Kapro Prolaser Vector 888 User manual

PROLASER®VECTOR
Self-Leveling Laser
Model No. 888
User Manual Manuel
d'utilisation Manual
del usuario
Руководство по
эксплуатации
Naudotojo vadovas

2
Thank you for purchasing the Kapro Prolaser®Vector Self-
Leveling Laser. You are now the owner of one of the most
advanced laser levels available. Our tools incorporate new
laser technology, enabling the professional user and the
serious DIY enthusiast to achieve accurate results and
reduce valuable work time.
The Prolaser®Vector has been designed for use in most
areas of construction, including:
• Laying Flooring
• Hanging doors and windows
• Leveling slopes with the manual mode
• Installing acoustic ceilings
• Installing partitions and drywall
• Electrical and plumbing layout
EN
NOTE
Keep this user manual for future
reference.

3
CONTENTS
Features ......................................................... 4
Safety Instructions ........................................ 5
Product Overview .......................................... 6
Battery Installation........................................ 7
Operating Instructions................................... 8
Maintenance .................................................. 10
Field Calibration Test..................................... 12
Specifications ................................................ 14
Warranty ........................................................ 15

4
FEATURES
• Laser Beams: two vertical & one horizontal
• Self-leveling mechanism
• Manual mode for leveling slopes
• Pulse mode for use with detector (sold separately)
• Freestanding or can be mounted to a tripod (5/8” thread)
• Audible and visible out-of-level warning
• Shockproof body
• Includescarryingpouch,Beamnder™glasses, tripod
adapter/wall mount
• Uses 3 AA batteries (included)
NOTE
Do not remove or deface warning
labels from this product.

5
SAFETY INSTRUCTIONS
WARNING
This product is a Class II laser.
Danger of laser radiation
• Serious eye injury can result from looking
directly into the beam or projecting the beam
into the eyes of others.
• Always position the laser beam so that it does not
cause anyone to look into the projected beam.
• Do no operate the laser level near children or allow
children to operate the laser level.
• Do not look into the laser beam using magnifying
optical equipment, such as binoculars or telescopes,
as this will increase the level of eye injury.
• Do not take the unit apart.
• Do not use in combustible environments such as in the
 presenceofammableliquids,gasesordust.

6
PRODUCT OVERVIEW
1. Front vertical beam window
2. Manual/Pulse mode button
3. Manual mode indicator
4. Horizontal beam button
5. Battery status indicator
6. Pulse mode indicator
7. Vertical beams button
8. Battery compartment cover
9. Battery compartment
10. Side beam window
11. Self-leveling mechanism lock

7
The Prolaser®Vector is powered by 3 AA batteries (included)
or a DC 4.5V transformer (not included).
IMPORTANT
An AC/DC converter can only be used when the laser unit
has rechargeable batteries. Using a converter with non-re-
chargeable batteries can damage the laser and be danger-
ous to the user.
To change the batteries:
1. Slide off the battery compartment cover.
2. Insert 3 new AA batteries of the same brand (regular or
good quality rechargeable), according to the diagram in
the battery compartment.
BATTERY INSTALLATION

8
OPERATING INSTRUCTIONS
This section describes the proper use of the Prolaser®Vector
in order to get the best working results.
NOTE
For proper functioning of the laser unit, avoid using near
heavy machinery or sources of vibration that may adversely
affect the leveling of the unit.
To use in self-leveling mode:
1. Placetheunitonarm,stable,drysurfaceormountthe
unit the tripod adaptor/wall mount.
2. Release the leveling mechanism lock by turning the base
of the unit and switching the laser ON.
3. Make sure the unit is as level as possible. The electronic
self-leveling mechanism will level the laser within 3
seconds.
NOTE: The laser can compensate for up to 3.5° from the
horizontal plane. If the surface slope is greater than this the
laser will sound an out-of-level alarm and the laser beams
willash.

9
4. Select the laser beams you want to project as follows:
• Press H for the horizontal beam
• Press V1/V2 once for V1 vertical beam
• Press V1/V2 button twice for V1 and V2 vertical beams
5. To activate the Pulse mode push the Manual/Pulse
button once. The brightness of the beam appears to be
reduced when in Pulse mode.
To use in manual mode:
1. Push the Manual/Pulse button once to turn the device
ON. The manual mode indicator will blink.
2. Select the laser beams you want to project as follows:
• Press H for the horizontal beam
• Press V1/V2 once for V1 vertical beam
• Press V1/V2 button twice for V1 and V2 vertical beams
3. Set the required slope angle by tilting the unit.
4. To activate the Pulse mode push the Manual/Pulse
button one more time.
NOTE: Pressing the Manual Pulse button three times turns
the laser OFF.

10
To properly maintain the Prolaser®Vector and ensure the
best functionality:
• Clean the unit with a soft cloth slightly dampened with
soap and water.
Do not use harsh chemicals, cleaning solvents or strong
detergents.
• Keep the aperture of the unit clean by wiping is clean with
a lint-free cloth moistened with isopropyl (rubbing) alcohol.
• Always store in a clean, dry place.
• If the unit gets wet, dry it off with a dry cloth. Do not store
or place the unit in the carrying case until it is completely
dry.
•Donotdrytheunitbyplacingitnexttoanopenreorwith
an electric dryer.
• Store between 14°F - 131°F (-10°C - 55°C)
• Do not drop the unit. Avoid rough handling and constant
vibration.
• Remove the batteries during lengthy periods of non-use.
MAINTENANCE

11
• Turn the laser unit off before removing the battery.
• Make sure the self-leveling mechanism is locked by
twisting the base of the unit before storing.
• The laser is not intended for outdoor use.
• When moving the laser, make sure the self-leveling
mechanism is locked to protect the internal pendulum.

12
FIELD CALIBRATION TEST
The Prolaser®Vector leaves the factory fully calibrated.
Kapro recommends checking the level regularly, especially
if the unit has been dropped or mishandled.
Horizontal Line Calibration Test
1. Set up the unit on a level surface (or in the tripod adaptor/
wall mount on a tripod) next to an unobstructed 100’
(30m) wall.
2. Level the unit as accurately as possible.
3. Turn on the unit and mark the position of the beam next
to the laser. = Point 1
4. Mark the position of the beam at a point approximately
100’ (30m) from the unit. = Point 2
5. After marking the two points move the laser from Point
1 to next to Point 2 and level the unit as accurately as
possible.
6. Turn on the unit and mark the position of the beam next
to the laser and another mark next to the original Point 1.
7. Measure the height difference between both sets
of markings. Ideally, the points should be identical.

13
However,ineldconditionsadifferenceofupto.25”(6mm)
is acceptable.
Vertical Line Calibration Test
1. Set up the unit about 60’ (20m) from a wall or any stable
vertical object.
2. Place a plumb bob style line level against the wall
hanging directly down to mark an accurate vertical line.
3. Level the unit as accurately as possible and position the
laser so that the V1-axis is pointing in the direction of the
line level on the wall.
4. Press the V1/V2 button and rotate the laser so that the
beam touches the edge of the line.
5. Check to see that the laser touches the line in all places.
6. Repeat the steps for the V2-axis.
7. If any of the beams seem to be inaccurate, repeat the test
with the line level repositioned against another area of the
wall. If the result is the same follow the instructions given
in the Warranty section of this manual.

14
Product Prolaser®Vector
Laser Class II
Horizontal beam accuracy ±3/25 at 30’ (±3mm/10m)
Vertical beam accuracy ±3/25 at 30’ (±3mm/10m)
Self-leveling range ±3.5°
Recommended working
range
100’ (30m)
165’ (50m) with detector
Laser source 635nm
Horizontal beam spread 120°
Storage temperature 14°F - 131°F (-10°C - 55°C)
Laser power supply 3x AA (DC 4.5V) (included)
Battery life 8 hours of continuous use
Dimensions 3.2” x 5.5” (81mm x
140mm)
Weight (including batteries) 1.9 lbs. (862gr)
AC/DC converter Frequency 50Hz – 60Hz
Voltage 85V-265V (not
included)
SPECIFICATIONS

15
WARRANTY
This product is covered by a two-year limited warranty
against defects in materials and workmanship. It does not
cover products that are used improperly, altered, or repaired.
In the event of a problem with the laser product you have
purchased, please return the product to the place of purchase
with proof of purchase.
Model No. 888 Serial number sticker is positioned on battery
cover.

16
Nous vous remercions pour votre achat du Niveau
automatique Prolaser®Vector de Kapro. Le produit que vous
venez d'acquérir fait partie des niveaux laser les plus avancés
disponibles sur le marché. Ces outils intègrent les dernières
technologies et permettent aux utilisateurs professionnels
et aux bricoleurs enthousiastes et consciencieux d'obtenir
rapidement des résultats de haute précision.
Le Prolaser®Vector est destiné à être utilisé dans la plupart
des travaux du secteur du bâtiment, notamment :
• Pose de sols
• Pose de portes et fenêtres
• Nivellement de pentes en mode manuel
• Installation de plafonds acoustiques
• Pose de cloisons et de parois sèches
• Installation électrique et sanitaire
Remarque
Conservez ce guide d'utilisation pour
consultation ultérieure.
FR

17
TABLES DES MATIÈRES
•Fonctions ....................................................... 18
Instructions de sécurité ................................ 19
Vue d'ensemble du produit ........................... 20
Installation de la pile..................................... 21
Utilisation....................................................... 22
Entretien......................................................... 24
Test de calibration sur site............................ 26
Caractéristiques ............................................ 28
Garantie.......................................................... 29

18
FONCTIONS
• Rayons laser : deux verticaux & un horizontal
• Mécanisme de nivellement automatique
• Mode Manuel pour le nivellement de pentes
• Mode Impulsion pour utilisation avec détecteur (vendu
séparément)
• Autoportant ou à monter sur trépied (pas de vis 5/8”)
• Alerte hors-niveau sonore et visible
• Boîtier anti-choc
• Inclut un sacoche de transport, des lunettes
 Beamnder™, un adaptateur pour trépied/support mural
• Alimenté par 3 piles AA (incluses)
Remarque
Ne pas retirer ou effacer les étiquettes
de mise en garde figurant sur ce produit.

19
INSTRUCTIONS DE SÉCURITÉ
AVERTISSEMENT
Ce produit est un laser de classe II. Risque de
rayonnement laser.
• Regarder directement dans le faisceau ou
projeter le faisceau dans les yeux de tiers
peut provoquer des lésions oculaires graves.
• Toujours placer le laser de sorte qu'aucune personne
ne puisse regarder directement dans le faisceau.
• Ne pas utiliser le niveau laser près d'enfants et ne pas
laisser les enfants utiliser le niveau laser.
• Ne pas regarder dans le faisceau laser à l'aide
d'instruments optiques tels que jumelles ou télescope,
 celaampliantledegrédelésionoculaire.
• Ne pas démonter l'appareil.
• Nepasutiliserenmilieuinammablecommeen 
 présencedeliquides,gazoupoussièresinammables.

20
VUE D'ENSEMBLE DU PRODUIT
1. Viseur de rayon vertical avant
2. Bouton de mode Manuel/Impulsion
3. Indicateur de mode Manuel
4. Bouton de rayon horizontal
5. État de chargement de pile
6. Indicateur de mode Impulsion
7. Bouton des rayons verticaux
8. Couvercle du compartiment à piles
9. Compartiment à piles
10. Viseur de rayon latéral
11. Mécanisme de nivellement automatique
