Kaon KSTB2020 User manual

Home
OK
Set
Select
Arrows
Install Guide – KAON Box
1. Connect the HDMI cord to the KAON box, then connect the other end to the HDMI port on your TV.
2. Connect the power cord to the back of the box and the other end to an electrical outlet.
3. Turn on your TV. Using the source or input button on the remote that came with your TV, nd and select the HDMI
input you plugged the KAON box into.
4. Install batteries in the KAON remote, and make sure your KAON box is turned on.
5. The TV screen should prompt you to sync your KAON remote.
• Press the “Set” button for 3 seconds – the remote will ash green
• Press the “Home” button; enter the three-digit number that appears
on the screen
• Use the “Select Arrows” to navigate to “Skip” and press “OK” to continue
6. The screen will prompt you to select your Wi-Fi network and enter
your Wi-Fi password. Select 5GHz on your home’s wireless network
when prompted.
• After input of Wireless Network the box will reboot.
• When box reboots, it will ask you to connect to the wireless network
you have assigned.
7. The Google Sign in Screen will appear; select “Skip” and press “OK” to
continue. You can either enter your Google ID now or later.
8. The Google Terms of Service will display on the screen; select “Accept”
and press “OK”.
9. Select “Yes” on the location screen and press “OK”.
10. Select “Yes” on the Help Improve Android Performance screen.
11. Choose a name for your KAON box (it will give you several options).
Use the Select Arrows to navigate through the options, highlight a
name, and press “OK”.
12. The next screen will display both apps selected. Select “Install the following apps – NDTC Stream It TV, YouTube”
and select “Continue”.
13. On the Welcome to Android TV Screen, press the Select Arrow to the right ve times to get to the last screen.
14. Select “Done” and press “OK” to continue
15. The NDTC Stream IT TV login screen will appear. Enter your username and password, select “SIGN IN”, and
press “OK”.
Need more help?
Contact NDTC at 662.1100
See Full Remote Diagram
on Page Three.

Install Guide – KAON Box
1. Connect the HDMI cord to the KAON box, then connect the other end to the HDMI port on your TV.
2. Connect the power cord to the back of the box and the other end to an electrical outlet.
3. Turn on your TV. Using the source or input button on the remote that came with your TV, nd and select the HDMI
input you plugged the KAON box into.
4. Install batteries in the KAON remote, and make sure your KAON box is turned on.
5. The TV screen should prompt you to sync your KAON remote.
• Press the “Set” button for 3 seconds – the remote will ash green
• Press the “Home” button; enter the three-digit number that appears
on the screen
• Use the “Select Arrows” to navigate to “Skip” and press “OK” to continue
6. The screen will prompt you to select your Wi-Fi network and enter
your Wi-Fi password. Select 5GHz on your home’s wireless network
when prompted.
• After input of Wireless Network the box will reboot.
• When box reboots, it will ask you to connect to the wireless network
you have assigned.
7. The Google Sign in Screen will appear; select “Skip” and press “OK” to
continue. You can either enter your Google ID now or later.
8. The Google Terms of Service will display on the screen; select “Accept”
and press “OK”.
9. Select “Yes” on the location screen and press “OK”.
10. Select “Yes” on the Help Improve Android Performance screen.
11. Choose a name for your KAON box (it will give you several options).
Use the Select Arrows to navigate through the options, highlight a
name, and press “OK”.
12. The next screen will display both apps selected. Select “Install the following apps – NDTC Stream It TV, YouTube”
and select “Continue”.
13. On the Welcome to Android TV Screen, press the Select Arrow to the right ve times to get to the last screen.
14. Select “Done” and press “OK” to continue
15. The NDTC Stream IT TV login screen will appear. Enter your username and password, select “SIGN IN”, and
press “OK”.
Need more help?
Contact NDTC at 662.1100

KSTB2020 |User/Installation Guide
TV POWER:
programmed with a TV infrared code.
TV INPUT:
Changes video input on TV if remote is
programmed with a TV infrared code.
POWER:
Switches STB power on or into standby
and audio system after remote has
been programmed with a TV/Audio
infrared code.
PAGE (Up or Down):
In the GUIDE or MENU screens, scrolls
one page up or down.
MENU:
Launches the MAIN MENU within the
App with Live Video or last viewed On-
Demand program.
LIVE TV:
Tunes to the last content viewed in the
App.
MUTE:
Mutes the audio on your audio device(s)
(TV, Audio System, or STB).
VOLUME (Up or Down):
Increases or decreases volume levels
on your audio device(s).
CHANNEL (Up or Down):
Selects the previous and next available
channels. (Hold for rapid advance.)
Within MENU or GUIDE, acts the same
as Page Up/Page Down.
13
2
9
6
13
17
19
21
22
5
8
12
7
4
16
15
18
24
23
20
11
14
10
1
2
3
4
5
6
7
8
9
Button Functionality
KURV 2.0 Voice
Remote Control Shown

KSTB2020 |User/Installation Guide
11
12
13
14
15
16
17
18
19
20
21
22
23
24
GOOGLE HOME:
Launches AndroidTV main menu, including access to Apps.
LAST:
Displays the last 15 items that have been watched.
BACK / EXIT:
Returns to previous menu or state within current App. From live video, this key
opens the Main Menu.
GUIDE:
Launches the Channel GUIDE (EPG) within the App.
ARROWS:
Moves to highlight items in respective direction.
OK / SELECT:
Short Press –
the current video playing appears, including the time shift bar.
Long Press – Invokes the App search menu. This is the same function as the
magnifying glass in the Main Menu.
SHOWS:
Launches the SHOWS play list in the App.
MOVIES:
Launches the MOVIES play list in the App.
SEARCH / VOICE:
Launches text-based Google Assistant search. Launches voice-
based Google Assistant search.
RECORD:
Begin recording selected content in the App.
REWIND:
Fast rewinds VOD or live TV.
FAST FORWARD:
Fast forwards VOD, or live TV.
PAUSE / PLAY:
Play or Pause toggle of VOD, or live TV.
0-9:
Enters channel numbers in the GUIDE or full screen video.
SET:
Set up the remote to control the TV, and to program an audio device with
infrared (IR) commands.
10
