4” mild steel or equivalent. Exceeding

Operation Manual HSG-8
KAKA Industrial®
— 3 —
workpiece can lie horizontally between shear
blades. Place workpiece between blades #14
and #19 and underneath hold-down plate.
Adjust hold-down plate to be positioned at
the top surface of the workpiece, with the
workpiece held horizontally. Secure the hold-
down plate in position by tightening it.
2.Support workpiece between blades and
underneath the hold down plate at position
where cut is desired. Pull handles #4
forward with both hands until blade cuts
through workpiece.
CAUTION
Do not reach in back of shear to grasp fall
out piece.
Shear thicker material is done by “snapping”
crank handles so that upper blade impacts
workpiece.
Upper blade is mounted at an angle so that
workpiece can be sheared in small increments.
To minimize distortion, approximately 5/8”
of workpiece should be sheared with each
impact.
SHEARING ROUND BARS
Round bars up to
1
/
2
” diameter can be cut with
this shear.
Place bar through holes in face of upper blade
#19 and die #2. Position bar where cut is
desired and pull handle #4 forward until bar is
cut.
SHEAR BLADES
Always keep shear blades lubricated and
clean of any dirt or rust. Abrasive particles on
blades will drastically reduce life of blades.
These blades should be sharpened according
to industry standards by a competent grinding
service only.
NOTE
If the material seems too thick or too hard,
do not force the shear ! Instead, use a
metal-cutting bandsaw to cut the workpiece.
Maintenance
1. Consult manual for specic maintaining and
adjusting procedures.
2. Keep tool lubricated and clean for safest
operation.
3. Remove adjusting tools. Form habit of
checking to see that adjusting tools are
removed before using machine.
4. Keep all parts in working order. Check to
determine that the guard or other parts will
operate properly and perform their intended
function.
5. Check for damaged parts. Check for
alignment of moving parts, binding, breakage,
and mounting or any other condition that may
affect a tool’s operation.
6. Check the handle and base mounting bolts
to ensure they are tight.
7. A guard or other damaged part should be
properly repaired or replaced. Do not perform
makeshift repairs. (Use parts list provided to
order repair parts.)

Operation Manual HSG-8
Model HSG-8
— 4 —
Troubleshooting Chart
Symptom Possible Cause(s) Corrective Action
Machine will
not shear
1. Workpiece material too
thick
1. Do not exceed machine capacity of ¼”
mild steel
2.Blades too far apart or not
parallel
2. Make sure hold-down plate #12 are tight
and hold lower blade securely
3.Dull blades 3. Have blades sharpened by a qualified
grinding service

Operation Manual HSG-8
KAKA Industrial®
— 5 —
Drawing

Operation Manual HSG-8
Model HSG-8
— 6 —
Parts List
Ref.No. Description QTY.
1 Base 1
2 Round die 1
3 Gear arms 1
4 Handle 1
5 Washer 5
6 Knot 1
7 Bolt M10x40 2
8 Connect plate 1
9 Nut M14 2
10 Screw M12x30 1
11 Hold down plate 1
12 Bolt 1
13 Washer 1
14 Lower blade 1
15 Bolt M8x25 2
16 Spring 1
17 Nut M10 2
18 Small shaft 1
19 Upper blade 1
20 Bolt M10x22 3
21 Washer 3

Operation Manual HSG-8
KAKA Industrial®
— 7 —
SERVICE RECORD
KAKA Industrial ®
Date Maintenance performed Repair components require
NOTES

Stock No: 172303
Edition 1 08/2018
