Kampmann 148941 User manual

Climate Controller
Type 148941 (white)
Type 148942 (black)
Type 148943 (white with Modbus interface)
Type 148944 (black with Modbus interface)
User manual
Keep these instructions in a safe place for future use!
I589/08/20/ EN SAP-Nr. 1313436

Table of Contents
1ABOUT THESE INSTRUCTIONS.................................................................................................................. 3
2INTENDED USE......................................................................................................................................... 4
3SAFETY INFORMATION............................................................................................................................. 5
4OPERATION OF THE CLIMATE CONTROLLER............................................................................................. 6
4.1 OPERATION AND DISPLAY ELEMENTS ......................................................................................................... 6
5FUNCTIONALITY OF THE CLIMATE CONTROLLER ...................................................................................... 8
5.1 GENERAL ............................................................................................................................................ 8
5.2 FAN CONTROL...................................................................................................................................... 8
5.3 TEMPERATURE CONTROL ........................................................................................................................ 8
6ALARM MESSAGES................................................................................................................................. 11
6.1 TROUBLESHOOTING............................................................................................................................. 11
7TIMER SETTINGS .................................................................................................................................... 14
7.1 TIMER CHANNELS ............................................................................................................................... 14
7.2 TIMER SETTINGS ................................................................................................................................. 14
8PARAMETER SETTINGS........................................................................................................................... 15
8.1 SETPOINT.......................................................................................................................................... 15
8.2 FAN STAGES ...................................................................................................................................... 16
8.3 CONTROLLER ..................................................................................................................................... 17
8.4 INPUTS............................................................................................................................................. 18
8.5 OUTPUTS.......................................................................................................................................... 21
8.6 UNIT ............................................................................................................................................... 22
8.7 SCREEN ............................................................................................................................................ 22
8.8 KEYS................................................................................................................................................ 23
8.9 SENSOR SETTINGS ............................................................................................................................... 23
9INSTALLATION ....................................................................................................................................... 24
9.1 TECHNICAL DATA ................................................................................................................................ 24
9.2 DIMENSIONS ..................................................................................................................................... 24
9.3 ELECTRICAL WIRING ............................................................................................................................ 25
9.4 CABLING........................................................................................................................................... 25
9.5 CLIMATE CONTROLLER VERSIONS AND ACCESSORIES .................................................................................... 26
9.6 CABLING DIAGRAM ............................................................................................................................. 28
10 MODBUS SETTINGS................................................................................................................................ 29
10.1 MODBUS INTERFACE CONFIGURATION ..................................................................................................... 29

10.2 MODBUS -PARAMETER LIST.................................................................................................................. 29
11 PARAMETER LIST ................................................................................................................................... 30

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
3
1 About these Instructions
Carefully read these instructions in full prior to any assembly and installation
work!
Anyone involved with the installation, commissioning and use of this product
is obliged to pass these instructions on to tradespeople who are involved at
the same time or subsequently, as well as to end users or operators. Retain
these instructions until final decommissioning!
We reserve the right to make content or design-related changes without
prior notice!
Key to Symbols
Caution! Danger!
Non-compliance with this information can lead to serious personal injuries or
damage to property.
Danger from electrocution
Non-compliance with this information can lead to serious personal injuries or
damage to property.
This symbol highlights useful hints, recommendations and
information for efficient and trouble-free operation.

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
4
2 Intended Use
The Kampmann Climate Controller type 148941/ type 148942/ type 148943
and type 148944 has been designed in compliance with the state of the art
and recognized safety-related regulations. Nevertheless, its use can result
in danger to people or damage to the units or other material property if it is
not appropriately installed and operated or correctly and properly used.
Applications
The Climate Controller type 148941 / type 148942 / type 148943 / type
148944 should only be used as a Climate Controller in conjunction with
Kampmann systems.
The Climate Controller is solely intended for use indoors (e.g. residential
and commercial properties, showrooms etc.).
The Climate Controller cannot be used
•outdoors
•in humid areas, such as swimming pools, in wet rooms
•in areas where there is a risk of explosion
•in areas with a high dust content
•in areas with an aggressive atmosphere
Protect the products from any moisture during installation. Check the
intended use with the manufacturer in case of any doubt. Any other use
than the use specified above is deemed not to be correct and proper. The
operator of the unit is solely responsible for any damage arising as a result
of this. Intended use is deemed to include observing the installation
instructions described in these instructions.
Specialist Knowledge
The installation of this product requires specialist knowledge of heating,
cooling, ventilation and electrical engineering. This knowledge, generally
learned in vocational training in one of the fields mentioned above, is not
described separately. Damage caused by improper installation is the
responsibility of the operator. The installer of these units should have
adequate knowledge of the following gained from specialist vocational
training
•safety and accident prevention regulations
•guidelines and recognised technical regulations of the respective
country, i.e. Association of German Electricians (VDE) regulations,
DIN and EN standards
Purpose and Scope of these Instructions
These instructions contain information on the commissioning, functionality
and operation of the Kampmann Climate Controller type 148941 / type
148942 / type 148943 / type 148944. The information contained in these
instructions can be changed without prior notification.

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
5
3 Safety Information
Only allow a qualified electrician to perform installation, assembly and
maintenance work on electrical units in compliance with VDE guidelines.
Wiring should comply with the applicable VDE regulations and provisions
laid down by the regional electricity providers. Non-compliance with the
regulations and operating instructions can result in the units malfunctioning
with consequential damage anddanger topeople. There isa danger offatal
injury caused by wires being swapped due to incorrect wiring! Disconnect
all parts of the system from the mains power supply and prevent them from
being reconnected before starting any connection and maintenance work!
Please read these instructions in full to ensure correct and proper
installation and the correct operation of the Climate Controller.
Please note the following safety-relevant information:
•Disconnect all parts of the system that are being worked on.
•Ensure that the system cannot be accidentally re-connected!
•Before commencing installation/maintenance work, wait until the
fan has come to a standstill after the unit has been switched off.
•Caution! Pipes, casings and fittings can become very hot or very
cold depending on the operating mode!
•Qualified personnel must have undergone training to provide them
with adequate knowledge of the following:
osafety and accident prevention regulations
oguidelines and recognized technical regulations, i.e.
Association of German Electricians (VDE) regulations
oDIN and EN standards
oaccident prevention regulations VBG, VBG4, VBG9a
oDIN VDE 0100, DIN VDE 0105
oEN 60730 (Part 1)
otechnical wiring regulations (TABs) issued by the regional
electricity providers
Protect the products from any moisture during installation. Check the use
with Kampmann GmbH in case of any doubt. Any use other than the use
specified above is deemed not to be correct and proper. The operator of
the unit is solely responsible for any damage arising as a result of this.
Intended use is deemed to include observing the installation instructions
described in these instructions.
Modifications to the Unit
Do not undertake any modifications, conversions or additions to the control
unit or attachment parts without discussing them with the manufacturer as
they could impair the safety and operation of the unit. Do not carry out any
measures on the unit not described in this manual. Make sure that on-site
systems and cabling are suitable for connection to the intended system!

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
6
4 Operation of the Climate Controller
The Kampmann Climate Controller is a control unit with a high-quality glass
surface for the control of secondary air equipment with EC fans and 2- or
4-pipe systems.
The timer program with 3 channels and 4 changeover points allows the user
to adjust the room temperature control on demand.
Product features:
•2.5” LCD display
•High-quality glass surface with capacitive keys
•LED ring acts as key feedback
•Selection of the value to be displayed (room temperature, setpoint,
setpoint offset)
•Automatic LED background lighting
•Integrated NTC temperature sensor for room temperature control
•Standby mode
•Eco/day changeover
•Manual or automatic mode
•Functional display
•Alarm display
•Filter message appears on the display
•Timer program with 3-time channels, each with 4 switchover points
•German and english language
•Modbus interfaces (only with type 148943 and type 148944)
4.1 Operation and Display Elements
The Climate control is operated using keys (5) to (9). These keys are used to
change fan stages/automatic mode, temperature setpoints and operating
conditions.
The user menu can be accessed by simultaneously pressing keys (5), (7) and
(8) for 3s. You can set the time and date and parametrise timer programs in
this menu (see chapter 7).
Special system requirements can be configured in the password-protected
expert menu (see chapter 8). The following system requirements are
available:
•Display
•Lock operating functions
•Type of setpoint setting
•Inputs and outputs
•Sensor calibration
•Control and regulation parameters

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
7
1. 2.5” LCD display
2. Header in the LCD
3. Main display in the LCD
4. Footer in the LCD
5. Raise setpoint temperature
6. Lower setpoint temperature
7. Adjust fan speed
8. Adjust fan speed
9. ON/OFF key with ring light
The footerof the LCD displays shows the following room statuses, depending
on the configuration:
Fan stage (visible as standard)
Active timer channel (visible as standard)
Heating / cooling (visible as standard)
Presence (not visible as standard)
Window contact / dewpoint (not visible as standard)
The header of the LCD displays shows the following operating statuses,
depending on the configuration and the system status:
Manual operation (priority 4)
Active alarm (priority 3)
Active Eco mode (priority 2)
i Filter message (priority 1)
The message with the highest priority (priority 4, …) is displayed if these
operating messages occur simultaneously.
In addition, the date and time can be enabled in the settings and thus appear
in the header.

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
8
5 Functionality of the Climate Controller
5.1 General
The type number of the Climate Controller is displayed on the start screen.
The Climate Controller can be switched on and off using the On/Off key (9).
In this mode, the display is switched off and the controller is disabled. Only
the protection functions (unit frost protection, room frost protection, heat
protection) remain enabled. This function is not enabled when using the key
card function.
The ring LED gives feedback each time a button is pressed. The main screen
is displayed if no key is pressed for 3 seconds.
The key fields of the Climate Controller are calibrated as soon as
mains power is applied. Therefore the user interface should not be
touched for 60s after voltage has been connected.
5.2 Fan Control
The EC fan is controlled by the 0-10 V output of the Climate Controller.
Manual fan stages and/or Automatic mode can be adjusted using keys (7)
and (8). A user-set speed is overwritten by the timer channel at the start of a
new timer channel segment. The speed increment between the individual
stages depending on the number of fan stages set up:
1 stage: 100% increment
2 stages: 50% increments
3 stages: 33% increments
4 stages: 25% increments
5 stages: 20% increments (default setting)
The fan is actuated for 1s at maximum speed to ensure the safe
start-up of the fan.
5.3 Temperature Control
The Climate Controller has an internal temperature sensor, which is used by
default for temperature control. Optionally, input 1 can be configured with an
external temperature sensor. In this case, this measured value is automatically
the basis for temperature control.

1.96 Climate Controller Type 148941 / Type 148942 / Type 148943 / Type 148944
Operation manual
9
5.3.1 Temperature control in 4-pipe mode
In 4-pipe mode, the controller automatically specifies the operating mode
based on the room temperature and the setpoint inputted. The parameters:
•Neutr. zone 4-p
•Valve hysteresis
•Nat. convection heating
•Nat. convection cooling
are used to define the properties of the room temperature control.
The parameter Neutr. zone 4-p is used to define the setpoint value for heating
and cooling mode. The corresponding valve is controlled depending on this
value and the hysteresis valve parameter. The fan is controlled depending on
the neutral zone and natural convection. The control voltage for the fan is
calculated on the basis of the P-band as well as the minimum and maximum
speed of the fan.
The Climate Controller is factory-configured as a 2-pipe unit
(Heating). The inputs and outputs need to be adapted if the unit is
a 4-pipe system.
Input 1: no function
Input 2: no function
Output 1: Cooling
Output 2: Heating
If ECO mode is enabled in heating mode, the heating setpoint is lowered by
the ECO setback parameter.
If ECO mode is enabled in cooling mode, the cooling setpoint is raised by the
ECO rise parameter.
