Kapro Prolaser Vector 873 User manual

Prolaser®Vector
Model No. 873
User Manual
Manual del usuario
Manuel d'utilisation
Руководство по эксплуатации
3AA
165'/50m INCLUDED

2
Thank you for purchasing Kapro’s 873 Prolaser®Vector.
You now own one of the most advanced laser tools available.
This manual will show you how to get the most out of your
laser tool.
APPLICATIONS
The 873 Prolaser®Vector is a laser level with red diodes.
The laser is innovatively designed for a very broad range of
professional and DIY jobs, including:
• Aligning tiles, marble, cabinets, borders, moldings and
trimmings
• Marking lay out for doors, windows, rails, stairs, fences,
gates, decks and pergolas installation.
• All types of DIY jobs, including hanging shelves, hanging
hooks, pictures, curtains and more
NOTE
Keep this user manual for future reference.
3AA
165'/50m INCLUDED
EN

3
CONTENTS
• Features 4
• Safety instructions 5-6
• Battery installation & Safety 7-8
• Overview 9
• Operating instructions 10-12
• Maintenance 13
• Field calibration test 14-24
• Specifications 25
• Warranty 26

4
FEATURES
• This Laser tool automatically determines the horizontal
and vertical plans
• This laser projects 1 horizontal and 2 orthogonal Vertical
red beams, intersects forward and on the ceiling.
• Self-level in automatic mode when the laser is positioned
within its self-leveling range.
• Visual and audible “out of leveling range” warning
• Pulse mode emits pulses that can be detected by a detector.
• The max. detectable range of the laser in pulse mode is
50m (165’).
• Manual mode allows angular layout/marking
• Strong and adjustable metal folding legs allow extreme
angles mounting and height adjustment
• Locking mechanism to protect the pendulum during
transportation.
• 1/4" tripod adaptor
• Shock resistant rubber casing
• Compactsize–tsinyourtoolbox
NOTE
This device contain precision components
that are sensitive to external shock, impact or
drop that may compromise its functionality –
handle with care to maintain its accuracy.

5
SAFETY INSTRUCTIONS
WARNING
This product is emitting radiation that is classified
As class II according to EN 60825 -1
The laser radiation can cause serious eye injury
• Do not stare into the laser beam
• Do not position the laser beam so that it unintentionally
blinds you or others.
• Do not operate the laser level near children or let children
operate the laser level.
• Do not look into a laser beam using magnifying optical
devices such as binoculars or a telescope, as this will
increase the level of eye injury.
WARNING: This product contains lead in solder and
certain electrical parts contain chemicals which are
known to the State of California to cause cancer, birth
defects or other Reproductive harm.
(California Health & Safety Code Section 25249.6- Proposition 65)
NOTE
The red goggles are intended to enhance the
visibility of the laser beam. They will not
protect your eyes against laser radiation.

6
• Do not remove or deface warning labels on the laser level.
• Do not disassemble the laser level, laser radiation can
cause serious eye injury.
• Do not drop the laser.
• Do not use solvents to clean the laser.
• Do not use in temperatures below -10°C or above 45°C
(14°F / 113°F)
• Do not operate the laser in explosive atmospheres such as
ammableliquids,gasesordust.Sparksfromthetoolcan
cause ignition.
• When not in use, turn off the power, engage the pendulum
lock and place the laser in the carrying pouch.
• Make sure the pendulum lock mechanism is engaged
before transporting the laser.
NOTE
If the Pendulum lock mechanism is not
engaged before transportation, internal
mechanical damage can occur.

7
BATTERY INSTALLATION
1. Press down on the latch and remove the battery cover.
2. Insert 3 new AA batteries of the same brand according to
the polarity diagram on the inside of the battery compartment.
3. Reclose the battery cover.
NOTE
If the laser level will not be used for a long
period, remove the batteries from the battery
compartment. This will prevent batteries from
leaking and corrosion damage.

8
WARNING: Batteries can deteriorate, leak or explode, and
cancauseinjuryorre.
1. Do not shorten the battery terminals.
2. Do not charge Alkaline batteries.
3. Do not mix old and new batteries.
4. Do not dispose of batteries into household waste.
5.Donotdisposeofbatteriesinre.
6. Defective or dead batteries must be disposed according to
local regulations.
7. Keep the batteries out of reach from children.

9
OVERVIEW
1. On/Off Locking Switch
2. Metal legs
3. Stabilizing rubber sleeve
4. Keypad
a. Manual Mode button d. Manual Mode LED
b. Beam Selector button e. Laser Beam LED
c. Pulse Mode button f. Pulse Mode LED
5. Horizontal window
6. Forward vertical window
7. Side vertical window
8. Battery cover
9. ¼” tripod mount

10
OPERATING INSTRUCTIONS
Working in Automatic mode (self-leveling):
In automatic mode the laser level will level itself in the range of ±3°
and will project horizontally or vertically or all 3 beams simultaneously.
1.Removethelaserfromthecaseandplaceitonasolidat 
Vibration free surface or on a tripod.
2.Turn the locking switch #1 clockwise to the ON position.
The laser level will generate horizontal and vertical beams
forward, and additional orthogonal side vertical beam. The
green LED near the V/H push button will light up.
3.The laser will generate cross beams forward and cross
beams upward above the laser when all beams are activated.
4.Choose the beams that you want to work with by pushing the
Beam push button V/H
5.Use the adjustable metal legs #2 to adjust the height of the
horizontal beam.
6.If the initial level of the laser is beyond ± 3° and the automatic
 modeisactivatedthelaserbeamswillashandabeepingalarm
will be heard. In this case reposition the laser on a more level
surface.
7.Before moving the laser level switch the locking switch #1 to
the OFF position this will lock the pendulum and protect
your laser.

11
Working in Manual mode:
In Manual mode the 873’s self-leveling mechanism is disabled and
thelaserlinescanbesetatanysloperequired.
1. Press the Manual push button mode . The laser will
project the cross lines and the red LED near the push
button will light up. The green LED of the laser beams near
V/H push button will light up.
2. Choose the beams that you want to work with by pushing
the Beam Selector push button V/H
3. To mark a slope, tilt the laser using the adjustable folding
legs to adjust the right angle and the height.
4. To turn the manual mode off, press again the Manual
push button .
5. While in Manual mode turning the locking switch #1 from
OFF to ON will turn off the Manual mode and the red LED
near the push button. The automatic self – leveling
will be activated if the laser level is within the self – leveling range.

12
Working in Pulse mode with a detector:
For outdoor work under direct sunlight, or bright conditions and
for extended indoor ranges up to 50 meters, use the pulse mode
with a Detector.
Whenthepulsemodeisactivatedthelaserbeamswillashat
averyhighfrequency(Invisibletothehumaneye)thiswillallow
the detector to detect the laser beams.
1. The pulse mode can be activated in Automatic and Manual modes.
2. To switch on the Pulse Mode press the Pbutton, the green
LED near the Ppush button will light up.
3. When the pulse mode is switched on, the visibility of the laser
beams are reduced a little bit.
4. To switch off the Pulse Mode press the Pbutton again, the
green LED near the Ppush button will go off.

13
MAINTENANCE
To maintain the accuracy of your project, check the accuracy
ofyourlaserlevelaccordingtotheeldcalibrationtests
procedures.
• Change the batteries when the laser beams begin to dim.
• Wipe the aperture lens and the body of the laser level with a
clean soft cloth. Do not use solvents.
• Although the laser level is dust and dirt resistant to a certain
degree do not store in dusty places as a long term exposure
may damage internal moving parts.
• If the laser level is exposed to water, dry the laser level
before returning it to the carrying case to prevent corrosion
damages.
• Remove the batteries if the laser level is unused for a long
period of time to prevent corrosion damages.

14
FIELD CALIBRATION TESTS
This laser level left the factory fully calibrated. Kapro
recommend that the user will check the accuracy of the laser
periodically, or if the unit falls or is mishandled.
1. Check the height accuracy of the horizontal beam.
2. Check the leveling accuracy of the horizontal beam.
3. Check the leveling accuracy of the vertical beam.
4. Check the perpendicularity between the 2 vertical beams.
1. Checking the Height Accuracy of the Horizontal beam.
(Up and down deviation)
1) Set up the laser on a tripod or on a solid surface
between two walls Aand B, approximately 5 meters apart.
2) Position the laser level approximately 0.5 meter from wall A
3) Unlock the pendulum and press the button to project the
horizontal and the vertical cross beams towards wall A.
4) Mark on the wall the center of the cross beams as a1
(seegure#1).

15
5) Turn the laser 180° towards wall B, and mark on the wall
the center of the cross beams as b1(seegure2).
6) Move the laser level towards wall Band position it
approximately 0.5 meter from wall B.
7) Mark on wall Bthe center of the cross beams as b2
(seegure3).
AB
a1
b1
b2
Figure # 3
0.5m
X
X
X
AB
a1
180°
X
Figure # 2
X
b1

16
8) Turn the laser 180° towards wall A, and mark on the wall the
center of the cross beams as a2(seegure4).
9) Measure the distances:
  Δa=|a2-a1|
  Δb=|b1-b2|
10)Thedifference|Δa–Δb|shouldnotbemorethan2mm,
otherwisetosendthelaserleveltoaqualiedtechnician
for repairs.
2. Checking the Level Accuracy of Horizontal beam.
(Side to side inclination)
1) Set up the laser on a tripod or on a solid surface at a distance
of approximately 1.5 meters from a wall 5 meters long.
2) Unlock the pendulum and press the button to project the
horizontal and the vertical cross beams towards the wall.
x a2
x a1
x b1
b2
x
A B
180°
Figure # 4

17
3) Mark point a1 on the wall, in the middle of the horizontal line
attheleftedgeofthehorizontalbeam(seegure5).
4) Turn the laser level counterclockwise until the right edge of
the horizontal beam reach’s near a1, mark a point a2 on the
wallinthemiddleofthehorizontalbeam(seegure6).
a1
approximately 5m
1.5m
Figure # 5
X
x a1
x a2
Figure # 6

18
5) The distance between a1 and a2, should not be more than
1mm,otherwisetosendthelaserleveltoaqualied 
technician for repairs.
3. Checking the Accuracy of the Vertical beam.
1) Hang approximately 4 meter plumb line on a wall.
2) After the plumb line has settled, Mark point a1 on the wall
behindtheplumblineneartheplumbcone.(seegure7).
3) Set up the laser on a tripod or on a solid surface in front of the
wall at a distance of approximately 2 meters.
4) Unlock the pendulum, and press the button to project the
vertical beam towards the plumb line.
5) Turn the laser so that the vertical beam will merge with the
plumb line below the hanging point.
approximately 4m
Figure # 7
a1 X

19
6) Mark point a2 on the wall, in the middle of the vertical beam at
the same height of a1.(seegure8).
7) The distance between a1 and a2, should not be more than
1mm,otherwisetosendthelaserleveltoaqualiedtechnician
for repairs.
a1
X
2m
X
a2
X
Figure # 8

20
4. Checking 90º accuracy between the 2 vertical beams.
Thisprocedurerequiresaroomofatleast5x5meterswith4walls.
1)Setupthelaseronatableorontheoorinthemiddleoftheroom.
2) Unlock the pendulum, and press the V/H push button 4 times
to project the forward and the side vertical beams
(seegure9).
Approximately 5m
Approximately 5m
Figure # 9
# הנומת 9
A B
C
D
Figure # 10
# הנומת 10
a1
a2
b1
b2
X
XX
A B
X
Figure # 9
