Kamstrup OMNIPOWER User manual

Instlltion mnul
OMNIPOWER – three-phse
Kmsrup A/S · Indusrivej 28, Silling · DK-8660 Sknderborg · T: [phone] · info@kmsrup.com · kmsrup.com

2 Kmstrup A/S • 55121316_E1_GB_10.2016
OMNIPOWER – three-phse
Connect the meter in ccordnce with the instlltion digrm on the meter’s type lbel.
Depending on the configurtion,  fixed vlue is displyed, or the disply chnges between select-
ed indictions every 10 seconds.
It is possible to chnge the disply reding mnully by ctivting the push button on the meter.
The vilble redings depend on the meter’s configurtion.
Security nd instlltion guidelines
The meter is only to be used for mesuring electricl energy nd shll operte within the specified
vlues only.
The meter must be disconnected when working on it. It cn be highly dngerous to touch the meter
prts when the meter is switched on.
Therefore, the relevnt security fuse must be removed nd kept in  plce where it cnnot be
inserted by unuthorized persons.
Current locl stndrds, guidelines, regultions nd instructions must be observed. Only uthor-
ized personnel is permitted to instll electricity meters.
Meters for direct connection must be protected ginst short circuit by  security fuse in ccord-
nce with the mximum current stted on the meter.
Filing to obey the ”Guidelines for sfety nd instlltion”, the gurntee no longer pplies.
LCD disply
Opticl interfce
LED (meter constnt)
LED breker sttus
(only meters with
internl breker)
Selble push button
Utility sels
Type lbel
Secondry module
Push button
The meter constnt LED blinks proportionlly to the consumed ctive energy.
Only uthorized personnel my brek the utility seling.

3Kmstrup A/S • 55121316_E1_GB_10.2016
OMNIPOWER – three-phse
The phse indictions hve vrious functions. They indicte the two situtions described below.
From the connection of the meter:
Indictions L1, L2, L3 Indicte
On Voltge is bove minimum limit (160 V)
Off Voltge is below minimum limit (160 V)
Indiction Indicte
On Lod is bove minimum limit (2.3 W)
Off Lod is below minimum limit (2.3 W)
If the lod exceeds the minimum limit, nd the meter is configured with this reding, consumption
will be indicted vi the qudrnt reding. The direction of the three-phse currents is indicted vi
the rrows bove, respectively L1, L2 nd L3.
7-digit identifiction field
Qudrnt indiction
Module indiction Text field
Unit field
Breker symbol
Tmper symbol
Triff indiction
Rdio network symbol
Error symbol
Phse sequence indiction
9-digit vlue field
Phse current indiction
Prepyment symbol
Supply voltge indiction

4 Kmstrup A/S • 55121316_E1_GB_10.2016
OMNIPOWER – three-phse
Terminls
Multi-core 7-core Mssive / terminls
35 mm2≥ 6 mm2≥ 6 mm2≥ 2.5 mm2
Screw: Pz 2 or stright slot
Torch: 2.5 – 3 Nm
Lod control, instlltion
For meters with lod control rely(s). Due to the dely in the meter, it is importnt to restrt the
meter (off/on) when the time is set correctly in the meter. This plces the relys in the correct
position nd stops the dely timer.
With built-in rdio
If the meter is supplied with integrl rdio for estblishment of remote reding, the meter uto-
mticlly connects to  rdio network. The integrl rdio is equipped with n internl ntenn. The
rdio signl strength cn be red vi the system. If the rdio signl is not sufficient, n externl
ntenn must be connected. Plese see current documenttion on vilble ntenns.
Mounting  communiction module in the meter my influence the rdio communiction. Plese
contct Kmstrup A/S.
With disconnect function
If the meter is delivered with built-in breker function, you must mke sure tht the red diode is off.
The diode indictes whether current is connected (diode turned off) or disconnected (diode turned
on) loclly t the consumer.
Short-circuit connection
When  3-phse meter is used for  2-phse instlltion, it is recommended not to mke 
short-circuit connection between the meter’s phse inputs 1 nd 2 (i.e. between terminls 1 nd 4
or between terminls 2 nd 5).

5Kmstrup A/S • 55121316_E1_GB_10.2016
OMNIPOWER – three-phse
Instlltion dimensions
80.3
171.7
269.2
Connection digrms
The vlid connection digrm ppers from the type lbel.
12345678910 11 12
L1
L2
L3
N
S0 +
20
-
21
P+
12345678910 11 12
L1
L2
L3
N
S0 +
20
-
21
P+

6 Kmstrup A/S • 55121316_E1_GB_10.2016
OMNIPOWER – three-phse
Connection digrm for modules
Tilslutningsskema for moduler (DK)
Connection diagram for modules (GB)
Anschlussschema für Module (DE)
Schéma de raccordement pour modules (FR)
Serial
63
64 GND
REQ
62 DATA
Pulse in/tariff 1+2/max reset
M-Bus network
25
24 M-Bus
230 VAC relay output for Load Control
Current loop
+
÷
32/144
33/145
230V supply
65
66
+
÷
Red/brown 2
Blue 11
3 System, 4 wire
Red/brown 2
Blue 8
3 System, 3 wire
Tariff 1+2
230 V
13 15
Tariff 3+4
230 V
15 33
18
19
RS-485
137 TX- / RX-
138 TX+ / RX+
17/17A NC
18/18A Common
19/19A NO
LON-Bus
55
56
LON 1/A
LON 2/B
Pulse out relay
A+
140
141
A-/R+
142
143
SO-supply
A+
40
41
+
÷

7Kmstrup A/S • 55121316_E1_GB_10.2016
